antoniolupi AL Studio MODULO6 User manual

Art. Modulo 6
MODULO6
design AL Studio

2
Art. Modulo 6
H
C
H
C
110/220 V ~
110/220 V ~
Installation manualASSEMBLY DIAGRAMS FOR MIRRORS
P.S.: Remove the corner protection only when isntallation is completed. We advise to make sure the lighting wires are prepared so they are in
correspondence to the center of the mirror.
1_ To attach the mirror to the desired height H. Mark the position of the xing holes of the brackets S, in such a way that the fold of such is located
at the height C

3
Art. Modulo 6
LED
Lampada 1 / Lamp 1 1 + |2 -
Lampada 2 / Lamp 2 3 + | 4 -
1
2
3
4
115V  230V AC
AC/DC CONNECTING BOX /
SCATOLINO DI CONNESSIONE
C
S
H
C
Installation manualASSEMBLY DIAGRAMS FOR MIRRORS
4_ Hang the mirror
2_ Fix the bracket S at the determined height, put the second bracket in
level with the rst and fasten it to the wall.
3_ Make the electrical connection between the network and the AC
adapter / DC, using the small box of the supplied connection as indicated.
