ANFIM AE 65 V User manual

AE 65 V | AE 65 V Stp | AE 65 V SC | AE 65 V Stp SC | AE 65 VT | AE 65 VT Stp | AE 65 VT SC | AE 65 VT Stp SC
EN
Original instrucon manual
Single Espresso Grinder Solida
*example Fig.
Standard variant

2
AE 65 V | AE 65 V Stp | AE 65 V SC | AE 65 V Stp SC
1
2
12
8
10
9
3
11
4
5
6
7
13
A
SINGLE ESPRESSO GRINDER
Overview

3
1
2
8
10
9
3
11
4
5
6
7
13
AE 65 VT | AE 65 VT Stp | AE 65 VT SC | AE 65 VT Stp SC
15
12
14
B
Solida | EN

4
16
AE 65 V SC | AE 65 V Stp SC
C
16
AE 65 VT SC | AE 65 VT Stp SC
D
SINGLE ESPRESSO GRINDER

5
AE 65 VT Stp | AE 65 VT Stp SC
17
F
AE 65 V Stp | AE 65 V Stp SC
17
E
Solida | EN

6
19
2
20
18
G
SINGLE ESPRESSO GRINDER

7
12
21
I
4
H
Solida | EN

8
9
AE 65 V | AE 65 V Stp | AE 65 V SC | AE 65 V Stp SC
J
AE 65 VT | AE 65 VT Stp | AE 65 VT SC | AE 65 VT Stp SC
9
K
SINGLE ESPRESSO GRINDER

9
22
M
AE 65 VT | AE 65 VT Stp | AE 65 VT SC | AE 65 VT Stp SC
15
14
L
Solida | EN

10
SINGLE ESPRESSO GRINDER
Scope of delivery
No. Name
1Bean container (incl. lid)
2Bean container intake
3Dispensing chamber (with lid)
4Grinding degree lock
5On/Offswitch
6Release buon (thermal overcurrent circuit-breaker)
7Power cable (with power plug)
8Start button
9Dispensing lever
10 Drip tray
11 Portafilter support*
12 Grinding degree slide
13 Clip for the type of bean used
14 Tamper**
15 Tamper knob**
16 Dispensing counter**
17 Filling lever (automac filling)**
18 Rubber ring
19 Locking screw for the bean container
20 Sliding valve
21 Grinding degree scale
22 Dispenser insert (with adjusng wheel for dispensing quanty)
*Design varies; depends on the grinder variant chosen
**Oponal; depends on the grinder variant chosen

11
Solida | EN
Solida
Contents
Overview ............................. 2
Scope of delivery ............... 10
General informa on .......... 12
Reading and storing the
instrucon manual...................... 12
Explanaon of symbols used ...... 12
Safety ................................. 14
Intended use ............................... 14
Safety informaon ...................... 14
Before using for the
fi rst  me ............................ 17
Funconing
and grinder variants.................... 17
Checking the grinder and
scope of delivery......................... 18
Seng up the grinder and
inserng the bean container ...... 18
Opera on .......................... 19
Adding espresso beans............... 20
Switching on the grinder ............ 20
Seng the grinding degree ........ 21
Grinding espresso beans ............ 21
Removing the grounds................ 22
Seng the dispensing quanty.. 22
Changing the type of
espresso beans ........................... 23
Cleaning ............................. 24
Cleaning the surface on which
the grinder stands....................... 25
Cleaning the casing..................... 25
Cleaning the dispensing
chamber...................................... 26
Cleaning the bean container ...... 26
Cleaning the grinding mechanism27
Troubleshoo ng ................ 29
Technical data .................... 32
Disposal ............................. 34
Disposing of the packaging......... 34
Disposing of the grinder ............. 34
Maintenance and service .. 34
CE conformity declara on . 35

12
SINGLE ESPRESSO GRINDER
General informa on
Reading and storing the instruc on manual
Before you start using the Solida Espresso Grinder, carefully read
through this original instrucon manual and the safety informa-
on. Only then will you be able to use the Single Espresso
Grinder safely and without danger. The original instrucon
manual is based on the standards and regulaons in force in the European
Union. Please also note the guidelines and laws that apply in your country.
For greater clarity, the Solida Single Espresso Grinder will be referred to
below simply as the “grinder”.
Please keep this original instrucon manual safe for subsequent quesons.
Please also pass this original instrucon manual on to subsequent owners
and users of the grinder.
Explana on of symbols used
The following symbols and signal words are used in this original instrucon
manual, on the grinder or on the packaging.
WARNING!
This signal word/symbol indicates a moderate risk, which, if
it is not avoided, can lead to death or serious injury.
CAUTION!
This signal word/symbol indicates a low risk, which, if it is
not avoided, can lead to minor or moderate injury.
NOTE!
This signal word warns of possible material damage.

13
Solida | EN
This symbol provides you with useful informaon about opera-
on or handling.
Declaraon of Conformity (see “Declaraon of Conformity” secon):
Products marked with this symbol fulfill all applicable community
provisions of the European Economic Area.
ETL Listed seal of approval:
Products marked with this symbol meet the requirements for
electrical product safety in the United States of America.
Products marked with this symbol meet the required criteria of
the NSF (Naonal Sanitaon Foundaon) regarding cleanliness
and hygiene in the food industry.
Products marked with this symbol are only permied for use
indoors.
This symbol indicates a risk of electric shock.
This symbol indicates that the grinder conforms to protecon
class I.

14
SINGLE ESPRESSO GRINDER
Safety
Intended use
The grinder is suitable only for grinding whole roasted espresso beans. Do
not use the grinder to grind other products or objects. It is intended for com-
mercial use and may only be serviced by trained personnel. It may, however,
be operated by other persons in a place where its use is supervised.
Any other use is not considered to comply with intended use and can result
in material damage or even personal injury. Do not make any changes to the
grinder. Neither the manufacturer nor the supplier can accept liability for any
injury or damage resulng from failure to comply with the safety informaon.
Safety informa on
WARNING!
Risk of electric shock!
Improper use, incorrect electrical installa on or a voltage that is too
high can all lead to electric shock.
– Connect the grinder only if the mains voltage of the socket com-
plies with the informa on indicated on the type plate.
– Only connect the grinder to a socket with good accessibility so
that you can disconnect it quickly from the power supply in the
event of a malfunc on.
– Do not use the grinder if you no ce any visible damage or if the
power cable or plug is faulty.
– If the grinder power cable is damaged, it must be replaced by
the manufacturer or by qualifi ed personnel in order to avoid
hazards.
– Connect the grinder only to a power supply with a 16 A-slow
fuse. If the power connec on at the installa on loca on of the
grinder is not protected in this way, have a 16 A-slow fuse fi  ed
by a qualifi ed electrician.
– Install the grinder only in loca ons where its use can be super-
vised by trained personnel.

15
Solida | EN
– Do not operate the grinder above an al tude of 2,000 meters.
– Do not immerse the grinder, the power cable or the power plug
in water or any other liquids.
– Do not clean the grinder with a water jet.
– Do not clean the grinder with compressed air
(e.g. with a compressed air blow gun).
– Never touch the power plug with wet hands.
– Never unplug the power plug from the wall socket by pulling on
the power cable; always grip the power plug.
– Never use the power cable to carry the grinder.
– Keep the grinder and power cable / power plug away from open
fl ames and hot surfaces.
– Do not posi on the power cable in such a way that it could cre-
ate a tripping hazard.
– Do not bend the power cable and do not place it over sharp
edges.
– Use the grinder in indoor areas only. Never operate the grinder
in damp areas or in the rain.
– Keep children away from the grinder.
– Make sure that children do not insert any objects into the grinder.
– If you are not currently using or cleaning the grinder or if there
is a malfunc on, switch the grinder off and remove the power
plug from the socket.
– Do not open the grinder casing; leave repairs to the experts. If
repairs are required, please contact a specialist workshop. If un-
authorized repairs are carried out, the connec on is not made
correctly or the grinder is operated incorrectly, all liability and
warranty claims are excluded. Only parts that comply with the
original appliance specifi ca ons may be used for repairs. This
grinder contains electrical and mechanical parts that are essen-
 al for protec on against poten al hazards.

16
SINGLE ESPRESSO GRINDER
WARNING!
Danger for children and persons with reduced physical, sensory or
mental capaci es (e.g. par ally disabled persons, elderly persons
with limited physical and mental capaci es) or a lack of experience
and knowledge (e.g. older children).
– This grinder may be used by children older than eight years and
by persons with reduced physical, sensory or mental disabili es
or a lack of experience and knowledge if they are supervised or
instructed on the safe use of the grinder and have understood
the resul ng dangers. Children are not permi ed to play with
the grinder. Cleaning and user maintenance may not be carried
out by children without supervision.
– Do not leave the grinder unsupervised when in opera on.
– Do not let children play with the packaging fi lm. Children can
become entangled in it and suff ocate while playing.
– Do not let children play with small parts. They can be life-
threatening if swallowed.
CAUTION!
Risk of  pping and injury!
Incorrect handling of the grinder can result in injury.
– Posi on the power cable so that nobody can become entangled
in it and cause the grinder to fall.
– Place the grinder on a level and stable surface to prevent it from
falling off .

17
Solida | EN
Before using for the fi rst  me
Func oning and grinder variants
The Solida grinder is available in various designs.
The following applies to all grinder variants:
The espresso beans in the bean container (1) fall into the grinding mecha-
nism as soon as the sliding valve (20) has been opened (see Fig. A/B).
Pressing the start buon (8) starts and stops the grinding process (start
buon in posion I or 0). The grounds fall out of the grinding mechanism
through the outlet directly into the dispensing chamber (3).
In grinder variants without the “Automac Filling” funcon (see
below), the grinding process must be stopped manually when the
maximum capacity of the dispensing chamber is reached. If this
does not happen, ground coffee may build up in the grinder and
impair its funcon (see “Troubleshoong” secon).
The operator dispenses the grounds collected in the dispensing chamber into
the inserted portafilter with the aid of the dispensing lever (9) (see Fig. J/K).
Depending on the design, your grinder will also have one or more of the
addional funcons/items of equipment listed below:
• “Automa c Filling”;
equipped with filling level lever (17) (see Fig. E/F):
The grinder can be leon all the me (start buon in posion I).
When the filling level lever is triggered, the grinding process stops auto-
macally as soon as the capacity of the dispensing chamber is reached,
and it starts again when the level of coffee grounds falls as they are
dispensed.
• Design with tamper (14) (see Fig. B):
The tamper fied to the grinder is used to compress the coffee grounds
in the portafilter when they are taken from the dispensing chamber.
• Design with dispensing counter (16) (see Fig. C/D):
The dispensing counter is used to read the number of shots dispensed.

18
SINGLE ESPRESSO GRINDER
Checking the grinder and scope of delivery
NOTE!
Risk of damage!
The grinder can be damaged if the packaging is opened carelessly
with a sharp knife or other pointed object.
– Be very careful when opening.
1. Remove the grinder from its packaging.
2. Check that the delivery is complete (see Fig. A, Band G).
3. Check for damage to the grinder or any of the individual parts.
If this is the case, do not use the grinder. Contact your supplier (see
“Maintenance and service” secon).
Se ng up the grinder and inser ng the bean container
You will need a slot screwdriver to fix the bean container (not
supplied).
1. Place the grinder on a level and stable surface that does not vibrate.
2. Make sure that the grinder is switched off(On/Offswitch (5) and start buon
(8) to posion 0) and connect the grinder to the power supply by inserng
the power plug into a properly installed earthed socket (see Fig. A/B).
3. Place the drip tray (10) into the corresponding casing recess below the
dispensing chamber (3).
4. Make sure that the rubber ring (18) has been properly inserted in the
bean container intake (2) and is lying flat (see Fig. G).
5. Posion the bean container (1) on the bean container intake.
When posioning the bean container intake, ensure that the nose of
the bean container is located in the corresponding recess in the bean
container intake.
6. Push the bean container down slightly into the bean container intake and
rotate the bean container clockwise to lock it in place on the grinder.

19
Solida | EN
If the bean container cannot be fixed in place by rotang it, it may not
be posioned correctly. Align the bean container correctly (see step 5)
and try again to fix it in place by rotang it (see also “Troubleshoong”
secon).
7. Use a slot screwdriver to ghten the locking screw (19) for the bean
container clockwise.
The grinder switches offautomacally when the bean container
is not inserted.
Opera on
NOTE!
Risk of overhea ng!
Exceeding the maximum permissible opera ng cycle can cause the
grinder to overheat.
– Do not exceed the maximum opera ng cycle
(see “Technical data” sec on).
– Observe the recommended break when the maximum permissi-
ble opera ng cycle is reached (see “Technical data” sec on).
• The grinder has a thermal overcurrent circuit-breaker which
interrupts the electric circuit of the grinder in case of electri-
cal overload.
To use the grinder again, first set the start buon (8) and
the On/Offswitch (5) to switch posion 0 (off).
Then push the release buon (6) in.
You can now switch the grinder on by seng the On/Off
switch to switch posion I and resume using the grinder (see
“Troubleshoong” secon).
• The grinder also has a motor protector, which switches off
the grinder when the motor becomes too hot.
As soon as the motor has cooled down, the grinder can be
put into operaon again (see “Troubleshoong” secon).

20
SINGLE ESPRESSO GRINDER
NOTE!
Risk of damage!
The operator cannot adjust the thermal overcurrent circuit-breaker. If
the circuit-breaker has been triggered several  mes, a service partner
must be contacted for advice as the motor winding may be damaged.
Adding espresso beans
1. Remove the lid from the bean container (1).
2. Pour whole roasted espresso beans into the bean container from above.
• The maximum filling quanty should be approx. 1 cm below
the edge of the bean container.
• The minimum filling quanty should not fall below approx. 2
cm in order to ensure that there are no dispensing fluctua-
ons.
3. Place the lid back onto the bean container.
4. If necessary, open the bean container by pulling out the sliding valve (20)
(see Fig. G).
Switching on the grinder
1. Ensure that the power plug is inserted into a properly installed earthed
socket.
2. Make sure that the start buon (8) is in posion 0.
3. Switch on the grinder by moving the On/Offswitch (5) to posion “I”.
The grinder is now ready to use.
