APsystems YC1000-3 Series User manual

REV1.2 Quick Installation Guide
1
APsystems YC1000-3-EU Microinverter Quick Installation Guide
The sketch of YC1000-3 support system.
All the solar panels are placed into two lines. Then put a YC1000-3 in the middle of the two lines and make
sure it is easy to connect with to four panels which are next to it, as well all the cables.
Step 1. Verify the grid voltage to match with microinverter rating.
Step 2. Lay the AC bus according to the arrangement of APsystems Microinverter.
Step 3. Attach the APsystems Microinverters to the racking.
Step 4. Attach the antenna to the microinverter, and keep the antenna vertical to the
earth.
Step 5. Connect the APsystems Microinverter cables to the AC bus cable.
NOTE: AC connector interface as follows, NOTE: Cover all unused T connectors with
from left to right PE, N, L3, L2, L1. sealing caps to protect the T connectors.

REV1.2 Quick Installation Guide
2
Step 6. Place the PV modules and connect each YC1000 to four PV modules close-by.
CH4 CH3 CH2 CH1
Step 7. Install a protective end cap at the end of AC bus cable.
a．Wire stripping
b．Insert the cable end into the gasket clamp.
c．Insert five wires into five cable clamps.
d．Rotate the nut with 2.5N·m until the latching
mechanism meets the base.
Step 8. Install the AC branch circuit junction box.
Step 9. Connect the cables to the branch junction box.
a. Put the unused end of the AC interconnector cable into the branch junction box.
b. Place cable connecting to the point of load interconnection into the branch junction box.
c. Wire the conductors: BROWN-L1; BLACK -L2; GRAY-L3; LIGHT BLUE-N; YELLOW GREEN-PE.
Step 10. Complete the APsystems installation map.
Each APsystems microinverter has two removable serial number labels. Peel labels off, affix one to the
respective location on the APsystems installation map, and affix another to the PV module frame which is
easy to see. Use the Scanning Gun to scan the serial numbers on the map into the computer or scan by
mobile phone, then complete the setting (see ECU manual).
NOTE: Step 1~10 can change sequence for convenience of installation.
Step 11. Start the operation.
1. Turn on the AC circuit breaker on each microinverter AC branch circuit.
2. Turn on the main utility-grid AC circuit breaker. Your system will start producing power after a
five-minute waiting time.
Product information is subject to change without notice.
(Please download manuals at www.APsystems.com).
