Anita GZ-539-407 User manual

User´smanual
(maintenance)
GZ-539-407
ANITA B, s.r.o.
Hliníky2068
68001 Boskovice
CzechRepublic
tel: [phone]
[phone]
fax:[phone]
e-mail: [e-mail]

ANITA©
SerieGZ-539
2

ANITA©
SerieGZ-539
3
INDEX
1. Specifications…………………………………………………………………. 5
2. Safety…………………………………………………………………………. 6
2.1. Directives…………………………………………………………..…6
2.2. Generalnotes ofsafety…………………………………………….…6
2.3. Safetysymbols………………………………………………………..6
2.4. Importantpointsfortheuser……………………………………….…7
2.5. Operatingandspecialistpersonnel…………………………………....7
2.5.1. Operatingpersonnel…………………………………………………… 7
2.5.2. Specialistpersonnel…………………………………………………… 7
2.6. Danger………………………………………………………………… 8
3. Properuse……………………………………………………………………… 9
4. Disposalofmachine…………………………………………………………… 9
5. Transportation, packing andstorage…………………………………………… 9
5.1. Transporattiontocustomer´spremises……………………………...…9
5.2. Transportationinsidethecustomer´spremises……………………...…9
5.3. Disposalofpacking materials…………………………………………. 9
5.4. Storage…………………………………………………………….…….9
6. Explanationsofsymbols……………………………………………………… 10
7. Controls………………………………………………………………………..10
7.1. On/Off switch………………………………………………………… 10
7.2. Keyonthemachinehead……………………………………………..11
7.3. Pedal…………………………………………………………………..11
7.4. Leverforlifting thepresserfoot……………………………………....12
7.5. Knee lever……………………………………………………………..12
7.6. Reversefeedlever……………………………………………………..13
7.7. Stitchlengthadjustmentwheel………………………………………..13
7.8. Adjustmentkeyforlimiting thereversestitchlength………………… 14
7.9. Threadwiperswitch…………………………………………………….14
7.10. Controlpanel…………………………………………………………..14
8. Installationandcommissioning ………………………………………………... 15
8.1. Installation……………………………………………………………..15
8.1.1. Adjustingthetableheight……………………………………………… 15
8.1.2. Assembling theoilpan………………………………………………… 16
8.1.3. Mountingthesewing head……………………………………………..17
8.2. Commissioning ………………………………………………………..19
8.3. Switching themachineon/off………………………………………… 19
8.4. Checking thefunctionofstartinhibitor………………………………. 20
9. Preparation……………………………………………………………………..20
9.1. Insertingtheneedle…………………………………………………… 20
9.2. Winding thebobbinthread/adjustingthepreliminarythreadtension…21
9.3. Removing/Insertingthebobbincase…………………………………..22
9.4. Threadingthebobbincase/adjustingthebobbinthreadtension……… 22
9.5. Threadingtheneedethread/Adjustingtheneedlethreadtension…….. 23
9.6. Settingthestitchlength………………………………………………. 24
10. Sewing………………………………………………………………………..…24
10.1. Adjustingmethodsofthreadtension…………………………………. 24
10.2. Adjustingpressureofpresserfoot……………………………………. 26

ANITA©
SerieGZ-539
4
10.3. Manualbacktackingbypressing thebutton…………………………..26
11. Adjustment……………………………………………………………………. 27
11.1. Notes ofadjustment…………………………………………………..27
11.2. Tools, gaugesandotheraccessories…………………………………. 27
11.3. Abbreviation…………………………………………………………. 27
11.4. Explanationofthesymbols…………………………………………..28
11.5. Hooklubrication……………………………………………………... 28
11.6. Needleheight………………………………………………………… 29
11.7. Presserfoottoneedleplateclearance………………………………... 29
11.8. Positioning thebottomfeeddog……………………………………... 30
11.9. Needlerise, hookclearance andbobbincasepositionstop………….. 31
11.10. Threadcatcherpositionandcuttingtest……………………………... 32
11.11. Threadpuller…………………………………………………………. 33
11.12. Centeringtheneedleintheneedlehole……………………………… 34
12. Careandmaintenance ………………………………………………………… 36
12.1. Maintenance intervals………………………………………………... 36
12.2. Cleaningthemachine………………………………………………....36
12.3. Oiling themachine…………………………………………………..…37
13. Wearingparts…………………………………………………………………. 38

ANITA©
SerieGZ-539
5
1. SPECIFICATIONS
Generalspecifications
Stitchtype301/304 zigzaglockstitch
Needlesystem 134R
Needlesize inNm60-100
Presserfootclearance:
Withhandlever 5.5mm
Withautomaticpresserfootlift6.0mm
Withknee lever 10.0mm
Max. stitchlength1,8mm
Max. speed5000spm
Max. zigzagstitchwidth8.0mm
Clearance width 300mm
Clearance height125mm
Bedplatedimensions 517x178mm
Sewingheaddimensions
Length approx.595mm
Width approx.230mm
Heightabovetableapprox.335mm
Netweightofsewing head approx.53kg
Gross weightofsewinghead approx.62kg
Connectiondata:
Operatingvoltage230V(±10%)50/60Hz
Max. powerconsumption0,6kVA
Fuseprotection 1x16A,inert
Noisedata:
Noiseemissionlevelatworkplace withasewing speedof4000 rpmLPA81.0dB(A)
(NoisemeasurementinaccordancewithDIN45 635-48-A-1ISO11204,ISO3744,
ISO4871)

ANITA©
SerieGZ-539
6
2. SAFETY
2.1. Directives
Thismachineisconstructedinaccordance withtheregulationscontainedintheconformity
andmanufacturer’sdeclarations.InadditiontothisInstructionManual,alsoobserveall
generallyaccepted,statutoryandotherregulationsandlegalrequirementsandallvalid
environmentalpretectionregulations!
Theregionallyvalidregulationsofthesocialinsurance societyforoccupationalaccidentsor
othersupervisoryorganizationsaretobestrictlyadheredto!
2.2. Generalnotesofsafety
Thismachinemayonlybeoperatedbyadequatelytrainedoperatorsandonlyafterhaving
completelyreadandunderstoodtheInstructionManual!AllNotesonSafetyandInstruction
Manualsofthemotormanufactureraretobereadbeforeoperatingthemachine!Thedanger
andsafetyinstructionsonthemachineitselfaretobefollowed!
Thismachinemayonlybeusedforthepurposeforwhichitisintendedandmaynotbe
operatedwithoutitssafetydevices.Allsafetyregulationsrelevanttoitsoperationaretobe
adheredto.
Whenexchanging sewing tools(e.g.needle,rollerpresser,needleplateandbobbin),when
threadingthemachine,whenleaving themachineunattendedandduringmaintenance work,
themachineistobeseparatedfromthepowersupplybyswitching offtheOn/Off switchor
byremoving theplug fromthemains!
Everydaymaintenance workisonlytobecarriedoutbyappropriatelytrainedpersonnel!
Repairesandspecialmaintenance workmayonlybecarriedoutbqualifedservicestaffor
appropriatelytrainedpersonnel!
Workonelectricalequipmentmayonlybecarriedoutbyappropriatelytrainedpersonnel!
Workisnotpermittedonpartsandequipmentwhichareconnectedtothepowersupply!The
onlyexceptionstothisrulearefoundintheregulationsEN50110.
Modificationsandalterationstothemachinemayonlybecarriedoutunderobservance ofall
therelevantsafetyregulations!
Onlysparepartswhichhavebeenapprovedbyusaretobeusedforrepairs!We
expresslypointoutthatanyreplacementpartsoraccessorieswhicharenotsuppliedbyus
havenotbeentestedandapprovedbyus.Theinstallationand/oruseofanysuchproductscan
leadtonegativechangesinthestructuralcharacteristicsofthemachine.Wearenotliablefor
anydamagewhichmaybecausedbynon-originalparts.
2.3. Safetysymbols
Danger!
Points tobeobserved!
Dangerofinjuryforoperatingandspecialistpersonnel!

ANITA©
SerieGZ-539
7
Caution
Donotoperatewithoutfingerguardandsafetydevices.
Beforethreading,changing bobbinandneedle,cleaning etc. Switchoff main
switch.
2.4. Important points fortheuser
•ThisInstructionManualisanintegralpartofthemachineandmustbeavailableto
theoperatingpersonnelatall times.
•TheInstructionManualmustbereadbeforeoperatingthemachineforthefirst
time.
•Theoperatingandspecialistpersonnelis tobeinstructedastothesafetyequipment
ofthemachineandregardingsafeworkmethods.
•Itisthedutyoftheusertoonlyoperatethemachineinperfectrunning order.
•Itistheobligationoftheusertoensurethatnoneofthesafetymechanismsare
removedordeactivated.
•Itistheobligationoftheusertoensurethatonlyauthorizedpersonsoperateand
workonthemachine.
FutherinformationcanbeobtainedfromourSales Department.
2.5. Operatingand specialistpersonnel
2.5.1. Operatingpersonnel
Operatingpersonnelarepersonsresponsiblefortheequipping,operatingandcleaningof
themachineaswellasfortakingcareofproblemsarising inthesewing area.
Theroperatingpersonnelisrequiredtoabservethefollowing pointsandmust:
•alwaysobservetheNotes onSafetyintheInstructionManual!
•neveruseanyworkingmethodswhichcouldadverselyaffectthesafetyofthe
machine!
•notwearloose-fittingclothing orjewelerysuchaschainsorrings!
•alsoensurethatonlyauthorizedpersonshaveaccesstothepotentiallydangerous
area aroundthemachine!
•alwaysinnediatelyreporttothepersonresponsibleanychangesinthemachine
whichmaylimititssafety!
2.5.2. Specialistpersonnel
Specialistpersonnelarepersonswithaspecialisteducationinthefieldsofelectrics,
electronicsandmechanics.Theyareresponsibleforthelubrication,maintenance,repair
andadjustmentofthemachine.
Thespecialistpersonnelisobligedtoobservethefollowing pointsandmust:
•alawaysobservetheNotes onSafetyintheInstructionManual!
•switchofftheOn/Offswitchbeforecarrying outadjustmentsorrepairs,andensure
thatitcannotbeswitchedonagainunintentionally!
•waituntil theluminousdiodeonthecontrolboxisnolongerblinking oronbefore
beginning adjustmentorrepairwork.
•neverworkonpartswhicharestillconnectedtothepowersupply!Exceptionsare
explainedintheregulationsEN50110.

ANITA©
SerieGZ-539
8
•replace theprotectivecoveringsandclosetheelectricalcontrolboxafterall
repairesormaintenance work!
2.6. Danger
Aworkingarea of1meteristobekeptfree bothinfrontofandbehind the
machinewhileitisinoperationsothatitalwayseasilyaccessible.
Neverreachintothesewingarea whilesewing!
Dangerofinjurybytheneedle!
Neverleaveobjectsonthetablewhileadjustingthemachinesettings!Objects
canbecometrappedorbeslungaway!Dangerofinjury!
Onlyoperatethemachinewithcover1closed!
Dangerofinjuryfromtherotatingtake-up lever!
Donotoperatethemachinewithoutthefingerguard2!
Dangerofinjurybytheneedle!
Donotoperatethemachinewithoutstartinhibitor3!
Dangerofinjurybytheneedle!
Donotoperatethemachinewithoutcover4!
Dangerofinjuryfrommoving parts!

ANITA©
SerieGZ-539
9
3. PROPERUSE
GARUDANGZ-539-407 ishigh-speed,zigzagsewingmachinewithbottomfeedanda
largehook.
Themachineisusedforproducingzigzaglockstitchseamsintheclothing andlinen
industry.
Anyandallusesofthismachinewhichhavenotbeenapprovedofbythe
manufacturerareconsideredtobeinappropriate!Themanufacturercannotbe
heldliableforanydamagecausedbytheinappropriateuseofthemachine!The
appropriateuseofthemachineincludestheobservance ofalloperational,
adjustment, maintenance andrepairmeasuresrequiredbythemanufacturer!
4. DISPOSAL OFMACHINE
Caremustbetakenthatpartssoiledwithlubricantsaredisposedofseparately
accordingtothelocallyvalidpollutioncontrolregulations!
5. TRANSPORTATION, PACKINGAND STORAGE
5.1. Transportationtocustomer’s premises
Themachinesaredeliveredcompletelypacked.
5.2. Transportationinsidethecustomer’s premises
Themanufacturercannotbemadeliablefortransprotationinsidethecustomer’spremises
nottootheroperatinglocations.Itmustbeensuredthatthemachinesareonlytransported
inanuprightposition.
5.3. Disposalofpackingmaterials
Thepacking materialsofthismachinecomprisepaper,cardboardandVCEfibre.Proper
disposalofthepackingmaterialistheresponsibilityofthecustomer.
5.4. Storage
Ifthemachineisnotinuse,itcanbestoredasitisforaperiodofup tosixmonths,butit
shouldbeprotectedagainstcorrosion, e.g. byafilmofoil.
Ifthemachineisstoredforlongerperiods,theindividualparts,especiallythesurfacesof
moving parts, mustbepretectedagainstagainstcorrosion, e.g.byafilmofoil.

ANITA©
SerieGZ-539
10
6. EXPLANATIONOFSYMBOLS
Inthisinstructionmanual,worktobecarriedoutorimportantinformationisaccentuated
bysymbols. Thesesymbolshavethefollowing meanings:
Note,information
Cleaning, care
Maintenance, repair,, adjustment, service work
(onlytobecarriedoutbytechnicalstaff)
7. CONTROLS
7.1. On/off switch
Switchthemachineonoroffbyturning
mainswitch1

ANITA©
SerieGZ-539
11
7.2. Keyonthemachinehead
•Aslongaskey1ispressedduring
thesewingoperation,themachine
sewsinreverse.
•Whensewing shellstitchesor
programmedpatterns,bypressing
key1afteramachinestop,the
patternissewninreverse.
7.3. Pedal
+1=Sew
. 0=Stop
-1=Presserfoot
-2=Threadtrim

ANITA©
SerieGZ-539
12
7.4. Lever forliftingthepresser foot
Thepresserfootisraisedbyturninglever1
7.5. Knee lever
Bypressing theknee lever1inthedirectionof
thearrow, theoresserfootisraised.

ANITA©
SerieGZ-539
13
7.6. Reversefeedlever
Aslongaslever1ispresseddutinythesewing
operation, themachinesewsinreverse.
7.7. Stitchlengthadjustmentwheel
Settherequiredstitchlengthbyturning
adjustmentwheel1.
Thestitchlengthsettingcanberead
onthescale.

ANITA©
SerieGZ-539
14
7.8. Adjustment keyforlimitingthereversestitchlength
Byturningadjustmentwheel1,thestitchlength
forreversesewing islimited.
7.9. Threadwiper switch
Thethreadwiperfunctionisswitchedonor
offbypressing switch1.
7.10. Controlpanel
Thecontrolpanelisusedtocall up machinefunctionsforsettingupthemachineandfor
sewing operation,forenteringparametervaluesand forreadingerrormessagesandservice
settings. Formoreinformationpleaseseeyourmotormanual.

ANITA©
SerieGZ-539
15
8. INSTALLATIONAND COMMISSIONING
Themachinemustonlybeinstalledandcommissionedbyqualified
personnel!Allrelevantsafetyregulationsmustbestrictlyadheredto!Ifthe
machineisdeliveredwithoutatable,besuretouseastandandtabletop
thatcanholdtheweightofthemachinewithitsmotor.Itisveryimportant
toensurethatthestandofthemachineisfirmandstready,alsoduring
.sewing.
8.1. Installation
Thesitewherethemachineisinstalledmustbeprovidedwithsuitableconnectionsforthe
electriccurrent, see Chapter1Specifications.
Itmustalsobeensuredthatthestandingsurface ofthemachinesiteisfirmandhorizontal,
andthatsufficientlightingisprovided.
Forpackingreasonsthetabletopisintheloweredposition.
Thetableheightisadjustedasdescribedbelow.
8.1.1. Adjustingthetableheight
•Lossenscrews1and2andsetthetableheightasrequired.
•Firmlytightenscrew1.
•Settherequiredpedalpositronandtightenscrews2.

ANITA©
SerieGZ-539
16
8.1.2. Assemblingtheoilpan
•Insertrubbersupport1.
•Insertbearingbushes2andfastenwithnails.
•Place oilpan3inthetable-topopening.
•Insertrubberpad4andfastenwithnails.

ANITA©
SerieGZ-539
17
8.1.3. Mountingthesewinghead
•Place bothhinges1inthe
appropriatedholesinthebedplateof
thesewinghead.
•Placethesewing headwithhinges1
intothebackrubberpads.
8.1.4. Mountingthespoolholder
•Mountthespoolholderasshownin
•Insertthespoolholderintotheholein
thetabletopandfastenitwiththe
nutsenclosed.

ANITA©
SerieGZ-539
18
8.1.5. Connectingtheplug-inconnectionsandearthcables
•Connectall plugsaslabelledtothecontrolbox.
•ScrewtheearthcablefromthesewingheadandthemainswitchtoearthpointA.
•ConnectearthpointAtoearthpointBwithearthcable2.Screwtheearthcable3
fromthemotortoearthpointB.

ANITA©
SerieGZ-539
19
8.2. Commissioning
•Checkthemachine, especiallytheelectricalleads, foranydamage.
•Cleanthemachinethoroughly(see chapter12Careandmaintence).
•Havespecialistsensurethatthemachine´smotorcanbeoperatérwiththeavailable
elektricitysupplyandthatitis connectedbyproperly.Ifnot,themachinemustnot
beoperated.
•Whenthemachineisrunning, thebalance wheelmustturntowards theoperator.
•Beforecommissioning themachine,removecap1andplug 2andfill inoil up to
marking 3, see Chapter12.03Oiling themahcine.
•Closetheholeagainwithplug 2.
Cap1isusedasatransportlockandmustnotbefittedduringoperation!
8.3. Switchingthemachineon/off
Switchthemachineon(see Chapter7.01 On/Offswitch).
Carryoutatestrun.

ANITA©
SerieGZ-539
20
8.4. Checkingthefunctionofstartinhibitor
•Switchthemachinaonatthemainswitchandtiltbackthesewing head.
•Theerrormessagemustappearonthekontrolpanel.
•Ifthemessagedoesnotappear, checkthesettingofsafetyswitch.
9. PREPARATION
AllregulationsandinstructionsinthisInstructionManualaretobeobserved!
Specialattentionistobepaidtothesafetyregulations!
Allpreparationworkisonlybecarriedoutbyappropriatelytrained
personnel.Beforeallpreparationwork,themachineistobeseparatedfrom
theelectricitysupplybyremoving theplug fromthemainsorswitching off
theOn/Offswitch!
9.1. Insertingtheneedle
Raiseneedlebar.
Loosenscrew1andinsert
needle2until youfeelit
stop.
Insertneedle2asfaras
possible.Thelongneedle
groovemustbefacing
forwards.
Tightenscrew1.
