Androware YC-06-C User manual

Auto-Darkening Welding Helmet
User’s Manual
YC-06-C
Warning: For your own protection, please read these instructions
carefully before using this auto-darkening welding helmet.
Auto-darkening welding helmets are designed to protect the eyes
and faces from spark, spatter, and harmful radiation under normal
welding conditions. Auto-darkening filter automatically changes
from light state to dark state when the arc is struck, and returns to
the light state when you stop welding.
Auto-darkening welding helmets comes ready to use. The only
thing you need to do before welding is to adjust the position of
headband.
BEFORE WELDING
Check the front cover lens and make sure that it is clean and no
dirt covering the two sensors on the front of filter cartridge. Also
check the front/inside cover lens and the back cover retaining
frame to make sure that they are secure.
Check all operating parts before use for signs of wear or damage.
Any scratched, cracked or pitted parts should be replaced
immediately before using to avoid severe personal injury.
Adjust the headband so that the helmet is seated as low as
possible on the head and close to your face. The angle of helmet is
adjusted on the buckles, fastened at the different settings.
DARK SHADE NUMBER SELECTION
The fixed shade has been pre-set at DIN11.
PRODUCT FEATURES
This model is designed & equipped with a special turn over (up &
down) headband mechanism. When the welder tilts the helmet
upwards ,the headband mechanism lowers the helmet’s centre of
gravity. The design of the welding helmet greatly reduces the
fatigue of welder’s head & neck.
The moment the welding electrode arcs with the surface, the filter
screen will automatically darken in about 0.0003 sec.
The delay time from dark to light is set about 0.3 s.
he helmet utilizes high performance solar cells as power supply
with a built-in 3V lithium battery as a power back-up. Under normal
conditional the battery has a life span will be in excess of 3 years.
The product is in full conformity with related DIN, ISO, EN safety
standards and ANSI Z87.1-2010 standards.
The ultra high performance of UV/IR auto-darkening filters provide
full protection for the user’s eyes & face against UV/IR radiation
during the entire welding process, even in the light state. The
UV/IR protection level is up to Shade 15 (DIN) at all times..
WARNING
This Auto-Darkening Welding Helmet is not suitable for:
Laser welding &
Oxyacetylene welding.
Never place this helmet and auto-darkening filter on a hot surface.
Never open or tamper with the auto-darkening filter.
This Auto-darkening welding helmet will not protect against severe
impact hazards, including grinding discs.
This helmet will not protect against explosive devices or corrosive
liquids.
Don’t make any modifications to either the filter or helmet, unless
specified in this manual.
Don’t use replacement parts other than those specified in this
manual.
Unauthorized modification and replacement parts will void the
warranty and expose the operator to the risk of personal injury.
Should this helmet not darken upon striking an arc, stop welding
immediately and contact your supervisor or the dealer.
Don’t immerse the filter in water.
Don’t use any solvents on filter’s screen or helmet components.
Use only at temperature:-5℃~+55℃
Storing temperature:-20℃~+70℃
Keep filter away from liquid and dirt.
Clean filter’s surfaces regularly, do not use strong cleaning
solutions. Always keep sensors and solar cells clean using a clean
lint-free tissue/cloth.
Regularly replace the cracked/scratched/pitted front cover lens.
Severe personal injury could occur if the user
fails to follow the aforementioned warnings,
and/or falls to follow the operating instruction.

COMMON PROBLEMS AND REMIDIES
*Irregular Darkening Dimming
Headband has been set unevenly and there is an
uneven distance from the eyes to the filter’s lens.
Reset headband to reduce the difference to filter.
*Auto-darkening filter does not darken or flickers
Front cover lens is soiled or damaged (change cover
lens)
Sensors are soiled (clean the sensors’ surface)
Welding current is too low.
*Slow Response
Operating temperature is too low (do not use at
temperatures below –5℃)
When the battery power in the filter screen is inadequate,
please stop using and change a new filter cartridge.
*Poor Vision
Front/inside cover lens and/or filter lens are soiled
change lens)
There is insufficient ambient light.
The protective film of the front/back cover lens is not
peeled off.
*Welding Helmet Slips
Headband is not adjusted properly (readjust headband)
Warning!
Operator must stop using the auto-darkening welding
helmet immediately if the above mentioned problems
cannot be corrected. Contact the dealer.
LENS & HELMET MAINTENANCE
Replacing the front cover lens if it is damaged (cracked,
scratched, soiled or pitted)
Step 1: Remove the back cover.
Step 2: Take out the auto-darkening cartridge.
Step 3: Take out the rubber seal with the front cover lens.
Step 4: Take out the front cover lens.
Step 5: Place the new front cover lens into the right position.
Step 6: Place the auto-darkening cartridge and the back cover into
the position.
THCHNICAL SPECIFICATIONS
Viewing Area: 92×42mm
Size of Cartridge: 110×90×9mm
Light state: DIN 3
Darken state: DIN11
Switching Time: <0.0003s
UV/IR protection: Up to DIN15
Operating Temperature: -5℃~+55℃
Storing Temperature: -20℃~+70℃
Helmet Material: High-impact resistant plastic/Polyamide Nylon.
Total Weight: 420g
THE PARTS LIST OF THE HELMET
THE PARTS LIST OF THE HEADBAND
1. NUT 2. SPRING
3. LOCATING PIECE-1 4. ADJUSTABLE BUCKLE
5. SCREW 6. EQUATION
7. LOCATING PIECE-2
SHADE GUIDE TABLE
NOTE:
PLEASE USE THIS GUIDE TO ENSURE YOU ARE USING THE
CORRECT WELDING HELMET FOR THE TYPE OF WELDING
CARRIED OUT.
