SX630 ORP Pen Tester Instruction Manual
1. Brief Introduction
Thank you for purchasing SX630 ORP Pen Tester. This tester is featured with reliable measuring
performance with a single-button operation in a slim body. The ORP probe is replaceable and suitable for
test tube measuring and other small-volume sample testing.
2. Specifications
1) Range: ±1999 mV
2) Resolution: ±1 mV
3) Accuracy: ± 0.2% F.S
4) Power: 2 x CR2032 Cell Batteries
5) Dimension and Weight: 148*29*14mm/43g
6) Waterproof rating: IP57
3. Instructions
1) Measurement: Rinse the probe in distilled water and dry it. Dip the probe in the sample solution. Stir
gently and wait until you receive a stable reading.
2) After measurement, rinse the probe with distilled water, dry it, and put the protection cap back on. It’s a
good practice to pour a bit storage solution that comes with kit into the protection cap when storing the
meter, since it will help keep the accuracy of the probe.
4. Notes
1) It is no need to calibrate when testing ORP, but if suspect to the performance of meter or the
measurement result, then can use ORP standard solution to test to identity whether the ORP electrode
or meter is accurate. The meter comes with the following standard solution: 220mV ± 15mV (25°C).
2) After the electrode has been used over a long period of time, the platinum surface will get polluted
which causes inaccurate measurement and slow response. Please refer to the following methods to
clean and activate ORP electrode:
(a) For inorganic pollutant, soak the electrode in 0.1mol/L dilute hydrochloric acid for 30 minutes, then
wash it in distilled water, then soak it in the 3M KCL storage solution for 6 hours.
(b) For organic or lipid pollutant, clean the platinum surface with detergent, then wash it in distilled
water, then soak it in the 3M KCL storage solution for 6 hours.
(c) For heavily polluted platinum surface on which there is oxidation film, polish the platinum surface
with toothpaste, then wash it in distilled water, then soak it in the 3M KCL storage solution for 6 hours.
3) The ORP electrode of this meter can be replaced. The replacement probe’s model number is SX635.
Please go to www.aperainst.de to watch a tutorial video for how to replace the probe.

4) The instrument will turn off automatically after 10 minutes if no operation.
5) Replace the batteries when appears on screen.
5. Warranty
We warrant this instrument to be free from defects in material and workmanship and agrees to repair or
replace free of charge, at option of APERA INSTRUMENTS (Europe) GmbH, any malfunctioned or
damaged product attributable to responsibility of APERA INSTRUMENTS (Europe) GmbH for a period of
two years from the delivery (a six-month limited warranty applies to electrodes). Warranty period is the
time limit to provide free service for the products purchased by customers, not the service life of the tester
or electrodes.
