anko K2304 User manual

Thermal Cooking Kitchen Machine
Instruction Manual
Scan the code to access over 150 recipes
Model No.: K2304
Rev: 5

Page 2 of 44

Page 3 of 44
1Important Safeguards............................................................................ 5
2Components .......................................................................................... 9
3Methods of Safe Installation................................................................ 10
4Before First Use .................................................................................. 10
4.1 Unpacking ....................................................................................... 10
5Assembling Components and Use of Accessories ............................. 10
5.1 Drive Coupling................................................................................. 10
5.2 Multifunction Blade .......................................................................... 11
5.3 Kneading Blade ............................................................................... 12
5.4 Butterfly Whisk ................................................................................ 13
5.5 Jar and Lid Assembly...................................................................... 14
5.6 Measuring Cup / Jar Lid Plug.......................................................... 15
5.7 Spatula ............................................................................................ 15
5.8 Strainer / Steamer Basket ............................................................... 16
5.9 Steamer Assembly .......................................................................... 16
6Instruction For Use ............................................................................. 17
6.1 Controls ........................................................................................... 18
6.2 Start / Pause.................................................................................... 18
6.3 Rotary Knob .................................................................................... 18
6.4 Auto Off Timer ................................................................................. 18
6.5 Speed .............................................................................................. 19
6.5.1 Turbo Mode.....................................................................................................................20
6.6 Heating Power................................................................................. 20
6.7 Temperature.................................................................................... 20
6.8 Scales.............................................................................................. 21
7Suggested Speed and Capacity for each Accessory.......................... 22
8Pre-Set Programs................................................................................ 22
9Recipes and Examples for Pre-set Function....................................... 36
9.1 P02 (Knead)- Pasta Dough ............................................................. 36
9.2 P03 – (Crush) Strawberry and Banana Smoothie........................... 36
9.3 P04 – (Chop) Coriander and Cashew Pesto................................... 36
9.4 P05 – (Sauté) Chickpea Curry ........................................................ 37
9.5 P06 – (Stew) Beef and Potato Stew................................................ 37
9.6 P07 – (Steam) Steamed Chicken.................................................... 37
9.7 P09 – (Yoghurt) Honey Yoghurt...................................................... 38
9.8 P11 – (Slow Cook) Potato and Chive Soup .................................... 38
9.9 P12 – (Quick Soup) Yellow Sweet Potato Curry Soup ................... 38
9.10 P13 – (Stir) Strawberry Compote .................................................... 39
9.11 P16 – Rice....................................................................................... 39
9.12 P17 – (Porridge) Apple and Cinnamon ........................................... 39
9.13 P18 – Congee ................................................................................. 40
10 Cleaning .............................................................................................. 40
11 Disposal............................................................................................... 41
12 Troubleshooting................................................................................... 42
13 Warranty Against Defect ..................................................................... 43

Page 4 of 44

Page 5 of 44
When using electrical appliances, in order to reduce the risk of fire, electric shock
and/or injury, these basic safety precautions should always be followed:
1 Important Safeguards
When using electrical appliances, basic safety precautions should always be followed,
including the following:
•Before using this appliance, read and follow all warnings and instructions in this manual, even
if you are familiar with this product.
•Keep appliance out of reach of young children.
•This appliance is not intended for use by persons (including children) with reduced physical,
sensory or mental capabilities, or lack of experience and knowledge, unless they have been
given supervision or instruction concerning use of the appliance by a person responsible for
their safety.
•Children should be supervised to ensure that they do not play with the appliance.
•Ensure children and babies do not play with plastic bags or any packaging materials.
•This appliance is heavy. Care should be taken when moving it. Turn off and unplug before
moving.
•Do not attempt to modify this product in any way.
•This appliance must be Earthed.
•Do not plug into the power socket before set up is completed.
•Keep Power Cord away from traffic areas and wet areas.
•VERY IMPORTANT:
Ensure the outside of the appliance does not get wet (water splashes etc.).
Do not use appliance with wet hands.
Do not immerse appliance in water or other liquids or use near sinks, baths or showers.
•Always operate the appliance from a power source of the same voltage, frequency and rating
as indicated on the product identification plate.
•Position the power supply lead properly so that it will not be walked on, pinched by items
placed on or against it or have the appliance resting on it.
•This appliance is intended to be used in household and similar applications such as:
–staff kitchen areas in shops, offices and other working environments
– farmhouses and by clients in hotels, motels and other residential type environments
–bed and breakfast type environments
–catering and similar non-retail applications
WARNING: Keep ventilation openings clear of obstruction.

Page 6 of 44
•Avoid contacting moving parts. Keep hands, hair, clothing as well as spatulas and other
utensils away during operation to prevent injury and/or damage to the appliance.
•Switch off the appliance and disconnect from supply before changing accessories or
approaching parts that move in use.
•Always unplug the appliance from the power supply if it is left unattended, and before
assembling, disassembling or cleaning.
•Be careful if hot liquid is poured into the food processor or blender as it can be ejected out
of the appliance due to a sudden steaming.
•The appliance is only to be used with the stand provided.
•The heating element surface is subject to residual heat after use.
•For cleaning, please refer to “10 Cleaning” section.
•For the operating times and speed settings for accessories, please refer to “7 Suggested
Speed and Capacity for each Accessory” section.
Caution, hot surface. Care must be taken. The surfaces are liable to get hot during use.
•Operate on a flat level surface only. Operating on sinks, draining boards or uneven surfaces
must be avoided.
•Keep hands and utensils out of the jar while in use. A rubber scraper may be used when the
appliance is turned off and unplugged.
•Always operate the appliance with the Lid in place.
•Never bypass the safety interlocking devices.
•Do Not attempt to open the lid or remove the jar when in use.
•Pay attention to the high-temperature food when you open the jar lid.
•Always insert the measuring cup / Lid Plug correctly in the hole in the top of the jar lid when
processing food.
•Do not exceed 2 minutes of use when set to the highest speed levels 8, 9 or 10 as the motor
can overheat. Switch off and allow the unit to cool down for at least 1 minute, then continue
again.
CAUTION: When blending / stirring hot liquids, (Never blend hot oil or fat), pour
through the special removable cap on the Lid of the jar. Begin processing at a lower
speed. Keep hands and other exposed skin away from the cover to prevent possible
burns.
•Injury can result if moving blades accidentally become exposed.
•Do not leave the appliance unattended when running.
•Do not use the jar for storing foods or beverages.
•Do not use appliance for mixing paints or other flammable liquids or in a location
contaminated with flammable gases or vapours.
•Avoid spillage of food or liquids onto the power connector in the jar recess. If there is a spill,
immediately turn off and unplug, allow the spillage to cool, then clean.

Page 7 of 44
•Make sure that the blade sealing ring is fitted correctly and the blade assembly is assembled
securely in the jar base before use.
The failure of correct assembly will cause the food leakage which will damage the appliance.
•Take care after using the heating function as the surfaces of components will stay hot for
some time after use.
•Ensure the jar, jar lid and steamer tray are assembled correctly when using the steamer
accessories.
•When I use, do not touch any part of the steamer accessory except its handles.
•Do not use the steamer without the jar lid in place.
•When opening the steamer lid, be careful not to be scalded by escaping hot steam.
•When using any other the heating functions, take care to avoid any injury by escaping hot
steam.
•Ensure that the vent hole in the steamer lid is unblocked during use.
•Take care not to knock the steamer tray off the top of the jar either during or after use.
•Do not reach for an appliance that has fallen into water. Switch ‘OFF’ at the power point and
unplug immediately.
•Do not let the power cord hang over the edge of a table or counter, or touch hot surfaces.
•Do not use appliance if it has been dropped or any part of appliance (including cord or plug)
has been damaged.
•If the supply cord is damaged, it must be replaced by the manufacturer, its service agent or
similarly qualified persons in order to avoid a hazard.
•The use of accessories not intended for use with this appliance may cause injuries to the
user or damage to the appliance.
•Do not install the unit on other appliances, on uneven surfaces or where it could be subject
to: heat sources (e.g., radiators or stoves), direct sunlight, excessive dust or mechanical
vibrations.
•Appliance should not be used outdoors, placed near a hot gas or electrical burner or placed
in a heated oven.
•Do not install near any heat sources such as radiators, heat registers, stoves, or other
apparatus that produce heat.
•Do not operate appliance underneath or near flammable or combustible materials (e.g.,
curtains).
•Any type of servicing, apart from ordinary cleaning, must be carried out by qualified electrical
person only. There are no user serviceable parts in this appliance.
•If this appliance is used by a third party, please supply the instruction manual with it.
•Do not misuse the power cord. Never carry or pull the appliance by the power cord or pull to
disconnect it from the outlet. Instead, grasp the plug body and pull to disconnect.

Page 8 of 44
•Do not use the unit in very hot or humid places, or under direct sunlight.
•It is not recommended to use this appliance with an extension cord or power board.
•Do not place any other appliances on top of the appliance.
•This appliance is designed for domestic use only.
•This product has not been designed for any uses other than those specified in this instruction
manual.
•Contact your local council for proper instructions for disposing of the unused appliance.
•No liability can be accepted for any damage caused by non-compliance with these
instructions or any other improper use or mishandling of appliance.
CAUTION: To prevent damage to the appliance do not use alkaline
cleaning agents when cleaning, use a soft cloth and a mild detergent.
IMPORTANT:
Care is needed when handling the Chopping Blade, emptying the Jar
and especially during cleaning.
Do Not touch the sharp edge of the blades. Only handle the top part
when you assemble, remove and clean the blade.
Misuse of this appliance may result in serious injury.
Only use your appliance for its intended domestic use.
CAUTION:
In order to avoid a hazard due to inadvertent resetting of the thermal
cut-out, this appliance must not be supplied through an external
switching device, such as a timer, or connected to a circuit that is
regularly switched on and off by the utility.
Read and Save These Instructions

Page 9 of 44
2 Components
1
Steamer Lid
7
Kneading Blade
2
Steamer Tray
8
Multifunction Blade
3
Steamer Base
9
Measuring Cup / Lid Plug
4
Strainer / Steamer Basket
10
Jar Lid
5
Butterfly Whisk
11
Jar
6
Spatula
12
Main Body
1
2
3
4
5
6
7
8
9
10
11
12

Page 10 of 44
3 Methods of Safe Installation
Place the appliance on a strong, flat and level surface.
Place your appliance where there is no heat source nearby or direct sunlight.
Splashing water on the appliance may cause a short circuit.
For good ventilation keep enough space between the side walls and your appliance.
Leave at least a 100mm gap between the back and sides of the Appliance and any wall.
Leave ample space above to access the jar lid and steamer.
4 Before First Use
4.1 Unpacking
•Remove all packaging materials and dispose of properly and thoughtfully.
•Before using your appliance and accessories, it is strongly advisable to clean them
thoroughly. Refer to “Cleaning” section for instructions.
5 Assembling Components and Use of Accessories
With the Appliance fully unpacked and placed in a suitable position as described previously,
you are now ready to use your appliance.
5.1 Drive Coupling
If not already fitted to the bottom of the jar, the drive coupling and rubber sealing gasket
must be fitted and secured properly.
