IntroducingApricorn'slatestinnovation,theEZUpgrade1.8T,
the ultimate 1.8" hard drive upgrade kit. EZ Upgrade 1.8T is
the perfect companion for upgrading the HDD in notebooks,
handheldcomputers,orother devicesthatuse1.8"HDD's. Thein-
cludedEZGigIIsoftwareisdesignedtopainlesslytransferallthedata
from the old hard drive to a new hard drive in 3 easy steps. Once the
transferiscomplete,EZUpgrade1.8Ttransformstheoldharddriveintoa
portable Hi-Speed USB 2.0 external backup and/or storage solution.
EZUpgrade1.8Tincludes:Apricorn’sEZGigIIBackup&UpgradeSoftware,a
Hi-SpeedUSB2.0harddriveenclosure,(USB1.1compatible)a miniUSB cable
and auxiliary power cable.
EZ Upgrade 1.8T is all you will need to easily transfer everything - data, applica-
tions, documents, address books, email, settings, OS, and preferences - from the
old hard drive to a new drive, in 3 easy steps.
First step, connect the hardware by sliding the new hard drive into the EZ Upgrade
1.8T enclosure and connecting to the device's (notebook, handheld computer, MP3
player,PDAetc.) USB port. Steptwo,runEZGigII’scloningutilitybybootingtotheCD.
Step three, install the new hard drive into the device. That’s it -you’re nished!
Once the new drive is installed, the old drive can be used in EZ Upgrade 1.8T's Hi-Speed
USB 2.0 enclosure as external. When used with EZ Gig II, the external drive becomes a
state-of-the-art backup solution.
The EZ Gig II Data Transfer Utility offers two different options: Disk Clone and Disk Image.
TheDiskCloneoptioncreatesanexactcloneofaharddriveandisperfectforupgradinghard
drives, or for a creating a Disaster Recovery Clone - The Ultimate Backup Solution.
The Disk Image option is an ideal backup tool. Disk Image creates a compressed “image” of
anentire harddrive, oranindividualpartition ofa harddrive. Disk Image can compress dataup
to 1/2 its original size, allowing backups to be made to a smaller hard drive, or multiple backups
of a larger hard drive.
Image EZ provides password protection for backup images, and a comments eld so each image
can be labeled and easily identied. Image EZ also allows restoration of individual les or folders.
Visit our website at www.apricorn.com or call 1-800-458-5448
©2007 Apricorn, Inc. Corporate Ofces: 12191 Kirkham Rd., Poway, CA. 92064 (updated 2/07)
•1.8" HDD upgrade
kit - easily upgrade
notebooks, handheld
computers, MP3
players, PDA's
• EZ Gig II backup &
upgrade software
• Enclosure can
be used as
backup or
external storage
once tranfer is
complete
• Hi-Speed USB
2.0 - transfer
rate up to 480
Mbps
• No Charge toll
free technical
support
• Plug-n-Play - no
drivers required
for Windows
2000 & XP
• Hot swappable
- just plug & go
• 3 year limited
warranty
ez upgrade 1.8t
1.8” hard drive upgrade kit

Features:
Creates an exact bootable clone of a hard drive and transfers the
data to a new hard drive via Hi-Speed USB 2.0 (USB 1.1 Compatible)
for upgrading devices that house 1.8" HDD's.
Allows the old hard drive to be redeployed in the EZ Upgrade 1.8T
Hi-Speed USB 2.0 enclosure. When used with the included EZ Gig II
Backup & Upgrade Software, the external drive becomes a full-
featured backup system.
Includes: Hi-Speed USB enclosure, 1 mini USB Cable, 1 auxiliary cable
and EZ Gig II Backup & Upgrade Software. EZ Gig II is comprised of
two modules, Clone EZ & Image EZ.
Disk Clone Key Features:
Automatic and manual upgrade modes
Supports backing up or restoring data via USB 2.0, USB 1.1, PC Card or
IDE Resizes transferred partitions to match new hard disk size
Creates, copies, moves and deletes partitions
Disk Image Key Features:
User dened compression levels
Create exact disk images for complete backup
Password protect each individual image backup
Provides comments eld to label each image back up
Drive Enclosure Specications:
Data Transfer Rate Up to 480 Mbps
Power Supply Bus powered from USB port, or from
auxiliary power cable
Physical size 4”H X 2.35"W X .625”H - weight 5oz.
Approvals FCC & CE Certied
Plug-n-Play No drivers required for Windows XP,
& 2000
Hot Swappable Just plug and go!
Warranty 3 years limited
Supported Operating Systems Windows 2000 / XP
System requirements: PC-compatible computer with Pentium
CPU or similar, 32 MB RAM, CD Rom,
CD-RW or Floppy drive
For more information about EZ Upgrade 1.8T and other innovative Apricorn products visit our
website at www.apricorn.com or call 1-800-458-5448
©2007 Apricorn, Inc. Corporate Ofces: 12191 Kirkham Rd., Poway, CA. 92064
