POWER SUPPLIES
Safety Protection
Over Voltage Protection (OVP)
Short Circuit Protection (SCP)
Under Voltage Protection UVP)
Over Current Protection (OCP)
Environmental:
Input Voltage
Input frequency Range
Efficiency
100~240VAC ± 10%
47Hz ~ 63Hz
Up to 85%
Operating Temperature
Net Weight
Safety Approvals
Size
0°C to 50°C
5.75 lbs
UL, CUL, FCC, TÜV, CE, C-tick, CCC, CB
3.4” (H) x 5.9” (W) x 7.1” (D)
SPECIFICATION:
• nVIDIA SLI Certified
• Available in 850W and 1000W
• Universal Input, automatically adjusts for 100V to 240V
power grids
• 80Plus® Certified
• Active Power Factor Correction (PFC) helps reduce
electrical waste
• Supports EPS12V v2.91 and ATX12V systems
• Four 12V output circuits provide supreme system stability
• Accurate power rating allows TruePower Quattro to
deliver its full rated power (24 hours a day rated at 50ºC)
• Up to 85% efficient
• 80mm low noise cooling fan
• Heavy duty protection circuitry prevents damage resulting
from short circuits (SCP), over voltages (OVP), under
voltages (UVP), and over current (OCP)
• 2 x 8-pin PCI-E connectors and 2 x 6-pin connectors for
PCI-Express graphics cards
• MTBF: 100,000 hours
• Safety approvals: UL, CUL, FCC, TÜV, CE, C-tick, CCC, CB
• Gold plated connectors for superior conductivity
• AQ5 – Antec Quality five-year parts and labor warranty
Full Throttle Power
Input:
Quiet
computing™
TruePower Quattro
www.antec.com 1-800-22ANTEC (US) / +31 (0) 10 462-2060 (EU)
UCC13#
850 Watt
0761345-07850-4
0761345-07851-1
1000 Watt
0761345-07990-7
0761345-07991-4
EC
GB
You could search the four corners of the earth for a stable and reliable power supply, but actually you
need to look no further than Antec’s TruePower Quattro™! Available in 850 and 1000 Watts, Quattro™
is more compact than most competing power supplies of the same wattage, yet ideally suited for
handling the most demanding system specs. TruePower Quattro™ is 80PLUS® certified which means
that Quattro™ consumes about 33% less energy than many equivalent power supplies with the same
power output. Four 12V rails increase your system stability by letting you distribute your power more
than ever before. Comes with four PCI-E connectors for powering one (or even two) of the newest
generation of video cards. All modular cables are sleeved and labeled to give your system a clean and
professional look-while the racing stripe paint job will add some extra style.
E
n
e
r
g
y
E
f
f
i
c
i
e
n
t
®
More than 80% efficient
at 20%, 50% & 100% load
www.80PLUS.org
