Anolis ArcSource 140 COB Recessed User manual

1
User instructions
ArcSource 140 COB Recessed US
The lighting unit generates light by means of high power LED multichip. The product was designed for
installation to a lower ceiling and is intended for indoor use only.
1. Attention
Do not install the lighting unit near high inammable liquids or materials.
Do not allow anything to rest on the lighting unit.
Do not use the lighting unit near high humidity or water or expose to the rain.
Do not install the lighting unit near the naked ames.
Do not install the lighting unit in dirty,dusty or badly ventilated location.
Su󰀩cient air accessing to the housing of the unit has to be ensured,
there must not be any heat or anti-noise insulation around 0.6m x 0.6m
around the unit (non-IC rated xture).
CAUTION!
Avoid looking directly into the LED light beam at close range!
2. Installation
1. Prepare a circular opening in the lower ceiling (1) as shown at the picture below.
2. Insert the ArcSource 140 COB Recessed into the opening. Both adjustable rests (3) must be turned at
bracket (4) position to pass them throw the aperture.

2
3. Turn adjustable rests (3) towards the lower ceiling (1).
4. Pass a cross-point screwdriver through aperture (2) and a screw (clockwise) the adjustable rest (3) until it
rmly supports against the lower ceiling. Repeat this adjustment for second adjustable rest. Now the lower
ceiling (1) is "squeezed" between adjustable rest (3) and frame (5) of the ArcSource 140 Recessed COB.
5. The light head can be tilted 15° from a vertical axis.
6. Connect cables to the ArcSource 140 COB Recessed.
3. ArcSource 140 COB Recessed connection
To connect needed cables to the xture, unscrew three screws (6) from the plastic cover (7).

3
Connect the cable to the suitable connection block (8). To pass the cable through the cable gland (9), make an
opening in the blank cable gland (9).
DIP switch
DALI DMX Power
4. DMX and DALI address setting and control
The xture can be controlled by one of the following method: DMX 512
DALI
ArcPixel Power US
(or ArcZone DRS Pixel US)
The DIP switch, located next to the connection blocks, allows to set a DMX address and also allows to switch
the xture to the update mode in case of software update.
DMX control
DIP 10 - ON=100W, OFF=140W
DIP 11 - ON=test (full light output)
DIP 12 - change from OFF to ON position switches the xture to the update mode.
DMX control
The DMX start address, is the rst channel used to receive instructions from the DMX controller. The address
may be any channel from 1 to 512.
Example of DMX addresses:
55
101

6. Di󰀨user and Anti Glare Louvre installation
1. Insert the di󰀨user (1) on the front transparent cover of the xture .
2. Snap the di󰀨user holder (2) in the housing of the front transparent cover.
3. Snap the Anti Glare Louvre (3) in the di󰀨user holder (2).
Design of the Anti Glare Louvre and di󰀨user holder allows another installation combinations:
Anti Glare Louvre only, Anti Glare Louvre+di󰀨user, di󰀨user holder+di󰀨user.
7. Technical specications
Light source: COB multichip
Available colour temperature: 2700K, 3000K, 5800K
Led life expectancy: 60,000 hours
Optical system available: 23°,35°
Input voltage: 48V DC
Max. power consumption: 100W
Supported protocols: USITT DMX 512, DALI
Control Channels: 1
Operating ambient temp. range: -20°C / +45°C (-4°F / +113°F)
Operating temperature: 56°C @ Ambient +45°C (+133°F @ Ambient +113°F )
Tilt adjustment of the light head: 15° (from vertical axis)
Weight: 4 kg (8.8 lb) including mounting trim kit
Mounting method: mounting trim kit (Included)
Cooling: axial fan
Protection against overheating: yes, temperature feedback
Ingress protection: IP 20
IC rating: non-IC rated
Connection
Power connection: connection block Degson DG 306-5
DMX and DALI connection: connection block Sauro MTB 028
Compatible drivers: ArcPixel Power US (only one ArcSource 140 COB
Recessed US per ArcDot output only)
ArcZone DRS Pixel US (only one ArcSource 140 COB Recessed US
per ArcZone DRS Pixel US)
Diameter of mounting opening in lower ceiling: 230mm +2/-0mm
8. DMX chart
Version 1.1
Channel Value Function Type of control
10-255
Dimmer (8 bit)
Dimmer intensity from 0% to 100% proportional

9. Dimensions
(All dimensions in inch)
10. Optional Accessories
(P/N 10980299) Anti Glare Louvre AS 140 COB black
(P/N 10980300) Anti Glare Louvre AS 140 COB white
(P/N 10980301) Anti Glare Louvre AS 140 COB silver
(P/N 10980302) Di󰀨user Holder AS 140 COB black
(P/N 10980303) Di󰀨user Holder AS 140 COB white
(P/N 10980304) Di󰀨user Holder AS 140 COB silver
(P/N 10980305) Di󰀨user 28° for AS 140 COB 23deg
(P/N 10980306) Di󰀨user 40° for AS 140 COB 23deg
(P/N 10980307) Di󰀨user 50° for AS 140 COB 23deg
11. Maintenance
Keep the xture clean, especially di󰀨user and the ribbed housing.

6
Version 1.9 US
June 16, 2017
Specications are subject to change without notice.
12. Sotware update
The following are required in order to update software:
- PC running Windows /XP/7/8/10 or Linux
- Software Uploader
- Robe Universal Interface
To update software in the xture:
I. Installation of the Software Uploader.
1.The Software Uploader program is available from the Anolis web site at WWW.anolis.cz.
2. Download the software to your PC.
II.Fixture software updating.
1.Connect the Robe Universal Interface to the PC and to the DMX input of the xture.
2. Switch the xture to the update mode by moving the DIP 12 from the OFF position to the ON position.
Note: The Dip 12 must go from OFF to ON position to switch the xture to the update mode.
3. Run the Software Uploader program. Select Robe Universal Interface from the COM ports and then
click on the Connect button.
4. If the connection is OK, click on the “Start Uploading button“ to start uploading. It will take several
minutes to perform software update.
If the option "Incremental Update" is not checked, all processors will be updated (including
processors with the same software version).
If you wish to update only later version of processors, check the “Incremental Update" box.
Avoid interrupting the process. Update status is displayed in the Info Box window.
When the update is nished, the line with the text “The xture is successfully updated“ will appear in
this window.
