Antik GX-5000 User manual

数字电视前端系统
www.antiktech.com
Your digital world.
Service
Digital Headend System
GX-5000
Digital Contents Processing Platform
Operation Guide
Version 1.1
GX-5000

数字电视前端系统
www.antiktech.com
Your digital world.
Service
Digital Headend System
I
About this Guide
Thank you for purchasing the digital TV headend equipment from ANTIK. This operation guide
is intended for technical personnel who use Digital Contents Processing Platform, GX-5000, It
describes the operation of the equipment. In the following table, we provide the document release
history.
Revision History
Contact Us
Address: Čárskeho 10, 04001 Košice, Slovak Republic
Telephone: [phone]
E-mail: [email protected]
Website: www.antiktech.com
Version
Date
Document Change
1.0
2017.05
Initial Version, based on main ver.1xxx FW
1.1
2018.04
Add new modules and improve other functions, based
on main ver.30xx FW

数字电视前端系统
www.antiktech.com
Your digital world.
Service
Digital Headend System
II
WARRANTY AND SERVICE
ANTIK warrants to the Purchaser that the Products and any Repaired Products (Repairs) will be
free from defects in material and workmanship for a period of one years from the date of shipment to
the Purchaser.
The obligation of ANTIK under this warranty is limited to replacing or repairing, at ANTIK's option,
Products or Repairs found by ANTIK to be defective within the warranty period. All such replacements
and repairs shall be performed at facilities designated by ANTIK and shall be performed only after the
customer has received a Return Material Authorization (RMA) number from ANTIK and has returned
the Product to ANTIK, shipping and insurance prepaid by Purchaser.
The returned Product must be accompanied by the customer's name, address and telephone
number, the model and serial number of the Product, a statement of the purchase date and a detailed
description of the problem. Products and Repairs returned by Purchaser shall be repaired by
ANTIK using new or refurbished parts and shall be returned to Purchaser by ANTIK, shipping prepaid
by ANTIK.
This warranty shall immediately become null and void if, in ANTIK's sole judgment, the Product has
been subject to unauthorized modification, misuse, neglect, accident, improper installation or
application, alteration or neglect in use, storage, transportation or handling, or if the serial number
and/or other Product markings have been removed, defaced or altered.
ANTIK may, at its discretion, perform out-of-warranty repairs at ANTIK facilities in exchange of
customary charges, or offer a written agreement extending the terms of this warranty at a price
stated in such agreement. All repairs performed out of warranty or pursuant to an extended warranty
agreement shall be subject to all of the applicable limitations and procedures of this Agreement.The
above warranties are in lieu of all other warranties, expressed, implied, or statutory or arising by
custom of trade usage, including any warranty of merchantability of fitness for any unique, special or
express purpose, and of all other obligations of liabilities whether in contract, tort or otherwise
including, without limitation, liability for damages (whether general or special, direct or indirect,

数字电视前端系统
www.antiktech.com
Your digital world.
Digital Headend System
III
Service
consequential, incidental, exemplary) or any claim for the loss of profits or business or for damage to
goodwill.
EXTENDED WARRANTY OPTIONS
Please contact Customer Service or your reseller for information on optional extended warranties.
CUSTOMER SERVICE
Support functions provided by ANTIK's Customer Service include complete factory repair for
both in-warranty and out-of-warranty equipment. You can contact your local ANTIK product
distributor or reseller. Or you can call us or write to us for Customer Support.
A Customer Service engineer will answer warranty-related questions, discuss your specific equipment
problems, and when necessary, give you shipping instructions for returning equipment to ANTIK
for repair.
To return a Product for service or repair, you must obtain a RMA number from ANTIK's Customer
Service. The following information is required:
•Customer name, address, telephone number
•Model number
•Serial number
•Detailed description of problem
All customer-returned units must be shipped to ANTIK freight prepaid, in the original carton or
equivalent. ANTIK is not responsible for damage in transit. All repairs will require return of the entire
equipment to ANTIK. No individual modules will be accepted for repair under this contract.

数字电视前端系统
www.antiktech.com
Your digital world.
Service
Digital Headend System
4
Table of Contents
1. SAFETY PROTECTION.................................................................................................................................... 1
2. INTRODUCTION...............................................................................................................................................2
2.1. Appearance............................................................................................................................................... 2
2.1.1. LED Indicators.............................................................................................................................. 2
2.1.2. LCD............................................................................................................................................... 3
2.1.3. Key pad..........................................................................................................................................3
2.1.4. USB............................................................................................................................................... 3
2.1.5. RJ45...............................................................................................................................................3
2.1.6. SFP................................................................................................................................................ 3
2.1.7. Mini USB...................................................................................................................................... 3
2.2. Function Cards Introduction.....................................................................................................................4
2.2.1. P01MS（reMUX & Scrambler Extension Subboard）................................................................4
2.2.2. D01S2（4 x DVB-S/S2 Demodulator Module）......................................................................... 4
2.2.3. D02S2（4 x DVB-S/S2 Demodulator Module, Support Input Stream Indentifier）...................4
2.2.4. D01T2（4 x DVB-C/T/T2 Demodulator Module）.....................................................................5
2.2.5. P01CI（4 x CI De-encryption Module）..................................................................................... 5
2.2.6. C01MOD（8 x QAM/2 x COFDM Modulator Module）........................................................... 5
2.2.7. C01TM（4 x COFDM Modulator Module）...............................................................................6
2.2.8. C01ASI（5 x ASI Input/Output Module）...................................................................................6
2.2.9. P01DA（2 x DS3 Input/2 x DS3 Output/1 x ASI Adaptor Module）......................................... 7
2.2.10. D01PA（2 x Channels Multi-format Signal SD/HD Decoder Module）.................................. 7
2.2.11. D02PA（2 x Channels Multi-format Signal SD/HD Decoder Module）...................................7
2.2.12. P01EC（4 x HDMI MPEG-2/H.264 Transcoder/Encoder Module）........................................ 8
2.2.13. P02EC（4 x SDI MPEG-2/H.264 Transcoder/Encoder Module）............................................ 8
2.2.14. P01AT（4 x H.265/AVS+/MPEG-2/H.264 HD/SD Transcoder Module）............................... 9
3. LCD MENU...................................................................................................................................................... 10
3.1. Main Menu............................................................................................................................................. 12

数字电视前端系统
www.antiktech.com
Your digital world.
Service
Digital Headend System
5
3.2. Network.................................................................................................................................................. 13
3.3. Misc........................................................................................................................................................ 13
3.4. System.................................................................................................................................................... 15
4. WEB INTERFACE........................................................................................................................................... 16
4.1. Status...................................................................................................................................................... 16
4.1.1. System Status.............................................................................................................................. 16
4.1.2. TS/IP-In Status............................................................................................................................ 16
4.1.3. TS/IP-Out Status..........................................................................................................................17
4.2. Modules.................................................................................................................................................. 17
4.2.1. P01MS（reMUX & Scrambler Extenson Subboard）...............................................................18
4.2.2. D01S2（4 x DVB-S/S2 Demodulator Module）....................................................................... 29
4.2.3. D02S2（4 x DVB-S/S2 Demodulator Module, Support Input Stream Indentifier）.................33
4.2.4. D01T2（4 x DVB-C/T/T2 Demodulator Module）...................................................................33
4.2.5. P01CI（4 x CI De-encryption Module）................................................................................... 36
4.2.6. C01MOD（8 x QAM/2 x COFDM Modulator Module）......................................................... 38
4.2.7. C01ASI（5 x ASI Input/Output Module）.................................................................................43
4.2.8. D01PA（2 x Channels Multi-format Signal SD/HD Decoder Module）.................................. 46
4.2.9. P01EC（4 x HDMI MPEG-2/H.264 Transcoder/Encoder Module）........................................ 50
4.2.10. P02EC（4 x SDI MPEG-2/H.264 Transcoder/Encoder Module）.......................................... 55
4.3. TS over IP...............................................................................................................................................62
4.3.1. TS/IP In........................................................................................................................................62
4.3.2. TS/IP Out.....................................................................................................................................63
4.3.3. TS/IP Local..................................................................................................................................64
4.4. System.................................................................................................................................................... 65
4.4.1. Network....................................................................................................................................... 65
4.4.2. System......................................................................................................................................... 66
4.4.3. Misc............................................................................................................................................. 66
4.5. Remux.................................................................................................................................................... 68

数字电视前端系统
www.antiktech.com
Your digital world.
Service
Digital Headend System
1
1. SAFETY PROTECTION
This User Guide is written for operators/users of the GX-5000 to assist in installation and operation. Please
read this User Guide carefully before installation and use of the device.
This equipment is provided with a protective earth grounding incorporated in the power cord. The main plug
shall only be inserted in a socket outlet provided with a protective earth contact. Any interruption of the
protective conductor, inside or outside the device, is likely to make the device dangerous. Do not remove the
covers of this equipment. Hazardous voltages are present within this equipment and may be exposed if the
covers are removed. Only trained and approved service engineers are permitted to service this equipment.
The supplied AC power cable must be used to power the device. If the power cord becomes damaged, it must
be replaced. No operator serviceable parts inside. For the correct and safe use of the device, it is essential that
both operating and servicing personnel follow generally accepted safety procedures in addition to the safety
precautions specified in this manual. Whenever it is likely that safety protection is impaired, the device must be
made in-operative and secured against unintended operation. The appropriate servicing authority must be
informed. For example, safety is likely to be impaired if the device fails to perform the intended measurements
or shows visible damage.
WARNINGS
The mounting environment should be relatively dust free, free of excessive vibration and the ambient
temperature between 10C° to 30C°. Relative humidity of 20% to 80% (non-condensed) is recommended.
Avoid direct contact with water.
Never place the equipment in direct sunlight.
The outside of the equipment may be cleaned using a lightly dampened cloth. Do not use any cleaning
liquids containing alcohol, methylated spirit or ammonia etc.
For continued protection against fire hazard, replace line fused only with same type.
Air intake for cooling is achieved via holes at the side of the device and the fans inside. The air flow should
not be obstructed. Therefore, the device has to be placed on a flat surface, leaving some space at the sides
of the device.
When in operation, the ambient temperature should not exceed the limit of 45C°.

数字电视前端系统
www.antiktech.com
Your digital world.
Service
Digital Headend System
2
2. INTRODUCTION
2.1. Appearance
GX-5000 appearance is shown as Fig.2-1 GX-5000 Appearance.
Fig.2-1 GX-5000 Appearance
2.1.1. LED Indicators
There are 11 LED indicators on GX-5000 front panel which refer to Fig.2-2, including,
1. Power
2. Warning
3. Alarm
4. Module 1-6 Status
5. User-defined A/B (not available in this version, and LED A is defined for P01MS)
Fig.2-2 LED Indicators
Connect to the power supply, the LED indicator of Power keep lighting. The LED indicator of Waring and
Alarm will not be lighted when the device starts and operators normally. These two indicators will turn orange
or red when the device operators abnormally, which prompts the user that an error has occurred.Operating
indicators of Module 1-6 are used to indicate the operating status of slot 1 to 6 respectively, and the indicator of
Warning and Alarm is used to indicate the device status.
GX-5000

数字电视前端系统
www.antiktech.com
Your digital world.
Service
Digital Headend System
3
2.1.2. LCD
LCD is mainly for showing unit’s IP address for management. There are also some simple menus for main
frame configurations. And user can make the daughter board reboot via LCD menu. For more details, please
refer LCD menu.
2.1.3. Key pad
There are six keys on front panel, UP, Down, Left, Right, Enter and Exit. User can check and setup LCD Menu
with them.
2.1.4. USB
USB is just for firmware update. USB is one of GX-5000 three (USB, Telnet and Web) different types of
firmware update methods. User needs to put firmware into USB key root folder, update it through upgrade
menu of LCD.
2.1.5. RJ45
There are two RJ45 ports, CA and Control. CA is for scrambler connecting CA server. Control is the
management port of GX-5000.
2.1.6. SFP
There are two SFP ports for TS over IP. They can work as backup or independent.
2.1.7. Mini USB
Mini USB is for debugging problem. They are USB to RS232 port actually. Before using this function, user
needs to install a RS232, for example Putty.exe, to enable this function.

数字电视前端系统
www.antiktech.com
Your digital world.
Service
Digital Headend System
4
2.2. Function Cards Introduction
2.2.1. P01MS（reMUX & Scrambler Extension Subboard）
32 independent DVB-TS re-Multiplex and Scramblers
Compliant with ISO13818 & EN300 468
Support 4 different local or remote CAS Simulcrypt processing
Support DVB CAS & BISS 1/E
Support error alarm of TS level
Support PID filtering, pass through and remapping
Support PSI/SI tables insertion or re-generation
Support PCR re-stamp & calibrate
Self temperature monitoring
2.2.2. D01S2（4 x DVB-S/S2 Demodulator Module）
4 x F type Female, 75Ω
Input Frequency Range: 950 ~ 2150 MHz
Input RF level: -65dBm ~ -25dBm
Symbol Rate: 2 ~ 45MSps
Roll Off factor: 0.35(DVB-S QPSK), 0.35/0.25/0.2(DVB-S2 8PSK)
FEC Puncture Rate: 2/3, 3/4, 3/5, 5/6, 8/9, 9/10(DVB-S2 8PSK), 1/2, 2/3, 3/4, 5/6, 6/7, 7/8(DVB-S QPSK)
Support BISS-1/E de-encryption(up to 40 PIDs de-encryption per tuner input)
Support T2-MI(up to 8 PLP IDs demodulation per tuner input)
2.2.3. D02S2（4 x DVB-S/S2 Demodulator Module, Support Input Stream Indentifier）
4 x F type Female, 75Ω
Input Frequency Range: 950 ~ 2150 MHz
Input RF level: -65dBm ~ -25dBm
Symbol Rate: 2 ~ 45MSps
Roll Off factor: 0.35(DVB-S QPSK), 0.35/0.25/0.2(DVB-S2 8PSK)

数字电视前端系统
www.antiktech.com
Your digital world.
Service
Digital Headend System
5
FEC Puncture Rate: 2/3, 3/4, 3/5, 5/6, 8/9, 9/10(DVB-S2 8PSK), 1/2, 2/3, 3/4, 5/6, 6/7, 7/8(DVB-S QPSK)
Support BISS-1/E de-encryption(up to 40 PIDs de-encryption per tuner input)
Support T2-MI(up to 8 PLP IDs demodulation per tuner input)
Support PLS (0 ~ 262141)
ISI ID: 1 ~ 255 user configurable
2.2.4. D01T2（4 x DVB-C/T/T2 Demodulator Module）
4 x F type Female, 75Ω
Full compliant for DVB-T2 v1.3
Input Frequency, 48 ~ 860 MHz(DVB-C), 104 ~ 862 MHz(DVB-T/T2)
Input Level, -15~ 15dBm(DVB-C), -70 ~ -20dBm(QEF, DVB-T/T2)
Symbol Rate, 1 ~ 7MSps（ITU J.83 Annex A DVB-C）
Constellation, 16/32/64/128/256 QAM(DVB-C), QPSK/16QAM/64QAM(DVB-T), QPSK/
16QAM/64QAM/256QAM(DVB-T2)
Bandwidth, 6/7/8 MHz
FFT Mode, 2K/8K(DVB-T), 1K/2K/4K/8K/16K/32K(DVB-T2)
Guard Interval, 1/4, 1/8, 1/16, 1/32(DVB-T) 1/4, 5/32, 1/8, 5/64, 1/16, 1/32, 1/64, 1/128(DVB-T2)
FEC Code Rate, 1/2, 2/3, 3/4, 5/6, 7/8(DVB-T) 1/2, 3/5, 2/3, 3/4, 4/5, 5/6(DVB-T2)
2.2.5. P01CI（4 x CI De-encryption Module）
4 x Independent Common Interface(DVB-CI)slots
Multiple programs CAS or BISS-1/E De-encryption
CAM watchdog
Compatible with most of popular CA systems
2.2.6. C01MOD（8 x QAM/2 x COFDM Modulator Module）
2 x F type Female, 75Ω（1 x main output，1 x -20dB monitor output）
Support QAM/COFDM Modulation Mode(cannot work at the same time)
2 groups of 4 adjacent channel carriers QAM RF output, 2 x Un-adjacent channel carries COFDM RF
output

数字电视前端系统
www.antiktech.com
Your digital world.
Service
Digital Headend System
6
RF output range: 48 ~ 996MHz, step by 1KHz
Symbol rate: 2.5 ~ 6.99MBauds
RF total output level: 94 ~ 118dBuV(110dBuV each carrier)
FFT Mode, 2K/4K/8K
Spurious rejection > 55dB
Output return loss -10dB
QAM Modulation, support ITU-T J.83 Annex A, C
Modulation Mode, 16QAM, 32QAM, 64QAM，128QAM，256QAM
MER > 36dB, BER < 10E-9
2.2.7. C01TM（4 x COFDM Modulator Module）
2 x F type Female, 75Ω（1 x main output，1 x -20dB monitor output）
4 x Un-adjacent channel carries COFDM RF output
RF output range: 100 ~ 862MHz, step by 10KHz
RF total output level: 84 ~ 114dBuV
Modulation Mode, QPSK/16QAM/64QAM
FFT Mode, 2K/4K/8K
Spurious rejection > 55dB
Output return loss -10dB
MER > 36dB, BER < 10E-5
2.2.8. C01ASI（5 x ASI Input/Output Module）
5 x BNC Female, 75Ω
Standard: DVB-ASI, EN50083-9
Up to 5 x ASI Input
Up to 5 x ASI Output
Maximum bit rate(each ASI): 213Mbps
Minimum accepting sensitivity: 200mV
Maximum input Voltage: 880mV
ASI Input or Output can be switched

数字电视前端系统
www.antiktech.com
Your digital world.
Service
Digital Headend System
7
Support T2-MI (In the T2-MI mode, ASI-5 is configured to input which can process 4 PLP ID, ASI-1 to
ASI-4 are configured to output which can select PLP ID TS to output via Web)
2.2.9. P01DA（2 x DS3 Input/2 x DS3 Output/1 x ASI Adaptor Module）
5 x BNC Female, 75Ω
Standard: DVB-ASI, EN50083-9 / ITU-T G.703
Frame Structure: ITU-T G.752 / ITU-T G.804
ASI Input or Output can be switched
Bit rate: 44.736Mbps
2.2.10. D01PA（2 x Channels Multi-format Signal SD/HD Decoder Module）
2 x HDMI 1.3(up to 1080i), 1 x D-sub 15 female(can be translated 2 x CVBS via cable)
Video Format: MPEG-2(MP@ML for SD, MP@HL for HD), MPEG-4/H.264 AVC Part 10(MP@L3 for
SD,[email protected] for HD), AVS+
Audio Format: MPEG-1 Layer II, AAC-LC, HE AAC V1/V2, AC3, AC3+
Aspect Ratio: 16:9, 4:3 Self-adaptation
Resolution and Frame Rate: 1080ix30, 1080ix29.97, 1080ix25, 720px60, 720px59.94, 720px50, 576ix25,
480ix29.97
Video PID Bit Rate: < = 50Mbps
2.2.11. D02PA（2 x Channels Multi-format Signal SD/HD Decoder Module）
3 x BNC Female 75Ωfor 2 x ASI/SDI , 1 x Genlock input
BNC for SDI Output or ASI Input/Output can be switched
1 x D-sub 15 female(can be translated 2 x CVBS via cable)
Video Format: MPEG-2(MP@ML for SD, MP@HL for HD), MPEG-4/H.264 AVC Part 10(MP@L3 for
SD,[email protected] for HD), AVS+
Audio Format: MPEG-1 Layer II, AAC-LC, HE AAC V1/V2, AC3, AC3+
Aspect Ratio: 16:9, 4:3 Self-adaptation
Resolution and Frame Rate: 1080ix30, 1080ix29.97, 1080ix25, 720px60, 720px59.94, 720px50, 576ix25,
480ix29.97

数字电视前端系统
www.antiktech.com
Your digital world.
Service
Digital Headend System
8
Video PID Bit Rate: < = 50Mbps
2.2.12. P01EC（4 x HDMI MPEG-2/H.264 Transcoder/Encoder Module）
4 x HDMI Input interface
Compliant with H.264/AVC Baseline, Main & High Profile @ L4.0 or less & MPEG-2 MP@ML
Independent Transcoding/Encoding mode control
Video Input Resolution: 1080i, 720p, 576i, 480i.
Support video resoultion downscaling(vertical & horizontal adjustable respectively).
Audio Coding: MPEG-1 Layer II, MPEG-2/4, AAC-LC/HE-AAC
Support VBR & CBR mode
Support GOP settings
Sampling Format: 4:2:0, 10-bit, YCbCr
Compression Bit Rate: 300K ~ 20Mbps
Aspect Ratio: 4:3, 16:9
2.2.13. P02EC（4 x SDI MPEG-2/H.264 Transcoder/Encoder Module）
4 x SDI Input, BNC Female 75Ω
Compliant with H.264/AVC Baseline, Main & High Profile @ L4.0 or less & MPEG-2 MP@ML
Independent Transcoding/Encoding mode control
Video Input Resolution: 1080i, 720p, 576i, 480i.
Support video resoultion downscaling(vertical & horizontal adjustable respectively).
Audio Coding: MPEG-1 Layer II, MPEG-2/4, AAC-LC/HE-AAC
Support VBR & CBR mode
Support GOP settings
Sampling Format: 4:2:0, 10-bit, YCbCr
Compression Bit Rate: 300K ~ 20Mbps
Aspect Ratio: 4:3, 16:9
Support second audio encoding with the extension card (only P02EC-PLUS)
Up to 8 x transcoder with the extension card (only P02EC-PLUS)

数字电视前端系统
www.antiktech.com
Your digital world.
Service
Digital Headend System
9
2.2.14. P01AT（4 x H.265/AVS+/MPEG-2/H.264 HD/SD Transcoder Module）
Support H.265/AVS+ HD/SD transcode to H.264 HD/SD or MPEG2 SD, and MEPG2 HD/SD transcode to
H.264 HD/SD, and H.264 HD/SD transcode to MPEG2 SD
Support AC/AC3+ transcode to MPEG/AAC, or passthrough(cannot work in the same time)
Compliant with H.264/AVC Baseline, Main & High Profile @ L4.0 or less & MPEG-2 MP@ML
Support video resoultion downscaling(vertical & horizontal adjustable respectively).
Audio Format: MPEG-1 Layer II, MPEG-2/4, AAC-LC/HE-AAC
Support VBR & CBR mode
Support GOP settings
Sampling Format: 4:2:0, 10-bit, YCbCr
Compression Bit Rate: 300K ~ 20Mbps
Aspect Ratio: 4:3, 16:9

数字电视前端系统
www.antiktech.com
Your digital world.
Service
Digital Headend System
10
3. LCD MENU
There is a LCD Menu for users to configure main frame and front interfaces. User can press enter key to start to
setup the unit. The LCD menu overview showed as below:

数字电视前端系统
www.antiktech.com
Your digital world.
Service
Digital Headend System
11

数字电视前端系统
www.antiktech.com
Your digital world.
Service
Digital Headend System
12
3.1. Main Menu
The LCD will show GX-5000 and management IP address when it boot up. User can press any key of front
panel to enter Main menu. Main menu includes 3 submenus, Network, Misc and System.

数字电视前端系统
www.antiktech.com
Your digital world.
Service
Digital Headend System
13
3.2. Network
Network menu includes IP address, Subnet Mask, Gateway, MAC Address and Web GUI Login for
management RJ45 port. User can see the below graph as reference. MAC address is read only. Web GUI Login
is for setup or reset web browser login ID and password, especially users forgot the ID or password.

数字电视前端系统
www.antiktech.com
Your digital world.
Service
Digital Headend System
14
3.3. Misc
This menu includes several unit’s status, Date, Time, Temperature, Fan status, Power supply, Error Operate and
Device label. User can setup Date and Time to display via front panel. Temperature is unit inside temperature.
Fan status will show error if any fan does not work. Power supply is the dual power supply’s status. It will show
error information when the power supply doesn’t work. Error Operate is to reset warned errors. Device label is
for setting up unit names which will show on LED and Web browser.
