APO DK-2890 User manual
DK-2890
User Manual (MK-II)
AEI
PROTECT-ON
SYSTEMS
LIMITED
www.apo-hk.com
FOR ELECTRIC LOCK
AND SECURITY SYSTEMS
BACK-LIT WEATHERPROOF
RFID ACCESS CONTROL KEYPAD
