APS LSE-D16-AB User manual

INDICATOR UNIT
LSE-D16-AB
MANUAL
Safety regulations Mounting page 02
Schematics page 03
Control elements Technical data page 04
Programming page 05
Functionality page 09
Factory settings page 10
www.aps-systems.ch

2
Safety regulations
Before the installation of the LSE-D16 Indicator unit read these instructions
carefully and completely. Improper handling can result in severe personal injury,
substantial property damage or even death.
Cleaning
Before cleaning first disconnect the equipment from the mains. Do not use any
liquid cleaner or corrosive agent but solely a dampened cloth.
Installation
Installation work must be carried out by certified technical staff only. Follow the
instructions in this handbook. Observe the locally applicable regulations for the
safe and riskless handling of electrical installations
Supplementary power
Power supplies for the LSE-D16 Indicator unit must comply with the stipulations
for safety extra-low voltage (SELV) given in IEC 346-4-41. We recommend our
power supplies of the EcoPower Series as they fulfil these stipulations
completely
Switching on the system
The LSE-D16 Indicator unit has no master switch. The system is alive as soon
as the power supply has been switched on.
A switch must be provided in the building installation as a cut-off device. The
switch must be labelled appropriately, must be in the vicinity of the equipment
and must be easily accessible to the user.
Mounting
Firstly, the front cut-out of 138 x 68 mm must be made. Then slide the LSE-D16
Indicator unit trough the cut-out and fix the mounting clips. Finally, tighten the
screws of the mounting clips.
All electrical connections are effected by the plug-in screw terminals

3
Schematics
*
The functions of the outputs LT (Lamp test), LQ (Lamp acknowledgement) and
HQ (Horn acknowledgement.) can be customised see page 9, output functions.
The LAN connection is intended for parameterisation in the web interface, as
well as firmware updates.

4
Control elements
The following buttons are integrated in the front of the unit:
Horn acknowl.
The output 9, Horn acknowledgement is activated
Lamp acknowl.
The output 10, Lamp acknowledgement is
activated
Lamp acknowl.
All LEDs, the buzzer as well as the lamp test
output are activated for 3 seconds.
Technical data
Signalling
2x 16 Multicolour LED / integrated buzzer
Indicator inputs
16 inputs each, NO/NC group 1 + 2
Time delay
5s/10s/60s for all fault inputs group 1
NO/NC
All inputs separate
System inputs
Buzzer / HQ Lamp / Lamp test / LQ Lamp
System outputs (DC operation onl.)
Buttons HQ / LQ / LT
Optional output functions
Common- / Common Priority 2 Output
Maximum load output relays
6A 30VDC / 6A 250VAC
Control elements
Horn ack. / alarm ack. / lamp test
Supply voltage
8-30VDC / 12-28.5VAC, 40-80Hz
Signal voltage
24V AC/DC ± 20%
Voltage system inputs
Analogue Supply voltage
Voltage system outputs
Current sink max. 30VDC
System output load
Max. 50mA
Power consumption
Max. 3W
Weight
260g
Dimensions WxHxD
72x144x75mm
Front panel cut out
138 x 68mm
Terminals
Plug-in screw terminals 0.2 -. 2.5mm2
Mounting position
Any
Protection degree housing
IP40
Protection connector
IP20
Temperature range
0 to 65°C

5
Programming
General
Programming can be done either with the web interface or with the operating
elements on the unit. The use of the web interface is described in a separate
documentation. Download the documentation from the homepage: www.aps-
systems.ch
Using the controls in programming mode:
Icon
Description
Designation
Function in programming mode
Horn
acknowledgement
HQ
Navigation up
Alarm acknowledge
LQ
Switch
Lamp test
LT
Navigation down
The programming mode is started as follows:
Power up the unit and push the HQ and LT keys at the same time within 10
seconds. If no other keys are pressed within 5 seconds, LSE-D16 will switch
back to operating mode. If additional keys are pressed, the programming mode
remains active for 30 seconds. If no other key is pressed for 30 seconds, LSE-
D16 will return to operating mode and will take over the programming. The
programming mode can be ended by pushing the HQ and LT keys. The settings
are saved. While the programming mode is active, the power LED blinks green.
Programming levels
LSE-D16 Operation-/Fault indicator has 6 programming levels:
1. Inputs group 1 (red): Normally open / closed switchover
2. Inputs group 1 (green): Normally open / closed switchover
3. Virtual DIP switch: time delays and system settings
4. Activation LT-Output as Common Output Priority 2
5. RGB-Colour setting inputs group 1
6. RGB-Colour setting inputs group 2
Levels 4 to 6 are deactivated in the factory settings.
They can be activated in level 3 with the virtual DIP switch 16.

6
When the programming mode is activated, LSE-D16 indicator unti starts at the
level 1. The levels can be changed in active programming mode using the HQ
and LT navigation keys. If for example Level 2 is active on operating input 1,
pushing the HQ keys switches the LSE-D16 indicator unit to level 1.
Level 1
Signalisation: Power-LED blinking green Input-LED blinking green
Level 1 is used to set if the inputs of group 1 are a NO closing contact or a NC
opening contact. The green flashing LED signals the selected fault indicator
input. The LQ key is used to switch the function:
Red LED off = NO closing contact
Red LED on = NC opening contact
Level 2
Signalisation: Power-LED blinking green Input-LED blinking red
Level 2 is used to set if the inputs of group 2 are a NO closing contact or a NC
opening contact.The red flashing LED signals the selected operating input.The
LQ key is used to switch the function:
Green LED off = NO closing contact
Green LED on = NC opening contact

7
Level 3
Signalisation: Power-LED blinking green LQ-LED blinking green
Level 3 is used to set the following additional parameters:
Green LED = DIP-Switch off
Red LED = DIP-Switch on
LED
Status
Function
1
Off
All inputs of group 1: Without switch-on delay
2
Off
1
On
All inputs of group 1: 5 seconds switch-on delay
2
Off
1
Off
All inputs of group 1: 10 seconds switch-on delay
2
On
1
On
All inputs of group 1: 60 seconds switch-on delay
2
On
3
Off
Internal buzzer on
3
On
Internal buzzer off
4
not used
4
not used
5
Off
LQ output as the image of the LQ key (active at keystroke)
5
On
LQ output as collective indicator
6
Off
According operation-LED suppressed whilst fault
6
On
According operation-LED not suppressed whilst fault
7
not used
7
not used
8
not used
8
not used
9
not used
9
not used
10
not used
10
not used
11
not used
11
not used
12
Off
Horn output as NO contact
12
On
Horn output as NC contact
13
Off
LQ and LT output normally open NO
13
On
LQ and LT output normally closed NC
14
Off
All LEDs not dimmed
14
On
All LEDs dimmed in idle state (no input group 1 active)
15
Off
LAN setting according to the parameterisation in the web interface
15
On
LAN setting overridden with Fixer IP: 192.168.1.123
16
Off
Advanced programming levels 4-6 off
16
On
Advanced programming levels 4-6 on
The functionality of the LSE-D16 indicator unit enhanced continuously. Older
units do not cover all described functions.

8
Level 4
Signalisation: Power-LED blinking green LQ-LED blinking magenta
In level 4, the LT output (terminal 8) can be switched to common output priority
2. As soon as at least one input of the group 1 is assigned to the common output
priority 2, the function is activated. Fault inputs that are assigned to priority 2 no
longer activate the common output priority 1.
The red blinking LED signals the selected fault input. Press LQ to change the
function:
LED off = not activated
LED lights green = activated on common output priority 2
Level 5
Signalisation: Power-LED blinking green LQ-LED blinking yellow
In level 5, the LED colour can be selected separately for each input of group 1.
The inputs of group 1 light up in the previously selected colour; the colour
changes with each press of the the LQ button. The colours available are red,
green, yellow, dark blue, magenta, light blue and white.
Level 6
Signalisation: Power-LED blinking green LQ-LED blinking dark blue
In level 6, the LED colour can be selected separately for each input of group 2.
The inputs of group 2 light up in the previously selected colour; the colour
changes with each press of the the LQ button. The colours available are red,
green, yellow, dark blue, magenta, light blue and white.

9
Functionality
Indicator unit
The LEDs on the front of the unit are an image of the associated inputs.
Output functions
Basic function factory setting
Alternative function
Setting location
HQ-Output active as long as
HQ button is pressed
LQ -Output active as long as
LQ button is pressed
Common output for
inputs of group 1
Level 3
DP-Switch 5
LT-Output active for appr. 5 seconds
by pressing LT button
Common Output Prio. 2
for inputs of group 1
Level 3 DIP 16
+ Level 4 *
* The inputs which shall activate the common output priority 2 can be selected
in the level 4. Remember to activate the advance programming in level 3 with
DIP-Switch 16.

10
Factory settings
The LSE-D16-24-AB is delivered with the following settings:
- Level 1: All inputs of group 1 = Closing contact NO
- Level 2: All inputs of group 2 = Closing contact NO
- Level 3: All virtual DIP-Switches = off
- Level 4: Common output priority 2 = not active
- Level 5: LED-Colour for all inputs of group 1 = red
- Level 6: LED-Colour for all inputs of group 2 = green
Reset to factory settings
The factory settings can be restored by pressing the three buttons HQ+LQ+LT
simultaneously for at least 10 seconds. All previous settings are lost; resetting
to the factory settings cannot be undone.
01.23
APS systems AG
Neumatt 4
CH-4626 Niederbuchsiten Tel. [phone]
Switzerland E-Mail: [e-mail] www.aps-systems.ch
