Apera Instruments Premium Series User manual

1
Premium Series PC60 5-in-1 Tester
(pH/Conductivity/TDS/Salinity/Temp.)
User Manual
APERA INSTRUMENTS (Europe) GmbH
aperainst.de

2
V7.7
Thank you for purchasing Apera Instruments PC60 Premium Multi-parameter Tester. Please
read this manual before use in order to properly use and maintain the product.
For video tutorials, please go to support.aperainst.de
Contents
1What’s in the Kit ............................................................................................................3
2Keypad Functions .........................................................................................................3
3Preparation Before Use ................................................................................................4
4pH Calibration................................................................................................................4
5pH Measurement ...........................................................................................................5
6Conductivity Calibration...............................................................................................6
7Conductivity Measurement ..........................................................................................6
8Probe Cleaning..............................................................................................................7
9Probe Storage ...............................................................................................................7
10 Parameter Settings ....................................................................................................8
11 Technical Specifications ...........................................................................................9
12 Probe Replacement ...................................................................................................9
13 Battery Replacement ...............................................................................................10
14 Troubleshooting Guide ...........................................................................................11
15 Warranty ...................................................................................................................12
ATTENTION
•Water droplets are added during production to maintain the moisture of the probe. This is
normal practice and should not be attributed to used product.
•Never use the product when it’s freezing cold. Let it warm to room temperature before using.
•The latest PC60 Tester comes with an upgraded probe structure equipped with a sensor
shield that prevents glass bulb breakage from accidental collisions (see picture below). Users
can remove the shield when cleaning the sensor and put it back on after cleaning.

3
1 What’s in the Kit
2 Keypad Functions
Short press ------ < 2 seconds
Long press ------ > 2 seconds
1. Short press to turn on the tester and long
press to turn off the tester.
2. When turned off, long press to enter
parameter setting.
3. In measurement mode, short press to turn on
backlight.
1. In measurement mode, short press to switch
parameter pH →COND →TDS →SAL
2. In parameter settings, short press to make
change
(Unidirectional)
1. Long press to enter calibration mode.
2. In calibration mode, short press to confirm
calibration.
3. When reading is locked, short press to
unlock;
Battery Cap
Buttons
Probe
Ring
Sensor
Probe Cap
LCD Display
pH Sensor
Platinum black
Conductivity
Sensor
Conductivity calibration vials
pH calibration vials

4
3 Preparation Before Use
3.1 Pull out the battery insulation slip, and take off the probe cap.
3.2 Rinse off the probe in pure water (preferably distilled or deionized water. RO water or tap
water is the alternative) , then shake off excess water.
3.3 Perform calibration. For pH calibration tutorial, refer to Section 4; for conductivity calibration,
refer to Section 6.
3.4 If the tester hasn’t been used for a long time (over 1 month), please soak the probe in the 3M
KCL soaking solution for 15 minutes, then calibrate it before test.
4 pH Calibration
4.1 How to Calibrate
4.1.1 Short press to power on.
4.1.2 Pour pH buffer solutions in the correspondent calibration vials
to about half volume.
4.1.3 Rinse the probe in pure water; Shake off excess water. Dip the
probe in the pH 7.00 buffer solution first, and make a quick stir
in the solution, then hold still.
4.1.4 Long press to enter calibration mode, screen will turn
green (Short press if you decide to quit calibration and
return to measurement mode).
4.1.5 Wait for the reading to stabilize (when stays on the screen),
then short press to start the 1st point calibration. After calibration
is completed, the tester will return to measurement mode. Icon
will appear at the bottom left of the screen, indicating a successful 1-
point calibration (middle point).
4.1.6 To calibrate 2nd point, use 4.00 pH buffer and repeat Step 4.1.3 to 4.1.5 (Do NOT turn off the
tester after you finish pH 7 calibration). will display next to , indicating a successful
2-point calibration (low and middle points).

5
4.1.7 If necessary (target pH > 8.00), calibrate 3rd point using 10.01 standard pH buffer and
repeat Step 4.1.3 to 4.1.5, will show up next to and , indicating a successful 3-
point calibration (high, low, and middle points).
4.2 Notes about Calibration
a) The 1st point calibration must be 7.00 pH. Perform the 2nd and 3rd point calibrations (4.00,
10.01, 1.68, or 12.45) immediately after the 1st point calibration is finished. Do NOT turn off
the meter before you calibrate 2nd or 3rd point. Otherwise, you will need to restart the
calibration process with 7.00 pH first.
b) The pH 4.00 and 7.00 buffer solutions poured into the calibration vials can be used for up to
10 times as long as they are not contaminated and the bottles are capped when not in use.
pH 10.01 can only be used for up to 5 times as it will lose its accuracy much faster. After that,
replace the buffer solutions in the calibration vials with new ones to keep the accuracy.
Keeping the freshness and cleanliness of calibration buffers is essential for accurate pH
measurement.
c) The tester can perform 1 to 3 points of automatic calibration and can recognize 5 types of pH
standard solutions. For details, please refer to the following table:
Calibration
USA Series
NIST Series
Indication icon
Recommended
1-pt
7.00 pH
6.86 pH
Accuracy requirement
≥ 0.1 pH
2-pt
Option A
1st pt: 7.00 pH
2nd pt: 4.00 pH or
1.68 pH
Option A
1st pt: 6.86 pH
2nd pt: 4.01 pH or
1.68 pH
Range < 7.00 pH
Option B
1st pt: 7.00 pH
2nd pt: 10.01 pH or
12.45 pH
Option B
1st pt: 6.86 pH
2nd pt: 9.18 pH or
12.45 pH
Range > 7.00 pH
3-pt
1st pt: 7.00 pH
2nd pt: 4.00 or 1.68 pH
3rd pt: 10.01 or 12.45 pH
1st pt: 6.86 pH
2nd pt: 4.01 or 1.68 pH
3rd pt: 9.18 pH or 12.45 pH
Range: 0 to 14.00 pH
5 pH Measurement
5.1 How to take pH measurements
Short press to turn on the tester. Rinse the probe in distilled
water, shake off excess water. Insert the probe in your sample
solution, make a quick stir and hold still. Record the reading when it
is stabilized
( appears and stays on screen).

6
5.2 Pure Water pH Measurement
When testing pure water like tap water, drinking water, RO water and distilled water, it will take longer
for the readings to get fully stabilized (typically 1-5 minutes). Please be patient. If still not working, add
Apera 3M KCL (AI1107) to your pure water at the ratio of 1:1000 (e.g. 1 ml KCL to 1000 ml water) to
accelerate stabilization while minimizing pH change. If the accuracy is not meeting your requirement,
please contact us at [e-mail] to find the specialized meter designed for pure water pH test.
6 Conductivity Calibration
6.1 Power on the tester. Press to switch to conductivity (Cond) measurement mode. Rinse
the probe in pure water and shake off excess water.
6.2 Pour 1413 μS and 12.88 mS conductivity calibration solution into the corresponding
calibration vials to about half volume.
6.3 Long press to enter calibration mode (screen turns green).
6.4 Dip the probe into 1413 μS/cm conductivity calibration solution, stir gently and hold still. When
the reading is fully stabilized ( stays on screen), short press to start one-point
calibration, the tester returns to measurement mode and will appear at the bottom left of
the screen, indicating a successful 1st point conductivity calibration.
6.5 If needed (your target conductivity level is greater than 2 mS or 2000 μS), dip the probe into
the 12.88 mS conductivity calibration solution. Follow the steps in 6.3 to 6.4 to complete the
2nd point of calibration using the 12.88 mS standard solution. will appear next to ,
indicating a successful 2-point conductivity calibration.
6.6 Conductivity Calibration Notes
The tester can calibrate 84 μS, 1413 μS/cm and 12.88 mS/cm conductivity calibration solution. User
can conduct 1 to 3 points calibration. Refer to the table below. Usually calibrating the tester with 1413
μS/cm conductivity buffer solution alone shall meet the testing requirement.
Calibration Indication Icon
Calibration Standards
Measuring Range
84 μS/cm
0 - 200 μS/cm
1413 μS/cm
200 - 2000 μS/cm
12.88 mS/cm
2 - 20 mS/cm
For conductivity calibration solutions, we recommend that users replace new solutions after 5 times
of use to keep the standard solution’s accuracy. Do NOT pour the used calibration solutions back into
the solution bottles in case of contamination.
7 Conductivity Measurement
7.1 Short press to turn on the tester. Rinse the probe in distilled water and dry it. Dip the probe
into your sample solution, make a quick stir, and hold still. Record the reading after it is fully

7
stabilized ( comes up and stays). Press to switch from conductivity to TDS, and Salinity.
7.2 Unit Conversion
a) 1000 µS/cm = 1 mS/cm = 1 EC (In conductivity mode, the unit will automatically turn
from µS to mS if the reading is greater than 1999 µS, meaning you will only see 2.XX mS
instead of 2XXX µS)
b) 1000 ppm = 1 ppt (In TDS mode, the unit will automatically turn from ppm to ppt if the
reading is greater than 999 ppm, meaning you will only see 1.XX ppt instead of 1XXX
ppm)
c) The TDS and Salinity values are converted from the conductivity values via a certain
conversion factor. TDS and conductivity is linear related, and its conversion factor is 0.40
to 1.00. Adjust the factor in parameter setting P5 based on the requirements in different
industries. The factory default setting is 0.71.
d) Salinity and conductivity is linear related, and its conversion factor is 0.5.
e) The tester only needs to be calibrated in Conductivity mode.
f) Conversion Example: if conductivity measurement is 1000 µS/cm, then the default TDS
measurement will be 710 ppm (under the default 0.71 conversion factor), and the salinity
be 0.5 ppt. If TDS conversion rate is changed to 0.5, then the TDS measurement will be
500 ppm.
7.3 Temperature compensation factor
The default setting of the temp. compensation factor is 2.0%/°C. User can adjust the factor
based on test solution and experimental data in parameter setting P4. The following table is
some common examples for setting up the temp. compensation factor.
Solution
Temperature
compensation factor
Solution
Temperature
compensation factor
NaCl
2.12%/°C
10% Hydrochloric acid
1.32%/°C
5% NaOH
1.72%/°C
5% Sulfuric acid
0.96%/°C
Dilute ammonia
1.88%/°C
8 Probe Cleaning
8.1 The tester is only as accurate as the probe is clean. Always thoroughly rinse off the probe before
and after each measurement with pure water in a container or with a wash bottle.
8.2 For tough contaminants, detach the sensor shield, soak the probe in Apera probe cleaning
solution (AI1166) or detergent water for 30 minutes. Then use a soft brush to remove the
contaminants. Afterwards, soak the probe in 3M KCL soaking solution for at least 1 hour. Rinse
it off, then re-calibrate the tester before using again.
9 Probe Storage
9.1 Under regular usage (daily or weekly use), make sure the probe cap is wet, and tightly close

8
the cap with the O-ring.
9.2 For long-term storage (you are not going to use the product for a while), add 3M KCL soaking
solution to the Fill line in the probe cap and store the probe in it. Close on the probe cap tightly
with the O-ring.
9.3 If you find white crystals inside or outside the probe cap, it is perfectly normal. It is the 3M KCL
soaking solution that crystalizes over time by its nature. Just rinse them off and add in new
soaking solution. This chemical is not poisonous nor dangerous, and the probe’s performance
will not be affected at all.
9.4 NEVER store the probe in pure water like tap, RO, distilled, or deionized water as they could
damage the pH probe. If this happens, immediately soak the pH probe Apera 3M KCL soaking
solution overnight, then re-calibrate it before using. Pure water is only for rinsing the probe.
10 Parameter Settings
10.1 Parameter Settings Tutorial
When turned off, long press to enter parameter settings → Short press to switch P1-P2-P3
…P8 → Short press to select parameter (starts flickering) → Short press to change
parameter → Short press to confirm the change →Long press to return to
measurement mode.
10.2 Parameter Setting Instruction
a) Select standard pH buffer solution (P1): There are two options of standard buffer solutions:
USA series and NIST series. Refer to following chart:
Icons
pH Standard Buffer Solution Series
USA series
NIST series
Three-point
calibration
1.68 pH and 4.00 pH
1.68 pH and 4.01 pH
7.00 pH
6.86 pH
10.01 pH and 12.45 pH
9.18 pH and 12.45 pH
Symbol
Parameter Setting Contents
Code
Factory Default
P1
Select pH buffer standards
USA –NIST
USA
P2
Select automatic lock
Off –On
Off
P3
Select backlight
Off –1 –On
1
P4
Temperature compensation factor
0.00 –4.00%
2.00%
P5
TDS factor
0.40 –1.00
0.71
P6
Salinity unit
ppt –mg/L
ppt
P7
Select temperature unit
°C –°F
°F
P8
Back to factory default
No –Yes
No

9
b) Automatic lock (P2): Select “On” to activate auto lock function. When reading is stable for
more than 10 seconds, the tester will lock the value automatically, and HOLD icon will
display on LCD.
Press to cancel auto. hold.
c) Backlight (P3)
“Off”-turn off backlight, “On”-turn on backlight, 1- backlight will last for 1 minute.
d) Factory default setting (P8)
Select “Yes” to recover instrument calibration to theoretical value (pH value in zero potential
is 7.00, slope is 100%), parameter setting return to initial value. This function can be used
when instrument does not work well in calibration or measurement. Calibrate and measure
again after recover the instrument to factory default status.
11 Technical Specifications
pH
Range
-2.00 to 16.00 pH
Resolution
0.01 pH
Accuracy
±0.01 pH ±1 digit
Calibration Points
1 to 3 points
Automatic Temperature Compensation
0 to 50°C (32 to 122°F)
Conductivity
Range
0 to 200.0 μS, 200 to 2000 μS,
2 to 20.00 mS/cm
Resolution
0.1/1 μS, 0.01 mS/cm
Accuracy
±1% F.S
Calibration Points
1 to 3 points
TDS
Range
0.1 ppm to 10.00 ppt
TDS Factor
0.40 to 1.00
Salinity
Range
0 to 10.00 ppt
Temperature
Range
0 to 50°C (32 to 122°F)
Resolution
0.1°C
Accuracy
±0.5°C
12 Probe Replacement
To replace a probe: 1) Take off the probe cap; 2) Screw off the probe ring
3) Unplug the probe; 4) Plug in the new replacement probe (pay attention
to the probe’s position); 5) Screw on the probe ring tightly. Soak the probe
in 3M KCL for 5-15 minutes. Then perform calibration before testing.

10
Probes compatible with PC60 Tester:
•AI1211 PC60-E (Regular pH/conductivity probe),
•AI3719-E PC60-DE (Double-junction pH/conductivity probe),
•AI1201 PH60-E (Regular pH glass bulb probe),
•AI3711-E PH60-DE (Double-junction pH glass bulb probe),
•AI1205 PH60S-E (Spear pH probe for solids/semi-solids pH testing),
•AI1203 PH60F-E (Flat pH probe for surface pH testing),
•AI1209 EC60-E (Conductivity probe)
13 Battery Replacement
Please install batteries according to the following steps. *Please note the correct direction of battery
installation:
The Positive Side (“+”) OF EVERY SINGLE Battery MUST FACE UP.
(WRONG INSTALLATION OF BATTERIES WILL CAUSE DAMAGE TO THE TESTER AND
POTENTIAL HAZARDS!)
①Pull the tester’s cap up
②Slide the battery cap along to the direction of arrow
③Open the battery cap
④Insert the batteries (ALL POSITIVE SIDES FACING UP) (see graph)
⑤Close the battery cap
⑥Slide and lock the battery cap along to the direction of arrow
⑦Fit the tester’s cap while making sure to push all the way down. The tester’s waterproof
design may be compromised if the cap is not fitted correctly.

11
14 Troubleshooting Guide
Trouble
Reason
How to fix
Cannot
calibrate
Pressing too soon
(showing )
Wait for to stay on screen before pressing
.
Incorrect standard solutions
(showing )
Reboot tester, calibrate pH 7 first, then pH 4.
For details refer to Section 4.2 (a).
Poor quality standard
solutions (showing )
Replace with fresh and clean standard
calibration solutions made by legitimate
scientific instrument manufacturers.
Contaminated probe
(showing )
Use a soft brush to clean the probe with Apera
probe cleaning solution or detergent water.
Aged probe
(showing )
Replace the probe.
Dried-out probe
(showing )
Soak the probe in Apera 3M KCL solution for at
least 30 minutes.
Probe is not fully submerged
(showing )
Make sure the probe is fully immersed in the
solution at least 1 inch.
Air bubbles around the sensor
shield (showing )
Make a quick stir in the solution to remove air
bubbles.
Reading is
always slowly
changing, won’t
stabilize
Contaminated probe
Use a soft brush to clean the probe with Apera
probe cleaning solution or detergent water.
Clogged junction
Use a soft brush to clean the probe with Apera
probe cleaning solution or detergent water, then
soak it in Apera 3M KCL soaking solution
overnight.
Aged probe
Replace the probe.
Testing pure water pH like
tap/drinking/RO/distilled water
Be patient, wait for 1-5 minutes to reach a fully
stabilized reading. If still not stabilizing, add
Apera 3M KCL solution to test water at 1:1000
ratio.
Display similar
readings in any
solutions or
always display
7.0 pH
Broken probe
If you don’t find any visible damage of the
probe, contact us for warranty fulfillment; If
there is visible damage, replace the probe.
Instrument defect
Contact us for warranty fulfillment.
Reading keeps
jumping
Probe is not fully submerged
in the solution
Make sure the probe is fully immersed in the
solution at least 1 inch.
Air bubbles around the sensor
shield
Make a quick stir in the solution to remove air
bubbles.
Probe is not properly
connected, or the pin
connector is broken.
Check the probe’s connector, make sure it’s not
broken and is correctly connected. Align the
probe and instrument correctly before plugging
in. Never force it. Ensure that the probe
connector is not exposed to air too long.

12
Calibration is
successful, but
reading is not
accurate
Aged probe
Replace the probe.
Air bubbles around the sensor
shield
Make a quick stir in the solution to remove air
bubbles.
Clogged junction
Clean the probe with probe cleaning solution,
then soak it in 3M KCL soaking solution
overnight.
Comparison with other
testers, test strips, or drop
tests
To compare accuracy with other testers, make
sure to perform calibration for all testers in the
same standard, then test another standard.
Whichever gives more accurate reading is the
more accurate one. Test strips or drop tests’
accuracy in not comparable to pH meters ‘.
Poor quality standard
solutions
Replace with fresh and clean standard
calibration solutions made by legitimate
scientific instrument manufacturers.
The probe is not suitable for
your application.
Contact us to find the most appropriate product
for your specific application.
15 Warranty
We warrant this instrument to be free from defects in material and workmanship and agree to repair
or replace free of charge, at option of APERA INSTRUMENTS (Europe) GmbH, any malfunctioned
or damaged product attributable to responsibility of APERA INSTRUMENTS (Europe) GmbH for a
period of TWO YEARS (SIX MONTHS for the probe) from the delivery.
This limited warranty does not cover any damages due to:
Transportation, storage, improper use, failure to follow the product instructions or to perform any
preventive maintenance, modifications, combination or use with any products, materials, processes,
systems or other matter not provided or authorized in writing by us, unauthorized repair, normal
wear and tear, or external causes such as accidents, abuse, or other actions or events beyond our
reasonable control.
day.
APERA INSTRUMENTS (Europe) GmbH
Wilhelm-Muthmann-Straße 18
42329 Wuppertal, Germany
Contact: [e-mail]
Website: www.aperainst.de
Tel. [phone]
