Anywire ASLINKSENSOR User manual

Transmission cable
DP (Red)
DN (Black)
[Function]
AnyWireASLINK System Products Guide
ASLINKSENSOR
[Photoelectric Diffuse Reflection Type (IP67)]
BS-H0317-1K
[Warranty]
[Type]
CAUTION
！
WARNING
！
CAUTION
！
WARNING
！
BS-H0317-1K 1 optical axis
AnyWireASLINK photoelectric sensor:
Diffuse reection type, bit operation
[Notes on Safety]
Precautions that must be observed in order to use this system safely are
indicated as shown below. You must observe these precautions.
A WARNING indicates a potentially hazardous situation which, if not
handled correctly, could result in death or serious injury.
A CAUTION indicates a potentially hazardous situation which, if not
handled correctly, may result in personal injury or property damage.
■Warranty period
The warranty on the delivered Product shall continue to be effective for one (1)
year after the delivery thereof to a location as designated by the original owner.
■Scope of warranty
Should a defect occur in any part of the Product during the foregoing warranty
period when it is used normally in acordance with the specications described in
this User's Manual, the Company shall replace or repair the defect free of
charge, except when it arises as a result of:
[1] Misuse or abuse of the Product by the owner;
[2] Fault caused by other than the delivered Product;
[3] The unauthorized modication or repair of the Product by any person other
than the Company's personnel;
[4] Any unusual force of nature, disaster or other cause beyond the Company's
control.
The term "warranty," as used herein, refers to the warranty applicable to the
delivered product alone. The Company shall not be liable for consequential or
incidental damages resulting from any malfunction.
■Repair at cost
After the expiration of the warranty period, the owner shall be responsible for all
costs and expenses incurred for the troubleshooting and repair of the Product.
Even during the warranty term, the Company shall repair any defects arising
from causes other than within the scope of the warranty as specied above, at
the owner's cost.
○System Safety
This system is intended for general industrial applications. It does not
have functions for supporting applications requiring higher levels of
safety such as safety-related devices or accident prevention systems.
The product must not be used for these purposes.
○Always turn off the power before attempting to mount or replace.
○Prolonged continuous ow of a rated load current or higher or a transit
current due to load short-circuit, etc., in the hybrid unit including the
output unit and the output circuit may result in smoking or ring. An
external safety device such as a fuse must be installed.
○System power supply
Use a stable, 24V DC power supply. Use of an unstable power supply
may cause problems with the system.
○Separately route high-voltage and power cables
Although the AnyWireASLINK has a high noise margin, lay the transmis-
sion lines and I/O cables so as to keep them away from high-voltage
and power cables.
○Connectors and terminals
・Pay careful attention to the length and installation of cable wiring to
ensure that connectors and cables are neither stressed nor discon-
nected even if they are stressed.
・Make sure to prevent any metal objects from getting inside the
connectors or the terminal blocks.
・Short-circuits caused by metal objects or mis-wiring are likely to
damage the device.
○Do not impose any external loads on the units. Doing so may cause a
failure.
○Do not disconnect or reconnect between the transmission line and slave
units. A malfunction may occur.
○Use the AnyWireASLINK within the range of the specications and
conditions shown below. [Name of each part]
[Contents in package]
BS-H0317-1K Unit … 1 unit
*Please purchase the attachment tting separately.
■Diffuse reection type Input indicator
ALM indicator
Light emitting surface
Attachment tap 2-M3
READER/WRITER
ARW-04 Ver.04-1.01LotNo.***
MADE IN JAPAN
A “Ver.*.**” is
described on
this label.
The version is
displayed when
POWER is on.
Front Back
ARW-04
-BSH03171K 1/8-
ASLINKSENSOR 2-wire (non-insulation)
Diffuse reection type
Sensitivity adjustment value (threshold)
Hysteresis
Alarm judgment value
Alarm judgment time
Light ON/dark ON
Operation mode
Light receiving display switching
Delay timer
One shot
Sensing level drop
Slave unit voltage drop
Waterproof (IP67)
Detection method
Model
Function
*An "address writer ARW-04 (Ver.04-1.01 or higher)" is required for setting to
the unit. Prepare it together.
Setting port
LINK indicator

[Connection Example]
You can select use of either a two-wire or four-wire terminal for the AnyWireASLINK according
to the load current.
This Products Guide describes a two-wire (non-isolated) terminal.
If the load current is small, using a two-wire (non-isolated) terminal allows for achieving
simplied wiring without a local power supply.
If you are prioritizing the sites of concentrated loads or the number of units connected,
hybridization with a four-wire (isolated) terminal, which supports local power supply, is also
possible.
Make sure to use a four-wire (isolated) terminal in the case of input and load driving using an
external power supply.
In the case of hybridization, refer to the Four-Wire (Isolated) Terminal Products Guide
separately.
■Relationship between the size and length of
the transmission line and the supply current (Table 1)
CAUTION
- Refer to Table 1 so that the size and length of the transmission
line and the allowable supply current lie within an appropriate
range.
- Connect the same symbols (DP, DN) correctly between the
AnyWireASLINK master and each device.
- The branching length or branch number has no limitation.
- Include the length of the cable provided with the terminal in the “total line length.”
- Connect the terminator “BT0 (polar)” to the terminal on the transmission line farthest from
the AnyWireASLINK master.
■ Example of mixture of 2-wire (non-insulation), 4-wire (insulation) terminals
ALM
LINK
IN
ALM
LINK
IN
4P link connector is
convenient for
branching.
The branching
has no limitation.
Dedicated at cable
1.25mm2(four-wire)
Black: DN
Red: DP
Black:
DN
Red: DP
AnyWireASLINK
master
24V DC* Black: DN
Red: DP
Black: DN
Red: DP
Black: DN
Red: DP
Red: DP Black: DN
Black: DN
Red: DP
Black: DN Red: DP
BT0
Red: DP Black: DN
ALM
LINK
IN
ALM
LINK
IN
ALM
LINK
IN
ALM
LINK
IN
ALM
LINK
IN
ALM
LINK
IN
Black: DN
Red: DP
Black: DN
Red: DP
Two points
Two points
Eight points
Eight points
24V DC*
ASLINKAMP
Independent use
ASLINKAMP
Independent use
ASLINKAMP
Expansion use
ASLINKAMP
Expansion use
ALM
LINK
IN
■Connection example using a two-wire (non-isolated) terminal
ALM
LINK
IN
2P link connector is
convenient for
branching.
The branching
has no limitation.
General-purpose
cabtire cable
Dedicated at cable
1.25mm2(two-wire)
Black: DN
Red: DP
Black:
DN
Red: DP
AnyWireASLINK
master
Black: DN
Red: DP
Black: DN
Red: DP
Black: DN
Red: DP
Black: DN
Red: DP
Black: DN Red: DP
BT0
Red: DP Black: DN
ALM
LINK
IN
ALM
LINK
IN
ALM
LINK
IN
ALM
LINK
IN
ALM
LINK
IN
ALM
LINK
IN
Black: DN
Red: DP
Black: DN
Red: DP
Two points
Two points
Two points
Two points
Two points
Two
points
Two
points
Two
points
Two
points
Two
points
Two
points
Two points
Two points
ASLINKAMP
Independent use
ASLINKAMP
Independent use
ASLINKAMP
Expansion use
ASLINKAMP
Expansion use
Transmission type
Transmission type
Black: DN
Red: DP
General-purpose power supply lter
ASLINK lter
-BSH03171K 2/8-
Recurrent
reection type
Object to be
detected
Recurrent
reection type
Object to be
detected
24V DC*
Total of line
portions of DP, DN
is total length.
* Make sure to use a
24V DC stabilized
power supply for the
power supply to be
connected.
* When complying with the
UL Standard, make sure
to use a 24V DC stabilized
power supply of "NEC
Class 2 Output."
AnyWireASLINK terminator
One terminator should be connected to
the DP, DN terminal farthest from the AnyWireASLINK master.
Connect it correctly so as not to set the wrong polarity.
CAUTION
In the case of connection to a load (e.g. input/output port)
controlled by a different power supply than that used in the
AnyWireASLINK, make sure to use a four-wire (isolated)
terminal. Otherwise, a malfunction may occur.
AnyWireASLINK terminator
One terminator should be connected to
the DP, DN terminal farthest from the AnyWireASLINK master.
Connect it correctly so as not to set the wrong polarity.
Total of line
portions of DP, DN
is total length.
General-purpose power supply lter
Supply current on the transmission line (DP, DN)
Total length
50m or less
1.25mm2
0.75mm2
MAX 2A
MAX 1.2A
MAX 1A
MAX 0.6A
MAX 0.5A
MAX 0.3A
0.5mm2MAX 0.8A MAX 0.4A MAX 0.2A
Total length: Over 50 m,
no longer than 100 m
Size of
the transmission
line (DP, DN)
Total length: Over 100 m,
no longer than 200 m

-BSH03171K 3/8-
①Power supply to the entire system
②Local power supply/branching
DP
DN
24V
0V
POWER IN
SLAVE
POWER IN
SLAVE
LG
24V0V
L N FG
～
DP
DN
DP
DN
24V
0V
DP DN
BT0
ANF-01
24V DC stabilized
power supply
24V0V
24V0V
PE
AnyWireASLINK
master
DP
DN
24V
0V
LG
24V0V
L N FG
～
DP
DN
24V
0V
DP
DN
DP
DN
24V
0V
DP DN
BT0
ANF-01
24V DC stabilized
power supply
2-wire
terminal
DP
DN
2-wire
terminal
DP
DN
2-wire
terminal
4-wire
terminal
DP
DN
24V
0V
4-wire
terminal
4-wire
terminal
DP
DN
24V
0V
4-wire
terminal
DP
DN
24V
0V
4-wire
terminal
24V0V
24V0V
PE
AnyWireASLINK
master
24V
0V
L
N
FG
～
24V DC stabilized
power supply
ANF-01
24V0V
24V0V
PE
DP
DN
24V
0V
4-wire
terminal
DP
DN
24V
0V
4-wire
terminal
A
B
ANF-01
24V0V
24V0V
PE
■Filter notation in the drawing
General-purpose power
supply lter
(Use it if necessary.)
ASLINK lter ANF-01 MAX 5A/24V DC
Filter of COSEL Co., Ltd. EAC-06-472 MAX 6A/24V DC
Model Type
Allowable power current
■Filter allowable power current
General-purpose power
supply lter
(Use it if necessary.)
General-purpose power
supply lter
(Use it if necessary.)
POWER IN
SLAVE
POWER IN
SLAVE
[Notes on Combined Use with Four-Wire (Isolated) Terminal]
If any of the side-by-side lines of DP, DN, 24V and 0V exceeds the total
length of 50m in a power supply system to be supplied, serially connect
the “ASLINK lter [Type ANF-01]” or “lter of COSEL Co., Ltd. [Type
EAC-06-472]” to 24V and 0V in the starting position of the side-by-side
lines.
This will improve noise resistance, reduce the impact of crosstalk by
transmission signals and stabilize the signals.
In any case of power supply to the entire system from the master driving
power supply or power supply from the local power supply, insert a lter.
If any of the side-by-side lines
of DP, DN, 24V and 0V exceeds
the total length of 50m
If any of the side-by-side lines
of DP, DN, 24V and 0V exceeds
the total length of 50m
If (A+B) of the side-by-side lines
of DP, DN, 24V and 0V exceeds
the total length of 50m
For details of ANF-01,
refer to ANF-01 Products
Guide.
2-wire
terminal
4-wire
terminal
Insert the “ASLINK lter [Type ANF-01]” regardless of
installation method and distance when complying
with CE Standard.
■AnyWire Type: ANF-01 Connection example

* When using this lter, please be careful of the positions of LOAD and LINE.
* When using this lter, please be careful of the positions of LOAD and LINE.
-BSH03171K 4/8-
■COSEL Co., Ltd. Type: EAC-06-472 Connection example
①Power supply to the entire system
DP
DN
24V
0V
LOAD
LINE
LG
24V0V
L N FG
～
DP
DN
DP
DN
24V
0V
DP DN
BT0
EAC-06-472*
24V DC stabilized
power supply
2-wire
terminal
4-wire
terminal
24V0V
24V0V
PE
AnyWireASLINK
master
DP
DN
24V
0V
LG
24V0V
L N FG
～
DP
DN
24V
0V
DP
DN
DP
DN
24V
0V
DP DN
BT0
24V DC stabilized
power supply
2-wire
terminal
DP
DN
2-wire
terminal
DP
DN
2-wire
terminal
4-wire
terminal
DP
DN
24V
0V
4-wire
terminal
4-wire
terminal
DP
DN
24V
0V
4-wire
terminal
DP
DN
24V
0V
4-wire
terminal
24V0V
24V0V
PE
AnyWireASLINK
master
24V
0V
L
N
FG
～
24V DC stabilized
power supply
24V0V
24V0V
PE
DP
DN
24V
0V
4-wire
terminal
DP
DN
24V
0V
4-wire
terminal
A
B
24V0V
24V0V
PE
■Filter notation in the drawing
General-purpose power
supply lter
(Use it if necessary.)
General-purpose power
supply lter
(Use it if necessary.)
General-purpose power
supply lter
(Use it if necessary.)
LOAD
LINE
EAC-06-472*
LOAD
LINE
EAC-06-472*
EAC-06-472*
LOAD
LINE
②Local power supply/branching
If any of the side-by-side lines
of DP, DN, 24V and 0V exceeds
the total length of 50m
If any of the side-by-side lines
of DP, DN, 24V and 0V exceeds
the total length of 50m
If (A+B) of the side-by-side lines
of DP, DN, 24V and 0V exceeds
the total length of 50m

-BSH03171K 5/8-
Red: DP (+)
Black: DN (-)
Transmission line
Light emitting and
receiving surfaces
UL style 2103
Two cores of No.24 AWG (black) φ4.1
Core nish outside diameter φ1.5
Applicable LP connector: LP2-PWH-10P
2 1
AB
CCover
Hole to pass the clamp
Clamp
① ②
⑤ ⑥
③ ④
Dedicated tool: LP-TOOL
Place the lines in the groove so that the black line (DN) is positioned nearer
the hinge side of the cover, and fold the part A onto the part B side and then
hitch the hook C to x the cover.
In this cover-mounted
state, check if the hooks
①and ②are tted.
Insert the body clamp into the hole
of the cover and crimp them with a
dedicated tool.
After crimping, check if the hooks
③to ⑥are tted securely.
[How to connect]
Connect the transmission line included with the base unit body to the transmission line
from the master unit.
Connect correctly for the polarity of +/-.
■Example of mounting an LP connector to the end of the transmission line
- Location where the unit will not be subject to vibration or shock.
- Places which are waterproof and not directly exposed to dust.
- Where the body is not exposed to waste metal or sputter.
- Places free from condensation.
- Location where the atmosphere is free of corrosive gas, ammable gas, and
sulfur.
- Location where there are no high-voltage or high-current cables.
- Location where there are no cables and controllers that generate servo,
inverter, or other high-frequency noise.
- Location where the unit will not be subject to direct sunlight.
[Installation Location]
[Example of installation]
Purchase the bracket separately.
M3 tightening torque: 0.5N・m or less
When securing the unit, allow a margin so that
no stress is applied to the cables and
connecting connectors etc.
Do not tighten the screws excessively.
Doing so may cause a failure.
CAUTION
[Precautions for use]
- This unit is used by connecting to the AnyWireASLINK transmission line.
This unit does not operate even if it is directly connected to the I/O card etc.,
of the sequencer.
- Use this unit in a proper voltage range.
- Also include the attached transmission line included with the unit in total
length.

Fig. 1
Black: DN
Red: DP：
Transmission
signal
AnyWireASLINK
Master
24V DC*
Setting port
[SET ON setting]
[SET OFF setting]
Default: 50 (AD value)
- Address writer (ARW-04): Parameter 01
Default: 10 (AD value)
- Address writer (ARW-04): Parameter 02
AD value
AD value
0 - 1023
0-100％
0-100％
0 - 1023
[Teaching Automatic Setting]
Hysteresis
Alarm value Hi
Alarm value Lo
5％
Threshold 50％
80％
20％
*The setting range depends on the setting of parameter 8.
*The setting range depends on the setting of parameter 8.
0-100％
0-100％
-BSH03171K 6/8-
Black: DN
Red: DP
AnyWireASLINK
Master
Object to
be detected
No object to
be detected
Black: DN
Red: DP
AnyWireASLINK
Master
■Setting of threshold
■Setting of hysteresis
[Various settings]
■Item
Address number setting Parameter settingTeaching
■Common procedure for address writer operation
Be sure to connect to the AnyWireASLINK master unit to use.
An address writer ARW-04 (Ver.04-1.01 or higher) is required for
operation.
For details about the operation method, refer to the address
writer's Products Guide.
1. Connect the terminal to the master unit of the AnyWireASLINK system.
Set with the address writer while supplying the transmission signal (DP, DN).
* Make sure to use a 24V DC stabilized
power supply for the power supply to be
connected.
2. Setting is required for all terminals.
Direct the address writer toward the setting port (Fig. 1) of this product.
(Bring the emitter as close as possible to the setting port.)
Address number setting
The address number is used to set which number of the transmission
frame to start with for the terminal to occupy.
Set the address number in a range from "0" to "254."
The default address-number setting of the
terminal is "255," which means no setting.
If the address number setting is "255," the
terminal cannot perform input/output operations.
Make sure to use the terminal after setting the
address number within the range of "0 to 254."
CAUTION
！
Teaching
Store the status when a work is present and when a work is absent in
the ASLINKSENSOR.
Carry out setting with the work actually used.
In the SET ON/SET OFF setting, based on the difference of AD value
stored at the time of with or without a workpiece, "threshold,"
"hysteresis," "alarm value Hi," and "alarm value Lo" are automatically
set in the following %.
Parameter setting
Set the threshold of the light receiving level to judge presence/absence
of detection. * Difference in the detection state stored in teaching is 100%.
Set the change in the amount of the light receiving value required to
turn the detection state from ON to OFF.

-BSH03171K 7/9-
■Alarm value Hi setting
■Alarm value Lo setting
■Alarm value monitor time setting
Set a monitor time for the alarm judgment value.
Default: 0 (AD value)
- Address writer (ARW-04): Parameter 03
Default: 50
Default: 0 (AD value)
- Address writer (ARW-04): Parameter 05
AD value
0 - 1023
0-100％
0-100％
AD value
0 - 1023
0-100％
0-100％
Variable
3 - 255
Unit
100ms
■Setting Light ON/Dark ON
Set light ON/dark ON
Default: 0
- Address writer (ARW-04): Parameter 06
■Setting for operation mode change
Set preventive maintenance function available/unavailable.
Variable Details
0 Preventive maintenance function unavailable
1 Preventive maintenance function available
- Address writer (ARW-04): Parameter 07
Default: 0
■Light receiving display setting
Variable Details
0
1
- Address writer (ARW-04): Parameter 08
Default: 0
Variable Details
0 Dark ON
1 Light ON
AD value display (0-1023 Digit)
0 - 100％display
■Setting of ON Delay
Set ON delay time.
Default: 0
- Address writer (ARW-04): Parameter 10
Variable
0 - 999 100ms
Unit
Set OFF delay time.
Default: 0
- Address writer (ARW-04): Parameter 11
Variable
0 - 999 100ms
Unit
■Setting of OFF Delay
*The setting range depends on the setting of parameter 8.
*The setting range depends on the setting of parameter 8.
Simple mode
Normal mode
Set One Shot time.
Default: 0
- Address writer (ARW-04): Parameter 12
Variable
0 - 999 100ms
Unit
■Setting of One Shot
Set an upper limit for the alarm judgment value.
* Set the alarm values so that Hi is greater than Lo.
Set light receiving display.
Due to this setting, the value of parameter 01, 02, 03, 04 or sensing
level is automatically converted into the AD value or 0-100%.
- Address writer (ARW-04): Parameter 04
Set a lower limit for the alarm judgment value.
* Set the alarm values so that Hi is greater than Lo.
Parameters [9] and [13] and subsequent parameters are parameters in the
system domain. Do not change the setting with the address writer.
[Monitor Display]
Unit operation status is indicated by the LED.
View A
Setting port
Display part
LINK (Green)
IN (Orange)
ALM (Red)
A
LINK
(Green)
LINK
ALM
IN
(Orange)
Name Display status
ALM
(Red)
Details
Transmission signal is appropriately supplied.
Sensing level drop
Slave unit voltage drop
Transmission signal abnormality
No transmission signal
Normal
When the master unit found that
the ID (address) of this unit is
a duplicate or is not set.
ON
OFF
Flashing
On
Flashing
Alternately flashing
On
Off
Off
On
Off
LINK
ALM
Normal status: LINK Flashing, ALM OFF, IN ON /OFF

[Specications]
[Outside Dimensions]
25.4
2-M3
(through)
17
（1000）
Red: DP
Black: DN
UL style 2103
Two cores of No.24 AWG (black) φ4.1
Core nish outside diameter φ1.5
Light emitting
and receiving
surface
31 (2)
Unit: mm
Input 1 point
33g
Diffuse reection
500 mm (White drawing paper 100×100 mm)
0 - 55°C, 10 - 90%RH (No condensation)
Ambient temperature/humidity for use
-25 - 70°C, 10 - 90%RH (No condensation)
Ambient temperature/humidity for storage
No corrosive gas
■General Specications
Atmosphere for use
0 to 2000m
Altitude of use *1
2 or less
Pollution level *2
Number of occupied points
■Transmission specications
■Individual specications
Frame/bit synchronization methodSynchronization method
DC power supply superimposed total frame/cyclic methodTransmission method
Voltage 24V DC +15% to -10% (21.6 to 27.6V DC
Ripple of 0.5Vp-p max.
Power supply
voltage for use
Dedicated protocol
Transmission procedure
Bus type
(Multi-drop method, T-branch method, Tree branch method)
Connection mode
512 max. (IN: 256, OUT: 256)
Number of connection points
Up to 128 units
Number of units connected
One to two cyclesResponse time *3
Mass
Detection method
Detection distance
Red LED
Light source
(Light emitting wavelength)
Protection structure
Current consumption
Protection circuit Power supply short-circuit protection,
Power supply reverse connection protection,
Interaction prevention function
IP67
-BSH03171K 8/9-
Parameter Variable
default
Variable Contents
【01.】50
Set the threshold of the light receiving
values of detection judgment.
0-1023
（0-100%）
Threshold
【02.】10
Set the change in the amount of the light receiving value
required to turn the detection state from ON to OFF.
0-1023
（0-100%）
Hysteresis
【03.】0
Set the upper limit of the light receiving
value that generates an alarm.
0-1023
（0-100%）
Alarm value Hi
【04.】0
Set the lower limit of the light receiving
value that generates an alarm.
0-1023
（0-100%）
Alarm value Lo
【05.】
50
Set the monitor time of the light receiving
value that generates an alarm. (1=100ms)
3-255
Alarm value
monitor time
【06.】
0
Dark ON
Light ON
0
Light ON/
Dark ON
【07.】
0
Simple mode (Preventive maintenance function unavailable)
Normal mode (Preventive maintenance function available)
0
Operation
mode
【08.】
0
AD value display (0 - 1023 Digit)
0 - 100% display
Light receiving
display
【10.】0-999 Set ON delay time. (1=100 ms) 0
ON Delay
【11.】0-999 Set OFF delay time. (1=100 ms) 0
OFF Delay
【12.】0-999 Set One Shot time. (1=100 ms) 0
One Shot
1
1
0
1
[Parameter and Item]
10mA
Transmission disconnection detection,
Transmission short-circuit detection,
Transmission power supply drop detection,
ID duplication and ID non-setting detection
RAS feature
Brightness corresponding to a light bulb 3000 lx or less
on the light receiving surface.
Ambient illumination use
11
20
[Troubleshooting]
Take measures as follows in the following case.
Symptom Measures
Detection
cannot be performed.
LINK IN ALM Cause Measures
○○○
Off Off Off
●
On
○
Off
○
Off
◎
Flashing
(0.5 seconds
alternately)
Flashing
(0.5 seconds
alternately)
○
Off
◎
－－◎
Flashing
(On for 0.2
seconds, off
for 1.0 second)
◎－●
Flashing
On
Indication Cause Measures
【E-0303】The set parameter is
incorrect.
When the following errors are indicated on the display window of the main body,
take measures as shown below.
When the following error is indicated on the address writer, take measures as
shown below.
- ASLINKSENSOR is
not connected to the
AnyWireASLINK
system.
- Power supply for the
AnyWireASLINK
system itself is not
turned on.
- The ASLINKSENSOR
maintains the
address 255 (setting
before shipment).
- The ASLINKSENSOR
has an address
duplicated with the
other unit.
- The internal power
voltage of the
ASLINKSENSOR
lowers.
- The sensing level
lowers.
- Directly connected to
24-0V power supply.
- Conrm that there is no
disconnection between the
ASLINKSENSOR and the
AnyWireASLINK system, and recover
the connection.
- Conrm the power status of the
AnyWireASLINK system, and turn on
the power.
- Set any address other than 255.
- Look for any other unit which has the
same error indication, and set any
address different from it.
- Decrease the number of units
connected to the same
AnyWireASLINK system.
- Shorten the transmission line
between the ASLINKSENSOR and
the master unit.
Conrm the parameter correspondence
table and set the correct parameter.
- Check the status of the
ASLINKSENSOR, then adjust the
optical axis, and clean the light
emitting and receiving surfaces, etc.
- Re-connect to the AnyWireASLINK
system.
-Is the angle of the light emitting and receiving surface correct?
→When it is wrong, adjust it to the correct angle.
- Are the wirings correct?
→Re-check the connection of the ASLINKSENSOR
transmission line.
- Is power with proper capacity fed to the AnyWireASLINK master
unit and slave unit?
→Check the power.
- Was the teaching carried out?
→Perform the teaching setting with the work to be actually
detected.
- Is the unit used within a detection range of the rating?
→Use it within a range of the rating.
Setting cannot be
performed
with ARW-03
and ARW-04.
- Is connecting correct?
→Re-check the connection of the ASLINKSENSOR
transmission line.
- Is power fed to the AnyWireASLINK system?
→Conrm the power supply.
- Is the set parameter correct?
→Conrm the parameter correspondence table and set the
correct parameter.
*1 Do not use or store the AnyWireASLINK device in an environment pressurized equal to
or higher than the atmospheric pressure at an altitude of 0m. Doing so could cause a
malfunction.
*2 Index that indicates the occurrence of conductive material in the environment where the
device is used.
Contamination level 2 indicates that only non-conductive contamination occurs.
However, incidental condensation could create temporary conductivity in this
environment.
*3 Time from when ON or OFF is detected until the transmission signal is transmitted.
The time combining this time and the transmission 1 cycle time is the transmission delay
time.

-BSH03171K 9/9-
[Address]
Anywire Corporation
:Contact by mailContact [email protected]
:Contact by website http://www.anywire.jp
Headquarters :1 Babazusho, Nagaokakyo-shi, Kyoto 617-8550 JAPAN
Printed in Japan 2016, 2017 UMA-13310C-EN
