Apollo AlarmSense User manual

L- L+ L+ L-
+
-
+
-
8
AlarmSense Manual Call Point
Installation Guide
Technical Information
9-33V DC
-40°C to 70°C
IP44
Product Overview
1
V
o
C
IP
2
7
0.6Nm
39215-003/Issue 1
3
5
9
Installation
0.6Nm
4
Part No Product Name Type
55400-894 AlarmSense Manual Call Point (Red) Indoor
Ensure sufficient cable is available to allow terminal block to
be inserted flush and aligned with the rear of the casing
Note the alignment marks
I
I
2-8.5V <1.5mA
10.5-15V 30±4mA
18-24V <1.5mA
33V <2mA
<10μA (15V supply voltage)
Item Qty. Item Qty.
1. Head unit 1 6. Fixing screws
(NOT SUPPLIED) N/A
2. Connector block 1
3. Fixing screws 2 7. Backbox 1
4. Mounting bracket 1 8. Reset key 1
5. Earth Continuity Terminal 1 9. Continuity link 1
6
X
Do not overtighten screws

Testing
© Apollo Fire Detectors Limited 2015
Apollo Fire Detectors Limited, 36 Brookside Road, Havant, Hampshire, PO9 1JR, UK
Tel: [phone] Fax: [phone]
Email: techsalesemails@apollo-fire.com Website: www.apollo-fire.co.uk
Commissioning
The installation must conform to BS5839–1 (or applicable local codes).
Transparent Hinged Cover
To provide additional protection against accidental operation, a
Transparent Hinged Cover, part no 44251-189, is available or 44251-175 for
multiples of 10.
ABC
Removal
ABC
1. Hold
2. Push
LED Indicator
Illuminated red when call point is operated. Troubleshooting
Before investigating individual units for faults, it is important to
check that the system wiring is fault free. Earth faults on data loops
or interface zone wiring may cause communication errors.
Problem Possible Cause
Control panel reports zone fault Incorrect zone wiring
Detector Removed
EOL device missing or incorrectly fitted
Control panel reports alarm MCP not reset
Incorrect EOL device
MCP does not activate alarm Incorrect wiring
Incompatible control panel
PP2528 - AlarmSense Manual Call Point Datasheet
