Anest Iwata SLE-30 User manual

INSTRUCTION MANUAL
OIL-FREE SCROLL COMPRESSOR
SLE-30/30H
SLE-40/40H
Thank you for purchasing our oil-free scroll air compressor.
●Before operation, be sure to read this instruction manual thoroughly for safe
and efficient use for a long operating lifetime.
●After reading it, store in a convenient place for immediate and future
reading.
Before use, be sure to fill in the blank spaces below for future repair and after service.
MODEL
SERIAL No.
Purchased from
Date of purchase
Date of use

1
Important information and Safety precautions
▪Important information
Read all important information and safety precautions before use. The operator shall be fully knowledgeable of
the requirements stated within this instruction manual, including important warnings, cautions and operation.
Read manual before performing any maintenance.
•Indications of warnings and cautions
WARNING
May cause injury or death.
CAUTION
May result in injury or property damage.
•Examples of warnings and cautions
May cause electric shock.
Do not touch.
Must be grounded.
＊Supplier is not responsible for any injuries or damages caused by disregard of warnings, operating instruction
specifications or maintenance schedules.
l@;
Indicates important notices you must observe.
They are helpful to achieve top performance and functions of the equipment.
Keep this booklet in an appropriate place for immediate reference.
Important

2
Important information and Safety precautions
▪Safety precautions
WARNING
Install in a safe area.
To prevent a fire or explosion, install in an area free offlammable gases or organic solvents.
Never install outdoors.
To prevent fire or electric shock, never install outdoors.
Turn off the main electric source.
To prevent electric shock or serious injury, always turn off the mainelectric source before
inspecting or wiring the unit.
Ask a qualified electrician.
Only a qualified electrician should performmaintenance on the unit.
Be sure to ground.
Unit must be grounded to prevent electric shock.
Never use to compress anything other than air.
Unit must onlybe usedto compress air.
Do not use with respiratory equipment, which
could cause serious injury or death.

3
Important information and Safety precautions
WARNING
Not for use as life support.
Serious bodily injury and/or death may occur. Unit must only be used to compress air.
Do not touch.
Keep hands and fingers away from fans, pulleys and belts while the power is on.
Serious injury, including entanglement of fingers or hands can occur.
Release pressure.
Release pressure from unit before conducting maintenance and/or inspection.
Failure to do so may cause serious injury.
Conduct maintenance and inspection.
Conduct maintenance and inspection according to this manual to prevent unit failure.

4
Important information and Safety precautions
CAUTION
Use at ambient temperatures of 36°F to 104°F.
Drain will freeze at less than 36°F and will cause unit failure.
Using over 104°F will cause a shorter lifespan or unit damage.
Use in an area free of dirt and dust.
Failure to do so may result in equipment failure.
Use in an area free of corrosive gas.
Failure to do so mayresult in equipment failure.
Only qualified personnel should perform repairs
to prevent electric shock or fire.
Keep Away.
Keep away from the compressor while it is operating, and allow it to cool before servicing.
Failure to do so may result in serious burns and or bodily harm.
Never alter the compressor
Fire and or electric shock may occur if unit is altered and warranty will be void.
Use genuine parts
Be sure to use only genuine parts during maintenance.
Failure to do so mayresult in equipment failure.

5
Contents
Important information and Safety precautions
Problems and remedies
■Important information --------------------------------
1
■Caution displays ------------------------------------
38
■Safety precautions -------------------------------------
2
■Compressor --------------------------------------------------
39
Maintenance and inspection
■Contents --------------------------------------------------
5
■Compressor maintenance standards --------------------
40
Before use
■Daily ----------------------------------------------------------
42
■Every 400 hours or every 2 months ------------------
42
■Inspect the product ------------------------------------
6
■Every 2500 hours or yearly -----------------------------
44
■Transportation ------------------------------------------
7
■Every 5000 hours or yearly -----------------------------
45
■Every 10000 hours or every 4 years -----------------
45
Installation
■Every 20000 hours or every 8 years ------------------
45
■Every 22500 hours or every 9 years ----------------------
45
■Precaution about installation --------------------------
8
■Installation space ---------------------------------------
9
Specifications
■Ventilation -----------------------------------------------
9
■Piping ------------------------------------------------------
11
■Compressor specifications ----------------------------------
46
■Electrical wiring -----------------------------------------
12
Appendix
Test operation
■Outer dimensions ---------------------------------------------
48
■Operation ------------------------------------------------
14
■Circuit diagram -------------------------------------------------
49
■Check control --------------------------------------------
16
■HMI setting -----------------------------------------------------
49
■Menu flow chart ----------------------------------------------
50
Operating panel
Warranty
■Changing the HMI Internal Clock ------------------
■Main screen ---------------------------------------------
17
19
■Operation, stop ---------------------------------------------
19
■Warranty and remain ---------------------------------------
51
■Status screen ------------------------------------------------
20
■Ambient Temperature ------------------------------------
21
■PLC Error ------------------------------------------------------
21
■Pump Details screen -------------------------------------
22
■Sensor Resets screen ------------------------------------
23
■Alarm screen ----------------------------------------------
24
■Settings 1 screen -------------------------------------------
25
■Settings 2 screen -------------------------------------------
26
■Units screen -------------------------------------------------
27
■Clock screen -------------------------------------------------
28
■Maintenance Note screens ------------------------------
29
■Maintenance screen ---------------------------------------
30
■Maintenance Log screen ---------------------------------
31
■Password screen --------------------------------------------
32
Communication
■BACnet/IP ----------------------------------------------------
33
■Modbus TCP -------------------------------------------------
36

6
Before use
▪Inspect the product
•Inspect the product to be sure you have the model you ordered.
•Check that there is no deformity or damage which occurred during transportation. Any shipping damage must be
immediately filed with the freight carrier.
•Check that the following accessories are included.
oCompressor instruction manual
oPump instruction manual
oRubber mat x 4
oBall valve
-
SL; Scroll 30; 30HP 208; 208V
40; 40HP 230; 230V
E; Enclosure 460; 460V
T; Three phase
N/A;
115psi (Maximum pressure)
H;
145psi (Maximum pressure)
230
T
SL
E
30
-

7
Before use
▪Transportation
•Transportation by forklift
Use holes for forklift on both sides of compressor.
Do not puncture panel with tips of
forklift.
•Transportation by crane
Use holes for forklift as illustrated and lift up by wire.
Be sure to use pads in order to protect
panels.

8
Installation
▪Precautions about installation
あDo not install
Do not use in an area which isexposed to rain, steam or high humidity.
High humidity can cause electric shock or fire.
Do not install in an area with corrosive gas (ammonia, acid, ozone gas and
sulfur dioxide) to prevent a shorter lifespan.
あ
Do not install
To prevent an explosion or fire, install in an area free of flammable gases
or organic solvents.
Ambient temperature
Use at ambient temperatures of 36°F to 104° F.
Using less than 36°F will cause unit failure or freezing.
Using over 104°F will cause a shorter lifespan or unit damage.
Do not install
Do not install the unit where it will be exposed to sunshine.
Increased inside temperature can cause unit failure.
Install the unit on a level floor
An uneven floor can cause abnormal vibration, noise or failure.
Do not install
Do not installwhere there is dust, dirt or debris.
Dust can increase the temperature and wear, resulting in a shorter
lifespan and unit failure.

9
Installation
▪Installation space
Securethe space around compressor as illustrated.
▪Ventilation
•Overall exhaust
The following ventilation volume is necessary in order to keep temperature increase inside room to9°Fabove room
temperature. When the static pressure is zero, select the actual figure larger thanthe figures in the chartbelow.
Model
SLE-30
SLE-30H
SLE-40
SLE-40H
Ventilation volume
(cfm)
7770
10595
Over 28 inch
(Left side)
Over 24 inch
(Front side)
Over 28 inch
(Right side)
Over 28 inch
(Back side)
Over 47

10
Installation
•Local exhaust
When installingthe exhaust duct, take precautions to minimize pressure loss of duct, and attach the ventilation fan at the
exhaust section. Keep distance between the duct inlet and exhaust of the compressor to 8 - 12 inches for easy
maintenance.
Model
SLE-30
SLE-30H
SLE-40
SLE-40H
Ventilation volume
(cfm)
2825
3535
あDo not fit exhaust duct directly to the
compressor.
Leave an 8-12 inch gap between the exhaust sections of the compressor and duct.

11
Installation
▪Piping
(1) Take pressure loss into considerationand decide the piping diameter of the exhaust piping.
(2) Connect the outlet of the compressor and piping by using a rubber hose and flexible tube.
Direct connection to a steel pipe can transfer vibration of the compressor to the pipe causing issues for the
print board of the compressor. Only use a rubber hose for the oil-free compressor.
(3) When there is a riser or concave section in the piping, be sure to install a drain valve at the low end.
Install a drain valve at the low end of the main piping as well.
(4) Installing an air receiver is optional.
When purchasing an air receiver, select a receiver larger than the following capacity.
SLE-30, SLE-30H; 200 Gallon
SLE-40, SLE-40H; 240 Gallon
Install main pipe at downward angle (about 1/100) toward
the end
Install drain valve at the end
Drain valve
Drainvalve
Ball valve
Air receiver

12
Installation
▪Electrical wiring
❖Precautions about wiring
たTurn off main electric source before inspecting
or wiring. Deviation from this instruction can
cause electric shock or serious bodily injury.
Only a qualified electrician should perform
repairs to prevent electric shock or fire.
Use a proper wire size.
Using a cable of less than designated size can cause a fire.
けBe sure to ground the unit when wiring to avoid
electric shock or fire.
❖How to run the wire
(1) Remove the door panel.
(2) Remove the lid of control box on the right.
(3) Be sure to securely connect the electric source（L1, L2, L3）and ground.

13
Installation
❖Wiring material
Use the correct size of cable and applicable breaker shown in the chart below.
208-230V
Model
Load specifications
Circuit protection Max Size
Motor load
each
(FLA)
Unit load
total
(FLA)
Non-time
delay fuse
(A)
Time delay
fuse
(A)
Inverse time
circuit
breaker
(A)
SLE-30
16.7 –15.2
108 - 98
300 -250
200-175
300 -250
SLE-30H
SLE-40
16.7 –15.2
142-130
400-350
250-250
400-350
SLE-40H
460V
Model
Load specifications
Circuit protection Max Size
Motor load
each
(FLA)
Unit load
total
(FLA)
Non-time
delay fuse
(A)
Time delay
fuse
(A)
Inverse time
circuit
breaker
(A)
SLE-30
7.6
50
125
90
125
SLE-30H
SLE-40
7.6
65
175
125
175
SLE-40H
Ground terminal
Power source terminal

14
Test operation
▪Operation
❖Preparation
(1) Check to be sure the air receiver piping has been firmly connected.
(2) Openthe ball valve of the compressor air outlet.
(3) Turn on the main electric source and be sure the display section of the operating panel lights up.

15
Test operation
❖Operation
Push the operating switch to start the compressor.
❖Check pressure increase
Be sure the pressure increases when the compressor starts.
CAUTI0N
If the pressure does not increase and an abnormal sound is heard during reverse rotation, stop the compressor.
Turn off the main electric source and then change two out of the three phases to get the correct rotation.
Be sure to push the stop switch to stopthe compressor and cut the leak breaker to avoid electric shock.
❖Check maximum control pressure
Operate the unit while the ballvalve of the air receiver is closed.
Be sure the compressor stops at the pressure shown below.
Model
Max. pressure (psi)
SLE-30, SLE-40
116
SLE-30H, SLE-40H
145
❖Check minimum control pressure
When maximum pressure is reached and compressor stops, open outlet valve and gradually reduce pressure.
Check that compressor restarts at below pressures.
Model
Min. pressure (psi)
SLE-30, SLE-40
101
SLE-30H, SLE-40H
130
＊In case the minimum pressure is changed to101/130 psi, the volume of the air receiver must be 1.5 times larger than
the recommendation at 94/123 psi.
❖Stop
Push the stop switch and stop the compressor.
After the test operation ends, open the stop valve of the air outlet.

16
Test operation
▪Check control
This compressor uses plural air ends and employs multi-stage control. It can start and stop each air end according to pressure
and air consumption. It automatically selectsthe number of air ends, in accordance with air consumption, and achieves
optimum and uniform operation at all times, aswell as energy-saving and labor-saving operations.
(1) Multi-stage control
Among air ends, which are operatingunder group control, it stops the air end which has been operating for a longertime
andrestarts the air end whose operating time has been shorter. This results in equalization of operating time of each
air end and operation with a minimum quantity ofair ends, in accordance with air consumption and energy-saving
operation, by eliminating waste of electricity.
❖This figure is an example of the operation of SLE-40 and SLE-40H.
SLE-30 and SLE-30H operate 6 air ends.
(2) Prevention of long-term operation
When the operating time of the an air end exceeds the set time, it changes operation from that air end to the one
which has stopped, preventing long-term operation of oneair end. This lengthens the lifetime of air ends and equalizes
the operating time.
Multi-stage control

17
Operating panel
▪Changing the HMI Internal Clock
The HMI system clock is set to default by the manufacturer. During an alarm event the alarm log screen displays
occurrence time and date as well as alarm message. The occurrence time and date correspond to the HMI system time
and date, therefore it is recommended to change the HMI system clock to correspond to the local time zone. Follow the
steps below to set the HMI system clock:
1. With HMI ON press and hold the left top corner of the operational screen
2. Maintenance popup screen will appear
Select System mode
3. Go to Main Menu

18
Operating panel
4. Go to Clock Setting
5. Set date and time to correspond to the local time zone

19
Operating panel
▪Main Screen
▪Operation and stop
❖Operation
Press the ON switch so the compressor operating lamp lights up and compressor immediately starts.
❖Stop
Press the off switch so that compressor operating lamp goes off and compressor immediately stops.
When jobends, be sure to cut leak breaker.
Main disconnect supplied by customer in the field.
Run Mode selection
buttons
E-Stop light and reset button
Current pressure at the outlet of the compressor
Alarm light
Compressor status indicator
