Antec Neo ECO Series User manual

N EO ECO P OWER S UPPLY S ERIES
U SER ’ S M ANUAL

2
U SER ’ S M ANUAL
N EO ECO S ERIES
Get economical power toda with the Neo ECO, Antec's high-efficienc power suppl series. Featuring 80 PLUS®
certification, a quiet double ball bearing 120 mm fan, and Universal Input with Active Power Factor Correction
(PFC), the Neo ECO series gives ou a cooler, quieter s stem all powered b Continuous Power.
Note: No power cord included. B reusing our existing cord, ou can reduce waste and help protect the
environment
S TANDARDS AND F EATURES
The connectors and power specifications of the Neo ECO PSU are all compatible with ATX12V v2.3 and EPS12V
v2.91 specifications. The Neo ECO features Universal Input, which automaticall senses when ou connect the
power suppl to an AC power source between 100 ~ 240V without setting a voltage switch. This power suppl
also features Active Power Factor Correction (Active PFC), which improves the power factor value of the power
suppl b altering the input current wave shape, helping to power transmission across the grid.
S YSTEM P ROTECTION
A variet of industrial-grade safet circuitr will help protect our computer: OCP (Over Current Protection), OVP
(Over Voltage Protection), SCP (Short Circuit Protection) and OPP (Over Power Protection). Sometimes the PSU will
“latch” into a protected state. You will need to power off the PSU and clear the fault before it will function again.
There are no user-replaceable fuses in our Neo ECO PSU.
80 PLUS® C ERTIFICATION
80 PLUS® certification is the most widel recognized
independent standard in power suppl efficienc . An 80 PLUS®
certified power suppl uses less energ and generates less heat
to sta cooler, run quieter and last longer. The Neo ECO has
been 80 PLUS® certified to be at least 80% efficient at a wide
range of operating loads; this will lower our operating costs
and help protect the environment.
P OWER O UTPUT & C ONNECTORS
The Neo ECO power suppl distributes power on separate rails. Some rails require a minimum load in order to run.
To see the output capacit and regulation for each different voltage, see Table 1. A list of all available power
connectors can be found in Table 2.
Neo Eco 620C

3
TABLE 1
Neo Eco 400 / 400C
Output
Voltage
Load
Max. Regulation Ripple & Noise
+3.3V 20A ±5% < 50 mV
+5V 20A ±5% < 50 mV
+12V 30A ±5% < 120 mV
–12V 0.8A ±10% < 120 mV
+5VSB 2.5A ±5% < 50 mV
Neo Eco 450 / 450C
Output
Voltage
Load
Max. Regulation Ripple & Noise
+3.3V 20A ±5% < 50 mV
+5V 20A ±5% < 50 mV
+12V 34A ±5% < 120 mV
–12V 0.8A ±10% < 120 mV
+5VSB 2.5A ±5% < 50 mV
Neo Eco 5 0 / 5 0C
Output
Voltage
Load
Max. Regulation Ripple & Noise
+3.3V 24A ±5% < 50 mV
+5V 24A ±5% < 50 mV
+12V 40A ±5% < 120 mV
–12V 0.8A ±10% < 120 mV
+5VSB 2.5A ±5% < 50 mV
Neo Eco 6 0 / 6 0C
Output
Voltage
Load
Max. Regulation Ripple & Noise
+3.3V 24A ±5% < 50 mV
+5V 24A ±5% < 50 mV
+12V 48A ±5% < 120 mV
–12V 0.8A ±10% < 120 mV
+5VSB 2.5A ±5% < 50 mV

4
TABLE 2
Part name Quantit
24(20+4)-pin main connector
8(4+4)-pin ATX12V/EPS12V
PCI-E 6-pin
(400W / 450W onl )
PCI-E 6-pin + 8(6+2)-pin connectors
(520W / 620W onl )
Molex connectors
x 3
Flopp
X 1
Serial ATA Connector
x 3
N
eo ECO 400/450/5 0/6 0

5
Part name Quantit
24(20+4)-pin main connector
8(4+4)-pin ATX12V/EPS12V
PCI-E 6-pin
(400W / 450W onl )
PCI-E 6-pin + 8(6+2)-pin connectors
(520W / 620W onl )
Molex connectors x 4 (400W/450W)
x 5 (520W/620W)
Flopp
X 1
Serial ATA Connector
x 5 (400W/450W)
x 6 (520W/620W)
Neo ECO 400C/450C/5 0C/6 0C

6
I NSTALLATION :
1. Install the Neo ECO PSU into either the top or bottom of our case with the four screws provided. Refer to
our case manual if ou are unsure where the power suppl should be installed.
2. Connect the 24(20+4)-pin main power connector to our motherboard. If our motherboard uses a 20-pin
connector, detach the 4-pin attachment on the 24-pin connector.
Note: The detachable 4-pin section cannot be used in place of a 4-pin +12V connector.

7
3. Connect the 8(4 + 4)-pin connector for the CPU.
Note: Please also refer to our motherboard user’s manual for an special instructions.
4. Connect the 6-pin PCI-E/8(6+2)-pin connector to our graphics card (if applicable).
5. Connect all Molex/SATA connector(s) to our hard drives, optical drives (CD/DVD/BluRa ™) and other
accessories. Please note that some devices will use either the older 4-pin Molex connectors, while others will
use the newer 15-pin SATA connector. 4-pin Molex connectors have two black wires, a ellow, and a red. The
SATA connector has an additional orange power wire.
6. Connect our flopp drive (if present) using the supplied FDD connector shown in Table 2.
7. Note: No power cord included. B reusing our existing cord, ou can reduce waste and help protect the
environment.
Connect the AC power cord to the power suppl AC inlet.
8. Turn the switch on the PSU to the “|” position.

8
