Apollo Sprayers T6000 User manual

T6000 Mist Applicator
INSTRUCTION MANUAL
DO NOT USE THE MIST APPLICATOR BEFORE READING THIS MANUAL
This manual contains important warnings and instructions.
Please read these instructions carefully and keep for your reference.
©2012 (Apollo Sprayers International, Inc.)

2
Table of Contents
1 General Safety Information: ......................................................................................................... 3
2 Prepare the T6000 Mist Applicator: ............................................................................................. 5
3 T6000 Mist Applicator Diagram: ................................................................................................... 6
4 Adjusting your Mist Applicator: ................................................................................................... 7
5 Spraying/Misting: ........................................................................................................................... 8
6 Maintenance: .................................................................................................................................. 9
7 Troubleshooting: ........................................................................................................................... 10
8 Warranty and Technical Support: ................................................................................................ 11
T6000 Mist Applicator® Instruction Manual
Congratulations on purchasing the T6000 Mist Applicator® for UV Sunless spray tanning. This product has
been specially designed to provide an efficient application of tanning solution products.
Take a minute to read and understand how to operate your new T6000 Mist Applicator™ and you will be able
to provide the perfect tan with every application.
Your T6000 is packaged with the following:
1. T6000 Mist Applicator
2. Instruction Manual
3. Parts Kit

3
1 General Safety Information:
Read all instructions and safety precautions before operating the unit.
THIS INDICATES A CONDITION THAT WILL CAUSE SERIOUS INJURY OR LOSS
OF LIFE IF THE WARNING IS IGNORED.
THIS INDICATES A CONDITION THAT COULD CAUSE SERIOUS INJURY OR
LOSS OF LIFE IF THE WARNING IS IGNORED.
THIS INDICATES A CONDITION THAT MAY CAUSE MINOR INJURY AND/OR
EQUIPMENT/PROPERTY DAMAGE.
• Risk of fire or explosion! Solvent and paint fumes can explode or ignite, causing severe
injury and property damage.
• Paints and solvents containing HALOGENATED HYDROCARBONS can react explosively
with aluminum. Always check the product’s label before using these materials in the unit.
• Hazardous vapors: Paint, solvents, insecticides and other materials may be harmful if
inhaled, causing severe nausea, fainting or poisoning.
• Make sure the room is well ventilated. Avoid all ignition sources, such as static electricity
sparks, open flames, hot objects, sparks from connecting and disconnecting power cords,
and working light switches.
• Follow the material and solvent manufacturers’ safety precautions and warnings. Do not
use liquids with flash points less than 100 degrees Fahrenheit (38 degrees Celsius).
• Static electricity can be produced by HVLP spraying. Make sure any electrically conductive
object being sprayed is grounded to prevent static sparking. The sprayer is grounded to
prevent static sparking. The spray grounded through the electrical cord. If an extension
cord is necessary, the cord must be a grounded with three wires made for the appropriate
voltage used.
• Use a respirator or mask whenever there is a chance that vapors may be inhaled. Read
all instructions with the mask to ensure that the mask will provide the necessary
protection against the inhalation of harmful vapors.
• Do not carry the turbine while spraying.
• Keep the turbine at the maximum distance from the spraying area.

4
1 General Safety Information cont’d.:
• Tipping the Mist applicator causes the Mist applicator to clog. Dried spray material also clogs the pressure
delivery tube and fittings. The Mist applicator does not function when clogging occurs.
• When not in use, be sure to disconnect the hose and place the Mist applicator into the holder in the turbine to
avoid tipping.
GROUNDING INSTRUCTIONS
This product must be properly grounded. In the event of an electrical short circuit, grounding reduces the risk of electrical
shock by providing an alternate path for the electrical current.
This product is equipped with a cord that has a ground wire and an appropriate ground plug. Plug the unit into an outlet
that is properly installed and grounded in accordance with local codes and ordinances.
IMPROPER INSTALLATION OF THE GROUND PLUG CAN RESULT IN THE RISK OF
ELECTRICAL SHOCK. IF REPAIR OR REPLACEMENT OF THE PLUG OR CORD IS
NECESSARY, DO NOT CONNECT THE GROUND WIRE TO EITHER FLAT BLADE TERMINAL.
THE WIRE WITH GREEN INSULATION (WITH OR WITHOUT A YELLOW STRIPE) IS THE
GROUNDING WIRE.
1. For any question regarding proper installation of the ground plug, consult a qualified
(licensed or certified) electrician.
2. Do not modify the plug provided. If the plug does not fit the outlet, have the proper
outlet installed by a qualified electrician.
3. This product is for use on a nominal 120-volt circuit and has a grounding plug that
looks like the plug in Figure 2. Make sure that the product is connected to an outlet
having the same configuration as the plug. No adapters should be used with this
product.
4. If an extension cord is required, use only a three wire extension cord that has the
same configuration as the unit cord, including the (round) ground terminal. Make
sure that the extension cord is plugged into a properly grounded receptacle.
5. When using an extension cord, be sure it is in good condition and heavy enough to
meet the specifications in the chart below. If an extension cord is needed the
following wire sizes must be used.
6. (See Chart 1) Figure 2
25’ cord……………………..…….10, 12, or 14 Gauge
50’ cord……………………….………..10 or 12 Gauge
100’ cord………………………………………10 Gauge
Chart 1 Extension Cord Requirements

5
2 Prepare the T6000 Mist applicator
1. Follow the diagram to prepare the Mist applicator
a. Unscrew the plastic cup from the Mist applicator. Pour tanning solution into the cup. Do not fill more than ¾
full.
b. Carefully screw the cup back onto the main body of the Mist applicator. Screw the cup on firmly but DO NOT
over tighten. Over tightening will cause the cup to “pop” and damage the threads. Leakage can
then occur requiring replacement of the cup.
c. Locate the air cap (#2) on the T6000 diagram. Slightly turn the air cap ring (#1) anti or counter clockwise
to loosen the air cap. Notice that you can now rotate the air cap freely.
d. Look at Mist Applicator Patterns diagram below. Note the position of the air cap and the direction of the
spray pattern. Pattern 1 is for spraying across from side to side. Pattern 2 is for spraying up and down.
Pattern 3 will produce a spot or circle. Patterns 1 and 2 are the most common positions for applying
tanning solutions.
e. Turn the air cap (#2) to the position you want. Turn the air cap ring (#1) clockwise to lock the air cap in
place.
MIST APPLICATOR PATTERNS
1. Misting across from side to side
2. Misting up and down.
3. Misting in a spot or circle
1. Next, position the T100 Turbo Unit as far away as
practical and possible from the area where you will
spray.
2. Attach the remaining end of the hose to the T6000
Mist applicator as follows:
a. Locate the coupler at the rear top of the T6000
Mist applicator. See T6000 diagram.
b. Pull back on the collar of the black connector on
the air hose.
c. Push the connector over the coupler and release.
Figure 7.
d. Your Mist applicator should now be firmly attached to the air hose.

6
3 T6000 Mist Applicator Diagram

7
4 Adjusting your Mist Applicator
a. Locate the Solution Flow Screw (#10) on the T6000 diagram.
b. Turning the Solution Flow Screw clockwise reduces and will eventually stop the flow of solution. DO NOT
over-tighten the screw as this will cause damage to the end of the needle. Once the trigger cannot be
pulled back there is no point in tightening the screw down more, this will only damage the end of the
needle.
c. Turning the Solution Flow Screw anti or counter clockwise will increase the flow of solution.
d. In general, 1 ½ - 2 full turn from the fully closed position will provide a good solution flow. You may find
that you want more or less solution. You can adjust the Solution Flow Screw to your desired setting.
NOTE: Opening the Solution Flow Screw more than 3 turns will not increase the solution flow and will in
fact decrease the efficiency of your Mist applicator.
e. In general, hold the T6000 Mist applicator 4” (10cm) from the person being sprayed. Moving the Mist applicator
back will increase the size of the mist pattern. Moving the Mist applicator closer will decrease the size of the
mist pattern. The further away you hold the Mist applicator, the more you will need to increase the solution
flow thus causing abnormal amounts of airborne solution (overspray).
f. Holding the Mist applicator closer to the person being sprayed along with a minimum flow of solution will
provide the best results, no streaks or running solution and virtually no mist in the spray area.
g. Be sure to move the Mist applicator at a slow, steady speed keeping the distance of the Mist applicator the same
throughout the application. This will ensure perfect results. It is actually very easy. Practice a few times
and you will be an expert.
h. It is best to hold the Mist applicator in a vertical position when spraying. If you want to change the direction of
the mist pattern, rotate the position of the air cap rather than turning the Mist applicator on its side.
i. Always hold or store the Mist applicator in a vertical position. A slot in the T100 Turbo Unit is provided to hold
and store the Mist applicator. It is a good habit to use it when you are not spraying.
j. Do not over-tighten the solution flow screw (#10) as this will damage the end of the needle point. Tighten
the screw until the needle cannot be pulled back. Once this point is reached there is no point in turning
the solution slow screw anymore as this will only cause damage to the needle point.
5 Spraying/Misting

8
1. You are now ready to begin misting.
2. The ON/OFF Switch is located under the carry handle of the T100 Turbo Unit. Turn it on. You will hear
a sound similar to a vacuum cleaner. You may also notice that air is now blowing out of the front of the
Mist applicator. This is correct. Air will continually flow from the air cap of the Mist applicator as long as
The T100 Turbo Unit is running and the air hose is connected.
3. Open the Solution Flow Screw as described in item 4.
4. Set the mist pattern you wish to use by adjusting the air cap to the desired position. Refer to Mist
Pattern Diagram.
5. Direct the Mist applicator to the area of the body that you want to start spraying.
6. Pull back on the trigger (#13) and move the Mist applicator as noted in the diagram below. Do not wave
a. the Mist applicator back and forth in front of your client by bending your wrist. Rather, keep your
wrist straight and move your entire arm. Movement should be steady, even and deliberate,
keeping your distance the same at all times.
PROPER MISTING TECHNIQUE
6 Mist Applicator Maintenance

9
1. It is VERY important to clean your Mist Applicator daily.
2. At the end of the day or when the equipment will not be used any more, disconnect the Mist Applicator
from the air hose.
3. Carefully unscrew the cup. If there is remaining solution, either close the cup with a cup lid, or pour the
remaining solution into a proper storage container.
4. Rinse the cup under warm running water until clean.
5. Fill the cup about ¼ full with water. Reconnect Mist Applicator to Air Hose. Turn on the T100 Turbo
Unit. Direct the Mist Applicator to a safe area and spray the clean warm water through the Mist
Applicator until the cup is empty.
6. Turn off the T100 ™Turbo Unit. Disconnect the Mist Applicator. Unscrew the cup.
7. Wipe all exposed areas dry.
8. Unscrew and remove the Air Cap Ring (#1). Rinse the threads under warm running water. Wipe the
threads clean and dry. Add a small amount of Mist Applicator lube to the threads.
9. Remove the Air Cap (#2). Rinse under warm running water. Wipe, clean and dry.
10. Remove the Air Distributor Plate (#5). Rinse under warm running water. Wipe clean, dry and lubricate
with Mist Applicator lube.
11. Reinstall the three pieces you just removed by reversing the removal procedure. Your Mist Applicator
should be ready for the next use. Store the Mist Applicator ™ in the holder on the T100 Turbo Unit.
12. The Solution nozzle (#3) can be removed for additional cleaning if necessary. We suggest doing this
at least once a week or more if you are using the Mist Applicator Daily. Be careful. There is a
Solution nozzle gasket (#4) around the threads of the Solution nozzle. Be sure to reinstall or leakage
will occur.Removal of the Solution nozzle is not necessary on a daily basis. You should however
remove it once a week and rinse under running water. The Solution nozzle can be easily removed
with an adjustable wrench or spanner. Place the tip of your adjustable wrench or spanner on the two
flat areas of the nozzle and twist anti or counter clockwise.
13. The Solution needle (#10) can also be removed for additional maintenance. To remove: Turn the
Solution Flow Screw anti or counter clockwise until it comes out of the Mist Applicator. Be careful
when removing the Solution Flow Screw as there is a small spring (#9) around the needle. Do not
lose it. This is important to the operation of the Mist Applicator. Set the spring aside and pull the
trigger all the way back until you can grab the needle with your finger tips and pull it out from the
back of the Mist Applicator. Once removed, rinse under warm running water, Clean and dry.
Reinstall reversing the removal procedure. NOTE: Occasionally it is necessary to lubricate the
needle (#10) where it slides through the gland nut (#7). Simply rub a few drops of Mist Applicator
lube around the needle shaft and reinsert into the back of the Mist Applicator.
7 Troubleshooting

10
a. T100 Turbo unit turned ON. Air blows out of T6000 Mist applicator?
b. This is correct. Air blows constantly when Turbo unit is ON.
c. T100 Turbo unit turned ON. Unit does not operate or blow air?
d. Check that the unit is plugged in to proper electric source. Be sure there is power at the electric source.
e. If there is no problem with electric supply, call for technical support.
f. T100 Turbo unit is turned ON, the trigger is pulled back on Mist applicator, but no solution comes out?
g. Check that the cup is screwed firmly to Mist applicator.
h. Check that there is no solution bubbling or leaking around the cup.
i. Turn T100 Turbo unit OFF. Unscrew cup. Be sure that Solution Tube and Disc (#14) is connected and
has not come loose. Locate the two small holes in the Disc around the Solution tube. Be sure that these
two small holes are not clogged with dried solution. To clean, carefully insert a pin through each hole
ensuring that they are clear.
j. Turn T100 Turbo unit OFF. Remove air cap ring, Remove air cap, Remove Air Distributor Plate. Remove
Solution nozzle (#3) with an adjustable wrench or spanner. There is a Solution nozzle gasket (#4) on the
Solution nozzle. Do not lose it. Rinse Solution Nozzle under running water and check for dried solution
that may have blocked the hole. Reinstall Solution Nozzle Gasket. Reinstall Solution Nozzle, Air
distributor plate, air cap and air cap ring. Try spraying again. If you still have a problem call for technical
support.
k. Solution leaks in front of trigger.
l. With an adjustable wrench or spanner tighten Solution Needle Packing Screw (#7). Do not over tighten.
This can cause Solution needle to stick and not spring back. Try spraying again. If leaking continues the
Solution Needle Packing needs to be replaced. (Rare). Remove Solution Needle Packing Screw (#7).
Pry out the Solution Needle Packing’s (4). Replace. Reinstall Solution Needle Packing Screw. Tighten
all the way, and then back off slightly. (1/8 turn) Test mist applicator for leakage. If you still have a problem
call for technical support.
m. When T100 Turbo unit is ON, Solution continues to spray from Mist applicator without trigger being pulled.
n. Immediately turn T100 Turbo unit OFF.
o. Disconnect mist applicator from air hose.
p. Slightly adjust (loosen) Solution Needle Packing Screw (#7). Test to see if problem is resolved.
q. Check to see that Needle Spring is installed. (#9). Remove Solution Flow Screw (#10). Look for Needle
Spring around the back of the Solution Needle. (See diagram). If lost, call for replacement.
r. Check Solution nozzle. Remove and clean following directions 9.c.iv. above.
s. Solution leaks around the top of the cup.
t. Make sure the cup is screwed firmly to the body of the Mist applicator.
u. Make sure the threads around the cup are clean and the threads inside the cup top assembly are clean.
v. Replace the cup top gasket. Pry out old gasket. Install new gasket. Test mist applicator.

11
8 Warranty and Technical Support
For all other technical questions please call your local distributor or Apollo Sprayers Inc. for technical
support.
Technical Support: Available:
Monday-Friday, 8am-4pm, PST.
Apollo Sprayers International, Inc.
1030 Joshua Way
Vista, CA 92081
Voice: 760-727-8300
Toll Free: 888-900-4857
Fax: [phone]
Email: [e-mail]
Warranty for T6000 Mist Applicator
Six Month Limited Warranty
This machine and Equipment is WARRANTED by APOLLO SPRAYERS INTERNATIONAL INC. for a total period of SIX
MONTHS from the ORIGINAL date of purchase by the ORIGINAL PURCHASER. Proof of purchase to be included and all
SHIPPING CHARGES to be pre-paid.
APOLLO SPRAYERS INTERNATIONAL, INC. upon examination of the machine/equipment will replace or repair at their
discretion any defects in material or workmanship.
This WARRANTY does NOT include: miss-use, damage, neglect, alterations, disassembled equipment or modifications,
lack of maintenance, cleaning, water damage to electrical parts and INCORRECT VOLTAGE CONNECTION. This
WARRANTY is in lieu of all other express warranties, any WARRANTY implied by law, including but not limited to implied
warranties of merchantability or fitness, is excluded to the maximum extent permitted by law and, if not excludable, it is
limited to the duration of the express Warranty. No representative or person is authorized to extend this Warranty or to
create for APOLLO SPRAYERS INTERNATIONAL, INC. any other liability in connection with the sale of any APOLLO
SPRAYERS product. APOLLO SPRAYERS INTERNATIONAL, INC. shall not be liable for any consequential, incidental,
or special damages of any kind directly or indirectly resulting from breach of any express or implied Warranty. Some States
do allow the exclusion of limitation of incidental or consequential damages or limitations on the length of any Warranty so
that the above limitations and exclusions may not apply to you; however, to the maximum extent permitted under applicable
law, the only rights and remedies shall be to obtain a replacement for any defective product. This Warranty gives you
specific legal rights and you may also have other rights which vary from state to state and country to country.
WARNING: This product can expose you to chemicals including Chromium, which
is known to the State of California to cause cancer and birth defects or other
reproductive harm. For more information go to www.P65Warnings.ca.gov.
