Anywave PA-140W User manual

ANYWAVE
PA-140W
User Manual
Version 1.4 –September 12, 2014

PA-140W User Manual
ACT-140PA-USR-DOC-V1.4, 09/12/2014 Page 2 of 13
Copyright Notice
Copyright © Anywave Communication Technologies, Inc. 2014, All rights reserved.
No part of this publication may be reproduced, translated, transcribed, stored in a retrieval
system, or transmitted into any form or by any means, without the express written permission
of Anywave Communication Technologies, Inc.
FCC Compliance
This equipment complies with relevant portions of Parts 2, 73, & 74 of the FCC rules
governing LPTV operation.
Disclaimer
Information provided by Anywave Communication Technologies is believed to be accurate
and complete; however, no liability can be assumed for its use.
The manufacturer makes no representations or warranties, either expressed or implied, by or
with respect to anything in this manual, and shall not be liable for any implied warranties of
fitness for a particular purpose or for any indirect, special, or consequential damages.
Information in this document is subject to change without notice and does not represent a
commitment on the part of the manufacturer.
USE OF THIS PRODUCT IN A MANNER OTHER THAN DESCRIBED IN THIS
MANUAL MAY RESULT IN DAMAGE TO THE EQUIPMENT AND/OR PERSONAL
INJURY.
PLEASE READ THIS MANUAL IN ITS ENTIRETY BEFORE ATTEMPTING TO
INSTALL THE EQUIPMENT. CONTACT ANYWAVE WITH ANY QUESTIONS OR
CONCERNS YOU MAY HAVE.
Anywave Communication Technologies Inc.
300 Knightsbridge Parkway, Suite 150, Lincolnshire, IL 60069
Tel: [phone]
Fax: [phone]
http://www.anywavecom.com/en/

PA-140W User Manual
ACT-140PA-USR-DOC-V1.4, 09/12/2014 Page 3 of 13
Unpacking
Carefully unpack the equipment and perform a visual inspection to determine if any apparent
damage has occurred during shipment. Please notify the delivery carrier and Anywave
immediately if shipment damage has occurred. Retain all original shipping materials.
Please locate and reference the Packing Check List to verify you have received all
components of your system. Retain the Packing Check List for future reference.
Also, please identify and remove all packing materials and supports (foam pads, etc.) prior to
initial turn on of the equipment.
Returns and Exchanges
Written approval and a Return Authorization Number (RAN) are required from Anywave for
all equipment returns. Please direct all return inquiries to the Anywave Service Department at
[email protected], providing the Sales Order number and Serial Number(s) of
the equipment. Complete details regarding the nature and circumstances of your return must
be included in your RAN request. Proper handling and return shipping instructions will be
provided with an approved RAN number.
Technical Support
Technical support and troubleshooting assistance for Anywave Transmitters is available
through the Anywave Service Department during normal business hours (8:00 AM - 5:00 PM
CST) at [phone].Email questions to [e-mail].
Note: For all service and support requests, you will need to provide the Serial Number of the
equipment with your Sales Order number. For future reference, please record that information
here:________________________________________

PA-140W User Manual
ACT-140PA-USR-DOC-V1.4, 09/12/2014 Page 4 of 13
WARNING
THE VOLTAGES, CURRENTS, AND RF ENERGY IN THIS EQUIPMENT ARE
DANGEROUS. PERSONNEL MUST AT ALL TIMES OBSERVE ALL SAFETY
WARNINGS, INSTRUCTIONS, AND REGULATIONS.
IN THE CASE OF EMERGENCY, ENSURE THAT ALL POWER HAS BEEN
DISCONNECTED.
ALWAYS DISCONNECT POWER BEFORE REMOVING COVERS,
ENCLOSURES, OR SHIELDS. DO NOT PERFROM SERVICE ON THE
EQUIPMENT WHEN ALONE OR FATIGUED. KNOW YOUR EQUIPMENT AND
DO NOT TAKE RISKS.
This manual is provided as a general guide for trained and qualified personnel well aware of
the dangers inherent in handling potentially hazardous electrical transmission equipment.
The installation, operation, maintenance and service of this equipment involves risks both to
personnel and equipment, and must ONLY be performed by qualified personnel exercising
due care. Anywave Communication Technologies, Inc. shall not be responsible for injury or
damage resulting from improper handling or from the use of improperly trained or
inexperienced personnel performing such tasks.
All local building and electrical codes as well as fire protection standards must be observed in
the installation and operation of the equipment.

PA-140W User Manual
ACT-140PA-USR-DOC-V1.4, 09/12/2014 Page 5 of 13
Contents
1 Product Appearance ..........................................................................................6
1.1 Front Panel.....................................................................................................6
1.2 Back Panel .....................................................................................................7
2 Specifications....................................................................................................8
3 Control Interface...............................................................................................9
3.1 Local Control Interface..................................................................................9
3.2 Serial Port Interface .......................................................................................9
3.3 Web Interface...............................................................................................10

PA-140W User Manual
ACT-140PA-USR-DOC-V1.4, 09/12/2014 Page 6 of 13
1 Product Appearance
1.1 Front Panel
RF Button
Press the RF button to turn the RF signal ON (inside blue light will light up).
Press the RF button again to turn the RF signal OFF (inside blue light will be off).
LED_PWR
Blue light will be on when the DC voltage of internal power supply is within the normal range
(48 VDC ~ 52 VDC).
Blue light will flash when the DC voltage of internal power supply is out of the normal range (48
VDC ~ 52 VDC).
Blue light will be off when the external power supply is turned off, or internal power supply
module does not work.
LED_FWD
Blue light will be on when RF_OUT has power output.
Blue light will be off when the RF button is turned off, or the PA enters the auto-protection mode
and therefore shuts down its RF output. There are several situations which will result in
auto-protection mode, such as the input power is too high, the reflected power is too high, or the
temperature is too high.
LED_RFL
Red light will be off when the reflected power is normal. (Threshold configurable)
Red light will be on when the reflected power is too high. It may be caused by no load connected
to port RF_OUT. In this case, the PA will enter auto-protection mode and there will be no RF
output.
LED_TEMP
Red light will be off when temperature is normal (≤ 140 oF).
Red light will be on when system temperature is too high (> 140 oF). It may be caused by a
broken cooling system. In this situation, the PA will enter auto-protection mode and there will be
no RF output.
Note:
1) The front fan covers can be removed to clean the air intake path. No screw driver is needed, and no
disassembly of the PA is required.
2) When a warning occurs and the PA enters auto-protection mode, the only way to clear this state is to
cycle power on the PA module once the problem(s) is resolved. Otherwise all warning LEDs will
remain on even if the problem(s) no longer exists.

PA-140W User Manual
ACT-140PA-USR-DOC-V1.4, 09/12/2014 Page 7 of 13
1.2 Back Panel
RF_IN
Connector: N
Impedance: 50 Ω
Rated Power: +1.76 dBm ± 1 dB
Note: If input power from RF_IN is lower than rated input value, the output power will be lower
than rated output power accordingly. This is because the PA has a fixed gain of 50 dB ± 1 dB. If
the input level from RF_IN is higher than the rated value, it will result in RF output distortion
and performance deterioration. If the input level is more than 1 dB higher than the rated value or
the output power is higher than 140 W, it may trigger the current-limiting function of the internal
power supply. The PA will enter the auto-protection mode, and there will be no RF output.
RF_OUT
Connector: N
Impedance: 50 Ω
Rated Power: 140 W (+51.46 dBm)
Note: RF_OUT must be connected with a load, otherwise the PA will enter the auto-protection
mode and there will be in no RF output. Please note that the PA is designed to withstand any load
conditions, including no load at all, without damaging the PA. However it is strongly suggested
to have a load connected with proper impedance.
MONITOR (loop out of RF_OUT)
Connector: BNC female
Impedance: 50 Ω
Rated Power: +1 dBm ± 3 dB
Note: It is OK to leave this port open without load.
RS232-A
Connector: DB9-M
Note: Connected to REMOTE (RS232) port ofACT-5X, which is used
for control and communication between the PA and the exciter.
RS232-B:
Connector: DB9-M
Note: For customers’remote control to both the PA and the exciter (The
exciter REMOTE(RS232) port is connected to the PA RS232-A
port)

PA-140W User Manual
ACT-140PA-USR-DOC-V1.4, 09/12/2014 Page 8 of 13
RJ45
Connector: 10M/100M Ethernet
Note: For customers’remote control to the PA.
FWD
Connector: SMA
Input Level: -20 to +10 dBm
Note: External Coupler Forward sample for PA_FWD Power Meter.
REF
Connector: SMA
Input Level: -20 to +10 dBm
Note: External Coupler Reflected sample for PA_REF Power Meter.
Note:
1) The back fan covers can also be removed to clean the air intake path. No screw driver is needed, and
no disassembly of the PA is required.
2 Specifications
Environment
Operation Temperature: -10 oC ~ +60 oC (+14 oF ~ +140 oF)
Operation Humidity: 20 % ~ 90 % (non-condensing)
Atmospheric Pressure: 86 kPa ~ 106 kPa
Power Supply
Voltage: 176 ~ 300 VAC (full load) / 90 ~ 176 VAC (half load)
Frequency: 47 ~ 63 Hz
RF Performance
Frequency: 473 MHz ~ 794 MHz
VSWR: ≤ 1.5
Shoulder Level: ≥ 30 dBc (before pre-correction @ 140 W)
Note
1) The electrical interface characteristics are measured at rated power. Values may change.
2) Operating in abnormal conditions may result in damage to the equipment. Long operating hours in
severe environments may reduce the reliability of the entire system, which may cause permanent
damage to equipment. Make sure all electrical interface characteristics and environmental parameters
are within the defined range listed above before operating this equipment.

PA-140W User Manual
ACT-140PA-USR-DOC-V1.4, 09/12/2014 Page 9 of 13
3 Control Interface
3.1 Local Control Interface
Local control and monitoring of the PA unit is accomplished via the ACT-5X Exciter front panel user
interface. Use a standard serial cable to connect the PA D9 RS232-A port to theACT-5X Exciter D9
REMOTE (RS232) port. With this connection established, all the PA information will be displayed in the
PAC sub-menu in the advanced menu ofACT-5X exciter, as shown below:
Table 1 PAC sub-menu in Advanced Menu
VOL_9
VOL_50
CUR_50
PA_FWD
PA_REF
GV
VSWR
PA_TEMP
PA__LVL
CUR1_50
Value
8.76V
50.35
12.04A
171.92W
0.77W
1.69V
1.14
117.3℉
140W
9.8A
Content
Voltage of
9V DC
supply
Voltage of
50V DC
supply
Current of
50V DC
supply
Forward
power of PA
Reflected
power of PA
Grid
Voltage
(bias
voltage)
Voltage
standing
wave ratio
Temperature
of PA
PA rated
power
Device
Current
Note: The displayed settings and numbers in the tables below are for illustration purposes only and may be
different from those in actual use.
A second sub-menu is available for configuring the PAnetworking settings. Enter the main menu of
ACT-5X exciter and locate the PA_CNFG sub-menu to setup the IP, GATEWAY and MASK PA
networking parameters.
Table 2 PA_CNFG sub-menu in Control Mode
IP
GATEWAY
MASK
Default
192.168.001.210
192.168.001.001
255.255.255.000
Options
***.***.***.***
***.***.***.***
***.***.***.***
3.2 Serial Port Interface
The port RS232-B of PA is reserved to be used as serial port interface for remote control.

PA-140W User Manual
ACT-140PA-USR-DOC-V1.4, 09/12/2014 Page 10 of 13
3.3 Web Interface
Enter the IP address of the PA (the default value is 192.168.1.210) in a web browser's address bar to cause
a login window to pop up.
There are two tiers of web interface available. The first “guest” tier is limited in monitoring and control,
allowing users to retrieve information such as PA status, network configuration, and alarms. The guest
account is accessed with a user name and password of "guest" and "guest" (case sensitive). The second
“admin” tier provides full status and control of the PA and is accessed with a username and password of
"anywavecom" and "anywavecom" (case sensitive).
Guest Web Page

PA-140W User Manual
ACT-140PA-USR-DOC-V1.4, 09/12/2014 Page 11 of 13
Admin Web Page

PA-140W User Manual
ACT-140PA-USR-DOC-V1.4, 09/12/2014 Page 12 of 13
Note:
1) To refresh the status of the PA unit, manually click the “Query”button(s) on the page, or set up the
“AUTO-REFRESH-CYCLE”for the auto periodic refreshing of status.
2) Configuration settings including “POWER_DEGREE”, “EXCITER_TYPE”, internet access
settings and “REFRESH-CYCLK”may be modified via this PA web GUI.

PA-140W User Manual
ACT-140PA-USR-DOC-V1.4, 09/12/2014 Page 13 of 13
Anywave Communication Technologies Inc.
300 Knightsbridge Parkway, Suite 150, Lincolnshire, IL 60069
Tel: [phone]
Fax: [phone]
Email: [email protected]
http://www.anywavecom.com/en/
