Apimaye Ergo User manual

1
APIMAYE ERGO & ERGO PLUS HIVES
Thank you for your purchase & welcome to the growing
Apimaye Beekeepers Family now in more than 30 countries!
Please follow the instructions included on how to set up and use
your new Apimaye Bee Hive
www.apimaye-usa.com and @ Facebook.com/ApimayeUSA
US PATENTED
KAFTAN BROŞÜR.indd 1 26.07.2019 11:16:54

2
BOX CONTENTS
a.
b.
c.
d.
e.
f.
g.
h.
i.
j.
ERGOPLUS HIVE
a
b
c
d
e
f
c
d
g
i
j
h
Top Cover
Top Feeder
Frame Spacer (4 pcs)
Optional 20 Frames
Super
Queen excluder
Brood Box Body
Bottom Board
Brood Division Board
Super Division Board
KAFTAN BROŞÜR.indd 2 26.07.2019 11:16:54

3
BOX CONTENTS
a.
b.
c.
d.
f.
g.
h.
i.
ERGOHIVE
f
i
a
b
c
d
g
h
Top Cover
Top Feeder
Frame Spacer (2 pcs)
Optional 10 Frames
Queen excluder
Brood Box Body
Bottom Board
Brood Division Board
KAFTAN BROŞÜR.indd 3 26.07.2019 11:16:55

4
Your hive is already assembled and is almost
ready to go. Please follow the instructions
to remove the Sliding Pollen Trap from the
bottom board and put the Red Plug in before
introducing the bees to the hive.
If using queen excluder,
make sure to:
1. Have the spacing pins facing down
2. Use the bottom slot of the latch (2a)
3. When queen excluder is
not installed, use the top slot
of the latch (2b)
ASSEMBLY
2a
1
2b
Pollen Tray
Pollen Trap Plag
Anti-slip
Pads
Sliding Pollen Trap
Screened Bottom
Board
Bottom Tray
Multifunctional Hive
Entrance
KAFTAN BROŞÜR.indd 4 26.07.2019 11:16:58

5
USING BOTTOM BOARD 1
Bottom board is mounted
on the brood box.
Includes pollen trap (a) and
tray (b), red pollen trap plug
(c), and screened bottom
board (d).
To enable pollen collection, the trap
should be inserted all the way in.
The pollen can be gathered from
the drawer below.
To disable the pollen trap, pull it out
completely as shown on right.
NOTE: Pollen is essential for bees! Enable
the pollen trap (a) only when there is high
pollen flow. It is not recommended to use it
continuously. Please research about pollen
collection before enabling the pollen trap
KAFTAN BROŞÜR.indd 5 26.07.2019 11:16:59

6
Remove the pollen trap and
drawer entirely to use it as
a full screen bottom or
when installing package
bees or transferring the bees
first time
Whenever you
remove the trap,
close the slot with
the red plug
The pollen trap must be
removed and the red
plug must be inserted on
the slot to use the
division board
USING BOTTOM BOARD 2
KAFTAN BROŞÜR.indd 6 26.07.2019 11:17:00

7
USING HIVE ENTRANCE
2 sliders are used as entrance reducers
2 single holes above the outmost
entrances are for drones
2 notches above the center entrances
are to shut lock the sliders
“Keep the hive entrances wide open when introducing bees to the hive.”
d
a
b
c
The round entrance (blue, green or yellow) piece can be set to be :
a) Additional hive entrance (horizontal slit on top)
b) Queen entrance for mating flights (big hole on top)
c) Ventilation (small holes on top)
d) Shut closed (handle on top)
KAFTAN BROŞÜR.indd 7 26.07.2019 11:17:01

8
HANDY FRAMES ASSEMBLY
Apimaye offers two different kinds of plastic frames.
Handy Frames and Pro Frames. Handy Frames can only take wax foundation,
while Pro Frames can take both plastic and wax foundation. Make sure you use only
beeswax foundation on your handy frames.
1. Your handy frames use
standard deep size wax
foundation (8 1/2″ x 16 3/4″)
2. The handy frames are made of 2
pieces that snap each other.
There are pins at both the top and the
bottom side.
Just split the two pieces and place them
like shown on the left.
Splitting them for the rst time will be
harder, you may want to use a hive tool
or a small knife to make it easier.
Do not split the frames like opening a
book as it may damage the pins at the
bottom. Just try to keep them parallel.
3. Put the wax foundation on top of one
of the halves, and then snap the other
half back on. It should take less than a
minute per frame.
It easy to install plastic foundations
on Pro Frames. Just split the frames
as you do in handy frames. Insert
the plastic foundation and snap the
pieces back.
When installing beeswax foundation
on the Pro Frames, split the 2 pieces,
place the beeswax foundation, press it with your ngers from each
corner to embed the beeswax foundation and snap the other piece
back. (It is important to press the beeswax foundation on the Pro
Frames to prevent the beeswax foundation from sagging.)
KAFTAN BROŞÜR.indd 8 26.07.2019 11:17:02

9
USING DIVISION & UNITING BOARD
You can use
only 4 frames
on each side
when using the
division board
To divide the
colony, use the
division board
with the slots
closed
Make sure the pollen
trap is removed
completely and the
slot is closed with
the red plug
To merge 2 colonies,
adjust the circular
gates for the small slots
first, then larger slots a
few days later
Ergo Plus Hives come with two division boards. The division board for the super is
shorter, therefore the two can not be used interchangeably. Make sure you’re using the
right division board.
KAFTAN BROŞÜR.indd 9 26.07.2019 11:17:03

10
USING SINGLE TOP FEEDER
To fill the feeder:
1. Remove the feeder top by holding from
the center
2. Put the feed (Syrup or candy)
3. Adjust the feed slot covers according to
the feed. The feeder and these covers are
designed to prevent bee drowning in syrup
3a. If feed is syrup make sure all the writings
“SYRUP” is outwards
3b. If feed is candy make sure all the writings
“CANDY” is outwards so bees can walk
to the center of the feeder
4. Close the feeder top and adjust the
yellow handles to secure slot covers
If you have a hive with a single top
feeder, your feeder has a cover with
yellow handles and 4 adjustable feed
slot covers.
You can not use syrup and candy at the same time in the single top feeder.
KAFTAN BROŞÜR.indd 10 26.07.2019 11:17:04

11
USING TOP FEEDER
If you have a hive with a pair of half feeders, each pair has a
cover and 2 adjustable feed slot covers.
To fill the feeders :
1. Remove the feeder cover by holding from the center as shown.
2. Adjust the feed selectors by removing and inserting them into the vertical
slots according to the feed type as follows:
a. If feed is syrup, place all the selectors with the word “SYRUP” away from
the center.
b. If feed is candy, place all the selectors with the word “CANDY” away from
the center.
3. Put in the feed, syrup (as shown below) or fondant / pollen patties.
4. Close the feeder cover.
You can not use syrup and candy at the same time in the single top feeder.
KAFTAN BROŞÜR.indd 11 26.07.2019 11:17:10

12
Liquid Feeding
The cover reading
“Syrup” should be the
outermost cover when
feeding syrup.
INNER COVER TYPE TOP FEEDER
Feeder Cover
Feeder Body
Built in Safety Locks
Alternating
Covers
HALF SIZE FULL SIZE
KAFTAN BROŞÜR.indd 12 26.07.2019 11:17:12

13
Solid Feeding
The cover reading
“Cake” should be the
outermost cover when
feeding cake.
Built-in feeders of the inner cover enable solid
and liquid feeding without having to open the
hive, while both the hive temperature balance
and the bees remain undisturbed.
INNER COVER TYPE TOP FEEDER
KAFTAN BROŞÜR.indd 13 26.07.2019 11:17:13

14
OPTIONAL SUPER
Ergo Deep Super
Ergo Medium Super
• Pro Frame
• Handy Frame
• Wooden Frame
• No Frame
• Handy Frame
• Wooden Frame
• No Frame
KAFTAN BROŞÜR.indd 14 26.07.2019 11:17:17

Please register your product at
apimaye-usa.com/register
And while you’re online, join our Facebook group
Apimaye Beekeepers where you can ask beekeeping
questions or share your bee pictures
Welcome to the family!
“The figures and definitions in this catalogue are entirely for information purposes. The manufacturer reserves the right to make,
at any time and without notice, all kinds of changes it deems necessary to the products, for the purpose of product improvement,
in line with manufacturing or marketing reasons.” This guide is copyright Yıldırım Plastik © 2019.
DON’T FORGET TO REGISTER
KAFTAN BROŞÜR.indd 15 26.07.2019 11:17:20
