Anolis ArcSource Outdoor 16 MC Pixel User manual

1
User instructions
ArcSource Outdoor 16 MC Pixel
The Anolis ArcSource Outdoor 16 MC Pixel is a multi-purpose, high-intensity RGBW LED unit for
generating a wide variety of e󰀨ects without the limitations associated with a solid xture unit.The unit´s high
light output can be pixel mapped and therefore can be controlled and used for large scale matrix applications,
as well as used for individual illuminating needs.
.
1.Attention
Consider the respective national norms during installation of the unit!
Do not install the unit near an open ame.
Avoid using the unit in locations subject to possible impacts.
Do not attempt to dismantle or modify the unit.
Do not install the module in badly ventilated location
Avoid looking directly into the LED light beam at close range.
2.Installation
The ArcSource Outdoor 16 MC Pixel unit should be connected to the ArcPixel Power-CE (ArcPixel Power US)
or ArcZone DRS Pixel. See their user manuals for full details of mains power requirements and DMX (ArtNet)
operation.
Wiring of the Chogori CGRBB-03BMMA-SL8001 (male)
1 GND (blue wire)
2 +48V (red wire)
3 Data (orange wire)
The ArcSource Outdoor 16 MC Pixel can be arranged in any position orientation. LED module body is mounted
on a steel “U” bracket (1) for tilt adjustment, after adjusting desired inclination, secure the tilt lock (2) by means
of the Allen key 6. For fastening the unit on the wall (truss etc) serves 3 apertures in the U-bracket

2
Top hat (half top hat) installation
1. Unscrew the four socket head screws 6x10 (1) in the ArcSource Outdoor 16 MC pixel housing and slide
the top hat (2) onto ArcSource outdoor 16 MC Pixel.
2. Screw the holder (3) to the top hat (2) by means of the two screws (4) with tooth washers
3. Secure the top hat on the xture with four socket head screws 6x10 (1) .

3
Examples of installation:
1. Ethernet connection between the Robe Media Server and the ArcPixel Power-CE
All LED outputs 1-4 may be used.
Number of needed ferrites:
- at each ArcDot output: 1
- total for installation: 4
Max. number of connected ArcSource Outdoor 16 MC Pixels to the one LED output of the ArcPixel Power-CE
is 3.

4
2. DMX connection between the Robe Media Server and the ArcPixel Power-CE
LED outputs 1-3 may be used only.
Number of needed ferrites:
- at each ArcDot output: 1
- total for installation: 3
Max. number of connected ArcSource Outdoor 16 MC Pixels to the one LED output of the ArcPixel Power-CE is 3.

5
3. Ethernet connection between the Robe Media Server and the ArcPixel Power-US
All LED outputs 1-4 may be used.
Max. number of connected ArcSource Outdoor 16 MC Pixels to the one LED output of the ArcPixel Power-US is 2.

6
4. DMX connection between the Robe Media Server and the ArcPixel Power-US
LED outputs 1-3 may be used only.
Max. number of connected ArcSource Outdoor 16 MC Pixels to the one LED output of the ArcPixel Power-US is 2.

7
4. Technical specications
Max input voltage : 50V DC max.
Maximum power consumption: 38 Watts
Available colour variants: RGBW, PW,SW, RGBA
LED device: 4x high power multichip LEDs
Beam angle: 7°, 24°, 34°, 42°x7°, 7°x42°
LED life expectancy: minimum 60,000 hours
Operating ambient temp. range: -20°C/+45°C (-4F/+113F)
Operating temperature: 70°C @ Ambient +45°C (158°F @ Ambient +113°F)
Compatible power supply : ArcPixel Power-CE, ArcPixel Power-US, ArcZone DRS Pixel
Cooling system: convection
Protection factor (CE): IP 67
Protection factor (US): Suitable for wet locations
IK rating: IK06
Construction:
Body+ "U" bracket High-pressure die cast aluminium
transparent cover tempered glass
Weight: 2.8 kg
Connection:
plug: Chogori CGRBB-03BMMA-SL8001 (male)
cable: Li9Y11Y, 2xAWG16+1xAWG 20 (length according
requirement)
5. Dimensions (mm)
ArcSource Outdoor 16 MC Pixel

8
Top hat
Half top hat
ArcSource Outdoor 16 MC Pixel with oor stand

9
6. Optional Accessories
(P/N 10980290)Top Hat ArcSource Outdoor 16 MC
(P/N 10980291) Half Top Hat ArcSource Outdoor 16 MC
(P/N 1098 0279) Floor stand for ArcSource Outdoor 16 MC
P/N 13051564) T-connector Chogori T-CGRBA-030303FFM-TS , IP 67
(P/N 1305 2023) Connection cable ArcDot, 2m *
(P/N 1305 2024) Connection cable ArcDot, 4m*
(P/N 1006 2330) Active Terminator for ArcDot*
(P/N 1006 2331 Passive Terminator for ArcDot*
(P/N 1305 1703) Ferrite GTFC 16-8-16 (for ArcDot) *
* Quantity depends on size of installation (see the ArcPixel Power-CE user manual)
Version 1.2
January 9, 2018
Specications are subject to change without notice
Made in CZECH REPUBLIC by ROBE LIGHTING s.r.o. Palackeho 416/20 CZ 75701 Valasske Mezirici
