Anova H2200 Manual

1
Instructions - User Manual
PRESSURE CLEANER
H2200
Milesur, SL.
Rúa Eduardo Pondal, nº 23 - Pol. Ind. Sigüeiro
15688 - Oroso - A Coruña 981 696465 www.millasur.com
EN

2
ANOVA thanks you for choosing one of our products and guarantees
the assistance and cooperation that has always distinguished our brand
over time.
This machine is designed to last for many years and to be of great use
if used in accordance with the instructions contained in the user
manual. We therefore recommend that you read this instruction manual
carefully and follow all our recommendations.
For more information or doubts, you can contact us through our web
supports such as www.anova.es
INFORMATION ABOUT THIS MANUAL
Pay attention to the information provided in this manual and on the
product for your safety and that of others.
•This manual contains instructions for use and maintenance.
•Take this manual with you when you go to work with the machine.
•The contents are correct at the time of printing.
•The rights to make changes at any time are reserved without
affecting our legal responsibilities.
•This manual is considered an integral part of the product and must
remain with it in case of loan or resale.
•Ask your dealer for a new manual in case of loss or damage.
READ THIS MANUAL CAREFULLY BEFORE USING THE MACHINE
To ensure that your machine provides the best results, please
read the usage and safety regulations carefully before using it.
OTHER WARNINGS:
Incorrect use could cause damage to the machine or other objects.
The adaptation of the machine to new technical requirements could
cause differences between the content of this manual and the
purchased product.
Read and follow all instructions in this manual. Failure to follow these
instructions could result in personal injury

3
INDEX CONTENT
1. SAFETY RULES AND PRECAUTIONS
2. FIELD OF APPLICATION
3. TECHNICAL DATA
4. OPERATING CHARACTERISTICS OF THE PUMP
5. INSTRUCTIONS FOR USE
6. CHANGE PUMP OIL
7. TROUBLESHOOTING
8. MAINTENANCE
9. STORAGE
10. ENVIRONMENT
11. WARRANTY CONDITIONS
12. EXPLODED
13. CE CERTIFICATE

4
1. SAFETY RULES AND PRECAUTIONS
Keep your owner's manual so you can refer to it at any time. This owner's manual is considered
a permanent part of the pressure washer and must remain with the product.
Your safety and the safety of others are very important. We have provided important safety
precautions in this manual and on the machine. Please read these precautions carefully.
Please read this manual carefully and pay particular attention to these symbols and the
instructions that follow:
Danger: Indicates that serious injury or death will result if instructions are not followed
Warning: Indicates a strong possibility of serious injury or death if instructions are not
followed.
Caution: Indicates the possibility of minor injury or a result if instructions are not followed.
Notice: Indicates that equipment or property damage may occur if instructions are not
followed
Note: Provides useful information.
If a problem arises or if you have any questions about your high pressure washer, please
consult your product dealer.
This book contains important information for the safe operation of this unit. Read and
understand all warnings before starting work.
Hazard symbols and meanings
Short circuit
Burst
Electric
shock
Injury
Poisoning
Wear protective
clothing and glasses
Safety regulations to be taken into account
Do not use the product with flammable or toxic liquids, or products that are not
compatible with the correct operation of the cleaner.
Do not use the product within the reach of people unless they are wearing
protective clothing and safety glasses.
Caveat
Do not use the product if a power cord or important parts of the product are
damaged, e.g. Eg safety devices, high pressure hoses, trigger gun.
Caveat
Do not direct the water jet towards people or animals, electrical equipment or
the machine itself.
Do not use the product outdoors in case of rain.
Caveat
Do not allow children or unprofessionals to use the product.
Do not touch the plug and/or socket with wet hands.
Do not use the product if the power cord is damaged.
Do not use the product if the high pressure hose is damaged.
Caveat
Do not squeeze the trigger in the operating position.
Caveat
Do not alter the calibration of the safety valve.
Caveat
Do not alter the original diameter of the spray tip.
Caveat
Do not leave the product unattended.
Caveat
Do not move the product by pulling on the power cord.
Caveat
All electrical conductors must be protected against jet water
Caveat
The product must only be connected to a properly grounded power supply.

5
The use of a safety residual current circuit breaker (RCCB) will provide
additional protection for the operator (30mA).
The high pressure jet can cause loose particles to be propelled at high speed,
so wear protective clothing and goggles.
Caveat
Before carrying out any work on the vacuum cleaner, remove the plug from
the outlet.
Caveat
Before pulling the trigger, grip the squirt gun firmly to counter recoil.
Caveat
Maintenance and/or repair of electrical components must be carried out by
qualified personnel.
Caveat
Release residual pressure before disconnecting the high pressure hose.
Caveat
Before using the product, check each time that the screws are well tightened
and that there are no broken or worn parts.
Use only detergents that do not corrode the lining materials of the high
pressure hose / pump / electrical cable. Do not use bleach, alcohol, gasoline,
hydrochloric acid, etc. as a solvent which is easy to burn and erode.
Danger
The product operates at fluid pressures and velocities high enough to
penetrate human and animal flesh, which could result in amputation or other
serious injury. Do not treat fluid injection as a simple cut, see a doctor
immediately.
Caution
Use only chemicals designed for pressure washers or mild soaps and
chemicals compatible with aluminum and brass pressure washer parts.
Caution
The machine uses normal temperature and the temperature for the inlet water
should not exceed 50ºC. The machine cannot be used with the temperature of
0ºC or below 0ºC.
Symbol
Indicator
This manual should be read before starting the installation of the unit.
High pressure water jets are potentially dangerous if used incorrectly. In
particular, do not direct the water jet towards people or animals,
electrical equipment or the machine itself.
2. FIELD OF APPLICATION
•Maintain and wash diversified vehicles, project machinery, architectural machinery and
agricultural machinery.
•Maintain and wash military vehicles, tanks, boats, planes and other military machinery.
•Wash and disinfect port containers located by divers.
•Washing sanitation recovery and disinfection in livestock.
•Daily washing of the glass of the building and the exterior wall.
•Wash and disinfect the environment of the town square, the street, hospitals, hotels,
restaurants and patios.
•Wash and disinfect the sanitary station, clean points and garbage transfer stations.
3. TECHNICAL DATA
Model
H2200
pump model
3WZ-18070B
Max. Pressure (PSI/bar)
1160/80
Flow (GPM/L/min)
3.38/12.8

6
RPM
2900
Power
2.2
Gross weight (kg)
28.5
Dimension (cm)
58x42x39.5
1. gun hook
2. hose hook
3. Handlebar
4. adjustable regulator
5. Bomb
6. Chassis
7. Entry
8. Departure
9. Electric motor
10.rubber wheel
11.switch
12.Power cord
13.high pressure hose
14.Spear
15.Gun
4. OPERATING CHARACTERISTICS OF THE PUMP
Please check each part according to the packing list when you open the box, to check whether
the parts are complete and in good condition, and keep the attachment and documents in good
condition.
1. CHANGE THE OIL INLET PLUG
Caution: The red cap on the pump is specially designed for transportation; Before using the
unit, replace the red plug with the yellow plug or the brass plug in the parts pack.
2. PRESSURE REGULATOR
The pressure setting is preset at the factory for optimal pressure and cleaning. If it is necessary
to reduce the pressure, the following methods can be used:
•Move away from the surface to be cleaned. The further away the user is, the lower the
pressure on the surface to be cleaned.
Warning: Do not attempt to increase pump pressure, a pressure setting higher than the
red cap
yellow cap
copper cap

7
factory pressure setting may damage the pump.
•Change to the 40º white nozzle. This nozzle provides a less powerful stream of water
and a wider spray pattern.
•Adjust the pump pressure regulator. Turn the pressure regulator knob counterclockwise
to lower the pressure. Once you have finished using your pressure washer, return the
pressure regulator to its original position by turning it clockwise.
•Do not try to turn the pressure regulator knob beyond the built-in stop line, otherwise the
pump will be damaged.
3. NOZZLE TYPE
Your unit is equipped with four spray nozzles. Each nozzle is color coded and offers a specific
spray pattern for a particular cleaning purpose.
0° 15° 25° 40°
chemical
nozzle
Applications
Caution: The high pressure spray from your unit can damage surfaces such as wood, glass,
automotive paint, automotive trim and trim, and delicate objects such as flowers and shrubs.
Before spraying, check the item to be cleaned to make sure it is strong enough to resist damage
from the force of the spray.
4. CHANGE OF NOZZLES
Caution: Do not attempt to change nozzles while unit is running. Shut off motor or gun before
changing tip.
•Pull back on the quick fix and insert the nozzle.
•Release the quick-lock nipple and twist to make sure it is secure in the quick-
lock socket.
Warning: Risk of injury. Make sure the nozzle is fully inserted into the quick-
lock socket before triggering the gun.
5. CLEANING NOZZLES
If the nozzle is clogged with materials such as dirt, excessive pressure can develop. If the
nozzle becomes partially clogged or restricted, the pump pressure will vibrate. Clean the nozzle
immediately using the supplied nozzle kit and following the instructions:
•Turn unit off and shut off water supply.
•Squeeze gun trigger to relieve water pressure.
•Disconnect the lance from the gun.
•Remove the nozzle from the lance. Remove any clogs with the provided nozzle cleaning
tool and rinse with clean water.
•Direct the water supply at the end of the spray wand to remove particles for 30 seconds.
•Reassemble the nozzle to the lance, making sure the attachment is secure.
•Reconnect the lance to the gun and turn on the water supply.
•Turn unit on and place lance on high pressure setting to test.
HOW TO USE CHEMICALS OR DETERGENTS
Warning: Application of chemicals or detergents in a low pressure state.
Caution: Use only chemicals or detergents designed for pressure washing or mild soaps.

8
To apply chemicals or detergents:
•The unit can suck detergents and other chemicals from a separate tank.
•Put the chemical or detergents in the separate tank.
Caution: Chemicals or detergents too viscous to be sucked up. Add the appropriate
water.
•Select the chemical nozzle (black). Now you are ready to enjoy your work.
After using chemicals
•Put the clean water into the separate tank and draw it through the chemical injection
system to thoroughly flush the system. If chemicals leak into the pump, the pump may be
damaged.
•Pumps darkened by chemicals will not be covered under warranty.
Warning: Chemicals or detergents will not siphon when the lance is on the high pressure
setting.
5. INSTRUCTIONS FOR USE
1. CHECK BEFORE OPERATION
•Check if all the nuts and bolts are tight enough and check if the power supply and water
can reach the flow rate demand of the machine.
•Checking the water filter: It is important to check the water filter before using the
machine.
Caution: A well cleaned filter means good performance and long life for your machine.
•Connection to water supply: Connect the water supply to the inlet port using a reinforced
hose.
Caution: The machine does not have a flow switch, the water source must provide 15L
per minute.
The inlet water temperature must not exceed 50°C
•Attach wand to gun: tighten securely.
•High pressure hose connection: insert the quick connect plug of the high pressure hose
into the water outlet, and the other side should be tightened with the trigger of the gun.
•Connection to the electrical supply:
oMake sure that the mains voltage is the same as that shown on the identification
label of the machine.
oWarning: Make sure that the plug complies with local regulations and that it is
provided with an earth connection.
oWarning: The outlet must be protected by a residual circuit breaker with a
sensitivity of less than 30mA.
oDo not connect other products to the same outlet.
oCaution: Insert the plug after checking the switch of the machine in the OFF
position.
2. MACHINE STARTUP
•Supply the water, then open the gun trigger.
•Turn on the unit.
•Warning: In case of power failure during operation, please turn off the unit for safety
reasons.
•Hold the gun in the open position for a few seconds to drain the air from the hose.
•At this point set the machine to your pressure requirements and you are ready to enjoy
your work.
•During washing, it is better not to exceed the working pressure, for any special demands,
you can also adjust the pressure as high as the maximum pressure, but the pressure
adjustment range should be under the spraying situation.
•During washing, the spray head should not be far from the dirty surface.

9
Warning: Do not use the machine when there are people and/or within reach of the jet.
•Stop the gun after finishing flushing, and then turn off the motor (no more than 2
minutes), because the discharge valve is still moving after the gun is stopped, the water
will flow in circles in the pump, which will cause May the water get hot and damage the
seal ring or other accessories if it spends a long time.
•During operation, it is normal for there to be a little water leakage from the pump, which
will not affect the use of the machine.
•Safety valve: The safety valve also functions as a pressure relief valve. When the gun
trigger is released, the safety valve opens and water recirculates through the pump inlet.
3. STOP THE MACHINE
•When you finish washing, turn off the unit.
•Hold the gun in the open position for a few seconds to drain the water from the hose.
6. CHANGE PUMP OIL
•The oil level should be checked periodically.
•The most important thing is that the oil should be changed after the first 50 hours of work
and successively every 100 hours.
•In any case, we suggest changing the oil at least once a year.
Oil type: SAE15W40 or new SAE30.
Oil capacity (ml): 470±5
1. How to change the pump oil:
To completely release the used oil from the pump through the oil outlet plug, reinstall the oil
outlet plug and let the clean kerosene into the crankcase, the kerosene level should be slightly
above the center line of the oil mirror.
Then run the unit without charging for about 10-15 seconds, stop and release all the kerosene.
Then apply new SAE15W40 or SAE30 oil. The oil level should be slightly above the red mark on
the oil mirror.
Oil inlet plug
level viewer
Oil outlet plug

10
7. TROUBLESHOOTING
Problem
Possible cause
Solution
The pump works, but the
pressure does not reach the
nominal values
pump sucking air
Check that hoses and fittings are
airtight
Worn or dirty valves
Check, clean or replace
Worn discharge valve packing
check and replace
Wrong or worn nozzle
check and replace
Worn piston packing
check and replace
dirty filter
check and clean
fluctuating pressure
Worn, dirty or stuck valves
Check, clean or replace
pump sucking air
Check that hoses and
accessories are tight.
Worn piston packing
check and replace
dirty filter
check and clean
Pressure drops after a
period of normal use
worn nozzle
check and replace
Worn, dirty or stuck valves
Check, clean or replace
Worn discharge valve packing
Check, clean or replace
Worn piston packing
check and replace
dirty filter
check and clean
loud pump
pump sucking air
Check that hoses and
accessories are tight.
Worn, dirty or stuck valves
Check, clean or replace
worn bearings
Check and replace if
necessary
Hot water
reduce the temperature
dirty filter
check and clean
water pressure in oil
High humidity in the air
Check and change oil twice
as often
Worn piston packing and oil
seal
check and replace
Water leaking from under
the pump
piston packing
check and replace
Worn retainer or piston guide
toe o-ring
check and replace
oil drip
Worn oil seal
check and replace
Engine won't start when
turned on
The plug is not well connected
or lack of power
Check the plug, cable and
switch
When I turn on the unit, the
motor buzzes but does not
work
The voltage of the converged
network is insufficient, lower
than the minimum required
Check that the mains power
supply is adequate
Convergence pump is stuck
or frozen Incorrect extension
cord
Follow the precautions in the
manual
engine stops Thermal overload tripped due
to overheating
Check that the mains voltage
corresponds to the
specifications: wait a few
minutes before turning the
unit on again

11
8. MAINTENANCE
If the machine is not going to be used for a long time, you need to drain the water from the
machine, the way to do this is to disconnect the water inlet hose, run the machine without water
supply for about half a minute, and open the gun to drain the remaining water inside the
machine.
•The user should frequently clean the filter to prevent the pressure from being insufficient
due to the clogging of the strainer.
•If the electrical cable is damaged, only professionals are authorized to change it.
•Precautions in the case of storage and / or freezing:
oIf the unit is going to be stored in a place where there is a risk of freezing, or if it is
going to remain unused for more than three months, we recommend putting some
antifreeze in the pump (a normal antifreeze like the one used in your vehicle is
sufficient). ). In any case, to avoid any risk, we suggest that you place the unit in a
warm room for a few minutes before using it.
oProlonged periods of disuse can lead to the formation of lime deposits. Working
through the hole in the rear, pry the driver off the motor several times with a
screwdriver. Then remove the screwdriver and continue with the reset operations.
9. STORAGE
•Store idle power tools in a place that is inaccessible to children and secure in a way that
will not endanger anyone.
•The machine out of use must be stored clean, on a flat surface.
•Store the machine in a place where the temperature range is not lower than 0ºC and not
higher than 45ºC.
•Unplug the plug from the power source before storing this machine, completely drain the
water from the machine's internal circuits, clean all parts, and store the machine in a safe
and dry place.
•You must also drain the water from the hose, gun and lances.
•Clean the detergent tank before storing the machine.
•Before storing the machine, always respect the points in the maintenance chapter.
10. ENVIRONMENT
Please dispose of your product in an ecological way. We must not dispose of
machines together with household waste. Its plastic and metal components
can be sorted according to their nature and recycled. The materials used to
pack this machine are recyclable. Please do not dispose of the packaging in
household waste. Please dispose of these packages at an official waste
collection point.
11. WARRANTY CONDITIONS
WARRANTY PERIOD
The warranty period under the terms described below is 2 years from the date of purchase, in
parts and labor, against manufacturing and material defects.
EXCLUSIONS
The guarantee does not cover in any case:
•Natural wear and tear.
•Misuse, negligence, careless operation or lack of maintenance.
•Defects caused by incorrect use, damage caused due to manipulations carried out by

12
personnel not authorized by Anova or use of non-original spare parts.
APP
•The guarantee ensures service coverage in all applicable cases, although the machine
must be accompanied by its respective purchase invoice and be managed through an
authorized Anova center.
ATTENTION!
TO ENSURE MAXIMUM OPERATION AND SAFETY, READ THE
INSTRUCTION BOOK CAREFULLY BEFORE USE.

13
12. EXPLODED

14
13. CE CERTIFICATE
DECLARATION OF CONFORMITY (CE)
DISTRIBUTION COMPANY
MILLASUR, SL
RUA EDUARDO PONDAL, Nº 23 PISIGÜEIRO
15688 OROSO - A CORUÑA
SPAIN
EC DECLARATION OF CONFORMITY
In compliance with the different CE directives, it is hereby confirmed that, due to
its design and construction, and according to the CE mark printed by the manufacturer
on it, the machine identified in this document complies with the relevant and
fundamental health and safety requirements. of the aforementioned EC directives. This
declaration validates the product to display the CE symbol.
In the event that the machine is modified and this modification is not approved by
the manufacturer and communicated to the distributor, this declaration will lose its value
and validity.
Name of the machine: PRESSURE CLEANER
Model: H2200
Recognized and approved standard to which it conforms:
Directive 2006/42/EC 2014/30/EU
Tested according to regulations:
EN 60335-1:2012+A11
EN 60335-2-79:2012
EN 62233:2008
Test reports:
14717780 001 50106846 001
Company seal
09/20/2021
