APsystems QS1 User manual

2019/09/20 Rev3.1 Quick Installation Guide
1
QS1 Microinverter Quick Installation Guide
The sketch of QS1 support system.
All the PV modules are placed into two lines. Then put a QS1 in the middle of the two lines and make sure it is easy to
connect with four PV modules which are next to it, as well all the cables.
Step 1. Verify the grid voltage to match with microinverter rating
Step 2. The AC bus distribution
a. The AC bus is arranged at the proper position of the microinverter.
b. One end of the AC bus access junction box into power grid.
c. Wire the conductors of the AC bus: L1 - BLACK; L2 - RED;PE - GREEN.
NOTE: Wiring colour code can be different according local regulation, check all the wires of the installation before
connecting to the AC bus to be sure they match.Wrong cabling can damage irreparably the microinverters, such an issue is
not covered by the warranty.
Step 3. Attach the APsystems Microinverters to the racking
NOTE: Do not place the microinverters (including DC and AC connectors) where exposed to the sun, rain or snow, even gap
between modules. Allow a minimum of 3/4’’(1.5cm) between the roof and the bottom of the microinverter to allow proper air
flow.The racking of install microinverter must be reliably grounding.
a. Mark the location of the microinverter on the rack, with respect to the PV module junction box or any other
obstructions.
b. Mount one microinverter at each of these locations using hardware recommended by your module racking
vendor.when install microinverter, grounding washer Must be facing the racking.
Step 4. Ground the system
a. There already has earth wire inside the AC cable, thus the grounding work could be done directly by it.
b. For those areas that have special requirements, the external grounding work could be done by grounding brackets.
Step 5. Connect the APsystems Microinverter to AC bus cable
Push the microinverter AC connector to the Bus cable connector. Listen for the "Click".
Please scan the QR code to get
mobile app and more support
to help the installation.
Power grid
grounding washer
Warning injure hand
grounding brackets
NOTE:Forbidden to hand carry the
inverter through AC cable.

2019/09/20 Rev3.1 Quick Installation Guide
2
Step 6. Install a Bus Cable End Cap at the end of AC bus cable
Step 7. Place the PV modules and connect each QS1 to the PV modules
Step 8. Complete the APsystems installation map
a. Each APsystems Microinverter has removable serial number labels.
b. Peel labels off, affix one to the respective location on the APsystems installation map,and fill in 1,2 in the label
below,according to the layout on the roof..
c. The other one serial number label, posted on the solar module frame is easy to view the position.
d. After the completion of installation drawings sent to APsystems website.www.APsystems.com.
NOTE: Sequence of steps 1~8 can change for convenience of installation.
NOTE: Using APsystems' mobile app ArrayApp can make the installation and registration much more simple.
Step 9. Start the operation
a. Turn on the AC circuit breaker on each microinverter AC branch circuit.
b. Turn on the main utility-grid AC circuit breaker. Your system will start producing power after a two-minute
waiting time.
Product information is subject to change without notice.(Please download manuals at www.APsystems.com).
a
b
c
d
Nut
Seal
Body
NOTE: Cover any unused connectors with Bus Cable
Y-CONN Cap to protect the connectors.
Best Practice: Use the Bus Cable Unlock Tool to split
the connectors.
Click
NOTE: AC connector interface as follows.
