ANSMANN POWERLIGHT 5.1 User manual

POWERLIGHT 5.1
D  f  i  
s      

4
8

GB POWERLIGHT PROFESSIONAL SPOTLIGHT
PLEASE READ THE INSTRUCTIONS BEFORE USE!
TECHNICAL DATA
> Powerlight Specification:
Main spotlight: Xenon, 6.5V, 5W
Secondary light: Luxeon LED
> Rechargeable Battery: Gel lead-acid 6 V / 4.5Ah, rechargeable, maintenance-free
> Charging time: max. 4.5h
> Battery life:
Main lamp (Xenon) > 5h, then automatic switch-over to
Secondary light (Luxeon LED) > 1h after switch-over
Secondary light (Luxeon LED) Continuous approx. 20h
Secondary light (Luxeon LED) Flashing approx. 40h
> Protection class II
> Protection type: IP65
> Operating /storage temperature: -20°C to +50°C
CHARGING
PLEASE NOTE:
> It is important to ensure that the car cigar-lighter is still live even when the ignition
key is removed from the ignition switch. If this is not the case, the battery will be
discharged.
> Charge the Powerlight fully before first using it.
> Charge the Powerlight fully before it is to be stored for an extended period.
> Charging options:
Mains charger: 100V - 240V
Motor vehicle charger: 12V / 24V
> The LED will light YELLOW to indicate that the Powerlight is being charged.
The LED changes to GREEN as soon as the battery is fully charged.
There is in parallel a battery capacity display using five LEDs.
> To maintain its charge, the Powerlight should always be stored in the wall-mounted
holder when not in use. Self discharging and a reduction in the battery capacity
will then be avoided. The Powerlight has an automatic charging voltage monitor and
so continuous charging is recommended.
> When removed from the wall-holder, the Powerlight switches “on” as a functional check.
OPERATION OF THE POWERLIGHT
Press the selector switch once: Main Spotlight is on
Press the selector switch twice: Secondary light (LED) is on
Press the selector switch 3x: Secondary light (LED) flashes
Press the selector switch 4x: Powerlight is switched off
The secondary light (LED) is actuated automatically if the bulb filament in the main
spotlight fails when switched on. Before reaching the low-battery voltage threshold, the
Powerlight automatically switches from the main spotlight to secondary light mode (LED),
with a remaining lighting duration of approx. 1 h. After this the Powerlight switches itself
off automatically as soon as the low-battery voltage threshold is reached and so avoiding
damage the battery pack.
BATTERY CAPACITY DISPLAY
When the Powerlight is in operation, the remaining battery capacity is shown by five LEDs,
as follows:
3 GREEN LEDs: > 75% > 50% > 25%
1 YELLOW LED: < 25%
1 RED LED: < 10%
EMERGENCY LIGHT FUNCTION
While the Powerlight is stored in the wall-holder for charging, should there be a mains
power failure, the main spotlight will light up and remain lit until either the mains power
is restored or the low-power limit of the battery is reached.
It is still possible to switch the Powerlight off manually.
REPAIR AND MAINTENANCE
Servicing operations may only be carried out by properly trained authorized service
companies. Only original replacement parts are to be used.
CHANGING THE BATTERY
PLEASE PROCEED AS FOLLOWS:
> Loosen the four screws left, right and at the bottom of the housing.
> Carefully remove the rear panel from the housing.
> Remove the old battery.
> Remove the red (+) and black (-) connectors from the battery.
> Install the new battery and then push it into place after refitting the connectors with the
correct polarity.
> Warning: do not short-circuit the battery!
> Re-assemble the Powerlight in the reverse order.
Exhausted batteries must be recycled in accordance with local regulations, and must NOT be
discarded in domestic waste!
POWERLIGHT DIAGRAM
1 Handle
2 ON/OFF selector switch
3 Belt holder for attaching by a snap-hook
4 Wall holder
5 Lens surround ring for reflector release and bulb changing
6 Hinge (the head can be swivelled forwards by 30° and backwards by 90°).
7 Holder for two filter/diffuser discs (white and orange supplied)
8 Housing with integrated lamp controls and charging electronics
BULB CHANGING
PLEASE FOLLOW THE INSTRUCTIONS BELOW:
> To open the housing, turn the Powerlight lens surround ring anticlockwise
> Carefully remove the ring
> Take care when removing the reflector from the Powerlight head
> Turn the main lamp gently until the V-shape cut-out is at the top
> Remove the bulb towards you
> Hold the new bulb with a cloth at all times. Push it carefully into the opening and lock it
in place with a half a revolution clockwise
> The V-shaped cut-out should now point downwards
> Carefully replace the reflector back in the Powerlight head.
Important: the openings for the bulbs must be in the correct positions
> Refit the Powerlight lens surround ring carefully ensuring that the threads mate correctly.
Turn it clockwise until it hits the end stop
GUARANTEE
For this product we offer a two years warranty for the specified operating modes:
This warranty does not extend to products which have been used improperly, altered,
neglected, damaged by accident or subjected to abnormal operating conditions or improper
handling.
In the event of a warranty claim, the faulty device and the proof of purchase should be sent
to the authorized repair centre. We reserve the right to repair or replace the unit.
The rechargeable lead-acid gel battery pack and the xenon bulb of the main lamp are
excluded from the two years warranty as they are consumable parts.

BESTELL-NR./PART NO. BEZEICHNUNG/DESCRIPTION
3002494 Hauptlampe Xenon 6,5V 5W / Main lamp Xenon 6.5V 5W
3002435 Filterscheibe klar / Filter/difuser disc white
3002445 Filterscheibe orange / Filter/difuser disc orange
3018022 Blei-Gel-Akku 6V 4,5Ah / Maintenance free lead acid battery 6V/4,5Ah
3002425 Wandhalterung / Wall mount
3002565 Ladegerät (100V - 240V) / Charger (100V - 240V)
3002475 KFZ-Kabel (12V / 24V) / Car adaptor (12V / 24V)
ANSMANN AG . Industriestraße 10 . D-97959 Assamstadt . Germany
Hotline: [phone] . E-Mail: [e-mail] . www.ansmann.de
ZUBEHÖR / ACCESSORIES
