Apator Metra E-ITN 30 Manual

ELECTRONIC HEAT COST ALLOCATOR
WITH INTEGRATED RADIO TRANSMITTER
E-ITN 30
Installation and service anual
APATOR METRA s.r.o.
Havlíčkova 919/24
787 64 Šumperk
tel.: [phone]
fa : [phone]
e-mail: prodej@metra - su.cz
www: http://www.metra - su.cz

E-ITN 30
Installation and service manual M2019/01a [EN]
TABLE OF CONTENTS
1. INTRODUCTION.........................................................................................................................4
1.1. LC Display.............................................................................................................................................. 4
2. DEVICE DESCRIPTION................................................................................................................5
2.1. Type E-ITN 30.2..................................................................................................................................... 5
2.2. Type E-ITN 30.3..................................................................................................................................... 5
2.3. Type E-ITN 30.4..................................................................................................................................... 5
3. TECHNICAL SPECIFICATIONS........................................................................................................6
3.1. Construction........................................................................................................................................... 8
4. OPERATION MODES...................................................................................................................9
4.1. Operation modes.................................................................................................................................... 9
4.2. Submenu navigation............................................................................................................................... 9
4.3. Sleeping mode....................................................................................................................................... 9
4.3.1. Submenu structure in sleeping mode..............................................................................................9
4.3.1.1. Activation of working mode................................................................................................................... 10
4.3.1.2. Allocator self test...................................................................................................................................10
4.3.1.3. Setting of radiator type E-ITN 30.3 only).............................................................................................10
4.4. Mode of waiting for start date...............................................................................................................10
4.4.1. Submenu structure in mode of waiting for start date......................................................................11
4.5. Working mode...................................................................................................................................... 11
4.5.1. Menu structure in working mode.................................................................................................... 11
4.5.1.1. Value for current billing period .............................................................................................................12
4.5.1.2. Value for the last billing period.............................................................................................................. 12
4.5.1.3. Alphanumeric code............................................................................................................................... 12
4.5.1.4. Serial number E-ITN 30.2, 30.4 only)..................................................................................................12
4.5.1.5. Temperature of the radiator sensor E-ITN 30.2, 30.4 only )................................................................12
4.5.1.6. Temperature of the surroundings sensor E-ITN 30.2, 30.4 only).........................................................12
4.5.1.7. Date of the billing period beginning......................................................................................................12
4.5.1.8. Current date.......................................................................................................................................... 12
4.5.1.9. Current time E-ITN 30.2, 30.4 only).....................................................................................................12
4.5.1.10. Display test E-ITN 30.3 only).............................................................................................................12
4.5.1.11. Average ambient temperature for the last billing period E-ITN 30.3 only).........................................12
4.5.2. Structure of submenu with month values E-ITN 30.2, 30.4 only)...............................................13
4.5.3. Structure of submenu with month values E-ITN 30.3 only)..........................................................13
4.5.4. Menu structure in service mode E-ITN 30.3 only)........................................................................14
4.5.4.1. Number of measuring cycles in single sensor mode............................................................................14
4.5.4.2. Max. temperature of radiator sensor in last billing period.....................................................................14
4.5.4.3. Date when the max. temperature of radiator sensor in last billing period was reached ......................14
4.5.4.4. Min. temperature of radiator sensor in last billing period......................................................................14
4.5.4.5. Date when the min. temperature of radiator sensor was reached in last billing period........................14
4.5.4.6. Value in penultimate billing period........................................................................................................14
4.5.5. Last year of battery life.................................................................................................................. 14
4.6. Error mode........................................................................................................................................... 15
5. OTHER INFORMATIONS.............................................................................................................16
5.1. Electronic seal reactivation...................................................................................................................16
5.2. Allocator parameters setting.................................................................................................................16
5.3. Transportation...................................................................................................................................... 16
5.4. Storage................................................................................................................................................. 17
5.5. Application and disposal....................................................................................................................... 17
5.6. Defects and their elimination................................................................................................................17
5.7. Warranty............................................................................................................................................... 17
6. ACCOMPANYING DOCUMENTATION...............................................................................................18
6.1. Ordering............................................................................................................................................... 18
6.2. Packing................................................................................................................................................ 18
2 / 46

E-ITN 30
Installation and service manual M2019/01a [EN]
7. INSTALLATION METHODS...........................................................................................................21
7.1. Allocator installation..............................................................................................................................21
7.2. Allocator back plate.............................................................................................................................. 21
7.3. List of installation material....................................................................................................................22
7.4. E-ITN 30 mounting place on segmented and panel radiators..............................................................23
7.4.1. Vertical position: ...................................................................................................................... 23
7.4.2. Horizontal position:........................................................................................................................ 23
7.5. Installation on segmented radiators......................................................................................................24
7.5.1. Description of installation............................................................................................................... 24
7.5.2. Installation differences................................................................................................................... 25
7.6. Installation on panel radiators..............................................................................................................26
7.6.1. Description of installation .............................................................................................................. 26
7.7. Installation on horizontal and vertical registers.....................................................................................28
7.7.1. Installation description................................................................................................................... 28
7.7.2. Proper E-ITN 30 installation on different register types.................................................................29
7.8. Model No. 1 – Cast iron radiators.........................................................................................................31
7.9. Model No. 2 – Cast iron radiators with flat vertical front panel.............................................................32
7.10. Model No. 3 – Cast iron radiators with distance pad..........................................................................33
7.11. Model No. 4 – Steel radiators.............................................................................................................34
7.12. Model No. 5 – Steel radiators with distance pad................................................................................35
7.13. Model No. 6 – Panel radiators with shaped front side........................................................................36
7.14. Model No. 7 – Panel radiators with a flat front panel..........................................................................37
7.15. Model No. 8 – Tubular radiators - ladder............................................................................................38
7.16. Model No. 9 – Tubular radiators – ladder with oval base....................................................................39
7.17. Model No. 10 – Radiators made from smooth or ribbed tubes - register...........................................40
7.18. Patter No. 11 – Aluminium radiator with vertical ribs..........................................................................41
7.19. Model No. 12 – Aluminium radiator with vertical ribs..........................................................................42
7.20. Model No. 13 – Radiator JAGA TEMPO.............................................................................................43
7.21. Model No. 14 – Radiators Koratherm horizontal K22HM....................................................................44
7.22. Model No. 15 – Radiators OT Koral...................................................................................................45
7.23. Model No. 16 – Koratherm Vertikal K20 V .........................................................................................46
3 / 46

E-ITN 30
Installation and service manual M2019/01a [EN]
1. INTRODUCTION
E-ITN 30 is modern electronic device intended for ratio based allocation of heat cost in buildings with central
heating system. The heat cost allocator E-ITN 30 uses the two-sensor measuring principle – integrates
temperature difference between sensor of radiator surface temperature and sensor of surrounding
temperature. Using this principle, allocator ensures measurement of consumption value only when the
radiator really emits heat. Agains to one-sensor allocator it minimizes the risk of summer consumption.
E-ITN 30 is intended to be installed in one-tube horizontal/vertical and two-tube heating systems with the
lowest mean design heating medium temperature ≥ 35 °C and highest mean design heating medium
temperature ≤ 90 °C.
Each radiator in billing (account) unit with common invoicing heat meter must be equipped with a heat cost
allocator of the same type. Technical conditions of heating system must be fulfilled when using heat cost
allocators E-ITN 30.
E-ITN 30 is not intended for heat cost allocation for floor heating systems, ceiling radiant heating, flap
controlled radiators, radiators with fan, systems with steam heating medium, air heaters and single tube
radiators if e ceeds the scope of one user. It must not be also used for heating elements that shape and
design does not allow reliable transfer of heat to heat cost allocators.
1.1. LC DISPLAY
Basic allocator status and measured values can be displayed on LCD. LCD can display five alphanumeric
characters. These values are highlighted by underline and overline, e.g. oPEn.
Meaning of some values may be different if the additional symbol „SM“ at the right bottom corner is
displayed. These values are mentioned with „SM“ symbol in te t , e.g. 385 SM.
The last symbol on the display indicate end of the battery life, see chapter 4.5.5. Last year of battery life.
To save the battery, after longer period of inactivity (appro . 1 min.), energy-saving mode is activated and
display is switched off. Display can be activated by pushing the button. (Illustration 1: E-ITN 30).
When pushing the button briefly, notice ----- on the display will appear. If the button is not pushed in 1 minute,
the display will switch off.
4 / 46
Illustration 1: E-ITN 30
LC display
push-button
IR diode for infra-red reading
serial number and bar code
Illustration 2:LC
Display

E-ITN 30
Installation and service manual M2019/01a [EN]
The data displayed on the LCD display may vary depending on the type of the allocator and also on the
active operating mode. For more information, see below.
2. DEVICE DESCRIPTION
Installation of allocator consists only from mounting of base plate from aluminium alloy and placing of
allocator to this base plate. Due to integrated radio transmitter, presence of flat occupant is not required
when data are read. No strangers also enter the flat. Data reading can be made by billing company
employee using mobile receiving unit RFU 35 outside the house. Data can be also read daily by central
reading system CRS 40 permanently installed in the building if required.
Measured data are transmitted in a short ~ 8 ms radio telegrams and secured by encryption. Data are
transmitted in shorter interval every appro . 30 s in the „reading period“, for the rest of the year data are
transmitted every appro . 240 s. Time interval between transmissions is not constant – is changed randomly
in time frame. So the situation when it would be impossible to read data (in reasonable time) from allocators
transmitting in the same time is prevented.
Allocator is equipped with mechanic and electronic seal and is delivered in sealed state with activated
electronic seal. In the case of unauthorized removing of base plate, the allocator saves the date of breach of
the electronic seal to its memory and stop to show measured data on the display. Only the notice oPEn is
displayed and indicates breach of the electronic seal, but allocator continues in measuring and transmitting
of measured data. Information about breach of the electronic seal is available in data transmitted by radio
module and in data transferred via IR interface.
Notice oPEn will disappear when electronic seal is activated again with reading unit IRU 10.00 via infra-red
interface.
The device is resistant against cheating. If any cheating is detected, allocator switches to the mode
inconvenient for the user – after cheating is finished, the allocator switches to standard mode.
2.1. TYPE E-ITN 30.2
Allocator is equipped with unified scale. No parameters (e.g. parameters related to radiator type, nominal
output or coefficient KC) are set before installation on the radiator. Billing period is year.
2.2. TYPE E-ITN 30.3
Allocator is equipped with individual scale. For proper evaluation of measured data, it is necessary to set:
•radiator type (KC)
•radiator nominal output (M)
•evaluation coefficient (KCHF) describing heat contact with sensor of radiator temperature
Parameter can be set by manufacturer or before installation with Programming unit for changing allocator
parameters of E-ITN 20.x, 30.x connected to PC. Radiator type (Kc) can be set in sleeping mode by pressing
the button. E-ITN 30.3 ican be ordered after agreement with manufacturer only. Billing period is year.
2.3. TYPE E-ITN 30.4
Allocator is equipped with unified scale. No parameters (e.g. parameters related to radiator type, nominal
output or coefficient KC) are set before installation on the radiator. Billing period is month.
5 / 46

E-ITN 30
Installation and service manual M2019/01a [EN]
3. TECHNICAL SPECIFICATIONS
Application tmin ≥ 35 °C (min. temperature of the heating medium)
tma ≤ 105 °C (ma . temperature of the heating medium)
Measuring principle two-sensor measuring principle
Conditions for registration temperature of the sensor of the radiator temperature ≥ 23 °C
difference of mean temperature of heating medium and surroundings
temperature ≥ 4 °C
Billing period year (E-ITN 30.2, E-ITN 30.3)
month (E-ITN 30.4)
Resulting rating factor K unified scale, K = 1 (E-ITN 30.2, E-ITN 30.4)
individual scale (E-ITN 30.3)
Calendar functions E-ITN 30.2
•consumption value in the last billing period
•for last 12 moths: month values, min., average and ma .
radiator temperatures, number of heating days
E-ITN 30.3
•for the last billing period: average surroundings temperature,
number of measuring cycles in single-sensor mode, ma .
radiator temperature, ma imal temperature date, minimal
temperature date
•for last 12 months: month values
E-ITN 30.4
•consumption value in the last billing period
•for last 12 moths: month values
•for last 6 moths: min., average and ma . radiator
temperatures, number of heating days
Display 5 digits LCD + 2 special symbols
Protection against cheating continuous control, if thermal influence is detected, allocator is
switched to single-sensor mode
mechanical seal with billing company label
electronic seal – records manipulation date when uninstalled
Data backup daily backup of measured values including real time
Function control automatic, can be activated and controlled by user
Dimensions 100 37 33 mm
Power supply lithium battery 3,0 V
Material ABS + PC / Al – F22
IP code IP 42
6 / 46

E-ITN 30
Installation and service manual M2019/01a [EN]
Conformity ČSN EN 834
Operating frequency 868 MHz
Transmitting power < 5 mW
Class of working cycle 1 (duty cycle percentage <0,1 %)
Transmission length 8 ms
Reading period
(frequent transmission)
E-ITN 30.2, E-ITN 30.3
•30 - 36 seconds first month after the billing period beginning
•240 - 246 seconds rest of the year
E-ITN 30.4
•30 - 36 seconds first 3 days after the billing period beginning
every month besides July and August
•240 - 246 seconds rest of the year
Transmission range up to 250 m (outside the building, with additional panel antenna)
Rem.: all metal parts of construction switch rooms, armouring, lifts,
etc.) can negatively affect the range of radio signal.
Data coding yes
Data available via radio interface
(for e act data structure see
manual for decoding software)
E-ITN 30.2, E-ITN 30.4
•reading date
•serial number
•value for the last billing period
•alphanumeric code for the last billing period
•actual value
•electronic seal status
E-ITN 30.3
•reading date
•serial number
•value for the last billing period
•alphanumeric code for the last billing period
•actual value
•electronic seal status
•average surroundings temperature for the last billing period
Data available via infra-red
interface (for e act data structure
see manual for decoding software)
E-ITN 30.2
•reading date
•serial number
•date of billing period beginning
•value for the last billing period
•alphanumeric code for the last billing period
•month values in last 11 months
•actual value
•ma . radiator temperature in last 11 months
•min. radiator temperature in last 11 months
•average radiator temperature in last 11 months
•number of days in month when conditions for measuring were
fulfilled in last 11 months
•date of electronic seal breakage
E-ITN 30.3
7 / 46

E-ITN 30
Installation and service manual M2019/01a [EN]
•reading date
•serial number
•date of billing period beginning
•value for the last billing period
•alphanumeric code for the last billing period
•monthly values in last 11 months
•average surroundings temperature for the last billing period
•number of measuring cycles in single-sensor mode for the last
billing period
•ma . radiator temperature in last 11 months
•day when the ma . temperature was achieved
•min. radiator temperature in last billing period
•day when the min. temperature was achieved
•date of electronic seal breakage
•set radiator type
•set nominal radiator output [W]
•set coefficient KCHF [ - ]
E-ITN 30.4
•reading date
•serial number
•date of billing period beginning
•value for the last billing period
•alphanumeric code for the last billing period
•monthly values in last 11 months
•value for the last year
•ma . radiator temperature in last 5 months
•min. radiator temperature in last 5 months
•average radiator temperature in last 5 months
•number of days in month when conditions for measuring were
fulfilled in last 5 months
•alphanumeric code for the billing period before last and 3
previous billing periods
•date of electronic seal breakage
3.1. CONSTRUCTION
Electronic heat cost allocator E-ITN 30 complies with ČSN EN 834:1995.
Allocator consist of cover and printed circuit board covered with mounting plate. Mounting plate is bolted with
cover and secured with latch and seal..
Cover, mounting plate, latch and seal are made from plastic material. There are marked values of the lowest
and highest heating medium temperature, manufacturer's mark, type of the allocator, serial number (both as
number and bar code) and optionally the partner's mark on the cover. The base plate is made of aluminium
alloy to ensure of a good thermal contact with the radiator.
To install the heat cost allocator, place it at the upper end of the aluminium back plate, push down so that
the locks in the housing fit in the aluminium back plate and push the bottom part of allocator towards back
plate. Allocator is fastened to back plate by latch and seal. Now the heat cost allocator can only be uninstall
after breaking the seal.
Device has an electrical circuitry with a 16-Bit microprocessor with e tremely low current consumption, is
equipped with radio transmitter and powered by lithium battery. The accuracy of the measuring circuit is
independent of the battery voltage. The LCD-display has 5 large main digits separated by dots and special
symbols.
8 / 46

E-ITN 30
Installation and service manual M2019/01a [EN]
4. OPERATION MODES
4.1. OPERATION MODES
The allocator can be in four operation modes:
•sleeping mode
•mode of waiting for start date
•working mode
•error mode
4.2. SUBMENU NAVIGATION
The allocator contains a simple submenus (depending on current operation mode), that allow to obtain
additional informations or perform other activities.
To switch between individual items of menu, push the button briefly. To enter the submenu, choose relevant
item and hold the button (appro imately 2 seconds) until --A-- appears on LCD. When you release the
button, designation of the 1st submenu item appears. Move in menu by short presses of the button. If the
button is not pushed for 20 seconds, the LCD returns to the main menu.
Activation process of item is the same as entering the submenu. Find the relevant item and hold the button
(for appro imately two seconds), till notice --A -- on the LCD appears.
Movement in options is the same – briefly press the button. Selected option confirmation as well – by long
(appro . 2 s) press of the button, till notice --A-- appears on LCD.
4.3. SLEEPING MODE
Allocator consumption is reduced to a minimum since no measuring and no calculations are carried out and
furthermore allocator does not transmit the data. Sleeping mode is suitable for prolonged storage prior to
allocator use. The storage period should not e ceed one year.
In sleeping mode allocator allows the following operations:
•activation of working mode
•allocator self test
•displaying of: set radiator type, heat output of the radiator and coefficient KCHF (E-ITN 30.3 only)
•setting of radiator type (E-ITN 30.3 only)
Sleeping mode is indicated with notice uPr on the display. If the display does not show any value or notice
(due power saving), press the button briefly to switch LCD on.
4.3.1. Submenu structure in sleeping mode
When notice uPr appears, hold the button till notice --A - - is displayed and indicates submenu activation.
Submenu activation and navigation in the items is described in chapter 4.2. Submenu navigation.
Table 1: Submenu structure in sleeping mode, type E- ITN 30.2 a 30.4
Activation of working mode Act
Allocator self test ti
Table 2: Submenu structure in sleeping mode, type E- ITN 30.3
Radiator type (e.g. 2) tot 2
Heat output of the radiator (e.g. 5000 W) 5000
Coefficient KCHF (e.g. 1.050) 1.050
Setting of radiator type ntt
Activation of working mode Act
Allocator self test ti
9 / 46

E-ITN 30
Installation and service manual M2019/01a [EN]
4.3.1.1. Activation of working mode
If the allocator is in a sleeping mode, working mode can be activated using button. For activation of working
mode, submenu item Act is used.
Working mode activation:
1. Switch to submenu in sleeping mode.
2. When notice Act appears, press and hold the button till notice --A - - is displayed. When you release
the button, first menu item is displayed: chapter 4.5.1. Menu structure in working mode.
4.3.1.2. Allocator self test
Allocator self test is used for control of all LCD segments and to test A/D converter for temperature
measurement. We can run the test in sleeping mode, working mode and also in mode of waiting for start
date. Option is located in submenu whose activation was described above.
To start the test:
1. Switch to submenu item marked as ti (allocator test) with brief press of the button.
2. While ti is displayed, press and hold the button, till notice --A - - appears.
3. Allocator self test has three phases. 1st phase: all segments are turned on . 2nd phase:
radiator temperature is displayed, e.g. 36.4°C and in 3rd phase surrounding temperature appears.
e.g. 25.4°C SM. Every value is displayed for 2 seconds and LCD is automatically switched into the
main menu when self test is completed.
If A/D converter malfunction is detected, allocator switches to fault mode and notice Error is displayed on
LCD.
4.3.1.3. Setting of radiator type E - ITN 30.3 only)
Switch to the submenu in sleeping mode. Switch to submenu 4 th item marked as ntt (radiator type setting)
with button short presses. While ntt is displayed, press and hold the button, till notice --A - - appears. After
button release, notice ot x is displayed (number „x“ indicates the selected type of radiator).
Press the button briefly to browse in radiator types and than choose the right one. Confirm selected type of
radiator with long press (hold the button till --A - - is displayed). After button release submenu item tot
appears (number „x“ gives us selected type of the radiator).
Table 3: Radiator setting – options
Steel plate radiator with vertical offsets ot 0
Steel plate radiator with smooth front panel ot 1
Steel segmented radiator ot 2
Cast iron segmented radiator ot 3
Universal (average value 0 to 3) ot 4
4.4. MODE OF WAITING FOR START DATE
This mode is suitable when you require to start multiple allocators on the same date. In this mode, the
allocator regularly updates real time and compares current date with start date. When the start date is
reached, the allocator will start measuring (switch to working mode).
Mode of waiting for start date is indicated with notice: e.g. o 1.12. (date indicates the date of start). If the
display does not show any indication (because of power saving), press the button briefly to switch it on.
In mode of waiting for start date, following actions can be performed:
•allocator self test
•displaying of: set radiator type, nominal radiator power and coefficient KCHF (E-ITN 30.3 only)
10 / 46

E-ITN 30
Installation and service manual M2019/01a [EN]
4.4.1. Submenu structure in mode of waiting for start date
For submenu activation and navigation between items see chapter 4.2. Submenu navigation. Allocator self
test activation is described in chapter 4.3.1.2. Allocator self test. Radiator type selection E-ITN 30.3 is
described in chapter 4.3.1.3. Setting of radiator type (E-ITN 30.3 only).
Table 4: Submenu structure in mode of waiting for start date, type E-ITN 30.2 and 30.4
Allocator self-test ti
Table 5: Submenu structure in mode of waiting for start date, type E-ITN 30.3
Radiator type (e.g. 2) tot 2
Heat output of the radiator (e.g. 5000 W) 5000
Coefficient KCHF (e.g. 1.050) 1.050
Allocator self-test ti
4.5. WORKING MODE
In working mode, allocator performs temperature measurement, calculates the increase of valuecal (if
measurement conditions are met), transmits measured data, updates real-time and makes some other
actions in regular intervals.
4.5.1. Menu structure in working mode
If nothing is displayed press the button briefly.
Table 6: Submenu structure in working mode, type E-ITN 30.2 a 30.4
Value for current billing period 245
Value for last billing period 458 SM
Alphanumerical code for last billing period A0iht
Serial number – first part -3400
Serial number – second part 0060-
* Radiator temperature 53.3°C
* Surroundings temperature 26.7°C SM
* Date of billing period beginning - E-ITN 30.2
- E-ITN 30.4
U 1.12.
dF 1
* Current date 10.12.
* Current time 12-45
Note: menu items marked as * are optional, see chapter 5.2. Allocator parameters setting.
Table 7: Submenu structure in working mode, type E-ITN 30.3
LCD test
Current date 10.12.
Start of the billing period u 1.2.
Value for last billing period 458 SM
Alphanumerical code A0iht
Average surroundings temperature for last billing
period
23.7°C SM
Value for current billing period 245
11 / 46

E-ITN 30
Installation and service manual M2019/01a [EN]
4.5.1.1. Value for current billing period
Value for current billing period is displayed as 389 (without insignificant zeros). It is calculated from the
beginning of the current billing period.
4.5.1.2. Value for the last billing period
Value for the last billing period is displayed as 3258 SM. Transfer of measured value for actual billing period
to value for the last billing period is performed, when new billing period is achieved in 00:00:00.
4.5.1.3. Alphanumeric code
5 digit alphanumeric code comprises from numbers and letters mentioned from following set:: 0, 1, 2, 3, 4, 5,
6, 7, 8, 9, A, b, c, d, E, F, h, i, J, L, n, o, P, r, t, u.
On LCD it is displayed e.g. A.0.i.h.t. Alphanumerical code is created when transfer of measured value for
actual billing period to measured value for last billing period is performed. If transfer of measured value was
never done before, . .-.-. . appears on the display (alphanumeric code value is not available).
4.5.1.4. Serial number E-ITN 30.2, 30.4 only)
Serial number is 8 digit figure and it is also labeled on the cover. Serial number is divided in two parts. E.g.
serial number „32000015” is displayed as figure -3200 and 0015-. Symbol „ - “ distinguish between first and
second part of the serial number.
4.5.1.5. Temperature of the radiator sensor E-ITN 30.2, 30.4 only )
Temperature of the radiator sensor is displayed as 45.9°C with accuracy of one decimal place.
4.5.1.6. Temperature of the surroundings sensor E-ITN 30.2, 30.4 only)
Temperature of the surroundings sensor is displayed as 26.7°C SM with accuracy of one decimal place.
4.5.1.7. Date of the billing period beginning
Beginning of the billing period is displayed as u 1.2. (year versions) or as dF 15 (month versions). After the
date is reached, allocator transfers value for current billing period to value for last billing period and
alphanumeric code is generated at 00:00:00 .
Beginning of the billing period can be set by manufacturer or with Programming unit for changing allocator
parameters of E-ITN 20.x, 30.x connected to PC or notebook to any required date.
4.5.1.8. Current date
Current date is displayed as 3.12.. Calendar takes leap years into account.
4.5.1.9. Current time E-ITN 30.2, 30.4 only)
Current time is displayed in 24 cycle, e.g. 8-56 (8:56 AM). Summer time is not distinguished.
4.5.1.10. Display test E-ITN 30.3 only)
During display test all segments are turned on . The test is important when the measured values
are read visually.
4.5.1.11. Average ambient temperature for the last billing period E-ITN 30.3 only)
Average surroundings temperature is displayed as 24.4°C SM with accuracy of one decimal place.
12 / 46

E-ITN 30
Installation and service manual M2019/01a [EN]
4.5.2. Structure of submenu with month values ( -ITN 30.2, 30.4 only)
Enter submenu from the main menu. When the display is on and 1st menu item is displayed (value for the
current billing period, e.g. 389), press and hold the button, till notice --A--, is displayed. After button release,
1st submenu item du is displayed (month values).
Table 8: Submenu structure in working mode, type E-ITN 30.2 and 30.4
Month values du
Allocator self-test ti
To switch between the submenu items, press the button shortly. If the button is not pressed in 20 seconds,
allocator switches back to the main menu and the 1st item will be displayed.
Measured month values can be displayed 11. moths back from the current date. When submenu item
„month value“ du is displayed press and hold the button till –A-- appear. After release, current month number
- 0 is displayed.
Table 9: Structure of submenu with month values, type E-ITN 30.2 a 30.4
Current month - 0
Value for the current billing period 389
Last month - 1
Value at the end of the last month 245
... ...
11th month back - 11
Value at the end of the 11th month back 1989
Total number of displayed items is 24.
To switch between submenu items, press the button shortly. To end this submenu, do not press the button for
20 seconds, allocator will switch back to the main menu and the 1st item (value for the current billing period)
will be displayed. Also the long button press can be used to e it. Press and hold the button till --A-- appears.
After release, menu item „value for the current billing period“, e.g. 389 is displayed.
Procedure how to run allocator test is described in chapter 4.3.1.2. Allocator self test.
4.5.3. Structure of submenu with month values ( -ITN 30.3 only)
Measured month values can be displayed 11 months back from the current date. When display is on and
item “value for last billing period“ (e.g. 3258 SM) is displayed, press and hold the button till notice --A--
appears. After release actual date is displayed as e.g. 10.07 (10 - month, 07 - the last two digits of the year).
Table 10: Structure of submenu with month values, type E- ITN 30.3
m0 – current moth, r0 - last two digits of the year „m0. r0“
0 – value for current billing period „ 0“
m1 – last month, r1 - last two digits of the year „m1. r1“
1 – value at the end of the last month „ 1“
... ...
m11 - 11. month back, r11 - last two digits of the year „m11. r11“
11 – value at the end of the 11th month back „ 11“
Total number of displayed items is 24.
E cept current moth, values correspond with measured values at the end of the month from the beginning of
the billing period.
To switch between submenu items, press the button shortly. To end this submenu, do not press the button
for 20 seconds, allocator will switch back to the main menu and the 1st item (LCD test) will be displayed. Also
13 / 46

E-ITN 30
Installation and service manual M2019/01a [EN]
the long button press can be used to e it. Press and hold the button till --A-- appears. After release, menu
item „value for last billing period“ will appear.
4.5.4. Menu structure in service mode ( -ITN 30.3 only)
Allocator can be switched into service mode by following procedure: when item „LCD test“ ( ) is
displayed, press and hold the button, till notice –A-- appears. After release allocator will switch into the
service mode.
Table 11: Menu structure in the service mode, type E-ITN 30.3
Number of measuring cycles in one sensor mode 7526 SM
Ma . radiator sensor temperature in last billing period 61.9°C SM
Date when ma . radiator sensor temperature in last billing period was
reached
3.12. SM
Min. radiator sensor temperature in last billing period 25.4°C SM
Date when min. radiator sensor temperature in last billing period was reached 12.12. SM
Value for penultimate billing period 3258 SM
Values are not displayed in 6 s intervals like in user mode, it is necessary to press the button shortly to see
ne t value. If button is not pressed for 20 s, allocator switch back to the user mode. Switching to user mode
can be speed up by button long press (press and hold the button till --A-- appear on the display.
4.5.4.1. Number of measuring cycles in single sensor mode
Number of measuring cycles is one sensor mode in last billing period is displayed as e.g. 7526 SM (without
meaningless zeros). Ma imal displayable value is 99 999. If this value is e ceeded, E SM is be displayed.
4.5.4.2. Max. temperature of radiator sensor in last billing period
Ma imal temperature of radiator sensor in last billing period is displayed as e.g. 61.9°C SM with accuracy to
one decimal place.
4.5.4.3. Date when the max. temperature of radiator sensor in last billing period was reached
Date when the ma imal temperature of radiator sensor was reached is displayed as e.g. 3.12. SM.
4.5.4.4. Min. temperature of radiator sensor in last billing period
Minimal temperature of radiator sensor in last billing period is displayed as e.g. 25.4°C SM with accuracy to
one decimal place.
4.5.4.5. Date when the min. temperature of radiator sensor was reached in last billing period
Date when the minimal temperature of radiator sensor was reached is displayed as e.g. 12.12. SM.
4.5.4.6. Value in penultimate billing period
Value in penultimate billing period is displayed as e.g. 3258 SM. Value will be overwritten at 00:00:00 when
the new billing period begins.
4.5.5. Last year of battery life
Battery lifetime is programmed in the microprocessor memory and the last year of battery lifetime is indicated
on LCD by blinking of the special symbol: BAT. After finishing this time the symbol stays displayed
permanently. Calculated battery lifetime is 10 years + 1 year reserve.
14 / 46

E-ITN 30
Installation and service manual M2019/01a [EN]
4.6. ERROR MODE
In error mode the notice Error is permanently displayed and allocator does neither measure temperatures,
count the increase of consumption nor transmit measured data. Allocator just actualizes real time. Allocator
switches from working mode to error mode automatically after registration of serious error (e.g. fault in A/D
converter, when the power supply of microprocessor was interrupted and loss of data in RAM memory
occurred, etc.).
Allocator backups important data to permanent memory daily. Data in this memory are saved even if the
power supply is interrupted. Even in the case of battery failure these data are not lost. Saved data could be
read by special tools.
15 / 46

E-ITN 30
Installation and service manual M2019/01a [EN]
5. OTHER INFORMATIONS
5.1. ELECTRONIC SEAL REACTIVATION
The electronic seal is used for detection if allocator was removed from back plate – more in chapter 2.
Device description. If you need to re-fit allocator (e.g. replace old radiator with new radiator), it is necessary
to reactivate the seal.
1. Insert new latch into allocator (Illustration 3: Electronic seal assembly). If use the old one, please
check its condition, especially electro-conductive rubber.
2. Secure the latch with mechanical seal.
3. Read allocator with IRU 10.00 unit (for more informations see Installation and service manual for
infra-red reading unit IRU 10.00). Allocator now displays the menu items.
4. Install allocator to the radiator.
5.2. ALLOCATOR PARAMETERS SETTING
Basic settings as per Setting protocol is done by manufacturer. Parameters can be changed later with
Programming unit for changing allocator parameters of E-ITN 20.x, 30.x connected to PC. Settings or
parameters adjustment can be performed only via built-in interface that is available only when allocator is
opened (disassemble from back plate).
5.3. TRANSPORTATION
E-ITN 30 allocators can be transported under following conditions:
•devices can be transported by all usual covered means of transport
•devices must be in original package
•originally packed devices must be stored and secured to avoid mechanical damages during
transportation
•devices can not be transported together with aggressive substances
•temperature during transportation from 0 °C to +55 °C
•relative humidity from 45 % to 75 %
16 / 46
Illustration 3: Electronic seal assembly
1
2

E-ITN 30
Installation and service manual M2019/01a [EN]
5.4. STORAGE
E-ITN 30 is an electrical device and can be stored under these conditions:
•devices must be originally packed by manufacturer and individually stored in antistatic bags
•storage temperature from +10 °C to +30 °C
•relative humidity from 45 % to 75 %
•devices must be stored in clean covered areas without aggressive substances and stored properly to
avoid mechanical damage
5.5. APPLICATION AND DISPOSAL
"This device is subject to a waste management in accordance with local legislation."
5.6. DEFECTS AND THEIR ELIMINATION
Any E-ITN 30 defect should be repaired by manufacturer only.
5.7. WARRANTY
If device is installed and handled according to manufacturer instructions mentioned in Installation and service
manual, manufacturer provide warranty under the valid legislation unless agreed differently.
The warranty is void if device was used contrary to Installation and service manual or damaged:
•during transport or storage by customer or reseller
•when mounted or dismantled to the customer device
•because of improper handling or installation into other device than agreed in manual
•if the product was e posed to different environment than agreed in manual
•if mechanically or in other way damaged by user
17 / 46

E-ITN 30
Installation and service manual M2019/01a [EN]
6. ACCOMPANYING DOCUMENTATION
6.1. ORDERING
Order must include Setting protocol that is available on the website for business partners. In every order
following items must be specified:
•quantity
•type
•attach Setting protocol – if column "required value" is empty, default values are set
•spare parts (e tra pieces)
•delivery date
•method of transport
Order e ample: 100 pcs E-ITN 30.2, required delivery 28.2.2012, EXW + filled Setting protocol.
6.2. PACKING
Allocators are disassembled (allocator, back plates, mounting material) and packed in the bo es of ma . 100
pcs. Packing sheet is included in every bo (e.g. Illustration 4: Packing sheet) with mark of the producer,
device type, number of items and their serial numbers, packing date and the name of the operative who
checked and packed the products. The lids of bo es are marked with label "THIS SIDE UP!". The bo es are
non-returnable. Bo es are stored always cover up on the standard shipping pallets.
Electronic heat cost allocator E-ITN 30 is sensitive to static electricity. For this reason, each allocator is
shipped in antistatic packaging. Antistatic package should be removed just before installation.
18 / 46

E-ITN 30
Installation and service manual M2019/01a [EN]
19 / 46
Illustration 4: Packing sheet

E-ITN 30
Installation and service manual M2019/01a [EN]
E-ITN 30
INSTALLATION
20 / 46
