Antronix CAG ONE User manual

USER MANUAL
Accuracy. Consistency. Performance
SINCE 1987

DIMENSION, WEIGHT AND ELECTRICAL
CONSUMABLE
Weight: 25 kg / 55 lbs
Length: 720 mm / 28.5”
Height: 220 mm / 8”
Dept: 260 mm / 10.5”
Power: 110 V, 60 Hz, 300W - 3A
250 Pairs / Grinding Wheel
1000 Pairs / Spinner Dresser
250 Pairs / Honing Stone

TECHNICAL DESCRIPTION
1. Front dust panel
2. Skate holder
3. Touch keyboard and Safety switch
4. Grinding wheel height adjuster
5. Dressing arm
6. Power cord
7. Vacuum cleaner Servocommander plug
8. Grinding wheel pressure adjuster
9. Grinding wheel
10. Spinner Diamond Dresser
5
10
9
8
7
2
3
4
6
1

INCLUDED ACCESSORIES AND SUPPLIES
SKATE SHARPENING CHART
1 x Servocommander 6 x Grinding wheels 6 x Honing stones
3 x Diamond Spinners 1 x Power cord 1 x CAG ONE
Transport case

INSTALLATION
1. PULL OUT THE MACHINE
FROM THE TRANSPORT
BOX
TAKE OFF BOTH TRANSPORT SCREWS
2. INSTALL THE DRESSING HANDLE AND
THE VACCUM CLEANER HOSSE (OPTIONAL)
INSTALL THE DRESSING HANDLE INSTALL THE VACCUM CLEANER
HOSSE (OPTIONAL)

INSTALLATION (Suite)
3. GENTLY MOVE THE SKATE
HOLDER DEVICE TO THE LEFT
4. PLUG THE POWER CORD, SERVOCOMMANDER
AND VACCUM CLEANER (OPTIONAL)
PLUG THE SERVOCOMMANDER PLUG THE VACCUM CLEANER CORD
IN THE "VACUUM" SLOT, AND TURN
IT ON (OPTIONAL)

INSTALLATION (Suite)
5. INSTALL THE GRINDING WHEEL
AND THE SPINNER DRESSER
6. ADJUST THE SHARPENING
GRINDING WHEEL HEIGHT
INSTALL THE GRINDING WHEEL
TURN THE POWER ON
INSTALL THE SPINNER DRESSER

INSTALLATION (Suite)
1. START SHARPENING 3. 1 SHARPENING CYCLE
2. CANCEL SHARPENING 4. 5 SHARPENING CYCLES
5. REGULAR SHARPENING 6. FINISHING
& DRESSING
1
25
4
6
3
7. ADJUST GRINDING WHEEL
PRESSURE

INSTALLATION (Suite)
8. SOFTLY SHAPE THE GRINDING WHEEL
OVER THE SPINNER DRESSER TO REACH
A REALLY SMOOTH FEELING
9A. CAGONE:
INSERT THE SKATE,
TURN THE HANDLE DELICATELY,
PRESS START
SHAPE THE GRINDING WHEEL FOR
2-3 SECONDS EVERY 3 PAIRS OF
SKATES
SHAPE THE GRINDING WHEEL FOR
2-3 SECONDS EVERY 3 PAIRS OF
SKATES
SHARPENING PROCESS COMPLETE,
FIRMLY REMOVE SHARPENING BURR
ON BOTH SIDES OF THE BLADE WITH
THE HONING STONE

INSTALLATION (Suite)
*10. ADJUST THE GRINDING WHEEL HEIGHT TO
SHARPEN FIGURE SKATES
RESURFACE THE WHEEL WHEN THE
NEW DIAMOND IS INSTALLED
9B. CAGONE PRO :
PRESS THE LEVER,
INSERT THE SKATE,
PRESS START
SHARPENING PROCESS COMPLETE,
FIRMLY REMOVE SHARPENING BURR
ON BOTH SIDES OF THE BLADE WITH
THE HONING STONE
*If your Cag One machine is equiped with the Self-Centering Blade holder #9B, forget about the step # 10

INSTALLATION (Suite)
REPLACE THE GRINDING WHEEL WHEN
SHE DOESN'T TOUCH THE SPINNER
DRESSER ANYMORE
REPLACE THE DIAMOND SPINNER
DRESSER WHEN GROOVED OR WHEN
BOUNCING
*10. ADJUST THE GRINDING WHEEL HEIGHT TO
SHARPEN FIGURE SKATES
MOVE THE WHEEL DOWN WITH THE
HEIGHT AJUSTER TONE "SAVE THE SPIKES"
NEW EXCESSIVE USAGE
*If your Cag One machine is equiped with the Self-Centering Blade holder #9B, forget about the step # 10
