ANTIDOTE Carbon Jack User manual

USER MANUAL

PAGE 3
YOUR CARBONJACK
PAGE 4
LIFETIME WARRANTY
PAGE 6
PARTS LIST AND TORQUE
SPECS
PAGE 9
OTHER PARTS SPECS
PAGE 10
SETUP
PAGE 18
FLOATING DAMPING
SUSPENSION (FDS)
PAGE 20
MAINTENANCE
PAGE 22
CONTACT
TABLE OF
CONTENTS

MEET THE
CARBONJACK
Hello!
Thank you for purchasing our frame and the trust you have placed in us. Your new purchase is unlike anything else on the
market.
The ANTIDOTE team have made every effort for you to enjoy the best flow imaginable while out on the trails.
This guide will provide you with the most important information about the Carbonjack. You will certainly find some useful
details, and above all else, the key details regarding the use of the product. Please pay special attention to installing the
rear shock.
In case of any difficulties, please check the "contact" section and contact us without hesitation!
We wish you many cycling adventures – with the ANTIDOTE Carbonjack, they will enter a whole new dimension

MEET THE
CARBONJACK
Your frame is covered by a limited lifetime warranty.
In the cases of damage other than resulting from wear, we are happy to help our customers deal with defects.
Details about the complaint process can be found on our website.

LIFETIME WARRANTY TERMS
LIFETIME:
The warranty applies indefinitely for the original owner, starting with the date of purchase.
2 YEARS:
Suspension bearings
Paint finish
THIS WARRANTY DOES NOT COVER:
Damage caused by:
-Improper installation of components, parts, or accessories
-Improper assembly and maintenance
-Misuse, abuse and neglect
Damage caused in the event of an accident or crash
Labor costs incurred for parts replacement or frame swap
Bikes used for commercial purposes, such as rentals or demo bikes
The warranty is entirely void in any case of modification of the frame, or forgoing the recommended fork travel and rear
shock length and/or stroke.
Candy Ray carbon-vectran handlebars are covered by a 5-year warranty starting with the date of purchase.
MEET THE
CARBONJACK

PARTS LIST AND TORQUE SPECS
MEET THE
CARBONJACK

PARTS
LIST 6

TORQUE
SPECS 7
PART TORQUE
Nm
MAX 4-5
13-15
8-10
5
8-10
8-10
6
9
13-15
20
MAX 2
12
6-8
13-15

SIZE S M L XL
Seat insertion (mm) 195 215 245 275
Headset: semi integrated ZS44/ZS56
Seat post diameter (mm) 30,9
brake adapter: PM180 or Pm203
Rear axle: LENGTH: min171mm, max 173,5mm. THREAD: M12x1,5
(min 15mm thread length)
Recommended rear shock: Ohlins TTX22 Custom, Fox Float X2, Fox DHX2
DVO Topaz T3Air (if you have different model of rear shock,
it may be incompatible. In case of problems, please contact us)
Rear shock length and stroke (mm) 210mmx55mm
Recommended seatpost travel
Oneup V2 (mm) 120/150* 150/180* 180/210* 210
Bike Yoke (mm) 125 160 185 185
*if you gonna use longer length for the size, travel may be limited
OTHER PARTS
SPECIFICATIONS
FRAME ADDITIONALS SPECIFICATION

set your
bike

necessary
tools
SUSPENSION PUMP
Use for setting the air pressure
correctly. See page 18 and read the
instructions carefully.
ELECTRONIC CALIPER
Allows for a precise measurement of
shock hardware and spacers
TORQUE WRENCH
All bolts must be tightened using
correct torque. See the TORQUE
SPECS segment on page 8
ALLEN AND TORX BITS
Allen and torx bits are necessary for
the entire frame and bike. Bits must be
used in combination with a torque
wrench.

REAR SHOCK
INSTALATION
step 3
Carefully push the bushing in, using a
vise makes the process easier. Apply
grease
step 4
Make sure the reducer bushing is flush
with the shock body
step 5
Insert the eyelet hardware in the other
eyelet. Do not remove the flanged
bushings!
step 2
Install the eyelet reducer bushing in
the eyelet closer to the shock
piggyback
step 6
Preload the assembly in the shock
eyelet using a vice or a press
step 1
Check the type of rear shock you have
– in case of questions regarding
compatibility, contact us

step 7
step 10 step 11
step 8 step 9
step 12
Make sure that the entire eyelet
assembly measures 30 milimetres
(within 0.03mm of negative tolerance)
The piggyback and the air valve
should be on the non-drive side of the
bike
Tighten the lower shock bolt in the
lower suspension link (apply 8-10 Nm
of torque)
Rotate the shock stanchion so that the air
valve is on the same side as the shock
piggyback, and the lower eyelet is
perpendicular to the upper eyelet
In order to install the rear shock,
remove the rear wheel from the frame
and insert the shock from the
swingarm side
Tighten the upper shock bolt in the
upper suspension link (apply 8-10 Nm
of torque)
REAR SHOCK
INSTALATION

step 1 step 2 step 3
The rear mudguard is fixed in place
using quick installation tape Dual Lock
Thin 3M SJ-4570. Press the mudguard
until it clicks in place
Repeat the process on the lower end
of the mudguard
Your mudguard is in place. Good to
go!
mud guard
INSTALATION

step 2
Use Teflon grease on the wheel axle
step 3
Set the wheel in the correct position, insert the
axle and tighten it (apply 12 Nm of torque)
step 4
If the seatpost cable prevents it from being
removed, push the cable from the other side
step 1
Remove the plastic pad spacers before installing
the wheel. Remember to always install them in
the brake caliper whenever the wheel is removed

step 3
Tighten the stem clamp bolts using appropriate
torque (consult your stem manufacturer for the
torque figure). Make sure not to overtighten the
bolts, as applying too much torque can damage
the handlebar
step 1
Tighten the stem bolts using appropriate torque
(consult your stem manufacturer for the torque
figure). Use a torque wrench
step 2
Tighten the seatpost clamp bolt (apply maximum
of 4-5 Nm of torque). Use a torque wrench
wrench
step 4
Tighten the axle nut (apply
13-15 Nm of torque)

setup
cheking
STEP 1
Set the derailleur limit screws
STEP 3
Before riding the bike, make sure that the brake
lever is tightened to the handlebar
STEP 2
Adjust the derailleur using the barrel adjuster on
the shifter

SUSPENSION
SETUP
FLOATING DAMPING SYSTEM
SUSPENSION SETUP
FDS suspension is a specific system in which the proper kinematic operation occurs only when the sag is set
correctly. The system allows for high pedalling efficiency while remaining fully active on uneven ground, as
well as under braking. The correct sag is set by adjusting the air pressure or choosing the correct coil spring
firmness, appropriately for the user's weight.
Sag is the percentage of the suspension travel by which the suspension compresses when the user assumes a
stationary position on the bike. For the FDS suspension, sag should be around 20-30%, depending on the
riding style. If the riding area is mostly flat and not very bumpy, the lower value will be a better choice as it
provides more efficiency. For rough terrain, set the sag at the higher value.
Air suspension can be adjusted with the help of a suspension pump shown on page 10. In the case of coil
sprung suspension, the sag is set by using a spring of appropriate firmness for the user's weight and riding
style

SUSPENSION
SETUP
step 3
Repeat the process in the back
step 1
When adjusting the suspension, wear all riding gear (such
as riding shoes, the helmet, and protective padding) in
order for your weight to be accurate. Stand on the pedals,
assume a riding position and use the help of another
person to stabilise the bike
step 2
Once in the riding position, have your assistant push the
sag indicator all the way down, towards the suspension
seal. Carefully dismount the bike and measure the sag
value in relation to the full suspension travel
step 4
If your bike is equipped with a coil sprung shock,
measure the eye to eye length of the shock while
standing on the pedals and subtract it from 210mm
(full shock length). The difference is your sag value.
Divide it by 55 to receive a percentage value
