The four position arrows along the outer edges allow you to place the panel
along the given edge independent of the other panels. When you drag the
panel over a position arrow, a transparent blue box will display showing the
new panel position. If you are satisfied with the position, release the left
mouse button and the panel will move to its new position.
You can also move a panel so that it is associated with another
panel. To do this, drag the panel over the panel you want it
associated with, and the icon with four position arrows will center
over that panel. Scrolling the cursor over the icon arrows will cause
a transparent blue box to display where the panel will be located. If you are
satisfied with the position, release the left mouse button and the panel moves
to its new position.
It is possible to combine panels so that they take up less space on the
screen. Combined panels have a row of tabs across the bottom. Clicking a
tab brings that panel to the foreground.
To combine panels, move the cursor to the title bar of the panel you
want to move. Click and drag the panel onto the panel you want to
combine it with. If the panels can be combined, the four-position
arrow icon will have a tab symbol in the center. Drag the cursor over
the tab symbol , a new tab will appear on the panel. Release the
mouse button to combine the panels.
3.3 Using HDPlayer
A. Screen
The Screen displays recorded video on the hard
disk drive. HDP provides various multi-screen
layouts; single-screen, quad, 1+7, 3x3, 4x4 and
full-screen. To change the image aspect ratio
displayed on each camera screen, select a
camera on the screen and click the right mouse
button. Selecting Aspect Ratio in the text menu
screen displays the following menu.
Fit to Screen: Displays images by fitting to the screen size.
Original Ratio: Displays images by fitting to the screen size
while maintaining their original ratio.
Half Size (x0.5) to Quadruple Size (x4): Select the desired
image size.
