Aobosi ZM1507A User manual
A aobosi
Model:ZM1507A
c
1
4
5
6
7
8
10
11
12
13
1 www.iaobosi.com
Section I. Precautions for Safety Use
SIGN SAMPLES
All users of this appliance must read and understand these safety
precautions before operating.
This sign indicates contents that may cause risk of a fire or an
electrical shock.
Specific warnings are written in the sign.
This sign indicates contents of regulating or directing actions.
Specific prohibitions are written around or in the sign.
This sign indicates prohibited acts.
Specific prohibitions are written around or in the sign.
PRECAUTIONS FOR SAFE USE
1. DO NOT PLUG IN OR UNPLUG WITH WET HANDS.
It may cause an electric shock or an injury.
2.DO NOT USE WITH OTHER THAN RATED VOLTAGE.
It may cause an electric shock, a fire or abnormal performance.if the
voltage is different, it may shorten the life of the motor or cause a failure.
3.PLUG THE POWER CORD CORRECTLY AND PUSH IT TIGHT IN A WALL
SOCKET.
It may cause electric shock or a fire.
4.IF THE SUPPLY CORD IS DAMAGED, IT MUST BE REPLACED BY THE
MANUFACTURER,ITS SERVICE OR SIMILARLY QUALIFIED PERSONS IN
ORDER TO AVOID A HAZARD.
If the power cord is damaged, it may cause electric shock or a fire.
5.NEVER ALTER THE APPLIANCE. ALSO, DO NOT DISASSEMBLE OR
REPAIR BY YOURSELF. DO NOT INSERT FINGERS, FOREIGN SUBSTANC-
ES OR OBJECTS SUCH AS PINS INTO GAPS OR HOLES IN THE BASE.
It may cause a fire, an electric shock or a failure. For any technical support,
contact the authorized local Customer Care Center.
6.DO NOT MOISTEN THE BASE OR SPLASH WATER ON THE BASE.
Be careful not to let any liquids or other substances get into the switch on
the appliance. DO NOT OPERATE THE SWITCH WITH WET HANDS.It may
CauSe electric shock or a fire.
7.WHEN THE POWER CORD, WIRE IS BROKEN OR DAMAGED OR THE
PLUG-IN.PART BECOMES LOOSE, DO NOT OPERATE IT.
It may cause an electric shock, a fire or an injury
8.FOR SAFETY, MUST DO GROUND CONNECTION DO NOT DO THE
GROUNDING.ON GAS PIPE, PLASTIC WATER PIPE, TELEPHONE WIRE, ETC.
It could cause an electric shock, a fire, or a malfunction and an explosion.Be
sure to use the socket with ground connection.
9.NEVER DISASSEMBLE BOWL SET DURING OPERATION OR INSERT
FINGERS,FOREIGN OBJECTS SUCH AS FORKS,SPOONS ETC. INTO
FEEDING TUBE OR JUICE OUTLET.
It may cause an injury, an accident or a failure.Never replace the spiral
pusher with any other objects or have eyes get dose to the feed port,
otherwise accidents may happen.
10.THIS APPLIANCE IS NOT INTENDED FOR USE BY PERSONS INCLUD-
ING CHILDREN) WITH REDUCED PHYSICAL, SENSORY OR MENTAL
CAPABILITIES,OR LACK OF EXPERIENCE AND KNOWL EDGE, UNLESS
THEY HAVE BEEN GIVEN SUPERVISION OR INSTRUCTION CONCERN-
ING USE OF THE APPLIANCE BY A PERSON RESPONSIBLE FOR THEIR
SAFETY.
Children should be supervised to ensure that they do not play with the
appliance.Children are not allowed to clean and perform user mainte-
nance without supervision.
11.DO NOT OPERATE WITHOUT LOCKING THE HOPPER PROPERLY.
It may cause an injury or a failure.
12.IF A GAS LEAK IS DETECTED, DO NOT PLUG IN THE APPLI ANCE'S
POWER CORD INTO A POWER OUTLET IMMEDIATELY VENTILATE THE
ROOM BY OPENING A WINDOW, AND ALLOW TO FULLY VENTILATE
BEFORE PLUGGING IN THE APPLIANCE.
It may cause an injury or a failure.
13.IF SCREW ROTATION IS STOPPED IN NORMAL OPERATION, PRESS
IRI BUTTON AND HOLD FOR 3 SECONDS AND THEN AFTER REVERSE
OPERATION IS COMPLETELY STOPPED, PRESS IONI BUTTON AGAIN.
If such a stop event continues during the operation, the parts may be
damaged and performance may be deteriorated due to overheating in a
motor. When the problem continues, immediately stop the appliance and
contact the local Customer Care Center.
2 www.iaobosi.com
3 www.iaobosi.com
14.CAUTION
1.Before use, please check if the power cord, the plug, the juice strainer, the spiral
pusher and any other part is damaged. If any of the said part is damaged, stop using
the appliance and contact our customer service department promptly. Do not disman-
tle and repair it by yourself, otherwise dangers may happen.
2.It is necessary before connecting the power supply to ensure that the juicing body,
the spiral pusher, the juicing body cap and all other dismountable parts are properly
installed.
3.Cut food ingredients into small blocks with sizes fitting the feed port of the juicing
body. Do not begin to process any vegetables or fruits with cores, hard seeds or thick
skin or shells until the cores, hard seeds or thick skin or shells are removed.
4.When feeding a food ingredient, do not make the pushing force too large but have it
just enough to cut the food ingredient.
5. Dyeing of the juice strainer, the juicing body cap, the spiral pusher and other accesso-
ries after juicing of some vegetables or fruits is normal and will neither affect food
eating nor do harm to health.
6. If the appliance has current limiting protection or its motor is locked and stops
automatically and cannot reverse automatically, switch off the power switch and put it
on the "o" position, then press the "ON" button of the power switch to discharge the
food ingredients in the appliance and finally press the "R" button of the power switch
for normal use of the appliance. If the motor is still locked, it is suggested to remove the
food ingredients in the spiral pusher before continue to use the appliance.This measure
can protect the motor.
7.Do not dismantle the dismountable parts of the appliance immediately after use but
after both the motor and the spiral pusher have stopped and the power supply is
disconnected.
8. Do not sterilize any accessories of the appliance with hot water with a temperature
higher than 80 ℃ or a microwave oven, otherwise they may heated, deformed and
damaged. The materials of all parts in contact with food ingredients should comply
with food hygiene certification and be clean, hygeian and reliable.
9. Do not clean the appliance with steel wool, abrasive cleaning agents or corrosive
liquids (such as gasoline or acetone).
10. The appliance is applicable to use by individuals or families only.1. Accessories,
other than those supplied with the appliance, include instructions for their safe use.
12. Switch off the appliance and disconnect from supply before changing accessories or
approaching parts that move in use.
13.Hazards or unsafe practices could result in minor personal injury or appliance
damage.Care shall be taken when handling the sharp cutting blades, emptying the
bowl and during cleaning.Always disconnect the appliance from the supply if it is left
unattended and before assembling, disassembling or cleaning.
4 www.iaobosi.com
Section 2. Operating Instructions
JUICING FUNCTION
1.Press [ON] button of the A aobosi
Juicer to start.
Tips : In case of Pulp blockage or
motor locking.Press and hold "REV"
button for approximately 3 seconds to
rotate the auger reversely and then
release it.Press "ON" button to resume
normal operation.
2.Clean the material and cut it into
pieces small sufficiently which can
pass through the Feed chute, and
place them onto the tray.
Note: Any hard core, seed, skin or
shell from fruits and vegetables shall
be removed in advance.
3. Gradually put the ingredients into
the hopper chute and press down with
the pusher. Press [ON] button of the A
aobosi Juicer to start.
Note:DO NOT place any metal objects
into.
4. After the extraction or processing is
complete, place the switch in the stop
position to stop.
Warning:When using [ON] or
Rev] button, make sure that the auger
stops completely.
1
2
3
4
10
9
8
7
11 12 13
5
6
1.Power Cable
2.Motor Base
3.On-Off Switch
4.Locking Button
5.Juice Container
6.Pulp Container
7.Food Pusher
8.Hopper
9.Feed Chute
10.Drum
11.Auger
12.Juicer Screen
13.End Cap
5 www.iaobosi.com
Section 3. Quick Start Assembly
1.Place the food pusher(7) onto the feeder chute（9）.
2.Place the hopper (8) onto the feeder chute（9）.
3.Install the drum (10) to the motor base (2).
4.Push and rotate anticlockwise.
5.Push the auger (11) into the drum (10).
6.Insert the juicer screen (12).
7.Place the end cap (13) and screw it anticlockwise.
8.Place the juice container (5) under the drum (10).
9.Place the pulp container (6) under the end cap (13).
1
2
3567
8
4
9
6 www.iaobosi.com
Section 4. Installation Notes
7 www.iaobosi.com
Section 5. Tips for Ingredients Selection
FRUIT JUICE EXTACTOR
Efficiently juices hard and soft fruits: even citrus fruits, usually one of the
hardest fruits to juice.
Jam can not be achieved, some fruit can not squeeze juice (such as bananas,
mangoes, dried fruit, sugar cane, etc.).
VEGETABLE JUICE
Cut vegetables to strips(less than 10 cm).
Juices all kinds of vegetables including carrots, beets, celery, peppers, and
radishes without destroying the natural flavor and nutrition benefits.Fresh
taste and full nutrition are guaranteed with this unique extraction process.
WHEATGRASS AND LEAFY GREENS
Cut it to strips(less than 10 cm).
Wheat grass, kale, cabbage, spinach and pine tree needles are just some of
the natural products that can be juiced with the juicer. Enjoy the best that
nature offers in raw foods of all kinds and juice them for full nutritional
benefits.
Instructions on Selection of Fruits
1.Select fresh fruits and vegetables, which contain more juice. The proper
fruits include: pineapple, beet root, celery stalk, apple, cucumber, spinach,
melons, tomato, orange and grape.
2.Thick skin on fruits such as orange, pineapple and raw beet root instead of
thin skin on fruit/vegetable needs to be removed. Seeds in oranges should be
removed as well, which may make the juice taste a little bitter.
3. Just extracted apple juice will turn brown very soon, and this process can
be slowed by adding drops of lemon juice into it.
4. Leaves and stems (such as those of lettuce) can be put into the extractor to
extract juice.
8 www.iaobosi.com
Section 6. Maintenance
1.Before cleaning this product, be sure to shut down the switch to disconnect
the power supply.
2.Clean this product after using it.
3.The Housing cannot be washed under water, and must be cleaned with
twisted wet clothinstead.
4.Before storing it, make sure this product is clean and dry.
5.Disassemble this product to wash the components by the following steps:
9www.iaobosi.com
First remove the plunger and tray.
Press down and hold the locking
button,and rotate the drum clockwise
to remove it.
First remove the plunger and tray.
Press down and hold the locking
button,and rotate the drum clockwise
to remove it. After removing extractor,
detach the end cap, juice screen and
auger in turn, all removable compo-
nents can be washed with water.
10 www.iaobosi.com
Section 7. Only Hand Wash & Easy Cleaning
1.HANDWASH OPTION:
You can thoroughly wash parts by immersing in
warm water diluted with one or two drops of
baking soda or dishwashing soap for about 30
minutes.
2.NOT DISHWASHER SAFE:
After using the juicer, remember not to put the
relevant attachments of the juicer into the dish-
washer for cleaning, because washing in the
dishwasher will cause damage to the relevant
attachments and cause the juicer to stop working.
WARNING
Do not immerse the motor base in water or any other liquid. Do not use
water jet to clean the motor base.
35.00cm
1.77inch
4.50cm
14.29inch
36.30cm
5.5nch
14.00cm
11 www.iaobosi.com
Section 8. Safety Index
PRODUCT NAME:
MODEL:
RATED VOLTAGE:
RATED POWER:
RATED FREQUENCY:
CONTINUOUS OPERATING TIME:
INTERVAL TIME:
SPEED:
LOAD
slow juicer
ZM1507A
120V
150W
60Hz
≤ 10 minutes
≥ 10 minutes
90~30 rpm/min
carrot,apple
Section 9.Warranty
Thank you for choosing A aobosi product. We sincerely hope that you are
satisfied with it.
The manufacturer's warranty covers the product for a period of 12 months from
the date of purchase against manufacturing faults. All warranties are automati-
cally kept track of in our system, so there is no need to register your product.
Any help or questions during use, please contact us via website www.iaobo-
suggest to provide a warranty card, a photo or a video if there’s broken spare
part or not working machine so that we can be much more clear about your
problems and offer you the best solution.
Please fill in the table and email it within 10 days from the date of purchase.
12 www.iaobosi.com
13 www.iaobosi.com
Please troubleshoot using the details below before contacting A aobosi
Customer Service for repair or service. When contacting A aobosi for
after-sales service, please have the manufacturer's serial number or bar code
available.
The Appliance Does Not Work
•Make sure the power cord is plugged in correctly.
•Make sure the drum is assembled correctly. If the drum is not locked into
place,the appliance will not operate.
•Make sure the appliance is assembled according to the instructions in this
manual.
•Refer to the instructions.lf the appliance still does not work, please contact A
aobosi Customer Service for additional support.
The Drum Does Not Open
•If there is a lot of pulp inside the drum, press [On] to release the excess pulp.
•Check the appliance for any foreign substance or solid objects including
seeds.
•Press Rev] button to push up stuck ingredients.
•Do not attempt to open by force. If the drum still does not open, please
contact Aaobosi Customer Service for additional support.
The Appliance Stops During Normal Operation
•Check for large pieces of food stuck in the appliance.
Noise is generated during operation
•The machine operates in an unbalanced state due to failure to mount auger
or juice filter in place.Mount auger or juice filter in place.
•The starting motor in the frame has been damaged.Contact after Sales
Support.
Section 10. Troubleshooting
14 www.iaobosi.com
•Refer to the section "If the Auger Stops Working" and follow the guideline for
the Rev] button.
•If the appliance still does not work, please contact Aaobosi Customer Service
for additional support.
Fine Lines or Scratch Marks around the Auger
•This is normal. Do not be concerned. These are molding marks resulting
from the normal manufacturing process.
Juice Leaks Over the Base
•Check for an excessive amount of ingredients in the hopper and/or chute.
•If you try to juice a large amount of food compared to the pulp chute, the
packing will be slightly pushed away. Juice may leak out of the gap.
•Do not force too much food into the juicer. Push food gradually for
extraction.
•Check to make sure the juice flap is closed.
Juicer Shakes when In-Use
•This is normal as the auger rotates. It is not a malfunction. Hard ingredients
such as carrots, potato, radish, beets, etc. may cause shaking more so than
soft ingredients
•Depending on the firmness of the ingredient, there may be a more
pronounced shaking of the motor.
During the early uses, the motor generates unpleasant smel
•It is a normal phenomenon.
•If this phenomena occurs frequently, please contact A aobosi Customer
Service for additional support.
Table of contents
Other Aobosi Juicer manuals
