APRIX Red dragon User manual

1
Red dragon
APRIX
smartphone
User Manual
2015/10/10

2
Contents
Getting Started.........................................................5
Overview .........................................................................5
Key Explainrd .................................................................. 5
Starting up....................................................................... 6
Switching Your Phone On/Off .........................................7
Getting Around Your Phone ............................................8
Phone Calls ............................................................10
Calling from the Phone.................................................. 10
Calling from Your Contacts ...........................................10
Calling from a Text Message.........................................10
Receiving Calls..............................................................11
Contacts .................................................................11
Messaging ..............................................................12
The Message Box .........................................................12
Sending an Message.....................................................12
Message Settings..........................................................13
Touch Input Settings .....................................................13
Getting Connected to the Internet........................13
Adding a New Network Connection .....................13

3
Turning On Wi-Fi ..........................................................14
Connecting to a Wi-Fi Network......................................14
Checking the Wi-Fi Network Status...............................14
USB tethering & portable hotspot ..................................14
Browsing the Internet............................................15
Browsing Options...........................................................16
Using Bookmarks...........................................................16
Making the Most of Multimedia.............................16
Camera..........................................................................16
FM..................................................................................16
Playing Music.................................................................17
Gallery............................................................................17
Making Voice Memos ....................................................17
Sorting out Your Phone Settings .........................18
Bluetooth........................................................................18
Setting Date and Time...................................................18
Display Settings.............................................................18
Sound &notification Settings..........................................19
Language Settings.........................................................19
Security Settings............................................................19
Managing Your Device Memory ....................................20
Reset to Factory Settings ..............................................20
Applications....................................................................20
Clock..............................................................................20
Calculator.......................................................................21

4
For Your Safety......................................................21
General Safety ..............................................................21
Distraction .....................................................................22
Product Handling........................................................... 23
Electrical Safety.............................................................26
Interference ................................................................... 26
Explosive Environments................................................28
FCC Compliance........................................................... 28
Health and safety information........................................29
Common fault diagnosis................................................ 31












5


GettingStarted
Overview
KeyExplainrd
Key Function

6
Key Function
Power Key Hold to switch audio profiles, or to turn on or off
Airplane mode, or to power off.
Press to switch your phone to Sleep mode.
Press to wake up your phone.
Home Key Press to return to the Home Screen from any
application or screen.
Hold to see recently used applications.
Menu Key Press to get the options for the current screen.
Back Key Press to go to the previous screen.
Volume Keys Press or hold to turn the volume up or down.
Startingup
StatusandNotificationlcons
Your phone will tell you exactly what’s going on by showing you simple
icons. Here’s what they mean
USB connected Missed call
Airplane mode Signal strength
Battery charge New message
Meeting mode Wi-Fi network
Alarm set Earphone insert
Silent mode New Wi-Fi network detected

7
Bluetooth icon USB debugging connected
InstallingtheSIM/SDCardandBattery
Switch off your phone before installing or replacing the battery, SIM, or
memory card.
1.Remove the back cover
2.Hold the SIM card with the cut corner oriented as shown and slip it into
the card holder.
3.Insert the memory card into the card slot with the metal contacts facing
down until it inserts to the right position.
4.Insert the battery by aligning the gold contacts on the battery with the
gold contacts in the battery compartment. Gently push down on the battery
until it clicks into place.
5.Press the cover gently back into place until you hear a click.
ChargingtheBattery
When you first get your new phone you’ll need to charge the battery.
Connect the adapter to the charger jack. Ensure that the adapter is inserted
with the correct orientation. Do not force the connector into the charger
jack.
Connect the charger to a standard AC wall outlet.
Disconnect the charger when the battery is fully charged.
SwitchingYourPhoneOn/Off
Make sure the SIM card is in your device and the battery is charged.
1. Hold Power Key to switch on your phone.

8
2. To switch it off, hold Power Key to get the phone options. Select Power
off, and then tap OK.
SettingUpYourPhonefortheFirstTime
When you first power on your phone after you purchase it or reset it to
factory settings (see chapter Sorting out Your Phone Settings – Privacy:
Reset to Factory Settings), you need to do some settings before using it.
SwitchingtoSleepMode
To save battery power, Sleep Mode suspends your device to a
low-power-consumption state while the display is off. Your device also goes
into Sleep Mode by itself when the display is automatically turned off after a
certain period of time. You can start sleep mode by the following method.
Press Power Key to switch to Sleep Mode.
WakingUpYourPhone
Press Power Key to activate your screen display.
Tap the icon, drag to the up.
NOTE: If you have set an unlock pattern, PIN or password for your
phone (see chapter Sorting out Your Phone Settings – Security Settings)
you’ll need to draw the pattern or enter the PIN/password to unlock your
screen.
GettingAroundYourPhone
TouchControl
You can use finger gestures to control your phone. The controls on
your touch-screen change dynamically depending on the tasks you’re
performing.

9
Tap the buttons, icons, or applications to select items or to open
applications.
Flick the screen to scroll up, down, left or right.
Point, drag and drop to move particular items across the screen.
Double-tap the screen to zoom in/out an image.
NOTE: You can view the phone screen in portrait or landscape
orientation simply by holding it upright or turning it on its side. Not all
screens are viewable in landscape.
HomeScreen
In the Home screen, besides the shortcut icon is displayed, you can
also set your own wallpaper, add the widgets or application shortcuts you
need, or remove them as you like.
ChoosingYourWallpaper
Press Home Key to return to the Home Screen.
Tap Menu Key and select Wallpaper.
Tap Gallery, Live Wallpapers, Video Wallpaper, or Wallpapers and choose
the image or animation you want to use as the wallpaper. Some cropping
may be needed for Gallery images.
Tap Set wallpaper.
Adding/RemovingitemstoYourHomeScreen
Press Home Key > tap to enter the Application Program Interface
In the list of applications, touch and hold the icon until the main screen
appears, move the application icon to the idle position, release the finger.
Press Home Key to return to the Home Screen.

10
Tap and hold the item you want to delete until the remove icon appears on
the top of the screen.
Drag the item to the remove icon and release your finger when the item
turns red.
PhoneCalls
There are many ways to make a call with your phone. And they’re all
easy to do.
CallingfromthePhone
Press Home key > tap > Phone or tap on the Home Screen.
Enter the phone number using the on-screen keypad.
Tap to delete wrong digits.
Tap the dial icon.
TIPS: To make international calls, hold to enter the “+”.
CallingfromYourContacts
Press Home key > tap > People.
Slide your finger to scroll the contacts list and tap the contact name you
want to call, when the contact details appear, click on the number;
choose the SIM card to dial.
You can search for a contact by tapping on the screen.
CallingfromaTextMessage
If a text message contains a phone number that you want to call, you
can make the call while viewing the text message.
