anko 43056125 User manual

Bluetooth Party Speaker
43056125

1 2
1. Important Safety Instructions
Before Use this Speaker
2. Your Party Speaker
Introduction
What's in the box
Overview of the Top control panel
Overview of the Rear panel
Overview of the remote control
3. Get started
Connect power
Prepare the remote control
Turn ON
Charging the internal Battery
Intrenal Battery Level indicator
4. Play
Basic key play operations
Play from USB
5. Listen to radio
Turn to FM radio stations
6. Connect with Bluetooth
7. Connect with Line-in
8.Connect with Wired Microphone/Guitar
9. Production information
Specification
USB play ability information
10. Troubleshooting
11.Warranty
Contents
Warning
CAUTION
RISK OF ELECTRIC
SHOCK DO NOT OPEN
The lighting flash with
arrowhead symbol, with an
equilateral triangle is
intended to alert the user to
the presence of uninsulated
dangerous voltage within
the products enclosure that
may be sufficient magnitude
to constitute a risk of electric
shock to persons.
CAUTION: TO REDUCE THE
RISK OF SHOCK, DO NOT
REMOVE COVER (OR BACK).
NO USER SERICEALBE PARTS
INSIDE REFEER SERVICING TO
QUALIFIED SERVICE
PERSONNEL.
The exclamation point
within an equilateral
triangle is intended alert
the user tithe presence of
important operating and
maintenance (servicing)
instructions in the l
iterature accompanying
the appliance.
Important precautions:
1. The apparatus shall not be exposed to dripping or splashing and that no objects filled with
liquids, suchas vases, shall be placed on the apparatus.
2. Minimum distances 100 cm around the apparatus for sufficient ventilation.
3. The ventilation should not be impeded by covering the ventilation opening swith items,
such as news papers, table-cloths or curtains.
4. No naked flame sources such as lighted candles,should be placed on the apparatus.
5. When the mainsplug or and appliance coupler is used as the disconnect device, the
disconnect device shall remain readily operable.
6.Workingtemperature:-10℃~+45℃.
7.Battery cannot be subjected to high or low extreme temperatures, low air pressure at high
altitude during use, storage or transportation.
8.Replacement of a battery with an incorrect type that can result in an explosion or the
leakage of flammable liquid or gas.
9.Disposal of a battery into fire or a hot oven, or mechanically crushing or cutting of a battery,
that can result in an explosion.
10.Leaving a battery in an extremely high temperature surrounding environment that can
result in an explosion or the leakage of flammable liquid or gas.
11.A battery subjected to extremely low air pressure that may result in an explosion or the
leakage of flammable liquid or gas.
12.The use of apparatus in moderate climates.
13.Attention should be drawn to the environmental aspects of battery disposal.
14.Batteries shall not be exposed to excessive heat such as sunshine, fire or the like.
15.Excessive sound pressure from earphones and headphones can cause hearing loss.
16.The internal battery is non-user replaceable.
17.Do not use this apparatus near the water.

3 4
2.Your Party Speaker
Introduction
With this unit, you can:
l Enjoy audio from USB storage Devices, and other external device;
l Listen to radio stations.
What's in the box
Check and identify the contents of your package:
l Speaker
l Remote control
l User manual
l Line-in/FM Antenna Cable( the same one cable)
lAC Power cable
Overview of the Top control panel
1.Display Window
2.Line-in Input jack
3.Previous button
4.Play/Pause button
5.EQ button
6. Power ON/OFF button
7.Volume/MIC Menu button
8.Next button
9.Mode button
10.Bass button
11.USB Input jack
12.LED ON/OFF button
1
2
3
4
5
6
7
8
9
10
11
12

5 6
1.Guitar Input jack
2.Microphone Input jack
3.Power ON/OFF Button
4.AC Power Input jack
1.Power function key
2.Menu function key
3.Volume+ function key
4.Play/Pause function key
5.Previous function key
6.Volume- function key
7.Channel- function key
8.Mute function key
9.Bass function key
10.Mode function key
11.Next function key
12.Scan function key
13.Channel+ function key
14.EQ funciton key
1
1
2
210
11
12
13
14
3
4
3
4
5
6
7
8
9
Overview of the Rear Panel Overview of the Remote Control

7 8
3. Get started
Caution
Caution
l Use of controls or adjustments or performance of procedures other than herein may
result in hazardous radiation exposure or other unsafe operation.
Always follow the instructions in this chapter in sequence.
Connect power
lRisk of product damage! Ensure that the power supply voltage corresponds to the
voltage printed on back or the underside of the unit.
lRisk of electric shock! When you unplug the AC power cord, always pull the plug
from the socket. Never pull the cord.
Before you connect the AC power cord, make sure that you have completed all other
connections
Connect the power cable to the wall socket:

9 10
3
1
2
Prepare the remote control
To insert the remote control batteries:
1. Open the battery compartment.
2. Insert 2 x AAA batteries with correct polarity (+/-) as indicated. The 2xAAA battery not
include in our products, please purchase from Authorized Seller.
3. Close the battery compartment.
Please Note:
l If you are not going to use the remote for a long time, remove the batteries.
l Do not use old and new or different type of batteries in combination.
Batteries contain chemical substances, so they should be disposed of properly.
Turn On
1. Connect the AC power cable and plug to the wall socket;
2. Press the “POWER” button to o "ON" status to power on the speaker.
The speaker will be powered by AC power and set the power switch on rear panel to ON
position.
3.Press the POWER button on the top panel or on the remote control to turn it into Standby
mode,Press the POWER button on the top panel or on the remote control to turn off the
speaker and get into Standby mode, press for a few seconds again to turn on the speaker.
Caution:
If you do not use this unit for a while, please switch the "POWER" button to "OFF" status,
and disconnect the AC power cable of this unit.
Charging the internal Battery
The speaker comes with a built-in rechargeable battery, follow the below steps to charge it:
1. Connect the power cable and plug to the wall socket on the rear .panel to start charging
2. battery indicator light Turn on the power ON/OFF button on rear and top panel, there is a
on the bottom left corner of the display panel, it will light up and slowly flash, that is being
charge.
3.When the battery indicator light on the top left corner of the display pane light up, the
battery is fully charged, then unplug the power cable to stop charging, both top and
bottom indicator light will turn off automatically.
Intrenal Battery Level indicator
1. When the battery is running out, the battery indicator light on the bottom left corner light
up and quickly flash.
2. During playing, if you hear a “DI” sound from the speaker means the battery is running
out and the speaker will turn off after 1 minute.
3.Please pay attention to the speaker sound, if the sound becomes abnormal, please
charge the internal battery on time to keep the battery life.
Note: please fully charge the product when it is not going to be used for a long time and
charge once a month to keep longer battery life.
4.Play
Basic key play operations
You can control play through following operations.
Key Function
AC Input jack
Insert the Line-in cable to external device.
Insert the USB driver to USB socket to play music.
Press this M button for function mode switching between
Bluetooth/AUX/USB/FM modes.
Press this BASS button for turn on or off the bass strong effect.
Press this LED button for turn on and off, or switch the light
effect.
Insert the 6.35 wired microphone to the MIC jack.
Insert the 6.35 Guitar to the GUITAR jack.
1.Press this previous button for previous track when playcing
music on USB or Bluetooth mode.
2.In FM mode, short press this button to adjust FM frequency
for 0.1MHz, or long press this button to search FM radio
from 108-87.5MHz automatically.
1.Press this PLAY/PAUSE button to play or pause the music
when playcing music on USB or Bluetooth mode.
2.Or press for a few seconds to disconnect the bluetooth if
speaker at Bluetooth mode.
Press this EQ button to switch the different music effect.
Note: It cannot switch if the BASS is on.
Press the POWER button to turn off the speaker and get into
Standby mode, press for a few seconds again to turn on the
speaker.
1.Press this previous button for previous track when playing
music on USB or Bluetootth mode.
2.In FM mode, short press this button to adjust FM frequency
for 0.1MHz, or long press this button to search FM radio
from 87.5-108MHz automatically.
1.Turn this VOLUME knob for volume increase or decrease
when playing music, the display will show from U 00 to
U 40 .
2.Press this VOLUME knob for one time to turn to the echo
volume level of microphone if using wired microphone,
the display will show “ E ”, then turn the knob to adjust the
sound volume of microphone echo.
3.Press this VOLUME knob for twice to turn to the
volume level of microphone if using wired microphone,
the display will show “ C ”, then turn the knob to adjust the
sound volume of microphone.
4.Press this VOLUME knob for twice to turn to the volume
level of guitar if using wired guitar, the display will show
“ C ”, then turn the knob to adjust the sound volume of guitar.

11 12
Play from USB
Make sure that the USB storage device containers playable audio in supported MP3
format.
1. Press or key to select
2. Press key to play or pause
Important:
USB socket is only for music playing, not support charging.
The MAX memory size of USB:32Gb
5.Listen to radio
Note
Make sure that you have connected and fully extended the supplied FM antenna.
1. Insert the Line-in/ FM Antenna Cable to the Line-in jack
2. Press the M/ MODE button on the Top Control panel or on the remote control
to switch to FM mode
3.Short press button to adjust the FM frquency for 0.1MHz, or long
press to search the FM radio automatically from 108~87.5MHz.
4.Short press button to adjust the FM frquency for 0.1MHz, or long
press to search the FM radio automatically from 87.5~108MHz.
5.Presss SCAN key on the remote control to search FM radio stations automatically.
6.Press CH- / CH+ key on the remote control to select the previous or next
radio station.
The FM Antenna cable is the same as Line-in cable.
Turn on FM radio stations
USB memory device should be formated as FAT32.

13 14
6.Connect with Bluetooth
1. Press the M/MODE button on the Top Control panel or on the remote control to switch
to the BLUETOOTH CONNECT mode, ( ) will be displayed on the screen.
2. Open the Bluetooth on the external device (must have Bluetooth function), and the
name “43056125” will show on the device, please try to connect it.
3. Once connected, you can hear a small sound from the speaker.
4. You can use the or key on the Top Control panel to control the tracks of the
external device.
5.Press button on the top control panel to disconnect the bluetooth.(This on remote
control not work for bluetooth disconnect function.)
Note: no password needed for connecting.
7.Connect with Line-in
1.Press the M/MODE button on the Top Control panel or on the remote control to
switch to the Line-in mode, (LINE) will be displayed on the screen.
2.Connect an external audio source use a supplied line-in cable.
3.Once connected,turn on your external device music
Caution: Please trun off party speaker before connect Line-in cable
in order to avoiding unexpected noise.
Insert 6.35mm wired microphone to play with microphone.
Insert 6.35mm wired guitar to play with guitar.
When playing with the wired microphone/guitar, please press this knob to adjust the sound
volume level of microphone/guitar.
8.Connect with Wired Microphone/Guitar
Microphone:
1.Turn this VOLUME knob for volume increase or decrease when playing music, the display
will show " U ".
2.Press this VOLUME knob for one time to turn to the microphone echo volume adjust mode,
the display will show " E ", then turn the knob to increase or descrease the microphone
echo volume if using wired microphone..
3.Press this VOLUME knob for twice to turn to the microphone volume adjust mode, the
display will show " C ", then turn the knob to increase or descrease the microphone volume
if using wired microphone.
Guitar:
If using wired guitar, the volume instruction the same as above 3 of microphone.
Important Notes
While using the microphone, avoid being put the microphone opposite the bass of Speaker,
as they may have Whistler Noisy.
To get the best singing performance, keep the micro phone within 5-15cm from your mouth
and at a 45 degree angle.
Caution: Please do not put the microphone directly face to the speaker, it may damage the
speaker.

15 16
9.Product information
Specifications
Amplifier
Output power
Input Sensitivity
FM
FM range
Speaker
Treble Speaker
Bass Speaker
General information
AC Power
Battery
60W
≥500mV
87.5-108MHZ
2 Inch
5.25 Inch
Rechargeable battery
USB play ability information
Compatible USB storage devices:
l USB flash memory (USB 2.0 or USB 1.1)
l USB flash players(USB 2.0 or USB 1.1)
l Memory cards (requires an additional card reader to work with this apparatus)
Supported for formats:
l USB or memory file format FAT32
l MP3 bitrate (data rate):32-320Kbps and variable bitrate
l Directory nesting up to a maximum of 8 levels
l Number of albums/folders:maximum 99
l Number of tracks/titles:maximum 999
l File name in Unicode UTF8 (maximum length:32 bytes)
Unsupported formats:
l Empty albums: an empty album is an album that does not contain MP3.
l Unsupported the file formats are skipped. For example, Word documents (.doc) or
MP3 files with extension .dlf are ignored and don't play.
10.Troubleshooting
Warning
Never remove the casing of this speaker.
If you encounter problems when using this speaker,check the following points before
requesting service.
No power
l Ensure that the AC power plug of the speaker is connected properly.
l Ensure that there is power at the AC outlet.
No sound or poor sound
l Adjust the volume.
l Disconnect the headphones.
l Check that the speakers are connected correctly.
l Check if the stripped speaker wires are clamped.
No response from the speaker
l Disconnect and reconnect the AC power plug, then turn on the speaker again.
Remote control does not work
l Before you press any function button, first select the correct source with the remote
control instead of the main unit.
l Reduce the distance between the remote control and the unit.
l Insert the battery with its polarities(+/- signs) aligned as indicated.
l Replace the battery.
l Aim the remote control directly at the sensor on the front of the speaker.
USB device not supported
l The USB device is incompatible with the unit. Try another one.
l The USB device is incompatible with the speaker or the USB damaged.
Poor radio reception
l Increase the distance between the speaker and your TV.
l Full extend the FM antenna.
l Put the speaker at a open area to search radio.
Bluetooth can not search or connect
l If other devices are connected to the machine, please disconnect other Bluetooth
devices and use the new device to search and connect again.
l Turn off the Bluetooth of your device , then turn on your device Bluetooth again,
search and connect. Or turn off the speaker and turn on again and switch to
Bluetooth mode.
AC220-240V~ 50Hz

17
Warranty
