Apollo Sprayers T5020 MIST APPLICATOR User manual

1
INSTRUCTION MANUAL
(For Professional Use Only)
T5020
MIST APPLICATOR™
DO NOT USE EQUIPMENT BEFORE READING THIS MANUAL
This manual contains important warnings and instructions.
Please read these instructions carefully and keep for your reference.
©2012 Apollo Sprayers International, Inc.

2
Table of Contents
1 General Safety Information: ...................................................................................................... 3
2 Set up and operate your T5020 Spray Tan System: ............................................................... 5
3 Using your T5020 Mist Applicator............................................................................................. 6
4 Troubleshooting the Mist Applicator........................................................................................ 7
5 Maintenance .............................................................................................................................. 8
6 T5020 Diagram and Parts List ................................................................................................... 9
7 Warranty…………………………………………………………………………………………………10
T5020 Mist Applicator™ Instruction Manual
Congratulations on purchasing the T5020 Mist Applicator. This product has been specially designed
to provide an efficient application of tanning solution products.
Take a minute to read and understand how to operate your new T5020 Mist Applicator and you will
be able to provide the perfect tan with every application.
Your T5020 Mist Applicator is packaged with the following:
1. T5020 Spray Gun
2. Parts Kit
3. Instruction Manual

3
1 General Safety Information:
Read all instructions and safety precautions before operating the unit.
THIS INDICATES A CONDITION THAT WILL CAUSE SERIOUS INJURY OR LOSS
OF LIFE IF THE WARNING IS IGNORED.
THIS INDICATES A CONDITION THAT COULD CAUSE SERIOUS INJURY OR
LOSS OF LIFE IF THE WARNING IS IGNORED.
THIS INDICATES A CONDITION THAT MAY CAUSE MINOR INJURY AND/OR
EQUIPMENT/PROPERTY DAMAGE.
• Risk of fire or explosion! Solvent and paint fumes can explode or ignite, causing severe
injury and property damage.
• Paints and solvents containing HALOGENATED HYDROCARBONS can react explosively
with aluminum. Always check the product’s label before using these materials in the unit.
• Hazardous vapors: Paint, solvents, insecticides and other materials may be harmful if
inhaled, causing severe nausea, fainting or poisoning.
• Make sure the room is well ventilated. Avoid all ignition sources, such as static electricity
sparks, open flames, hot objects, sparks from connecting and disconnecting power cords,
and working light switches.
• Follow the material and solvent manufacturers’ safety precautions and warnings. Do not
use liquids with flash points less than 100 degrees Fahrenheit (38 degrees Celsius).
• Static electricity can be produced by HVLP spraying. Make sure any electrically conductive
object being sprayed is grounded to prevent static sparking. The sprayer is grounded to
prevent static sparking. The spray grounded through the electrical cord. If an extension
cord is necessary, the cord must be a grounded with three wires made for the appropriate
voltage used.
• Use a respirator or mask whenever there is a chance that vapors may be inhaled. Read
all instructions with the mask to ensure that the mask will provide the necessary
protection against the inhalation of harmful vapors.
• Do not carry the turbine while spraying.
• Keep the turbine at the maximum distance from the spraying area.

4
1 General Safety Information cont’d.:
• Tipping the Spray Gun causes the Spray Gun to clog. Dried spray material
also clogs the pressure delivery tube
and fittings. The Spray Gun does not function when clogging occurs.
• When not in use, be sure to disconnect the hose and place the Spray Gun into the holder in the turbine to avoid
tipping.
GROUNDING INSTRUCTIONS
This product must be properly grounded. In the event of an electrical short circuit, grounding reduces the risk of electrical
shock by providing an alternate path for the electrical current.
This product is equipped with a cord that has a ground wire and an appropriate ground plug. Plug the unit into an outlet
that is properly installed and grounded in accordance with local codes and ordinances.
IMPROPER INSTALLATION OF THE GROUND PLUG CAN
RESULT IN THE RISK OF
ELECTRICAL SHOCK. IF REPAIR OR REPLACEMENT OF THE PLUG OR CORD IS
NECESSARY, DO NOT CONNECT THE GROUND WIRE TO EITHER FLAT BLADE TERMINAL.
THE WIRE WITH GREEN INSULATION (WITH OR WITHOUT A YELLOW STRIPE) IS THE
GROUNDING WIRE.
1. For any question regarding proper installation of the ground plug, consult a qualified
(licensed or certified) electrician.
2. Do not modify the plug provided. If the plug does not fit the outlet, have the proper
outlet installed by a qualified electrician.
3. This product is for use on a nominal 120-volt circuit and has a grounding plug that
looks like the plug in Figure 2. Make sure that the product is connected to an outlet
having the same configuration as the plug. No adapters should be used with this
product.
4. If an extension cord is required, use only a three wire extension cord that has the
same configuration as the unit cord, including the (round) ground terminal. Make
sure that the extension cord is plugged into a properly grounded receptacle.
5. When using an extension cord, be sure it is in good condition and heavy enough to
meet the specifications in the chart below. If an extension cord is needed the
following wire sizes must be used.
6. (See Chart 1) Figure 2
25’ cord……………………..…….10, 12, or 14 Gauge
50’ cord……………………….………..10 or 12 Gauge
100’ cord………………………………………10 Gauge
Chart 1 Extension Cord Requirements

5
1 Introduction
CONGRATULATIONS!! You have just purchased the finest HVLP Mist Applicator available. You are about to enjoy the
great benefits of HVLP spray tanning. Our designs are the result of many years experience in manufacturing HVLP spray
systems, and Mist Applicators.
Whether you are new to spray tanning, you have sprayed tans before, or are just new to HVLP spray tanning, there are
some basic spraying guide lines that will help you to achieve the best results and optimum success from your new
equipment. Reading this information carefully and following these simple steps will ensure that you get the best
performance and results from your new TrueHVLP™ spray tanning system.
HOW SUN-MIST® HVLP SPRAY TANNING SYSTEM WORKS
Your spray tanning system has three components: the motor unit, the air hose and the Mist Applicator. The motor unit
when connected to the correct electrical power supply and with the on/off switch in the “on” position, provides a
continuous source of clean, warm, dry, High Volume Low Pressure (HVLP) air. The air hose connects the motor unit to
the Mist Applicator. Air flows through the hose to the nozzle of the specially designed Mist Applicator. Atomization of the
tanning solution is achieved when the air mixes with the stream of fluid passing through the tip/nozzle. This low pressure
atomization principle achieves minimal overspray (wasted spray) to the environment.
The Sun-Mist motor unit has one air hose outlet on the side of the case and is designed to run one Mist Applicator.
Your Mist Applicator offers you many options. You can adjust (click) the air cap (#2) to three positions. One will produce a
horizontal pattern for spraying across, another will produce a vertical pattern for spraying up and down, and the third will
produce a round pattern for detailing muscles or other intricate parts of the body.
FAMILIARIZING YOURSELF WITH YOUR MIST APPLICATOR
Familiarize yourself with the controls on the Mist Applicator. There are three principal controls. The rotating air
cap (#2), the material flow screw (#18) and the air cap locking ring (#1). Click the rotating air cap into each
position. Horizontal, Vertical and 45°. When the air cap is in the 45° position the pattern is round. This is useful
for spraying detail areas such as muscle toning. (Flow will increase when using the diagonal position and it is
usually necessary to reduce the flow by adjusting the flow screw (#18). (See Diagram Spray Patterns, Pg. 3).
Next, turn the material flow screw (#18) anti- or counter-clockwise to open or release more fluid, clockwise to
close or reduce material flow.
PREPARING TO SPRAY
You should now be ready to spray your client. Good quality results with your Sun-Mist spray tanning system
are a combination of careful preparation of your client, a proper spraying environment, a basic knowledge of
the solution you will be using and how these solutions work with your Sun-Mist spray tanning system.
You Sun-Mist motor unit is equipped with our new variable speed control. When you turn the motor on it will
start at high speed. To lower the speed of the motor and make the unit quieter, simply rotate the knob
clockwise to the desired speed. If you slow the motor too much you will notice that your Mist will not be as fine.
Be careful to always have your motor speed fast enough to atomize the solution you are spraying evenly. We

6
suggest starting with the speed ½ way and go from there. Each solution is a little different and may require
slightly different speeds.
USING YOUR MIST APPLICATOR
Your Sun-Mist® Mist Applicator is certified. This means your Mist Applicator only uses approximately 3psi or
less. All passages and air ports are much larger than an airbrush system. If one of these air passages
becomes blocked, or build up of solution starts to occur, your spray pattern will become distorted. Therefore,
always keep your Mist Applicator clean. Your Sun-Mist® Mist Applicator comes fitted with a custom size
tip/nozzle (#6) and needle (#15). This size has been designed to perfectly atomize and a variety of UV Sunless
tanning solutions. Using this size tip/nozzle and needle you can achieve from a 1/4" to 7” fan pattern, simply by
rotating the air cap (#2) to the desired fan type (See Mist Applicator Diagram 1 & 2 on pages 13 & 14), opening
the material flow screw (#18) counter-clockwise and moving the Mist Applicator closer or further away from the
client. A little practice will enable you to master this very easy technique.
PRACTICE: Remove the cup from your Mist Applicator. Fill it approximately half way with some water. Attach the cup to
the body of the Mist Applicator. Attach the Mist Applicator to the air hose. Turn the turbine unit on. You will notice air is
now flowing through the air cap, this is normal and correct. Position the air cap (#2) in the horizontal position, turn the
solution flow screw (#18) counter clockwise approximately 1 to 1 1/2 turns. Point the Mist Applicator away from yourself
(and anyone else) and pull the trigger all the way back. You should see a “V” shaped mist (or triangle) called a fan pattern.
Now, with the trigger depressed, slowly begin to turn the solution flow screw (#18) clockwise (closing). Notice that the fan
pattern is beginning to get smaller. Now, reverse this and notice the pattern get larger. Take a large piece of cardboard
and direct the pattern at the surface. Turn the solution flow screw 2 full turns and hold the Mist Applicator approximately 6"
from the surface. Pull the trigger. Observe the outline and size of the pattern. Now, turn the solution flow screw clockwise
(closing). Move the Mist Applicator an inch or two closer to the surface of the cardboard. Pull the trigger. Notice the
pattern has become smaller. You can continue reducing the material flow and move the Mist Applicator even closer to the
cardboard and the pattern will continue to get smaller and smaller. Next, rotate the air cap to a diagonal position (See
Spray Patterns, Pg. 4). Vary the solution flow and the distance of the Mist Applicator from the work surface. Notice the
change in pattern size.
Caution: Even when the turbine unit is turned off, pressure will remain in the spray cup. If you pull the trigger back, a
stream of fluid will flow. To prevent accidents, turn paint flow screw (#18) clockwise until it is completely closed. The
trigger is now locked in the closed position.
Note: It is not necessary to empty and clean your Mist Applicator when you pause between applications. Be sure,
however, to clean your Mist Applicator thoroughly at the end of your work session. It is a bad idea to leave solution in your
Mist Applicator overnight. PROPER SPRAY TECHNIQUE

7
Mist Applicator recommended maintenance: Check: Cup gasket, nozzle gasket, gland seal, air cap holes, nozzle/needle
assembly every 50 hours or when necessary. Clean or replace parts as needed. Mist Applicator maintenance kit part
#A5256.
TROUBLESHOOTING
1.Solution cup full, motor unit air is supplied to the Mist Applicator. Trigger is pulled and no solution comes out—Reason:
Cup not pressurizing.
Check:
A) Air Feed Tube/one way air valve (#25) A.5232
B) Air Feed Connector (#8) (A.5211)
C) Cup is screwed on tight
D) Cup top gasket is not damaged.
2. When Mist Applicator is connected to a turbine and the turbine is on, air continually flows through the air cap even if
the trigger is not pulled. Response: This is correct, “bleeder” type Mist Applicators are necessary and desirable to
ensure longevity of the motor unit.
3. If you think that you are getting too much “overspray”
Try: Moving the Mist Applicator closer to the work
Closing down the fluid flow
RECORD OF MIST APPLICATOR MAINTENANCE
DATE MAINTENANCE PERFORMED
Mist Applicator recommended maintenance: Check: Cup gasket, nozzle gasket, gland seal, air cap holes, nozzle/needle
assembly every 50 hours or when necessary. Clean or replace parts as needed. Mist Applicator maintenance kit part
#a.5256

8
MIST APPLICATOR MAINTENANCE AND CLEANING
1. You do not need to clean your Mist Applicator every time you stop spraying. Either set the Mist
Applicator down carefully so as not to tip it over, or hang it by the hook. You should, however, clean
your Mist Applicator at the end of a work session or at the end of the day. It is not a good idea to leave
solution in the Mist Applicator over night. Also, pay careful attention in keeping the cup threads clean,
this includes the threads on the main gun body as well. Dried material on the threads can cause the
cup to lock onto the surface making removal difficult.
2. When you have finished spraying, pour the remainder of your solution out of the Mist Applicator cup.
Pour in a small amount cleaning fluid. Use a cleaner that is compatible with the solution you just
sprayed (water if nothing else is available). Shake the Mist Applicator gently. Wait about one minute
and spray out the cleaner in the cup.
3. If necessary, remove the Fluid tip (7) and nozzle washer (17). A standard wrench will fit the flanges on
the fluid tip. Be careful not to loose or misplace the nozzle washer. Rinse with appropriate cleaner.
4. To remove the fluid needle assembly, turn the solution adjusting screw (4) all the way counter- (anti)
clockwise until it comes out of the Mist Applicator. Carefully remove the spring (3). Pull the needle
assembly back towards you out of the back of the Mist Applicator. Wipe or rinse clean.
5. Wipe all exposed areas clean again giving special attention to the cup threads.
6. Although they might not need attention every time you spray, you should be aware of two additional
important parts on your Mist Applicator. One is the cup gasket (11) and the fluid Needle Packing (13).
The cup gasket insures that the cup is properly sealed to the Mist Applicator body, the cup is properly
pressurized and no fluid leaks from the Mist Applicator cup. Replace if necessary. The fluid needle
packing (13) compresses around the fluid needle assembly to prevent fluid from leaking around the
needle. This is adjusted by tightening (or loosening) the needle packing screw (14). Be sure that this
screw is not too tight as to not permit free movement of the needle assembly. Be sure that this screw is
not too loose as to permit fluid to leak around the needle. Normally, this is preset at the factory and
should need no adjustment. Replace fluid needle packing (13) when it becomes impossible to prevent
leaking.
7. Store your Mist Applicator for the next use.

9

10
Warranty and Technical Support
For all other technical questions please call your local distributor or Apollo Sprayers Inc.
For spraying technique visit www.hvlptanning.com
Technical Support: Available Monday-Friday, 8am-3pm, PST.
Apollo Sprayers International, Inc.
1030 Joshua Way
Vista, CA 92081
Voice: 760-727-8300
Toll Free: 888-900-4857
Fax: [phone]
Email: [email protected]
Apollo Sprayers International, Inc.
One Year Limited Warranty
Your Sun-Mist T700-BLK tanning system is WARRANTED by APOLLO SPRAYERS INTERNATIONAL, INC. for a total
period of ONE YEAR on a PRO-RATED Basis (see schedule below) from the ORIGINAL date of purchase by the
ORIGINAL PURCHASER. Proof of purchase to be included and all SHIPPING CHARGES to be pre-paid.
APOLLO SPRAYERS INTERNATIONAL, INC. upon examination of the
machine/equipment will replace or repair at their discretion any defects in material or
workmanship.
WARRANTY SCHEDULE
First Six Months…………………..Parts NO CHARGE……………………….Labor.……………NO CHARGE
Second Six Months………………Parts NO CHARGE……………………….Labor….…………CHARGED
Labor will be CHARGED at the current hourly rate, or specified Job Rate.
This WARRANTY does NOT include: miss-use, damage, neglect, alterations, disassembled equipment or modifications,
lack of maintenance, cleaning, water damage to electrical parts and INCORRECT VOLTAGE CONNECTION. This
WARRANTY is in lieu of all other express warranties, any WARRANTY implied by law, including but not limited to implied
warranties of merchantability or fitness, is excluded to the maximum extent permitted by law and, if not excludable, it is
limited to the duration of the express Warranty. No representative or person is authorized to extend this Warranty or to
create for APOLLO SPRAYERS INTERNATIONAL, INC. any other liability in connection with the sale of any APOLLO
SPRAYERS product. APOLLO SPRAYERS INTERNATIONAL, INC. shall not be liable for any consequential,
incidental, or special damages of any kind directly or indirectly resulting from breach of any express or implied Warranty.
Some States do allow the exclusion of limitation of incidental or consequential damages or limitations on the length of any
Warranty so that the above limitations and exclusions may not apply to you; however, to the maximum extent permitted
under applicable law, the only rights and remedies shall be to obtain a replacement for any defective product. This
Warranty gives you specific legal rights and you may also have other rights which vary from State to State.
For warranty repairs inside the United States please call 888-900-4857 or outside the United States call, 760-727-8300.
All repairs must be accompanied by an RMA number from the factory. Please call first before sending any equipment
back to the factory for repair.
