Apera Instruments PH1 User manual

PH1 Value pH Tester Kit
User Manual
APERA INSTRUMENTS (Europe) GmbH
www.aperainst.de
v 5.1

Thank you for purchasing the Apera Instruments PH1 Pocket pH Tester Kit. Please read this manual carefully
before use in order to properly use and maintain the product.
For video tutorials, please go to aperainst.de/service/support
Table of Contents:
1. General Introduction .......................................................................................................................................1
2. What’s in the Kit? ............................................................................................................................................1
3. Preparation before Use...................................................................................................................................2
4. Calibration.......................................................................................................................................................2
5. Measurement..................................................................................................................................................3
6. Parameter Setting...........................................................................................................................................3
7. Technical Specifications .................................................................................................................................4
8. Probe Cleaning ...............................................................................................................................................4
9. Probe Storage.................................................................................................................................................4
10. Troubleshooting Guide....................................................................................................................................4
11. Battery Replacement ......................................................................................................................................6
12. Warranty..........................................................................................................................................................6
ATTENTION
•Water droplets are added during production to maintain the moisture of the probe. This is normal
practice and should not be attributed to used products.
•Never use the product when it’s freezing cold. Let it warm to room temperature before using.
•The latest PH1 Tester comes with an upgraded probe structure equipped with a sensor shield that
prevents glass bulb breakage from accidental collisions (see picture below). You can remove the
shield when cleaning the sensor and put it back on afterwards.
Sensor Shield

1
1. General Introduction
2. What’s in the Kit?
stands for stabilized reading
stands for successful calibration
is pH 4, is pH 7, is pH 10.
Short Press (tap)
Long Press
(hold for 2 seconds)
1) Power on
2) In settings, change
parameter
3) In calibration mode,
cancel calibration.
1) Power Off
2) When turned off,
long press to enter
settings.
1) In calibration mode,
start calibration
2) In settings, short
press to confirm
changes.
In measurement
mode, long press to
enter calibration
mode.
Probe Cap
•Water droplets are added during production to
maintain the moisture of the probe. This is normal
practice and should not be attributed to used
products.
•The fill line shows the level to which you should
pour the soaking solution or sample solution.
•For details of probe storage, see Section 7.
pH Probe
•Built with Apera’s proprietary lithium glass
membrane for high accuracy and fast
response.
•Temp. sensor is built in for automatic
temp. compensation.
•The pH probe is non-replaceable.

2
3. Preparation before Use
3.1. Prepare a cup of pure water (250-500ml) for probe rinsing. Pure water refers to tap water, RO
water, distilled water, or deionized water.
3.2. Pull off the battery insulation paper; Take off the probe cap.
3.3. Perform a 2-point calibration in pH 7.00 and pH 4.00 standard buffers. Refer to Section 4 for tutorial.
4. Calibration
■Notes
a) The 1st point calibration must be 7.00 pH. Perform the 2nd and 3rd point calibrations (4.00 or 10.01)
right after the 1st point calibration is finished. Do NOT turn off the tester before you calibrate 2nd or
3rd point. Otherwise, you will need to restart the calibration process with 7.00 pH first.
b) In calibration mode, when the measured value is not fully stabilized ( is not staying on LCD),
pressing will cause .
c) Only pH 4.00 and pH 7.00 buffer solutions are included in the test kit, pH 10.01 is not. You can
purchase it separately if needed (when your target pH level is > 8.0 pH).
4.1 Short press to power on.
4.2 Rinse the probe in pure water and shake off excess water. Long
press to enter calibration mode. (Short press to go
back to measurement mode if you want to cancel the
calibration).
4.3 Insert the probe in the 7.00 pH calibration solution to start 1st
point calibration; Make a quick stir in the solution then hold still;
Wait for to appear and stay on the screen.
4.4 Short press to start 1st point calibration; tester returns to
measurement mode; will display on the lower left corner,
indicating a successful 1-point calibration.
4.5 To calibrate 2nd point, use 4.00 pH buffer and repeat Step 4.2 to
4.4 (Do NOT turn off the tester after you finish pH 7 calibration).
will display next to , indicating a successful 2-point
calibration.
4.6 If necessary (target pH > 8.0), calibrate 3rd point using 10.01
standard pH buffer (sold separately) and repeat Step 4.2 to 4.4.
will show up next to and , indicating a successful
3-point calibration.

3
d) Having good-quality standard calibration buffers ready is the foundation for reliable pH
measurement. The bottled buffers (50ml.) in the kit can be used for up to 10 times of calibration
(make sure they are tightly closed when not in use). After that, we recommend replacing them with
new ones to keep the accuracy.
e) Tester will automatically recognize pH buffer solution, users can choose calibration points: 1 point, 2
points, or 3 points. For details, please refer to the following table:
Calibration Solution
Calibration icon
When
1-point
Calibration
7.00 pH
Required Accuracy ≥ 0.3 pH
2-point
Calibration
7.00 pH and 4.00 pH
Target pH level < 8.0 pH
7.00 pH and 10.01 pH
Target pH level > 8.0 pH
3-point
Calibration
7.00 pH, 4.00 pH
and 10.01 pH
Wide measuring range
5. Measurement
5.1. Short press to power on the tester. Remove the probe cap.
5.2. Rinse the probe in pure water. Then shake off excess water.
5.3. Fully submerge the probe into your sample solution at least 1 inch deep, then hold still. Record the
readings after the reading is fully stabilized ( comes up and stays on screen).
◆Pure Water pH Measurement
When testing pure water like tap water, drinking water, RO water and distilled water, it will take longer for
the readings to get fully stabilized (typically 1-5 minutes). Please be patient. If still not working, add Apera
3M KCL (AI1107) to your pure water at the ratio of 1:1000 (e.g. 1 ml KCL to 1000 ml water) to accelerate
stabilization while minimizing pH change. If the accuracy is not meeting your requirement, please contact
us at [e-mail] to find the specialized meter designed for pure water pH test.
6. Parameter Setting
Prompt
Parameter Setting Content
Code
Factory Default Setting
P1
Select pH buffer series
USA –NIST
USA
P2
Select temperature unit
˚F –˚C
˚C
P3
Back to factory default setting
No –Yes
No
Parameter Setting Tutorial
When turned off, long press to enter parameter settings → short press to switch P1-P2-P3
→short press to select the parameter you want to change (parameter flicking) →short press
to make changes, short press to confirm parameter change → long press to go back to
measurement mode.

4
7. Technical Specifications
pH
Range
0 –14.0 pH
Resolution
0.1 pH
Accuracy
±0.1 pH
Calibration Points
1 –3 points
Automatic Temperature Compensation
0 –50˚C (32 – 122˚F)
Temperature
Range
0 –50˚C (32 – 122˚F)
Resolution
0.1˚C /˚F
Accuracy
±0.5˚C/±1˚F
◆pH probes do NOT last forever. They age through normal use and will eventually fail. The average
lifetime of a probe is 1-3 years depending how it is used and maintained. To ensure you receive a
long life from your tester, please ensure you follow the guide below.
8. Probe Cleaning
8.1. The tester is only as accurate as the probe is clean. Always thoroughly rinse off the probe
before and after each test with clean water in a container or with a wash bottle.
8.2. For tough contaminants, detach the sensor shield, soak the probe in Apera’s cleaning solution
(AI1166) or detergent water for 30 minutes. Then use a soft brush to remove the contaminants.
Afterwards, soak the probe in Apera 3M KCL soaking solution (AI1107) for at least 1 hour.
Rinse it off, then re-calibrate the tester before using.
9. Probe Storage
9.1. Under regular usage (daily or weekly use), just make sure the probe cap is wet, and tightly
close the cap with the red O-ring.
9.2. For long-term storage (when you are not going to use the product for a while), add Apera 3M
KCL soaking solution (AI1107) or pH 4.00 buffer solution to the Fill line in the probe cap and
store the probe in it. Close on the probe cap tightly with the red O-ring.
9.3. If you find white crystals inside or outside the probe cap, it is perfectly normal. It is the 3M KCL
that crystalizes over time by its nature. Just rinse them off and use the tester as normal. This
chemical is not poisonous nor dangerous, and the probe’s performance will not be affected.
9.4. NEVER store the probe in pure water like tap, RO, distilled, or deionized water as they could
damage the pH probe. If this happens, immediately soak the pH probe Apera 3M KCL soaking
solution overnight, then re-calibrate it before using. Pure water is only for rinsing the probe.
10. Troubleshooting Guide

5
Trouble
Reason
How to fix
Cannot
calibrate
Pressing too soon
(Showing Er2)
Wait for to stay on screen before pressing .
Poor quality standard
solutions
(Showing Er1)
Replace with fresh and clean standard calibration solutions
made by legitimate scientific instrument manufacturers.
Contaminated sensor
(Showing Er1)
Use a soft brush to clean the probe with Apera probe cleaning
solution or detergent water.
Incorrect calibration order
(Showing Er1)
Reboot tester, calibrate pH 7.0 first, then pH 4.0. For details
refer to calibration notes (a).
Broken probe
(Showing Er1)
If you don’t find any visible damage of the probe, contact
Apera for warranty fulfillment; If there is visible damage,
replace the tester.
Dried-out probe
(Showing Er1)
Soak the probe in Apera 3M KCL solution for at least 15
minutes.
Probe is not fully submerged
solution
(Showing Er1)
Make sure the probe is fully immersed in the solution at least
1 inch deep.
Air bubbles around the
sensor
(Showing Er1)
Make a quick stir in the solution to remove air bubbles.
Reading is
always slowly
changing, won’t
stabilize
Contaminated sensor
Use a soft brush to clean the probe with Apera probe cleaning
solution or detergent water.
Clogged junction
Use a soft brush to clean the probe with Apera probe cleaning
solution or detergent water, then soak it in Apera 3M KCL
soaking solution overnight.
Aged probe
Replace the tester.
Testing pH of low ionic
strength solutions like
tap/drinking/RO/distilled
water
Be patient, wait for 1-5 minutes to reach a fully stabilized
reading. If still not stabilizing, add Apera 3M KCL solution to
test water at 1:1000 ratio.
Display similar
readings in any
solutions or
always display
7.0 pH
Broken probe
If you don’t find any visible damage of the probe, contact
Apera for warranty fulfillment; If there is visible damage or the
probe is more than 6 months old, replace the tester.
Instrument defect
Contact us for warranty fulfillment.
Reading keeps
jumping
Probe is not fully submerged
in the solution
Make sure the probe is fully immersed in the solution at least
1 inch deep.
Air bubbles around the
sensor
Make a quick stir in the solution to remove air bubbles.
Probe is not properly
connected, or the pin
connector is broken.
Check the probe’s connector, make sure it’s not broken and is
correctly connected. Align the probe and instrument correctly
before plugging in. Never force it. Ensure that the probe
connector is not exposed to air too long.
Calibration is
successful, but
reading is not
accurate
Aged probe
Replace the tester.
Air bubbles around the
sensor
Make a quick stir in the solution to remove air bubbles.
Clogged junction
Clean the probe with Apera probe cleaning solution, then soak
it in Apera 3M KCL soaking solution overnight.
Comparison with other
testers, test strips, or drop
tests
To compare with other testers, make sure to calibrate all
testers in the same pH 7.0 solution, then test pH 4.0.
Whichever gives more accurate reading is the most accurate
one. Test strips or drop tests’ accuracy in not comparable to
pH meters‘.

6
11. Battery Replacement
Please install batteries according to the following steps. *Please note the correct direction of battery
installation:
The Positive Side (“+”) OF EVERY SINGLE Battery MUST FACE UP.
(WRONG INSTALLATION OF BATTERIES WILL CAUSE DAMAGE TO THE TESTER AND POTENTIAL
HAZARDS!)
12. Warranty
We warrant this instrument to be free from defects in material and workmanship and agree to repair or
replace free of charge, at option of APERA INSTRUMENTS (Europe) GmbH, any malfunctioned or damaged
product attributable to responsibility of APERA INSTRUMENTS (Europe) GmbH for a period of TWO YEARS
(SIX MONTHS for the probe) from the delivery.
This limited warranty does not cover any damages due to:
Transportation, storage, improper use, failure to follow the product instructions or to perform any preventive
maintenance, modifications, combination or use with any products, materials, processes, systems or other
matter not provided or authorized in writing by us, unauthorized repair, normal wear and tear, or external
causes such as accidents, abuse, or other actions or events beyond our reasonable control.
APERA INSTRUMENTS (Europe) GmbH
Wilhelm-Muthmann-Straße 18
42329 Wuppertal, Germany
Contact: [e-mail]
Website: www.aperainst.de
Tel. [phone]
