Anthem I225 User manual

INTEGRATED 225
OPERATING MANUAL
™
w w w . a n t h e m A V . c o m

SAFETY PRECAUTIONS
READ THIS SECTION CAREFULLY BEFORE PROCEEDING!
The lightning flash with arrowpoint within an equilateral triangle
warns of the presence of uninsulated “dangerous voltage”
within the product’s enclosure that may be of sufficient
magnitude to constitute a risk of electric shock to persons.
The exclamation point within an equilateral triangle warns users
of the presence of important operating and maintenance
(servicing) instructions in the literature accompanying the appliance.
WARNING: TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT EXPOSE THIS PRODUCT TO RAIN OR MOISTURE
AND OBJECTS FILLED WITH LIQUIDS, SUCH AS VASES, SHOULD NOT BE PLACED ON THIS PRODUCT.
CAUTION: TO PREVENT ELECTRIC SHOCK, MATCH WIDE BLADE OF PLUG TO WIDE SLOT, FULLY INSERT.
CAUTION: FOR CONTINUED PROTECTION AGAINST RISK OF FIRE, REPLACE THE FUSE ONLY WITH THE SAME AMPERAGE
AND VOLTAGE TYPE. REFER REPLACEMENT TO QUALIFIED SERVICE PERSONNEL.
WARNING: UNIT MAY BECOME HOT. ALWAYS PROVIDE ADEQUATE VENTILATION TO ALLOW FOR COOLING. DO NOT
PLACE NEAR A HEAT SOURCE, OR IN SPACES THAT CAN RESTRICT VENTILATION.
IMPORTANT SAFETY INSTRUCTIONS
WARNING TO REDUCE THE RISK OF ELECTRIC
SHOCK, DO NOT REMOVE COVER (OR BACK).
NO USER-SERVICEABLE PARTS INSIDE. REFER
SERVICING TO QUALIFIED SERVICE PERSONNEL.
RISK OF ELECTRIC SHOCK
DO NOT OPEN
WARNING
1. Read Instructions – All the safety and operating instructions should be read before the product is operated.
2. Retain Instructions – The safety and operating instructions should be retained for future reference.
3. Heed Warnings – All warnings on the product and in the operating instructions should be adhered to.
4. Follow Instructions – All operating and use instructions should be followed.
5. Cleaning – Unplug this product from the wall outlet before cleaning. Do not use liquid cleaners or aerosol cleaners. Use
a damp, soft cloth for cleaning.
6. Water and Moisture – Do not use this product near water – for example, near a bath tub, wash bowl, kitchen sink, or
laundry tub; in a wet basement; or near a swimming pool; and the like.
7. Accessories – Do not place this product on an unstable cart, stand, tripod, bracket, or table. The product may fall,
causing serious injury to a child or adult, and serious damage to the product. Use only with a cart, stand, tripod, bracket,
or table recommended by the manufacturer, or sold with the product. Any mounting of the product should follow
manufacturer’s instructions, and should use a mounting accessory recommended by the manufacturer.

8. Ventilation – Slots and openings in the cabinet are provided for ventilation and to ensure reliable operation of the
product and to protect it from overheating, and these openings must not be blocked or covered. The openings should
never be blocked by placing the product on a bed, sofa, rug, or other similar surface. This product should not be placed
in a built-in installation such as a bookcase or rack unless proper ventilation is provided or the manufacturer’s
instructions have been adhered to.
9. Power Sources – This product should be operated only from the type of power source indicated on the marking label.
If you are not sure of the type of power supply to your home, consult your product dealer or local power company. For
products intended to operate from battery power, or other sources, refer to the operating instructions.
10. Grounding and Polarization – This product may be equipped with a polarized alternating-current line plug (a plug having
one blade wider than the other). This plug will fit into the power outlet only one way. This is a safety feature. If you are
unable to insert the plug fully into the outlet, try reversing the plug. If the plug should still fail to fit, contact your
electrician to replace your obsolete outlet. Do not defeat the safety purpose of the polarized plug.
11. Power-cord Protection – Power-supply cords should be routed so that they are not likely to be walked on or pinched
by items placed upon or against them, paying particular attention to cords at plugs, convenience receptacles, and the
point where they exit from the product.
12. Outdoor Antenna Grounding – If an outside antenna or cable system is connected to the product, be sure the antenna
or cable system is grounded so as to provide some protection against voltage surges and built-up static charges. Article
810 of the National Electrical Code, ANSI/NFPA 70, provides information with regard to the proper grounding of the mast
and supporting structure, grounding of the lead-in wire to an antenna-discharge unit, size of grounding conductors,
location of antenna-discharge unit, connection to grounding electrodes, and requirements for the grounding electrode.
13. Lightning – For added protection for this product during a lightning storm, or when it is left unattended and unused for
long periods of time, unplug it from the wall outlet and disconnect the antenna or cable systems. This will prevent
damage to the product due to lightning and power-line surges.
14. Power Lines – An outside antenna system should not be located in the vicinity of overhead power lines or other electric
light or power circuits, or where it can fall into such power lines or circuits. When installing an outside antenna system,
extreme care should be taken to keep from touching such power lines or circuits as contact with them might be fatal.
15. Overloading – Do not overload wall outlets, extension cords, or integral convenience receptacles as this can result in
a risk of fire or electric shock.
Antenna Lead-In Wire
Antenna-Discharge Unit 
(NEC Section 810-20)
Grounding Conductors 
(NEC Section 810-21)

Power Service Grounding
Electronic System
(NEC ART 250. Part H)
NEC-National Electrical Code
Electrical Service 
Equiptment
Ground Clamp
Ground Clamps

S2898A

Anthem, Sonic Frontiers, and Paradigm are trademarks or registered trademarks of Paradigm Electronics Inc.
Copyright Paradigm Electronics Inc. All rights reserved. The information contained herein may not be reproduced in whole
or in part without our express written permission. We reserve the right to change specifications and/or features without
notice as design improvements are incorporated.
RECYCLING AND REUSE GUIDELINES (Europe)
In accordance with the European Union WEEE (Waste Electrical and Electronic Equipment) directive effective
August 13, 2005, we would like to notify you that this product may contain regulated materials which, upon disposal,
require special reuse and recycling processing. For this reason Paradigm Electronics Inc. (the manufacturer of
Paradigm speakers and Anthem electronic products) has arranged with its distributors in European Union member
nations to collect and recycle this product at no cost to you. To find your local distributor please contact the dealer
from whom you purchased this product or go to our website at www.paradigm.com.
Please note that only the product falls under the WEEE directive. When disposing of packaging and other shipping
material we encourage you to recycle through the normal channels.
16. Object and Liquid Entry – Never push objects of any kind through openings as they may touch dangerous voltage points
or short-out parts that could result in a fire or electric shock. Do not expose this product to dripping or splashing and
ensure that no objects filled with liquids, such as vases, are placed on the product.
17. Servicing – Do not attempt to service this product yourself, as opening or removing covers may expose you to
dangerous voltage or other hazards. Refer all servicing to qualified service personnel.
18. Damage Requiring Service – Unplug this product from the wall outlet and refer servicing to qualified personnel under
the following conditions
• When power-supply cord or plug is damaged.
• If liquid has been spilled, or objects have fallen into the product.
• If the product has been exposed to rain or water.
• If the product does not operate normally by following the operating instructions. Adjust only those controls that are
covered by the operating instructions as an improper adjustment of other controls may result in damage and will require
extensive work by a qualified technician to restore the product to its normal operation.
• If the product has been dropped or damaged in any way.
• If the product exhibits a distinct change in performance – this indicates a need for service.
19. Replacement Parts – When replacement parts are required, be sure the technician has used replacement parts
specified by the manufacturer or have the same characteristics as the original part. Unauthorized substitutions may
result in fire, electric shock, or other hazards.
20. Safety Check – Upon completion of any service or repairs to this product, ask the service technician to perform safety
checks to determine that the product is in proper operating condition.
21. Heat – The product should be situated away from heat sources such as radiators, heat registers, stoves, or other
products (including amplifiers) that produce heat.

1
1. INTRODUCTION
Thank you for purchasing the Anthem Integrated 225.
The I225 is an integrated preamplifier and amplifier. Anthem products are engineered to recreate the passion
of live performance and thrill of the best movie theaters by using the highest level of circuit design, superior
build quality, innovative features, and intuitive ergonomics.
1.1 BEFORE MAKING CONNECTIONS
Check that you have received everything listed below and report discrepancies to your dealer as soon as
possible. Retain all packing materials and use them for any future shipment.
Packing List:
• Integrated 225 • 2 AA Batteries • Power cord (North America only)
• Remote control • Operating manual
Keep the invoice that you received from your authorized Anthem dealer at time of purchase – without
it service will not be provided under warranty.
Safety Instructions:
• Read all precautions and instructions at the beginning of this manual.
• Do not connect power if there are signs of damage to any part of the exterior.
• The Front Panel power button does not disconnect the product from the AC line. Ensure that the
power cord remains readily accessible at all times.
• Use only the supplied power cord to connect power.
• Allow adequate ventilation to ensure reliable operation and to prevent overheating. The amount of
space required above the unit for radiation depends on ambient air temperature and circulation.
Installation inside an unventilated space such as a cabinet with a front that can be closed or a
closet is not recommended.
• Failing to comply with any safety instruction, precaution, or warning in this Operating Manual is in
violation of the intended use of the product.
• Anthem and any related party assume no liability for the user’s failure to comply with requirements.
1.2 IN-USE NOTICES
• Disconnect the power cord before connecting or disconnecting any components.
• Do not remove the top cover.
• Do not modify the product.

2
1.3 FRONT PANEL
1– Volume Control
2– Power On / Standby
3– Mute
4– Balance
5– Treble
6– Bass
7– Tone Defeat
8– Remote Control Sensor
9– Stereo Mini Input Jack and Selector – for use with a portable audio device
10 – Headphone Jack
11 – Source Selection
1. INTRODUCTION continued …
For a larger diagram see inside back cover.
POWER
PHONO CD BALANCED
RECORDER
MUTE
BASSTONE DEFEAT TREBLE BALANCE
AU X 1 AU X 2 AU X 3
INTEGRATED 225
AU X 4
1011 9 8 7 6 5 4 3 2
1

BALANCED INPUT
RS-232 CONTROL 12 V
TRIGGER
IN OUT IN OUT
I.R.
RECEIVER
PHONO
GND
PHONO CD AUX 1
OUTPUTS
SPEAKER OUTPUTS
AUX 2 AUX 3 RECORDER REC
OUT
PRE
OUT
R+ - L- +
L
R
INPUTS
RISK OF ELECTRIC SHOCK – DO NOT OPEN
RISQUE DE CHOC ELECTRIQUE – NE PAS OUVRIR
FUSE T12A/250V
AC 120V/60Hz
POWER CONSUMPTION: 300W TYPICAL
CAUTION |TO PREVENT ELECTRIC SHOCK, DO NOT REMOVE
TOP COVER. NO USER-SERVICEABLE PARTS INSIDE, REFER
SERVICING TO QUALIFIED SERVICE PERSONNEL.
WARNING |TO PREVENT FIRE OR SHOCK HAZARD, DO NOT
EXPOSE THIS UNIT TO RAIN OR MOISTURE.
L
R
L
R
INTEGRATED 225
DESIGNED AND ENGINEERED BY
SONIC FRONTIERS INTERNATIONAL
MADE IN TAIWAN
78
3
24
1
6
5
3
1– XLR (balanced) input – connect if using source with balanced output
2– RS-232 interface – for use with custom control systems
3– 12 Volt trigger in / out
4– I.R. receiver in / out
5– Fuse
6– Power cord connection
7– Left speaker output
8– Right speaker output
9– Preamplifier (volume-controlled) output – connect if using external amplifier
10 – Record (line level) output
11 – 5 RCA inputs
12 – Phono input with ground connection
1.4 REAR PANEL
For a larger diagram see inside back cover.
1. INTRODUCTION continued …
12 11 10 9

4
1.5 REMOTE CONTROL
1– Power OFF
2– IR Transmitter (front face)
3– LED
4– Power ON
5– Set (for customization of remote)
6– Control mode (to control other components)
7– Volume
8– Tone Enable / Bypass
9– Mute
10 – Source
The remaining keys are for custom setup to control other equipment.
When a key is pressed, the keys light with amber color.
Rear: Battery cover – low battery power is indicated by LED double
blink and no backlight
1. INTRODUCTION continued …
1 2
3
5
6
9
8
7
4
10

5
1.6 INTERCONNECTS
These illustrations show audio, IR, and trigger connectors used between source components and the I225.
1. INTRODUCTION continued …
3.5mm
Mini (stereo)
XLR Female
(connects to output)
XLR Male
(connects to input)
Digital Audio Analog Balanced or AES/EBU
1/4” Stereo
Headphone
3.5mm
Mini (Mono)
12V Trigger
IR Emitter
Analog Left
Channel
RCA Black or
White RCA Red
Analog Right
Channel

6
2.1 INPUT CONNECTIONS
Connect source components and recorder according to the diagrams in the following pages. If using a
turntable, connect it to PHONO input only. If the turntable is equipped with a ground wire, connect it to the
ground terminal next to the PHONO input by unscrewing the terminal then inserting wire and tightening the
screw terminal onto the wire.
Do not use ‘RCA-compatible’ connectors that have a hollow center pin with a hole at the tip – inserting
them into the Integrated 225’s RCA jacks can cause internal damage.
2.2 SPEAKER CONNECTIONS
Depending on the level of the input signal and volume setting, the voltage at the outputs can be high enough
to cause electric shock – be sure that power is turned off when connecting or disconnecting anything.
Ensure that the speakers are rated for use with this amplifier – an overdriven speaker can pose a fire hazard.
Connect the red (+) connection on the speaker to the red (+) binding post on the appropriate amplifier
channel, and the black (–) connection on the speaker to the black (–) binding post on the same amplifier
channel, using cable that is insulated to handle the maximum output of the amplifier. Do not overtighten the
binding posts as this may cause damage. Each binding post accepts a connection from one speaker.
2.3 TRIGGER
This feature allows the amplifier to be turned on or off remotely via the trigger. The 3.5mm (.125”) mini-jack
INPUT receives a 12V signal from an upstream component or system controller. The same trigger signal can
be linked to other components through the OUTPUT.
2.4 I.R. (INFRA RED) RECEIVER
External IR receivers allow the Remote Control to be used from other locations in your home. Once an IR
receiver is wired to another room, connect it to I.R. RECEIVER IN. The signal can be linked to other
components through I.R. RECEIVER OUT.
2.5 POWER
After the system is connected use the supplied power cord to connect power. It is normal for a ‘click’ to be
heard from inside the chassis when connecting power.
2. CONNECTIONS

7
Example 1: CD Player to Integrated 225
2. CONNECTIONS continued …
BALANCED INPUT
RS-232 CONTROL 12 V
TRIGGER
IN OUT IN OUT
I.R.
RECEIVER
PHONO
GND
PHONO CD AUX 1
OUTPUTS
SPEAKER OUTPUTS
AUX 2 AUX 3 RECORDER REC
OUT
PRE
OUT
R+- L-+
L
R
INPUTS
RISK OF ELECTRIC SHOCK – DO NOT OPEN
RISQUE DE CHOC ELECTRIQUE – NE PAS OUVRIR
FUSE T12A/250V
AC 120V/60Hz
POWER CONSUMPTION: 300W TYPICAL
CAUTION |TO PREVENT ELECTRIC SHOCK, DO NOT REMOVE
TOP COVER. NO USER-SERVICEABLE PARTS INSIDE, REFER
SERVICING TO QUALIFIED SERVICE PERSONNEL.
WARNING |TO PREVENT FIRE OR SHOCK HAZARD, DO NOT
EXPOSE THIS UNIT TO RAIN OR MOISTURE.
L
R
L
R
INTEGRATED 225
DESIGNED AND ENGINEERED BY
SONIC FRONTIERS INTERNATIONAL
MADE IN TAIWAN
AUDIO OUT
LR

8
2. CONNECTIONS continued …
Example 2: Recorder to Integrated 225
BALANCED INPUT
RS-232 CONTROL 12 V
TRIGGER
IN OUT IN OUT
I.R.
RECEIVER
PHONO
GND
PHONO CD AUX 1
OUTPUTS
SPEAKER OUTPUTS
AUX 2 AUX 3 RECORDER REC
OUT
PRE
OUT
R+- L-+
L
R
INPUTS
RISK OF ELECTRIC SHOCK – DO NOT OPEN
RISQUE DE CHOC ELECTRIQUE – NE PAS OUVRIR
FUSE T12A/250V
AC 120V/60Hz
POWER CONSUMPTION: 300W TYPICAL
CAUTION |TO PREVENT ELECTRIC SHOCK, DO NOT REMOVE
TOP COVER. NO USER-SERVICEABLE PARTS INSIDE, REFER
SERVICING TO QUALIFIED SERVICE PERSONNEL.
WARNING |TO PREVENT FIRE OR SHOCK HAZARD, DO NOT
EXPOSE THIS UNIT TO RAIN OR MOISTURE.
L
R
L
R
INTEGRATED 225
DESIGNED AND ENGINEERED BY
SONIC FRONTIERS INTERNATIONAL
MADE IN TAIWAN
AUDIO OUT
LR
AUDIO IN
LR

9
3.1 POWER ON/OFF
Power on is indicated when the LED above the from panel power button is lit.
Front panel – power ON/OFF
•Press POWER in the lower left of the front panel.
Remote control – power ON
•Make sure that INT control mode is set then press the power key
in the upper left.
Remote control – power OFF
•Make sure that INT control mode is set then press the power OFF
key in the upper right.
3.2 SOURCE SELECTION
Select a source by pressing one of the following buttons – make sure that INT control mode is set if using
remote control
When RECORDER is selected, the REC output is disabled since a recorder cannot record itself.
3.3 VOLUME CONTROL
Front panel
•Rotate the volume knob clockwise to increase the volume and counterclockwise to
decrease the volume.
Remote control
•Make sure that INT control mode is set then use the VOL+and VOL keys.
Mute:
When MUTE is pressed, the audio is silenced and the front panel indicator above the
button flashes. Press MUTE again and sound will return.
3. OPERATION
POWER
MUTE
PHONO CD BALANCED
RECORDER
AU X 1 AU X 2 AU X 3 AU X 4

10
3.4 BALANCE CONTROL
If the center of the soundstage is off-center, rotate the balance control in the direction that the
soundstage needs to be moved. The center position is the default.
3.5 TONE CONTROL
To adjust the bass and/or treble level, rotate the Bass and Treble
knobs on the front panel. The center position is the default. If an
adjustment is made, you can press TONE on the front panel or remote
to quickly turn the adjustment on/off without having to return the
knobs to the center position – the indicator above the button lights when the controls are defeated.
It is normal for a ‘click’ to be heard from the chassis when pressing Power, Mute, or a source button.
3. OPERATION continued …
BASSTONE DEFEAT TREBLE
BALANCE

11
4. REMOTE CONTROL CUSTOMIZATION
4.1 CODES FOR OTHER BRANDS
The Integrated 225 remote can control other components – a list of brands and setup instructions are at the
end of this section. If the brand for your component is not listed, try searching for a code as follows
1. Turn on the component, for example the DVD player.
2. Press a control mode key other than INT, for example DVD.
3. Press and hold SET until the LED flashes twice then press 9,9,1.
4. Press 0for cable converters, satellite receivers, or video accessories, 1for TVs, 2for DVD players
or VCRs, or 3for CD players or audio amps/tuners.
5. Aim the remote towards the player and press POWER (or Play). If the player does not respond, press
CH+to try the next code. If the player responds, press SET to lock the code. Codes are sent in order
of popularity. CH goes to the previous code. If no code is found see section 4.2.
6. After finding a code, record it Press and hold SET until the LED flashes twice, then press 9,9,0,1.
Wait 3 seconds and count the number times that the LED flashes. This represents the first digit (for
example, 3 flashes = 3, no flash = 0) – write this down. Next, press 2for the second digit, 3for the
third digit, 4for the fourth digit, 5for the fifth digit and write the number of flashes each time.
4.2 LEARNING COMMANDS
Commands from almost any other infra-red remote control can be captured by the Integrated 225 remote
control. The factory command is still available by pressing SET before pressing the taught key.
If the factory command is used more than the learned command, the learned command can be programmed
in Layer2 instead. In this case, the learned command is sent by pressing SET before pressing the key.
Before teaching a key note the following:
• Control mode keys and SET can not be taught. These keys never send IR commands.
• A multiple key sequence (for example Rec+Pause or Rec+Play) can not be taught to one key.
• A high level of ambient light, light from displays, and exposed fans could interfere with learning.
To teach a key:
1. Point the source and Integrated 225 remotes at each other, holding them approximately 2 inches apart.
2. Press and hold SET until the LED flashes twice then press 9,7,5. One long blink indicates low
battery or faulty memory – the remote will not go into learn mode under either of these conditions.
3. Press the desired control mode key.
4. Press the key to be taught, or to program the command into Layer2 press SET (don’t hold) and then
press the key to be taught.
5. The LED flashes rapidly. Within 4 seconds, press and hold the teaching key on the source remote
until the LED flashes twice. One long blink means bad capture (try again), memory full (delete
another command), or unlearnable code.
6. Repeat steps 3-5 or 4-5 as often as desired until memory is full.
7. To exit, press and hold SET until the LED flashes twice or wait 10 seconds.
Deleting learned commands:
1. Press and hold SET until the LED flashes twice, then press 9,7,6.
2. To delete a learned command from one key, press the control mode key, then the key to be deleted
twice. To delete all learned commands in the control mode, press the control mode key twice.

12
4. REMOTE CONTROL CUSTOMIZATION continued …
4.3 COPYING COMMANDS
The command from one key can be copied to another key (not applicable to Power, Record, and Set keys).
To copy a command to another key in the same control mode:
1. Press the control mode key.
2. Press and hold SET until the LED flashes twice.
3. Press 9,9,4.
4. Press the key to be copied.
5. Press the new key that will have the command. The LED flashes twice.
To copy a command into a different control mode:
1. Press and hold SET until the LED flashes twice.
2. Press 9,9,4.
3. Press the control mode key of the key to be copied then the key to be copied.
4. Press the new control mode key then the new key that will have the command. The LED flashes twice.
To set the original functions:
1. Press the control mode key.
2. Press and hold SET until the LED flashes twice.
3. Press 9,9,4.
4. Press the control mode key twice.
4.4 VOLUME LOCK
With Volume Lock engaged, the volume and mute keys control the Integrated 225 regardless of control mode,
making operation more convenient.
To engage Volume Lock for MAIN:
1. Press and hold SET until the LED flashes twice.
2. Press 9,9,3.
3. Press MAIN.
To dis-engage Volume Lock for TV and re-engage the TV’s volume control:
1. Press ZONE2 (or ZONE3).
2. Press and hold SET until the LED flashes twice.
3. Press 9,9,3.
4. Press VOL .
The Volume and Mute keys now control the Integrated 225 for every control mode selection except TV. You
may continue to disengage other control modes one at a time. To disengage all, press VOL+in step 4.

13
4.5 PROGRAMMING MACROS
Macros are used to execute multiple functions with one key press, such as powering the Integrated 225,
cable box, and display On at the same time. Up to 32 commands can be programmed.
Programming a Macro that works regardless of control mode setting:
1. Press and hold SET until the LED flashes twice.
2. Press 9,9,5.
3. Press the key you want to use to activate your macro (e.g. Power).
4. Enter the command sequence that you want the macro to execute.
5. To exit, press and hold SET until the LED flashes twice or wait 10 seconds.
To clear the macro, repeat the steps above but skip step 4.
Programming a Macro that works in one control mode:
1. Press the control mode key.
2. Press and hold SET until the LED flashes twice.
3. Press 9,7,8.
4. Press the key you want to use to activate your macro (e.g. Power).
5. Enter the command sequence that you want the macro to execute.
6. To exit, press and hold SET until the LED flashes twice or wait 10 seconds.
To clear the macro
1. Press and hold SET until the LED flashes twice, then release.
2. Press 9,7,8.
3. Press the control mode key where you programmed the macro.
4. Press the key that was programmed to activate the macro.
5. To exit, press and hold SET until the LED flashes twice or wait 10 seconds.
4. REMOTE CONTROL CUSTOMIZATION continued …

14
4. REMOTE CONTROL CUSTOMIZATION continued …
The following codes are for setting operation of other components with the Integrated 225 remote control. If codes for
your components are not in this library, see sections 4.1 and 4.2.
To enter a 5-digit code
1. Press the control mode key near the top of the remote (e.g. CD).
2. Press and hold SET until the LED flashes twice.
3. Enter the 5-digit code. Two LED blinks indicate that the code is accepted.
CD Players:
Acoustic Research 30420
Admiral 30305
Aiwa 30157
Arcam 30157
Audio Research 30157
Burmester 30420
Cairn 30157
California Audio Labs 30029, 30303
Cambridge Soundwks 30157
Carver 30157, 30179
Curtis Mathes 30032
Denon 30626, 30003, 30034
DKK 30000
DMX Electronics 30157
Emerson 30305
Fisher 30000, 30179
Funai 30305
Garrard 30393, 30420
Genexxa 30032, 30305
Grundig 30157
Hafler 30173
Harman/Kardon 30100, 30157, 30173
Hitachi 30032
Inkel 30157, 30180
Integra 30101
Jerrold 30003
JVC 30032, 30072
Kenwood 30626, 30000, 30029, 30028,
30037, 30190
KLH 31318, 31372, 31373, 31711
Krell 30157
Linn 30157
LXI 30179, 30305
Magnavox 30157, 30038, 30274, 30305
Marantz 30626, 30029, 30157, 30038,
30180, 30435
Matsui 30157
McIntosh 30256, 30290, 30660
MCS 30029
Memorex 30000, 30032, 30179, 30420,
30468
Micromega 30157
Miro 30000
Mission 30157
Modulaire 30000, 30032, 30087, 30179,
30180, 30420, 30468
MTC 30420
NSM 30157
Onkyo 31327, 30101
Optimus 30000, 30032, 30037, 30087,
30179, 30305, 30393, 30420,
30468
Panasonic 30029, 30303, 30388, 30752
Parasound 30420
Penney 30029
Philips 30626, 30157, 30274
Pioneer 31062, 30032, 31087, 30305,
30468
Polk Audio 30157
Proceed 30420
Proton 30157
QED 30157
Quad 30157
Quasar 30029
RadioShack 30000, 30032, 30179, 30180,
30420, 30468
RCA 31062, 30032, 30053, 30179,
30305, 30420, 30468
Realistic 30000, 30032, 30087, 30179,
30180, 30305, 30420, 30468
Revox 30157
Roksan 30435
Rotel 30157, 30420
SAE 30157
Sansui 30000, 30157, 30305
Sanyo 30000, 30087, 30179
Scott 30305
Sears 30179, 30305
Sharp 30037, 30034, 30180
Sherwood 30180
Sonic Frontiers 30157
Sony 30490, 30000, 30100, 31364,
30185
Sugden 30157
Sylvania 30157
Symphonic 30180, 30305
TAG McLaren 30157
Tandy 30032
Tascam 30393, 30420
Teac 30490, 30180, 30378, 30393,
30420
Technics 30029, 30303
Techwood 30303
Thule Audio 30157
Victor 30072
Wards 30032, 30157, 30053, 30087,
30179
Yamaha 30490, 30036, 31292
Yorx 30000
DVD Players:
3D LAB 20503, 20539
Accurian 21072, 21416
Acoustic Solutions 20730
Advent 21016
Afreey 20698
Aiwa 20641
Akai 20695, 20705, 20770, 20899,
21089
Alba 20672, 20717
Alco 20790
Allegro 20869
Amphion Media Wks 20872
AMW 20872
Apex Digital 20533, 20672, 20717, 20755,
20794, 20796, 20797, 20830,
21004, 21020, 21056, 21061,
21100
Arrgo 21023
Aspire Digital 21168, 21407
Audiovox 20717, 20790, 21041, 21071,
21072, 21121, 21122
Awa 20730
Axion 21071, 21072
Blaupunkt 20717
Blue Parade 20571
Blue Sky 20695
Bose 21895
Brandt 20651
Broksonic 20695, 20868
Byd sign 20872
California Audio Labs 20490
Celestial 21020
Centrex 20672, 21004
Cinea 20831
CineVision 20876, 20833, 20869
Citizen 21003, 21277
Clairtone 20571
Coby 20778, 21086, 21107, 21177
Craig 20831
Creative 20503, 20539
Curtis Mathes 21087
CyberHome 20816, 20874, 21023, 21024,
21117, 21129, 21502
Cytron 20705
Daewoo 20784, 20705, 20770, 20833,
20869, 21169, 21172, 21234,
21242
Dansai 20770
Daytek 20872
Decca 20770
Denon 20490, 20634
Denver 20778
Desay 21407
Digitrex 20672
Disney 20675, 21270
DiViDo 20705
Dual 20675, 21068, 21085
Durabrand 21127
DVD2000 20521
Electrohome 21003
Emerson 20591, 20675, 20821, 21268
Enterprise 20591
Entivo 20503, 20539
Enzer 20770
ESA 20821, 21268
Firstline 20651
Fisher 20670
Funai 20675, 21268, 21334
Gateway 21073, 21158
GE 20522, 20815, 20717
Go Video 20573, 20744, 20717, 20715,
20741, 20783, 20833, 20869,
21044, 21075, 21099, 21158,
21304, 21730
Go Vision 21071, 21072
GoldStar 20741, 20801, 20869
Goodmans 20790
Gradiente 20490, 20651
Greenhill 20717
Grundig 20539, 20705
Harman/Kardon 20582, 20702
Hitachi 20573, 20664, 21247, 21764
Hiteker 20672
Humax 21588
iLo 21348
Initial 20717
Insignia 21268
Integra 20571, 20627
IRT 20783
JBL 20702
Jensen 21016
JMB 20695
JVC 20558, 20623, 20867, 21164
Kawasaki 20790
Kenwood 20490, 20534
KLH 20717, 20790, 21020, 21149
Kloss 20533
Koss 20651, 21061
Lasonic 20627, 20798
Lecson 21533
Lenoxx 21127
LG 20591, 20741, 20801, 20869
LiteOn 21058, 21158, 21416, 21440
Loewe 20511, 20741
Logix 20783
Magnasonic 20651, 20675
Magnavox 20503, 20539, 20646, 20675,
20821, 21268
Malata 20782, 21159
Marantz 20503, 20539, 20675
McIntosh 21533
Medion 20651
Memorex 20695, 20831, 21270
Microsoft 20522, 21708
Minato 20752
Mintek 20839, 20717

15
Mitsubishi 21521, 20521, 21403
Momitsu 21082
Mustek 20730
NAD 20591, 20741
Naiko 20770
NEC 20785, 20869
Nesa 20717
NexxTech 21402
Norcent 21003, 20872, 21107, 21265
Onkyo 20503, 20627, 20792
Optimus 20571
Oritron 20651
Palsonic 20672
Panasonic 20503, 20490, 20571, 20703,
21362, 21462, 21490, 21632,
21762
Philips 20503, 20539, 20646, 20675,
20854, 21260, 21267, 21354
PianoDisc 21024
Pioneer 20525, 20571, 20631
Polaroid 21020, 21061, 21086
Polk Audio 20539
Portland 20770
Presidian 20675, 21072
Prima 21016
Proceed 20672
Proscan 20522
ProVision 20778
Qwestar 20651
Radionette 20741
Radio Shack 20571
RCA 20522, 20571, 20717, 20790,
20822, 21022, 21132
Realistic 20571
Reoc 20752
Rio 20869
Rotel 20623
Rowa 20823, 21004
Saba 20651
Sampo 20698, 20752
Samsung 20490, 20573, 20744, 20820,
20899, 21044, 21075
Sansui 20695
Sanyo 20670, 20675, 20695, 20873,
21334
Schneider 20783
Schwaiger 20752
Sensory Science 21158
Sharp 20630, 20675, 20752, 21256,
21642
Sharper Image 21117
Sherwood 20770, 21043
Shinsonic 20533, 20839
Slim Art 20784
SM Electronic 20730
Sonic Blue 20573, 20715, 20783, 20869,
21099
Sony 20533, 21533, 20864, 21033,
21070, 21431
Sova 21122
Superscan 20821
SVA 20717, 20860
Sylvania 20675, 20821, 21268
Symphonic 20675, 20821, 21268, 21334
Tatung 20770
Teac 20571, 20717, 20790
Technics 20490, 20703
Technika 20770
Technosonic 20730
Tevion 20651
Theta Digital 20571
Thomson 20522, 20511
Tivo 21503, 21588
Toshiba 20503, 20573, 20539, 20695,
21045, 21154, 21503, 21588,
21639
Tredex 20800
Unimax 20770
United 20730
Universum 20591
Urban Concepts 20503, 20539
US Logic 20839
V 21064, 21226
Venturer 20790
Victor 21597
Vizio 21064, 21226
Xbox 20522, 21708
Yamaha 20490, 20539, 20545
Yamakawa 20872
Zenith 20503, 20591, 20741, 20869
Zeus 20784
Zoece 21265
VCRs:
A-Mark 20037, 20240, 20000, 20278,
20046
ABS 21972
Admiral 20060, 20048, 20039, 20047,
20104, 20209, 20020, 20062,
20479
Adventura 20037, 20240, 20000
Adyson 20072
Aiko 20278
Aiwa 20037, 20000, 20124, 20307,
20479
Akai 20041, 20061, 20106, 20175
Alba 20209, 20072, 20278
Alienware 21972
Allegro 20039
America Action 20278
American High 20035, 20081
Amstrad 20000
Asha 20240
Astra 20035, 20240
Audiovox 20037, 20278, 20038
Avis 20000, 20072
Beaumark 20240
Bell & Howell 20035, 20048, 20039, 20000,
20104, 20046, 20479
Broksonic 20184, 20121, 20209, 20002,
20208, 20479, 21479
Calix 20037
Candle 20037, 20038
Canon 20035
Capehart 20002, 20020, 20062
Carrera 20240
Carver 20035, 20081
CCE 20072, 20278
Cineral 20278
Citizen 20035, 20037, 20240, 20000,
20209, 20278, 20479, 21278
Classic 20037
Colortyme 20060, 20035, 20045, 20278
Colt 20000, 20072
Craig 20037, 20047, 20240, 20072,
20271
Criterion 20000, 20072
Crosley 20035, 20081, 20000, 20149
Crown 20072, 20278
Curtis Mathes 20060, 20035, 20162, 20240,
20000, 20041, 20278, 20432,
20760, 21035
Cybernex 20240
CyberPower 21972
Daewoo 20037, 20045, 20278, 20020,
20046, 20561, 21278
Daytron 20037, 20278, 20020
Dell 21972
Denon 20081, 20042
Derwent 20041
DirecTV 20739
Dual 20000
Durabrand 20039, 20038
Dynatech 20240, 20000
Electrohome 20060, 20037, 20240, 20000,
20043, 20209, 20061
Electrophonic 20037
Emerald 20184, 20121
Emerex 20032
Emerson 20037, 20184, 20240, 20000,
20121, 20043, 20209, 20002,
20278, 20202, 20208, 20061,
20479, 20561, 20593, 21278,
21479, 21593
Fisher 20039, 20047, 20000, 20104,
20046
Fuji 20035, 20033
Fujitsu 20045, 20000
Funai 20037, 20000, 20072, 20278,
20593, 21593
Garrard 20000
Gateway 21972
GE 20060, 20035, 20048, 20240,
20000, 20149, 20202, 20760,
20807, 21035, 21060
Gemini 20060
General 20045
Genexxa 20037, 20000, 20278
Go Video 20240, 20432, 20526, 20614
GoldStar 20035, 20037, 20039, 20000,
20278, 20038, 21237
Goodmans 20037, 20081, 20000, 20072,
20278, 20020, 20062
Gradiente 20000, 20008
Granada 20081, 20042
Grundig 20081
Harley Davidson 20000
Harman/Kardon 20081, 20038
Harvard 20072
Harwood 20072
Headquarter 20046
Hewlett Packard 21972
HI-Q 20035, 20047, 20000
Hitachi 20035, 20037, 20045, 20000,
20042, 20041, 20089, 20105,
21037
Howard Computers 21972
HP 21972
Hughes 20042, 20739
Humax 20739
Hush 21972
Hytek 20047, 20000, 20072
iBUYPOWER 21972
ITT Nokia 20240, 20041
Janeil 20240
Jensen 20067, 20041
JVC 20067, 20041, 20008, 20061,
21162
KEC 20037, 20278
Kenwood 20067, 20041, 20038, 20046
KLH 20072
Kodak 20035, 20037
KTV 20000
LG 20037, 20240, 20038, 21037
Linksys 21972
Lloyd's 20240, 20000, 20072, 20038,
20208
Loewe 20081
Logik 20240, 20000, 20072
Lumatron 20278
Luxor 20046, 20106
LXI 20037, 20000, 20042, 20067
M Electronic 20240
Magnasonic 20037, 20240, 20000, 20072,
20278, 20020, 20593, 21278
Magnavox 20035, 20037, 20048, 20039,
20081, 20240, 20000, 20149,
20563, 20593, 20618, 21593,
21781
Magnin 20240
Marantz 20035, 20081, 20038, 20062
Marta 20037
Matsui 20037, 20209
Matsushita 20035, 20162, 20081, 21162
Media Center PC 21972
MEI 20035
Memorex 20035, 20162, 20037, 20048,
20039, 20047, 20240, 20000,
20104, 20209, 20072, 20278,
20062, 20046, 20307, 20479,
21037, 21162, 21237, 21262
Metz 20037
MGA 20060, 20240, 20043, 20061
MGN Technology 20240
Microsoft 21972
Midland 20240
Mind 21972
Minolta 20042, 20105
Mitsubishi 20060, 20048, 20047, 20000,
20042, 20067, 20043, 20041,
20061, 20807
Motorola 20035, 20048
Movie Walker 20072
MTC 20240, 20000, 20072
MTX 20000
4. REMOTE CONTROL CUSTOMIZATION continued …

16
Multitech 20039, 20000, 20072
NAD 20240, 20104
NEC 20104, 20067, 20041, 20038
New Tech 20072
Nikko 20037, 20278
Nikkodo 20037, 20278
Nishi 20240
Niveus Media 21972
Noblex 20240
Northgate 21972
Olympus 20035, 20162, 20104
Onkyo 20222
Optimus 21062, 20035, 20162, 20037,
20048, 20047, 20240, 20000,
20104, 20062, 20432, 20593,
21048, 21162, 21262
Optonica 20062
Orion 20184, 20240, 20000, 20104,
20121, 20209, 20002, 20278,
20208, 20479, 21479
Panama 20035
Panasonic 21062, 20035, 20162, 20000,
20020, 20225, 20614, 20616,
21035, 21162, 21262
Penney 20035, 20162, 20037, 20047,
20081, 20240, 20000, 20042,
20067, 20038, 21035, 21237
Pentax 20042, 20105
Philco 20035, 20081, 20000, 20209,
20479
Philips 20035, 20162, 20048, 20081,
20045, 20000, 20209, 20062,
20616, 20618, 20739, 21081,
21181
Pilot 20037
Pioneer 20162, 20081, 20042, 20067
Polk Audio 20081
Portland 20278, 20020
Presidian 21593
Profitronic 20240
Proscan 20060, 20202, 20760, 21060
Protec 20000, 20072
Protech 20072
Pulsar 20039, 20240, 20278
Pulser 20240
Quarter 20046
Quartz 20035, 20047, 20046
Quasar 20035, 20162, 20002, 21035,
21162
Radio Shack 20035, 20162, 20037, 20048,
20047, 20240, 20000, 20104,
20046, 20062, 21037, 21162
Radix 20037
Randex 20037
RCA 20060, 20035, 20048, 20240,
20045, 20000, 20042, 20149,
20105, 20106, 20202, 20760,
20807, 20880, 21035, 21060
Realistic 20035, 20162, 20037, 20048,
20047, 20240, 20000, 20104,
20121, 20278, 20046, 20062,
21162
ReplayTV 20614, 20616
Ricavision 21972
Runco 20039
Samsung 20060, 20240, 20045, 20000,
20038, 20432, 20739, 21014
Samtron 20240
Sanky 20048, 20039
Sansui 20240, 20000, 20067, 20209,
20041, 20072, 20002, 20271,
20479, 21479
Sanyo 20047, 20240, 20000, 20104,
20046, 20159, 20479
Scientific Atlanta 20008
Scott 20184, 20045, 20121, 20043,
20208
Sears 20060, 20035, 20162, 20037,
20048, 20039, 20047, 20033,
20045, 20000, 20042, 20104,
20067, 20043, 20209, 20041,
20072, 20046, 20105, 21237
Sharp 20048, 20047, 20032, 20000,
20062, 20807, 20848
Shintom 20039, 20240, 20000, 20072,
20208
Shogun 20240
Siemens 20037, 20104
Signature 20060, 20035, 20037, 20048,
20000, 20149, 20046, 20479
Singer 20037, 20240, 20072
Sonic Blue 20614, 20616
Sonographe 20046
Sony 20035, 20047, 20032, 20033,
20000, 20067, 20046, 20636,
21032, 21232, 21972
Soundmaster 20000
Stack 9 21972
STS 20042, 20105
SV2000 20000, 20072
SVA 20000
Sylvania 20035, 20081, 20000, 20043,
20593, 21593, 21781
Symphonic 20240, 20000, 20002, 20593,
21593
Systemax 21972
Tagar Systems 21972
Tandy 20000, 20104
Tatung 20048, 20081, 20000, 20067,
20041, 20008
Teac 20000, 20067, 20041
Technics 20035, 20162, 20037, 20000
Teknika 20035, 20037, 20000
Telecorder 20240
Telefunken 20041, 20208
Tevion 20479
Thomas 20000, 20002
Thomson 20060, 20041, 20202
Tisonic 20278
Tivo 20618, 20636, 20739, 21996
TMK 20240, 20000, 20208
TNIX 20037
Tocom 20240
Toshiba 20240, 20045, 20000, 20042,
20043, 20209, 20041, 20062,
20845, 21008, 21145, 21972,
21996
Tosonic 20278
Totevision 20037, 20240
Touch 21972
Trix 20037
Ultra 20045, 20278, 20020
Unitech 20240
Vector 20045
Vector Research 20184, 20038
Vextra 20072
Victor 20067, 20041, 20008
Video Concepts 20045, 20061
Videomagic 20037
Videosonic 20240, 20000, 20072
Viewsonic 21972
Villain 20000
Voodoo 21972
Wards 20060, 20035, 20037, 20048,
20047, 20081, 20033, 20240,
20045, 20000, 20042, 20043,
20041, 20072, 20038, 20149,
20046, 20062, 20479, 20760
Wharfedale 20593
White Westinghouse 20000, 20209, 20072, 20278,
20479
World 20209, 20002, 20479
XR-1000 20035, 20240, 20000, 20072,
20208
Yamaha 20041, 20038
Zenith 20037, 20039, 20033, 20000,
20209, 20041, 20278, 20479,
21139, 21479
ZT Group 21972
Satellite Receivers:
Aiwa 01514
AlphaStar 00772
Bell ExpressVu 00775
Chaparral 00216
Coolsat 01806
Crossdigital 01109
DirecTV 01377, 00392, 00566, 00639,
01639, 01142, 00247, 00749,
01749, 00724, 00819, 01856,
01076, 01108, 00099, 01109,
01392, 01414, 01442, 01443,
01444, 01609, 01640
Dish Network System 01505, 01005, 00775, 01170,
01775
Dishpro 01505, 01005, 00775, 01775
DX Antenna 01530
Echostar 01505, 01005, 00775, 01170,
01775
Expressvu 00775, 01775
Fortec Star 01821
Funai 01377
GE 00392, 00566
General Instrument 00869
GOI 00775, 01775
Hisense 01535
Hitachi 00749, 00819, 01518
Houston 00775
HTS 00775, 01775
Hughes 01142, 00749, 01749, 01442,
01443, 01444
Humax 01790
iLo 01535
Innova 00099
Jerrold 00869
JVC 00775, 01170, 01507, 01775
LG 01226, 01414
Magnavox 00724, 00722
Maspro 01530
McIntosh 00869
Memorex 00724
Mitsubishi 00749
Motorola 00869
NEC 01519
Netsat 00099
Next Level 00869
Optimus 00724
Panasonic 00247, 00701, 01508
Pansat 01807
Paysat 00724
Philips 01142, 00749, 01749, 00775,
00724, 00819, 01076, 00722,
00099, 01442
Pioneer 01142, 01442
Primestar 00869
Proscan 00392, 00566
Proton 01535
Radio Shack 00566, 00775, 00869
RCA 00392, 00566, 01142, 00775,
00855, 00143, 01392, 01442
Samsung 01377, 01142, 01276, 01108,
01109, 01442, 01609
Sharp 01489
SKY 00099
Sony 00639, 01639, 01524, 01640
Star Choice 00869
Star Trak 00772, 00869
Thomson 00392, 00566
Tivo 01142, 01442, 01443, 01444
Toshiba 00749, 01749, 00790, 00819,
01285, 01501, 01530
UltimateTV 01392, 01640
Ultrasat 01806
Uniden 00724, 00722
US Digital 01535
USDTV 01535
Voom 00869
Zenith 01856
PVRs:
ABS 21972
Alienware 21972
CyberPower 21972
Dell 21972
DirecTV 20739
Gateway 21972
Hewlett Packard 21972
Howard Computers 21972
HP 21972
Hughes 20739
4. REMOTE CONTROL CUSTOMIZATION continued …
