anko HEGSM40 User manual

Smart Fan with Wi-Fi
User Manual
Model No.: HEGSM40
Rev 2
Note: The specifications and/or components of this appliance are subject to change without prior notice.

Page 2 of 28

Page 3 of 28
1Safety Instructions.......................................................................4
2Components .................................................................................6
3Assembly ......................................................................................7
3.1 Base and Stand ........................................................................................... 7
3.2 Attach Head to Stand .................................................................................. 8
3.3 Safety Grille and Fan Blade ........................................................................ 9
4Instructions for Use ...................................................................13
4.1 Head Tilt......................................................................................................13
4.2 Height Adjustment .....................................................................................13
5Remote Control..........................................................................14
6Smartphone Control App Setup ...............................................15
7Wi-Fi Pairing ...............................................................................16
7.1 How to Reset the Fan Wi-Fi........................................................................17
8Operation....................................................................................18
8.1 Using the Fan Remote Control and Fan Control Panel.............................18
8.2 Fan Modes ..................................................................................................19
8.2.1 Normal Mode........................................................................................................ 19
8.2.2 Nature Mode ........................................................................................................ 19
8.2.3 Sleep Mode.......................................................................................................... 19
8.3 Timer...........................................................................................................20
8.4 Oscillating (Swing) Function .....................................................................20
8.5 Using the Smart Phone App ......................................................................20
9Using Google Home Device ......................................................22
9.1 Link TuyaSmart account in Google Home Control .................................23
9.2 Control your Fan through Google Home ..................................................23
10 Using Amazon Echo Device......................................................24
10.1 Control your Fan through Echo.................................................................24
11 Shared Device ............................................................................25
12 Care and Cleaning .....................................................................25
13 Storage........................................................................................25
14 Troubleshooting.........................................................................26
15 Warranty Against Defect ...........................................................27

Page 4 of 28
1 Safety Instructions
When using electrical appliances, basic safety precautions should always be followed,
including the following:
•Carefully read this instruction manual before using appliance.
•Ensure that the fan is switched off from the supply mains before removing the guard.
•Keep appliance out of reach of young children.
•This appliance is not intended for use by persons (including children) with reduced
physical, sensory or mental capabilities, or lack of experience and knowledge, unless
they have been given supervision or instruction concerning use of the appliance by a
person responsible for their safety.
•Children should be supervised to ensure that they do not play with the appliance.
•Ensure children and babies do not play with plastic bags or any packaging materials.
•Do Not disassemble the appliance. There are no user serviceable parts inside.
•VERY IMPORTANT:
Ensure that appliance does not get wet (water splashes etc.).
Do not use appliance with wet hands.
Do not immerse appliance in water or other liquids or use near sinks, baths or showers.
•Always operate the appliance from a power source of the same voltage, frequency and
rating as indicated on the product identification plate.
•Position the power supply lead properly so that they will not be walked on or pinched
by items placed on or against them.
•Use appliance only for its intended use. Appliance is intended for household use only
and not for commercial or industrial use.
•Do not use appliance if it has been dropped or any part of appliance (including cord or
plug) has been damaged.
•If the supply cord is damaged, it must be replaced by the manufacturer, its service
agent or similarly qualified persons in order to avoid a hazard.
•The use of accessories not intended for use with this appliance may cause injuries to
the user or damage to the appliance.
•Do not install the unit on other appliances, on uneven surfaces or where it could be
subject to: heat sources (e.g. radiators or stoves), direct sunlight, excessive dust or
mechanical vibrations.

Page 5 of 28
•Appliance should not be used outdoors, placed near a hot gas or electrical burner or
placed in a heated oven.
•Do not install near any heat sources such as radiators, heat registers, stoves, or other
apparatus that produce heat.
•Do not hang or wall-mount the appliance.
•Do not operate appliance underneath or near flammable or combustible materials (e.g.
curtains). Keep at least 300mm clearance around sides, back, front and top.
•Do not allow curtains, drapes or any other items to drape across the appliance or
openings.
•Unplug this apparatus during lightning storms or when unused for long periods of time.
•Do not block any ventilation openings.
•Never insert fingers or any other objects through the fan guard and ventilation
openings.
•Do not use the product in oily or dirty areas (e.g. the kitchen, smoky place, etc), as the
air vents may become blocked.
•Turn off and unplug before cleaning or storing.
•There are no user serviceable parts in this appliance.
•If this appliance is used by a third party, please supply the instruction manual with it.
•Do not misuse the cord. Never carry the appliance by the cord or pull to disconnect it
from the outlet. Instead, grasp the plug and pull to disconnect.
•Do not insert or allow foreign objects to enter the grille openings as this may cause
damage to the appliance and/or injury to the user.
•No liability can be accepted for any damage caused by non-compliance with these
instructions or any other improper use or mishandling of appliance.
Additional Safety Instructions
If using an extension cord:
•The technical specifications of the extension cord must match or exceed the technical
specifications of this appliance.

Page 6 of 28
•Do not allow the cord to hang over the edge of the work surface or to come into contact
with stoves or other hot surfaces.
•If the cord or plugs are worn or damaged, do not use.
•Unplug from the power socket by grasping the plug body - Do Not pull on the cord.
Read and Save These Instructions
2 Components
1 Front Grille
2 Locking Screw
3 Fan Grille Lock / Band
4 Fan Blade Spinner Nut
5 Fan Blade
6 Rear Grille Nut
7 Rear Grille
8 Motor Head Assembly
9 Control Body
10 Head to Post Locking Screw
11 Inner chrome tube
12 Height Adjustment Locking Screw
13 Stand Post
14 Base Cover
15 Base W eight
16 Screw and W asher
17 Remote Control
1
2
3
4
5
6
7
8
9
11
10
12
13
14
16
15
17

Page 7 of 28
3 Assembly
3.1 Base and Stand
Your Fan has been boxed unassembled to minimise packaging waste. Each part is
designed to fit together and be disassembled easily for cleaning or storage.
•First, with the aid of a Philips Head screwdriver, unscrew the Screw and Washer
from the bottom of the stand post. (Anticlockwise).
•Place the base flat on the floor and fit the post into the recess in the top of the base.
•Whilst holding the post and base together, tip up so that the underneath of the base
is accessible.
•Place the Screw and Washer through the hole and with the aid of a Philips Head
screwdriver, tighten the Screw and Washer. (Clockwise).

Page 8 of 28
3.2 Attach Head to Stand
•Stand the Base with attached post on the floor.
•Loosen (anticlockwise) the post Height Adjustment Locking Screw, pull out the
inner chrome tube to the desired height and then retighten the locking screw.
•Place Motor assembly at the top of the Stand Post and lower down all the way.
Note: if the motor assembly will not slide down the chrome post, loosed the Head
to Post Locking Screw on the back of the motor assembly until it can slide down.
•Tighten the Head to Post Locking Screw (Clockwise). Do Not overtighten.

Page 9 of 28
3.3 Safety Grille and Fan Blade
•To assemble the safety grille and blade assembly, first remove the Rear Grille Nut
(Anticlockwise) from the front of the fan motor housing.
•Fit the rear safety grille into position with the slots in the 12 and 6 o’clock position
ensuring the location pins are located as shown below, and refit the Nut and tighten.
•If Fitted, remove the protective plastic sleeve from the motor spindle shaft and
discard.
•Place the Fan Blade onto the motor spindle.
Note: The groove in the rear centre of the fan blade aligns with a T-bar on the motor
spindle to ensure correct positioning.

Page 10 of 28
•Secure the blade into place by gently hand tightening the spinner nut
anticlockwise onto the end of the motor spindle. The spinner nut is self-tightening
when the motor starts, so do not over-tighten the spinner nut, just nip it up.
NOTE: The Spinner Nut screws on in the opposite way to a normal nut.
It tightens when rotated Anticlockwise.
•Take the front grille and using a Philips Head screwdriver, unscrew and remove the
small screw in the locking mechanism at the bottom of the grille.
