Anita Garudan GPS/G-3525 Series Guide

User's Manual
and Spare Parts Book
GPS/G-3525
ANITA B, s.r.o.
Průmyslová 2453/7
680 01 Boskovice
Czech Republic
tel: [phone]
[phone]
fax: [phone]
e-mail: [email protected]
MP00800EN_161116

ANITA ©
MP00800EN_161116 2
All rights reserved.
Property of Anita B s.r.o. and protected by copyright. The use of this content without
written permission is prohibited.
Copyright © Anita B s r.o. (2016)
www.garudan.cz

ANITA ©
MP00800EN_161116 3
Content
1) SPECIFICATION ................................................................................................................... 4
2) DESCRIPTION...................................................................................................................... 5
3) SAFETY INSTRUCTIONS....................................................................................................... 6
4) SAFE INSTALLATION ........................................................................................................... 7
5) ELECTRIC DEVICE SETTING ................................................................................................. 7
6) DISPOSAL INSTRUCTIONS................................................................................................... 7
7) BEFORE MACHINE OPERATION.......................................................................................... 8
1. Lubrication ...................................................................................................................... 8
2. Needle insertion.............................................................................................................. 9
3. Upper threading.............................................................................................................. 9
4. Bobbin threading............................................................................................................. 9
5. Installing and removing the shuttle case...................................................................... 10
6. Thread tension adjustment........................................................................................... 10
7. Bobbin winding ............................................................................................................. 11
8. Adjusting height of presser foot ................................................................................... 11
9. Used oil disposal............................................................................................................ 11
8) MECHANICAL MAINTENANCE.......................................................................................... 12
1. Adjustment of bottom shaft: shuttle hook, Figure 16,17............................................ 12
2. A. Adjustment of needle and hook: shuttle hook (CB) ............................................... 12
2. B. Adjustment of needle and hook: rotary hook (RH)................................................. 14
3. Adjusting the shuttle spring position........................................................................... 15
4. Adjustment of sub presser foot ................................................................................... 16
5. Programmable presser foot ......................................................................................... 17
6. Threading of upper thread........................................................................................... 17
7. Additional tensioner for extra heavy materials XH...................................................... 18
8. Adjusting the mechanism of opening of upper thread................................................ 19
9. Adjustment of wiper .................................................................................................... 20
10. A. Adjustment of trimming mechanism: shuttle hook ................................................ 21
10. B. Adjustment of trimming mechanism: rotary hook RH ............................................ 21
11. Adjustment of speed of movement of the trimming lever ......................................... 22
12. Setting of hand wheel.................................................................................................. 23
13. Setting of bobbin winder ............................................................................................. 23
14. Sensors for initial position of X, Y and Z axis ............................................................... 24
15. Barcode reader............................................................................................................. 25
16. Feeding frame .............................................................................................................. 25
17. Thread holder............................................................................................................... 26
18. Needle cooling ............................................................................................................. 26
19. Lower feed frame lock ................................................................................................. 26
20. Lubrication of rotary hook (RH) ................................................................................... 27
21. Lubrication of ball screw shaft bearing........................................................................ 29
22. Connection to air supply.............................................................................................. 30
23. Operation of pedals ..................................................................................................... 31
24. Table of maximum sewing speeds............................................................................... 32
9) TROUBLESHOOTING......................................................................................................... 33
www.garudan.cz

ANITA ©
MP00800EN_161116 4
1) SPECIFICATION
Model
GPS/G-3525G general material
GPS/G-3525H heavy material
GPS/G-3525XH extra extra heavy material
GPS/G-3525_ _-xx/xx/xx feeding frame type (1-piece =20/ 2-piece
=22/; Options, e.g. Measuring of lower thread winding = BC,Barode
reader = BR, Control of the machine through buttons = HC, Laser
pointer =LP, Needle cooler =NC, Rotary hook =RH, Thread holder TH,
Programmable height of presser foot =PP, Safety curtain =SC
Sewing area
350 x 250 mm
Max. sewing speed
(for stitch lenth up
to 3mm)
*for rotary hook
2600/3000* spm (for GPS/G-3525G and GPS/G-3525H)
1000 spm (for GPS/G-3525XH)
(see table on page na 31)
Stitch length
0,1 – 12,7 mm
No. of needles
GPS/G-3525G 135x17 Nm. 80-120
GPS/G3525H 135x17 Nm. 120-160
GPS/G-3525XH 190 Nm. 140-200
Hook
Double capacity shuttle hook / Extra large capacity rotary hook
Lift of Presser Foot
max.
20 mm (stroke: 0 -7 mm)
Lift of feeding
frame
Standard 35 mm
Thread Trimmer
Standard
Memory Device
USB port- all devices USB compatible
Communication
interface
USB port
No. of stitches in
memory
Unlimited
No. of patterns in
memory
Unlimited
Driving unit
750 W servomotor
Power supply
1-fáze 220 V÷ 240 V, 50/60Hz (power input 2 kW)
Air consumption
0,6 Mpa (6 kg/cm2)
Ambient
temperature
5℃
～
40℃
www.garudan.cz

ANITA ©
MP00800EN_161116 5
2) DESCRIPTION
Fig. 1
www.garudan.cz

ANITA ©
MP00800EN_161116 6
3) SAFETY INSTRUCTIONS
1. Read this manual carefully before start and make sure all you understand all
concerning machine operation.
2. When maintenance is needed for the machine, only authorized or trained staff
should perform this task.
3. Please, pay attention to the notes about max. voltage on the lables.
4. The machine should be grounded.
5. Air consumption is from 0,55 to 0,6 MPa.
6. Use buttons on/off or main switch (see fig. 1) in following situations:
1) Connection/disconnection of cables on operation panel or control box
2) Before threading
3) Before perfrormance of mechanical adjustment
4) When you finish machine operation
7. Maintanance should be performed by authorized staff only.
8. Use only original parts supplied by manufacturer
For position of operation safety components see fig. 2.
A Stop switch. Use it in emergency situation. For machine re-start follow notes on LCD
monitor
B Thread take up cover.
C Motor cover.
D Finger guard.
E Safety label on switch board: for preventiv against electric injuries
F Safety guard: eye protection.
Fig. 2
www.garudan.cz

ANITA ©
MP00800EN_161116 7
4) SAFE INSTALLATION
All installation and service work have to be done without power supply.
A. The machine cannot be used if voltage is 10% above or 10% below
the formal voltage.
B. Check if there is correct air pressure in the pneumatic system.
C. For safe operation, please, use the machine in accordance with following conditions:
•The ambient operation temerature is from 5to 40°C
•The ambient storage temperature is from -10 to 60°C
D. Humidity is between 20 – 80% (relative humidity)
5) ELECTRIC DEVICE SETTING
A. Power voltage
•The voltage should be within the range of +-10% of the formal voltage.
•Power frequency should be within the range of +-1% of the formal frequency
(50/60Hz).
B. Electromagnetic wave noise
•The power should not be adjacent to strong magnetic field or high frequency stuff.
C. The liquid such as water is prevented from flowing into the adjusting box or motor
6) DISPOSAL INSTRUCTIONS
Please, hand the machine over to Anita B, s.r.o. after end of machine operational life.
www.garudan.cz

ANITA ©
MP00800EN_161116 8
7) BEFORE MACHINE OPERATION
1. LUBRICATION
Fig. 3
Check the
amount
oil in the oil
gauge window.
Fill up the oil
Fig. 3, 4
Fig. 4
Machine should be lubricated before its first use or if reusedafter a long period of idleness.
Fig. 5
Open the
shuttle lid, and
fully lubricate
the
shuttle , then
put on the
hook lid.
Fig. 5, valid for
shuttle hook.
For
lubrication of
rotary hook see
chapter 20
For safety, the hook lid should
be closed during operation.
Fig. 6
In case of need, add silicon oil in the cup
of the bracket for lubrication of upper
thread.
www.garudan.cz

ANITA ©
MP00800EN_161116 9
2. NEEDLE INSERTION
Loosen the screw of needle holder (1),
fully insert the needle (2) into the needle
socket in needle holder while keeping the
needle slot (3) facing tip of the hook, then
tighten it with the screw (1)
Fig. 7
3. UPPER THREADING
Lead the thread as the figure 8 shows and put
the thread take-up lever in upper stop
position to prevent slipping of the thread.
You will find detailed description in fig. 29
Fig. 8
4. BOBBIN THREADING
A. Put bobbin (1)into bobbin case (2) as the
fig. 9 shows (the shuttle rotates in clockwise
direction).
B. Bobbin thread is led through the bobbin
case spring and bobbin case hole (3)
C. The remain of bobbin thread end should be
kept about 25mm long.
Fig. 9
www.garudan.cz

ANITA ©
MP00800EN_161116 10
5. INSTALLING AND REMOVING THE SHUTTLE CASE
Hold out lever of the the shuttle case and
insert the the bobbin case until its lock fits in
the groove of the shaft, ending up clicking,
see fig. 10.
[Notice]
If the shuttle is not correctly installed,
machine can be damaged during operation
Fig. 10
6. THREAD TENSION ADJUSTMENT
A. Needle thread tension adjustment, fig. 11:
As the Figure shows, turn screw (1)of the main
tensioner clockwise to
increase the tension, while counterclockwise to
reduce the tension. Additional tensioner (2) is
used for final adjustment of the end of needle
thread after trimming.
B. Bobbin thread tension adjustment, fig. 12:
As the figure shows, turn screw 1 clockwise to
increase the tension, while counterclockwise to
reduce the tension.
Fig. 11
Fig. 12
www.garudan.cz

ANITA ©
MP00800EN_161116 11
7. BOBBIN WINDING
A) Insert the bobbin (3) on bobbin winder
shaft (1).
B) Press the winder lever (2) to activate the
operation and start the machine.
C) When the bobbin is fully wound with
thread, the winder lever releases the
bobbin. Cut the thread by knife (4), see fig.
13
Fig. 13
8. ADJUSTING HEIGHT OF PRESSER FOOT
A. Loosen screw of the presser foot (1) in
the lower end position and set the height of
the foot so the foot tip is approximately
0.5mm above the surface of the sewn
material, then tighten screw, fig. 14
Fig. 14
9. USED OIL DISPOSAL
The oil container (1)attached under the
base table should be taken away for
cleanup after it is full with oil.
Fig. 15
www.garudan.cz

ANITA ©
MP00800EN_161116 12
8) MECHANICAL MAINTENANCE
1. ADJUSTMENT OF BOTTOM SHAFT: SHUTTLE HOOK, FIGURE 16,17
A. Loosen both screws (2) at the bottom side of baseplate. By this the eccentric of segment
gear is loosen.
B. By the screwdriver (3) set the play of shuttle driver (7) in value 0,1mm or lower by
turning of the eccentric.
C. Check if there is no axial movement of the eccentric - ring (4) must be without any play
with the casting of baseplate.
D. Tighten both screws (2).
Fig. 16 Fig. 17
2. A. ADJUSTMENT OF NEEDLE AND HOOK: SHUTTLE HOOK (CB)
The hook in connection with the needle must be set so that the edge is in the position of
lower relief of needle when the hook is taking the loop of upper thread. Figure 20, detail A.
Recommended process, Figure 18,19,20:
A. Set the needle into the lower reversal point by turning the hand wheel. Put the stop
sleeve (2) on needle bar and insert the scale (4) between stop sleeve and bushing (3).
Tighten the screw (5) so that there is no play between the bushing, stop sleeve and
scale. The thickness of the scale for shuttle hook is 2.5mm.
B. Remove the scale (4) and pull the scale (2) onto the bushing (3) by turning the hand
wheel.
C. In this position the ege of the hook must be in the axe of the needle. Loosen the
screw (1)(Fig. 18) and turn with the shuttle driver (7) (Fig. 20) to the position so that
the hook (8)touches the shuttle driver by turning in clockwise. In this position the
edge of the hook must be in the axe of the needle. The screw (7) is loosen so there is
neccessary to set this screw in contact with the needle, Figure 20, detail B. It is used
as protection of the hook.
D. Loosen the screw (1)now and move with the needle bar so that the edge of the hook
(8), which is in the axe of the needle, is placed just above of lower edge of hook relief
(1), Fig. 22. Tighten screw (1).
www.garudan.cz

ANITA ©
MP00800EN_161116 13
Fig. 18 Fig. 19
E. Turn safety levers (2), Fig. 20 and remove the ring of the hook (3) from the hub (4).
F. Loosen the screw (5) and set the edge of the hook in distance of 0.05 - 0.1mm from
the hook relief (9) by turning the eccentric. Figure 20, detail A.
G. After that set the distance from the axe of the needle and the edge of hub of hook
relief (4) in value 7,5mm.
H. Put the ring of the hook (3), lock safety levers (2) to vertical position and check if all
screws are tightened carefully.
I. As this process is not so easy and there is neccessary to do more operations,at the
same time,it is recommended to check all values after adjustment or do it once
again.
www.garudan.cz

ANITA ©
MP00800EN_161116 14
Fig. 20
2. B. ADJUSTMENT OF NEEDLE AND HOOK: ROTARY HOOK (RH)
The hook in connection with the needle must be set so that the edge is in the position of
lower relief of needle when the hook is taking the loop of upper thread. Figure 19,21,22,23.
Recommended process:
A. Set the needle into the lower reversal point by turning the hand wheel. Put the stop
sleeve (2) on needle bar and insert the scale (4) between stop sleeve and bushing (3),
Figure 19. Tighten the screw (5) so that there is no play between the bushing, stop
sleeve and scale. The thickness of the scale for rotary hook is 2mm for medium and
2.5mm for heavy materials.
B. Remove the scale (4) and pull the scale (2) onto the bushing (3) by turning the hand
wheel.
C. In this position the ege of the hook must be in the axe of the needle
Loosen screws (5), Fig. 23 on the ring of the hook (4) and set the edge to the axe of
the needle (6).
D. Loosen the screw (1), Fig. 21 now and move with the needle bar so that the edge of
the hook, which is in the axe of the needle, is placed just above of lower edge of hook
relief (1), Fig. 21. Tighten screw (1).
E. Set the edge of the hook in distance of 0.05 - 0.1mm from the hook relief (1)at the
same time, Fig. 22. Tighten screws (5) on the ring of the hook (4), Fig. 23.
F. As this process is not so easy and there is neccessary to do more operations,at the
same time,it is recommended to check all values after adjustment or do it once
again.
www.garudan.cz

ANITA ©
MP00800EN_161116 15
Fig. 21 Fig. 22, 23
3. ADJUSTING THE SHUTTLE SPRING POSITION
A. Remove the needle plate, loosen screws (2)
of a base (1), Fig. 24.
B. Set the position of base towards the
the needle (3), as same as in the Figure,
tighten screws (2).
Fig. 24
www.garudan.cz

ANITA ©
MP00800EN_161116 16
4. ADJUSTMENT OF SUB PRESSER FOOT
A. Set the needle bar to the lower
reversal point by turning hand wheel.
Loosen screws (2) of the eccentric (1)
and set this eccentric to the position
whre the screw (2) is in upper
postion. The eccentric (1)is placed on
the main shaft (3), Fig. 26.
Fig. 25
Fig. 26
Fig. 27
www.garudan.cz

ANITA ©
MP00800EN_161116 17
B. Set the position of the driver (6)in value 17mm from the edge of presser bar (9). At
tightening the screw (5) check the position of the needle in the middle of sub
presser foot (7), Fig. 25, 27.
C. Loosen safety screw (4), Fig. 26 and set the screw (12)to the end right position in
round slot of the lever, Fig. 25.
D. Set the screw (11)so that there is touch with stopper of hand screw (10), Fig. 25.
E. Set the play between driver of presser bar (6)and bushing of presser bar (8)in value
9mm, Fig. 27. After that tighten the screw (4), Fig. 26.
F. Tighten all srews carefully.
G. Set needed height of the stroke of sub presser foot (7). This is done by moving of
the screw (12)in round slot of the lever, Fig. 25.
H. The height of presser foot (7) is set in comparison with thickness of the material by
hand screw (10).
Summary: sub presser foot (7) should be moved with delay in value 5mm of trace of the
needle in moving from lower reversal point. The sub presser foot may not be in touch with
the materials at movement of the material when the needle is over the material.
5 . PROGRAMMABLE PRESSER FOOT
The machine could be equipped by programmable
presser foot
-parameter 34 ON/OFF.
The parameter is controlled by pneumatic valve (1).
The height of presser foot is set by screw (2).
The height of programmable presser foot is set by
screw (3), Fig. 28.
Fig. 28
6. THREADING OF UPPER THREAD
Lead the thread from thread stand to guides (1)on the head of the machine. After that
thread through silicon oil bottle for lubrication. After that thread through tensioner (3), guide
(4), tensioner (5) and spring (6), guide (7) which is under the spring (6), needle lever (8),
guides (9) and (10)and guide (11)to the needle. Please keep the direction to the needle (12),
Fig. 29.
www.garudan.cz

ANITA ©
MP00800EN_161116 18
Fig. 29
7. ADDITIONAL TENSIONER FOR EXTRA HEAVY MATERIALS XH
This tensioner (1)
is helpful with sewing of two thicknesses of materials. It divides the tension
of the thread in combination with main tensioner. By this the stitch composition is perfect
and setting of tension is easier, Fig. 30.
It is pneumatically actuated, parameter 51 ON/OFF.
Fig. 30
www.garudan.cz

ANITA ©
MP00800EN_161116 19
8. ADJUSTING THE MECHANISM OF OPENING OF UPPER THREAD
Opening of plates (3) of main tensioner is actuated by pneumatic valve (1)which is
connected with rod (2), Fig. 31. This valce is controlled by parameter 16. This parameter
indicates the position of the needle when the plate is opened. These plates are opened at
last trimming movement. It ensures sufficient length of upper thread after trimming so
that the first stitch with next sewing operation is done properly and there is no risk of
removal of the thread.
Correct movement and size of opening of plates is set by position of rod (2) when the
control pin of main tensioner (4), Fig. 32 is in touch of stagnation area of rod (2). We are
oriented by distance from the edge (6)of stagnation area (5) with adjustment of point of
touch of pin (4). This point of touch afects the size of opening of plates.
Set the value in 0.6mm for general materials and 0.8-1mm for heavy materials.
It is done by loosing nut (7) and turning of piston rod of pneumatic cylinder. Finally
tighten the nut (7).
Fig. 31
Fig. 32
www.garudan.cz

ANITA ©
MP00800EN_161116 20
9. ADJUSTMENT OF WIPER
Adjustment of the position of wiper, Fig. 33. Its Function is to take out upper thread after
the trimming. Make sure that the upper thread ends are on the reverse side of material
when starting new section of sewing after the trimming.
A. Loosen the screw (5) on the shaft of wiper (4). Set the height of wiper so that it must
go through the space between needle and presser foot. The needle is in stopping
position of the machine. The distance from the needle is 1mm.
B. Press the lever (3) in the direction of the arrow and loosen the screws (1). Set the play
of wiper from the axe of presser foot in value 10mm in extreme position. Tighten
screw (1).
Fig. 33
C. Turning ON and OFF of wiper
Use the button (1)on the cover of solenoid
for turning ON/OFF, Fig. 34.
Fig. 34
www.garudan.cz
