APS 1000P Series User manual

Operations Manual
OM-001-01000-00P-04.0
APS-1000P Series
Power Converters
Entire Contents Copyright 2004 by Adaptive Power Systems, Inc. (APSI) • All Rights Reserved • No reproduction without written authorization from APSI.
ADAPTIVE Power Systems
Worldwide Supplier of Power Conversion Equipment
TM

CONTENTS
Entire Contents Copyright 2004 by Adaptive Power Systems, Inc. (APSI) • All Rights Reserved • No reproduction without written authorization from APSI.
APS-1000P Series Operation Manual ii OM-001-01000-00P-04.0
Contents
Front Matter
Contents ....................................................................................................... ii
Contact Information..............................................................................v
Warranty Information......................................................................... vi
Chapter 1 Introduction
Introduction...............................................................................................1-1
Overview...........................................................................................1-1
Safety Notices..................................................................................1-2
Preparation for Installation...............................................................1-5
Installation Instructions....................................................................1-6
Example Wiring Diagram................................................................1-7
Storage and Transportation..............................................................1-8
Chapter 2 Specifications
Overview....................................................................................................2-1
Introduction.......................................................................................2-2
APS-1000P Specifications...............................................................2-2
Input Electrical Specifications.........................................................2-3
Output Electrical Specifications .....................................................2-3
Isolation Data....................................................................................2-4
Power versus Output Frequency Rating Chart...............................2-5
Displays and Controls .....................................................................2-6
Mechanical Specifications ...............................................................2-6
Environmental Specifications .........................................................2-6
Output Surge-Current Capability ....................................................2-7

CONTENTS
Entire Contents Copyright 2004 by Adaptive Power Systems, Inc. (APSI) • All Rights Reserved • No reproduction without written authorization from APSI.
APS-1000P Series Operation Manual iii OM-001-01000-00P-04.0
Chapter 3 Unit Description
Overview....................................................................................................3-1
Front Panel Organization .................................................................3-1
Frequency Display and Selection ...................................................3-3
Voltage Display and Selection ........................................................3-4
Current Display and Selection.........................................................3-5
Multimeter Display and Selection ..................................................3-6
Cabinet Controls and Connections .................................................3-7
Chassis Details..................................................................................3-7
Cabinet Features ...............................................................................3-9
Chapter 4 Operating Instructions
Overview....................................................................................................4-1
Basic Operation ................................................................................4-2
System Parameter Settings...............................................................4-9
System Parameter Table.................................................................4-10
Setting System Parameters (Programming) .................................4-11
Program Parameter Settings ..........................................................4-14
Program Parameter Table...............................................................4-15
Setting Program Parameters (Programming) ...............................4-16
Error Messages ...............................................................................4-20
Error Message Table ......................................................................4-22
Interpreting Error Messages...........................................................4-23
Chapter 5 External Interfaces
Overview....................................................................................................5-1
PLC External Interface ....................................................................5-2
Manual Switcher (Three Program Control) ...................................5-3
RS-232 External Interface ...............................................................5-4
How to Verify RS-232 Serial Operation.........................................5-4
RS-232 Command and Control Functions......................................5-7
Front Panel and RS-232 Command Functions...............................5-7
RS-232 System Control Functions..................................................5-8
RS-232 Program Functions..............................................................5-9
GPIB External Interface ................................................................5-10
GPIB Standard Status Data Structure............................................5-11

CONTENTS
Entire Contents Copyright 2004 by Adaptive Power Systems, Inc. (APSI) • All Rights Reserved • No reproduction without written authorization from APSI.
APS-1000P Series Operation Manual iv OM-001-01000-00P-04.0
Chapter 5 External Interfaces (cont'd)
GPIB Command and Control Functions.......................................5-14
Front Panel and GPIB Command Functions................................5-14
GPIB System Control Functions...................................................5-15
GPIB Program Functions...............................................................5-16
GPIB Status Queries.......................................................................5-17
Chapter 6 System Calibration
Overview....................................................................................................6-1
Calibration Setup .............................................................................6-2
Calibration Instructions ...................................................................6-4
Low-Voltage Mode (V-LO) Calibration ........................................6-6
High-Voltage Mode (V-HI) Calibration.........................................6-7
Low-Current Mode (A-LO) Calibration.........................................6-8
High-Current Mode (A-HI) Calibration .......................................6-10
Low-Power Mode (P-LO) Calibration..........................................6-12
High-Power Mode P-HI) Calibration............................................6-14
Chapter 7 System Maintenance
Overview....................................................................................................7-1
Introduction ......................................................................................7-1
System Design..................................................................................7-2
APS-1000P Series System Block Diagram ....................................7-3

CONTACT INFORMATION
Entire Contents Copyright 2004 by Adaptive Power Systems, Inc. (APSI) • All Rights Reserved • No reproduction without written authorization from APSI.
APS-1000P Series Operation Manual vOM-001-01000-00P-04.0
Contact Information
Adaptive Power Systems, Inc.
17711 Mitchell North • Irvine, CA 92614 USA
Telephone: [phone]
FAX: [phone]
E-mail: [e-mail]
Web: http://www.adaptivepower.com

WARRANTY INFORMATION
Entire Contents Copyright 2004 by Adaptive Power Systems, Inc. (APSI) • All Rights Reserved • No reproduction without written authorization from APSI.
APS-1000P Series Operation Manual vi OM-001-01000-00P-04.0
APS-1000P Series Power Converters Limited Warranty
Adaptive Power Systems, Inc. (APS) warrants each unit to befreefrom defects inmaterial
and workmanship. For the period of one (1) year from the date of shipment to the
purchaser, APS will either repair or replace, at its sole discretion, any unit returned to the
APS factory in Irvine, California. It does not cover damage arising from misuse of the unit
or attempted field modifications or repairs. This warranty specifically excludes damage to
other equipment connected to this unit.
Upon notice from the purchaser within (30) days of shipment of units found to be defective
inmaterialorworkmanship,APSwillpayallshippingchargesfortherepairorreplacement.
If notice is receivedmore thanthirty(30) days from shipment, all shipping charges shall be
paid by the purchaser. Units returned on debit memos will not be accepted and will be
returned without repair.
This warranty is exclusive of all other warranties, expressed or implied.
APS-1000P Series Service and Spare Parts Limited Warranty
APSwarrantsrepairworktobefreefromdefectsinmaterialand workmanshipfortheperiod of
ninety (90) days from the invoice date. This Service and Spare Parts Limited Warranty applies
to replacement parts or to subassemblies only. All shipping and packaging charges are the sole
responsibility of the buyer. APS will not accept debit memos for returned power sources or for
subassemblies. Debit memos will cause return of power sources or assemblies without repair.
This warranty is exclusive of all other warranties, expressed or implied.

CHAPTER 1
INTRODUCTION
Entire Contents Copyright 2004 by Adaptive Power Systems, Inc. (APSI) • All Rights Reserved • No reproduction without written authorization from APSI.
APS-1000P Series Operation Manual 1 - 1 OM-001-01000-00P-04.0
Chapter 1
Introduction
Overview
Chapter 1 contains important information you should read BEFORE attempting to
install and power-up your APS-1000P SeriesPower Converter. The information in this
chapter is provided for use by experienced operators. Experienced operators
understand the necessity of becoming familiar with, and then observing, life-critical
safety and installation issues. Topics in this chapter include:
Safety Notices
Warnings
Cautions
Preparation for Installation
Installation Instructions
Transportation
Storage
Introduction to the APS-1000P Power Converter
APS-1000P Series Power Converters have been designed for long-life trouble-free
operation in the shop-floor testing environment. The input to APS-1000P units is
commercially available power at fixed voltage and frequency. The output from APS-
1000P units is programmable power at user-controlled voltages and frequencies.
There are several operational modes: (1) front panel manual control; (2) manually
programmed test sequences; (3) external control of the manually programmed test
sequences; and (4) external programmable control. All units have the ability to be
externally controlled by remote switch closures. For more complex control sequences

CHAPTER 1
INTRODUCTION
Entire Contents Copyright 2004 by Adaptive Power Systems, Inc. (APSI) • All Rights Reserved • No reproduction without written authorization from APSI.
APS-1000P Series Operation Manual 1 - 2 OM-001-01000-00P-04.0
and data acquisition, each P-series unitincludes auser-specified RS-232external serial
interface or GPIB external parallel interface.
The APS-1000P Series of Power Converters have been designed to provide frequency
and voltage conversion in a controlledtest environment. Both manually adjustable and
remotely programmable settings are provided. All APS-1000P Series Power
Converters provide 1-phase output power. Different models cover the power range
from 2 kVA to 60 kVA. All units provideuser-controlled 1-phase output powerwithin
the frequency range of 45 –500 Hz.
All APS-1000P Series units operate as double-conversion power converters. The first
conversion is AC to DC. The second conversion is DC back to AC. All units (except
the 1-phase input APS-1002P, APS-1003P, and APS-1005P) operate with 3-phase
input power. After rectification, filtering removes high-frequency content. Low-ripple
DC is subsequently converted to 1-phase AC by a high-frequency pulse-width-
modulated (PWM) switcher. Precise control is maintained by using a highly stable
digital oscillator.
APS-1000P Series Power Converters are designed for long-term continuous operation
in sheltered (no rain) environments. Because there are no batteries, APS-1000P units
operate reliably over a wide ambient temperature range. Through the use of switching
technology the equipment is efficient (about 85%). Power Converter units are
relatively tolerant of high dust environments.
Safety Notices
APS-1000P Series Power Converters can transfer very large amounts of
electrical energy very quickly.
The rapid transfer of large amounts of electrical energy is fundamental to any
high-performance power source.
Only experienced operators who have both read and understood the
information in this manual should attempt to operate the unit.
The following warnings and cautions herein must be observed at all times.

CHAPTER 1
INTRODUCTION
Entire Contents Copyright 2004 by Adaptive Power Systems, Inc. (APSI) • All Rights Reserved • No reproduction without written authorization from APSI.
APS-1000P Series Operation Manual 1 - 3 OM-001-01000-00P-04.0
WARNINGS indicate potentially hazardous situations,which, if not avoided, could result in
death orserious injury. All warnings throughoutthis manual will appear as follows:
WARNING
IF THIS EQUIPMENT IS NOT USED IN A MANNER SPECIFIED BY THE MANUFACTURER,
THE PROTECTION PROVIDED BY THE EQUIPMENT MAY BE IMPAIRED
WARNING
THIS EQUIPMENT CONTAINS HIGH ENERGY, LOW IMPEDANCE CIRCUITS!!
LETHAL POTENTIALS ARE CONTAINED WITHIN THE CABINET.
CARE MUST BE EXERCISED WHEN OPERATING, CALIBRATING, OR SERVICING
THIS EQUIPMENT, IN ORDER TO PREVENT SERIOUS OPERATOR INJURY OR
EQUIPMENT DAMAGE.
OBSERVE THE FOLLOWING WHEN SERVICE AND MAINTENANCE ARE REQUIRED:
1) REMOVE ALL JEWELRY FROM ARMS AND NECK WHEN SERVICING THIS
EQUIPMENT. THIS PREVENTS THE POSSIBILITY OF SHORTING THROUGH THE
JEWELRY AND CAUSING BURNS TO THE OPERATOR.
2) WEAR SAFETY GLASSES WHEN SERVICING THIS EQUIPMENT TO PREVENT EYE
INJURY DUE TO FLYING PARTICLES CAUSED BY ACCIDENTAL SHORT CIRCUIT
CONDITIONS.
3) DO NOT REMOVE ANY PANEL OR COVER WITHOUT FIRST REMOVING THE INPUT
POWER BY OPENING ALL CIRCUIT BREAKERS.
4) SERVICE OTHER THAN REGULARLY SCHEDULED CALIBRATION OR EXTERNAL
CLEANING SHOULD BE REFERRED TO PERSONNEL AUTHORIZED BY THE
FACTORY TO SERVICE THIS EQUIPMENT.

CHAPTER 1
INTRODUCTION
Entire Contents Copyright 2004 by Adaptive Power Systems, Inc. (APSI) • All Rights Reserved • No reproduction without written authorization from APSI.
APS-1000P Series Operation Manual 1 - 4 OM-001-01000-00P-04.0
CAUTIONS indicate a potentiallyhazardous situation,which, if not avoided, may result
in minor or moderate injury. It also may be used to alert against unsafe practices.
Cautions will appear as shown below. All cautions should be rigorously observed.
CAUTION
Read the INSTALLATION and OPERATION instructions
of this manual before installing or operating this equipment.
To protect the equipment from damage, caution statements are used as follows:
CAUTION
Refer to INDUSTRY STANDARDS for the safe correct size of the power
input cables. The incorrect use of small-gauge input cables may cause
overheating and damage the cables or the equipment.
Before using this AC converter, please read all the safety labels that are attached
to this unit.
Before turning on the input power source to this equipment, please check to make
sure that the input voltage selection is correct.
WARNING
Before turning on the input power source to this equipment,
please check to make sure that a good earth ground is connected
to the proper terminal.

CHAPTER 1
INTRODUCTION
Entire Contents Copyright 2004 by Adaptive Power Systems, Inc. (APSI) • All Rights Reserved • No reproduction without written authorization from APSI.
APS-1000P Series Operation Manual 1 - 5 OM-001-01000-00P-04.0
Preparation for Installation
Important Information and Instructions
Thissection containsinstructionsforunpacking, inspecting,preparingandstoringyour
APS-1000P Power Converter.
Unpacking and Inspection
APS-1000P Power Converters are well packed to provide protection in the normal
shipping environment. If the shipping box appears damaged upon receiving, please
inspect the power source for scratches or damage. If the product has been damaged,
please alert the freight company and contact APS or the distributor. Please keep the
original box and packing to assist in determining how the damage occurred.
What to do if Damage has Occurred
If your APS-1000P Power Converter was damaged in shipment, you must file a
damage claim with the freight company. Do not return the product before contacting
APS to receive a Returned Merchandise Authorization (RMA) number.
Please retain all the original packing materials. If the APS-1000P Power Converter
must be sent back for repair, use the original packing materials for packing.

CHAPTER 1
INTRODUCTION
Entire Contents Copyright 2004 by Adaptive Power Systems, Inc. (APSI) • All Rights Reserved • No reproduction without written authorization from APSI.
APS-1000P Series Operation Manual 1 - 6 OM-001-01000-00P-04.0
Installation Instructions
Input and Output Circuit Breakers
APS-1000P Power Converter input and output circuit breakers and their connections
are on the rear of the unit. Please check to make sure all wires are connected correctly
and secured. Cooling fans, located at the sides and rear of the unit, provide air
circulation for cooling and heat removal.
A typical wiring diagram is shown on the following page.
AC Line Input Current Requirements
TheACinputrequirementfortheAPSPower Converter dependsontheconfiguredAC
input voltage and total power level of the specific APS 1000 model. For three phase
AC input models, the current shown in the table below is for each phase.
Input wire sizes must be chosen to support the maximum currents shown in this table
and must conform to local electrical safety codes. Note that these values are based on
the AC input circuit breaker rating for each model. The actual AC input currents are
lower than the values shown.
AC Line Input Current Requirements
Model
1003P
1005P
1010P
1020P
1030P
1040P
1060P
Input Phase
1-phase / 2-wire +
GND
3-phase
Rated Power
Total Power
3 KVA
5 KVA
10 KVA
20KVA
KVA
30KVA
40KVA
60KVA
Phase
Currents
230V, 1ø
20 A
36 A
-
-
-
-
-
208V, 3ø
-
-
40 A
100 A
125 A
175 A
250 A
220V, 3ø
-
-
40 A
100 A
125 A
150 A
250 A
240V, 3ø
-
-
40 A
75 A
100 A
150 A
225 A
380V, 3ø
-
-
30 A
50 A
75 A
100 A
150 A
415V, 3ø
-
-
20 A
40 A
60 A
100 A
125 A
480V, 3ø
-
-
20 A
40 A
50 A
75 A
125 A

CHAPTER 1
INTRODUCTION
Entire Contents Copyright 2004 by Adaptive Power Systems, Inc. (APSI) • All Rights Reserved • No reproduction without written authorization from APSI.
APS-1000P Series Operation Manual 1 - 7 OM-001-01000-00P-04.0
Input Voltage Requirement and Selection
APS-1000P Series Power Converters are delivered with a universal input transformer.
You will receive your unit factory-connected and tested at the voltage specified at the
time of order. Please check the unit data plate to verify the voltage is correct.
Operating Environment
APS-1000PSeriesPowerConvertersaredesignedtooperatereliablyoverawiderange
of environmental conditions. Please operate within the following limits:
Temperature: 0 C –40 C (32 F –104 F)
Humidity: 20% –80% (Non-condensing)
Altitude: Below 2,000 meters (6,500 feet) of elevation

CHAPTER 1
INTRODUCTION
Entire Contents Copyright 2004 by Adaptive Power Systems, Inc. (APSI) • All Rights Reserved • No reproduction without written authorization from APSI.
APS-1000P Series Operation Manual 1 - 8 OM-001-01000-00P-04.0
Example Wiring Diagram
INPUT / OUTPUT Power Panel at Rear of APS Unit (typical)
WARNING
THIS EQUIPMENT CONTAINS HIGH ENERGY, LOW IMPEDANCE CIRCUITS!!
LETHAL POTENTIALS ARE CONTAINED WITHIN THE CABINET.
ONLY FULLY-QUALIFIED PERSONNEL SHOULD ATTEMPT TO MAKE INPUT
OR OUTPUT POWER CONNECTIONS.
N G L G N C B A
OUTPUT CONNECTIONS INPUT CONNECTIONS
NOTE: Terminal Phases R, S, T are North American (U.S.) A, B, C
NOTE: Other terminal configurations are possible. For example, there is no
neutral terminal for 3-phase delta-winding inputs. In addition, depending on
voltage range, there may be no neutral terminal. All units provide 1-phase
outputs. Inputs are 3-phase, except for APS-1002P, APS-1003P, and APS-
1005P, which have 1-phase inputs (2-wire plus ground).

CHAPTER 1
INTRODUCTION
Entire Contents Copyright 2004 by Adaptive Power Systems, Inc. (APSI) • All Rights Reserved • No reproduction without written authorization from APSI.
APS-1000P Series Operation Manual 1 - 9 OM-001-01000-00P-04.0
Storage and Transportation
Packing Instructions
Please retain all the original packing materials. If the equipment must be sent back for
repair, use the original packing materials for packing. Please contact the APS repair
center or factory before returning equipment. Be sure to send all accessories and
indicate the symptoms and cause of failure if known.
Other packing Material
If the original packing material is missing, please follow the instructions below:
Wrap the equipment in PU(polyurethane) foam or Styrofoam.
The equipment must be protected byshock-resistant material, about 70 to 100mm
thick (3 to 4 inches).
The front panel must be protected with cardboard.
Secure packing tightlyand insert unit into a wooden crate if possible.
Label the box “fragile” and transport carefully.
Non-Operating Environment
The APS-1000P Series Frequency Converter can be stored and transported under
the following environment:
Temperature: –40 C –55 C ( –40 F –131 F)
Altitude: 7,620 meters (25,000 feet)
Avoid sudden temperature changes. Sudden changes in temperature may result in
condensation inside the equipment.

CHAPTER 2
TECHNICAL SPECIFICATIONS
Entire Contents Copyright 2004 by Adaptive Power Systems, Inc. (APSI) • All Rights Reserved • No reproduction without written authorization from APSI.
APS-1000P Series Operation Manual 2 - 1 OM-001-01000-00P-04.0
Chapter 2
Specifications
Overview
Chapter 2 summarizes the capabilities and general features of the APS-1000P family
ofPowerConverters. Functional capabilities aresimilar for all units. APS units convert
fixed line voltage at a fixed frequency to user-selected 1-phase output voltages and
frequencies. The primary differences between units are size, weight, type of external
data interface, and specific power handling capability. All units provide built-in PLC
remote control for three program memories.
At the time of purchase, APS-1000P users select between one of two external control
and data interfaces: either RS-232 or GPIB. Both external interfaces provide full input
and output control of functions anddata, independent of internally stored programs. In
addition, the external interfaces control eight APS-1000P internal program memories.
Please note, application of external control and data acquisition require instrumentation
programming skills. Therefore, Adaptive Power Systems recommends that only
experienced test instrumentation programmers prepare the RS-232 or GPIB test
programs.
The Displays and Controls Table in this section provides summary information about
the programmable memories and external control. More detailed information about
external interface control is found in Chapter 5.
ThisChapterincludes fivesummarytablesandasurge-currentperformancegraph.The
tables summarize different capabilities and features of APS-1000P Power Converters.
The graph illustrates over-current (start-up surge-current) capabilities.

CHAPTER 2
TECHNICAL SPECIFICATIONS
Entire Contents Copyright 2004 by Adaptive Power Systems, Inc. (APSI) • All Rights Reserved • No reproduction without written authorization from APSI.
APS-1000P Series Operation Manual 2 - 2 OM-001-01000-00P-04.0
Introduction
APS-1000P Power Converters are rugged versatile workhorses. The intended location
for APS-1000P units is the test floor, not a laboratory workbench. The smallest unit,
the APS-1002P, weights 177 lbs. The largest unit, the APS-1060P, weighs 1825 lbs.
Users can select from several modes of operation:
full-manual operation
manually programmed operation
remote PLC operation
remotely programmed serial data operation (RS-232 option)
remotely programmed parallel data operation (GPIB option)
combinations of these operational modes
In keeping with their workhorse nature, all APS-1000P units feature a 200% start-up
surge-current capability. The ability to source initial surge currents prevents the
programmed over-current protection from disabling a test.
APS-1000P Specifications
The following five tables and surge current graph provide detailed information about
the entire family of APS-1000P Series of power converters.
Input Electrical Specifications
Output Electrical Specifications
Displays and Controls
Mechanical Specifications
Environmental Specifications
Surge-Current Rating Graph

CHAPTER 2
TECHNICAL SPECIFICATIONS
Entire Contents Copyright 2004 by Adaptive Power Systems, Inc. (APSI) • All Rights Reserved • No reproduction without written authorization from APSI.
APS-1000P Series Operation Manual 2 - 3 OM-001-01000-00P-04.0
Input Electrical Specifications
Model
1003P
1005P
1010P
1020P
1030P
1040P
1060P
Input Phase
1-phase / 2-wire + Ground
3-phase
Input Voltage(VAC L/L)
230 V ± 15%
2 0 8 , 2 2 0 , 2 4 0 ( 3 W + G ) 3 8 0, 4 1 5 , 4 8 0 ( 4 W + G ) ± 1 0 %
Input Frequency
47 –63 Hz
Output Electrical Specifications
Total Power
3 KVA
5 KVA
10 KVA
20 KVA
30 KVA
40 KVA
60KVA
Maximum
Amps
0 –150 V
25.2 A
42.0 A
84.0 A
168.0 A
252.0 A
336.0 A
504.0 A
0 –300 V
12.6 A
21.0 A
42.0 A
84.0 A
126.0 A
168.0 A
252.0 A
Phase
1-phase / 2-wire + Ground
Voltage
Low Range
0 –150 V
High Range
0 –300 V
Resolution
0.1 V
Accuracy
(1% + 0.2 V)
Frequency
Range
45 –500 Hz
Resolution
0.1 Hz at 45 –99.9 Hz, 1 Hz at 100 –500 Hz
Accuracy
0.2%
Parameters
1003P
1005P
1010P
1020P
1030P
1040P
1060P
Current
Range
L
0.000 –3.5 A
0.00 –35.00 A
0.0-350A
H
3.00 –35.00 A
30.00 –350.0 A
300-3500A
Resolution
L
0.001 A
0.01 A
0.1A
H
0.01 A
0.1 A
1A
Accuracy
L
(1% of reading + 0.005
A)
(1% of reading + 2 counts)
H
(1% of reading + 0.01
A)
(1% of reading + 1 count)
Power
Range
L
0.0 –350.0 W
0.000 –3.500 kW
0.0-35.0kW
H
300 –5000 W
3.00 –60.00 kW
30.0-350kW
Resolution
L
0.1 W
0.001 kW
0.01kW
H
1 W
0.01 kW
0.1kW
Accuracy
L
(1.5% of reading + 0.5
kW)
(1.5% of reading + 5 counts)
H
(1.5% of reading + 1.0
kW)
(1.5% of reading + 1 count)
Power
Factor
Range
0.001 –1.000
Resolution
0.001
Accuracy
Depends on the accuracy of V, A, W
Harmonic Distortion
1% (Resistive Load)
Crest Factor
3 to 1
Load Regulation
0.5%
Protection
Over-Current, Short-Circuit, Over-Temperature
Efficiency
85% (at full load)

CHAPTER 2
TECHNICAL SPECIFICATIONS
Entire Contents Copyright 2004 by Adaptive Power Systems, Inc. (APSI) • All Rights Reserved • No reproduction without written authorization from APSI.
APS-1000P Series Operation Manual 2 - 4 OM-001-01000-00P-04.0
Isolation Data
The following isolation specifications applyto standard APS1000 Models.
Isolation Data
Input to Output Isolation
Working: 1000Vac, Max. 2500 Vac for 60 secs
Input to Chassis Isolation
Working: 1000Vac, Max. 1500 Vac for 60 secs
Output to Chassis Isolation
Working: 600Vac, Max. 945 Vdc for 60 secs

CHAPTER 2
TECHNICAL SPECIFICATIONS
Entire Contents Copyright 2004 by Adaptive Power Systems, Inc. (APSI) • All Rights Reserved • No reproduction without written authorization from APSI.
APS-1000P Series Operation Manual 2 - 5 OM-001-01000-00P-04.0
Power versus Output Frequency Rating Chart
The following thermal ratings applyto models 1020, 1030 and 1040 as a function of
load and programmed output frequency at an ambient temperature of 25°C. This
derating is caused by heat build-up in the output transformer.
Output load ratings expressed as restive load reflecting % of full load for frequency
ranges at which the power source can operate continuously are as follows:
45Hz ~ 100Hz 90% resistive load
< 200Hz 77% resistive load
< 300Hz 65% resistor load
< 400Hz 52% resistor load
< 500Hz 40% resistor load
At an output frequencyof 500Hz and output power into 70% resistor load, the power
source can operate for a period of 15 minutes then instrument output will shut down
because output transformer is too hot.
10%
20%
30%
40%
50%
60%
70%
80%
90%
100%
50
100
200
300
400
500
150
250
350
450
15min
30min
Continuity
Power
Frequency(Hz)
Resistor
Load
