Aqila Securehub User manual

Aqila Home
Security System,
Protects
your Family
Anytime
Anywhere
Smart Security Kit
User Guide

Untuk versi
bahasa Indonesia silahkan
unduh pada website,
www.getaqila.com/download

3
www.getaqila.com
Product List
Feature
Aqila Securehub™ Device
LED Light Indicator
QUICK START GUIDE
Aqila Securehub™ Installation
ACCESSORIES INCLUDED
Motion Sensor
Door/ Window Sensor
SETTINGS
Aqila Smart App Setting
Add Device
Quick Alarm Operation
Electrical Facility Control
Alarm Notification
Add/ Delete Sensor
Zone Settings via App
Device Settings
AQILA SMART APP
Other App Settings
Connecting Wired Sensor &
Electronic Facilities
SMS Message Operations
Aqila Securehub™ Specification
Q&A
5
6
7
8
9
12
15
17
18
20
21
21
24
24
25
29
31
32
33
36
Table of Contents

5
www.getaqila.com
With a dual network (WIFI & GSM), Aqila Smart Home
Security System was created to provide comfort and
a sense of security, enable you to do real-time and
direct monitoring on all security aspects of your home.
Protects your house 24/7. The Aqila SecurehubTM
Control Panel is the main device of your Aqila security
system, with the main functions as a communication
center with all wireless sensors installed in your house
and send alarm notifications.
If there is an event that triggers an alarm such as a
door/ window being opened or an intruder enters the
house whenever the alarm is activated, then Aqila
SecurehubTM will forward the information regarding
the alarm directly either via App Notification, SMS or
Phone Calls.
Take out a devices from Aqila Smart Home Security
Kit package. If you received incomplete device or
sensors, please contact us or the nearest distributor.
AQILA
Home
Security
System
Product
List
Aqila Securehub™
(Control Panel)
2 Door/ Window
Sensors
Motion
Sensor
Remote
Control
Double-tape
Wall Bracket
Batteries
Motion Sensor
Bracket
Fischer and
Screw
Electrical
Adapter
User Guide

6Smart Security
PANDUAN
PENGGUNA
Features Wireless
Technology, DIY
Installation
105dB Siren
24 Hours
Protection
Entry/ Exit Delay
Dual Network
Wi-Fi + GSM
FHSS, Frequency
Hopping Spread
Spectrum
1000mA Battery
Backup
Connects up to
10 Remote Control
Connects up
to 50 sensors
iOS & Android
App
50 Zone
Name
Instant
Notification
3 Groups of SMS,
5 Groups of
Phone Call

7
www.getaqila.com
AQILA
Securehub™
Device
White LED: Arming (Aktif) / Disarming
Red LED: Aqila Securehub™ Status
Green LED: AC Power
LED Yellow/ Red: GSM Signal Indicator
Temper Switch
Power Switch
SIM Card Slot
Bracket Hole Loudspeaker
Connection Button Wired Accessories
Interface
Adapter Interface

8Smart Security
PANDUAN
PENGGUNA
Feature
Function
Status LED Indicator
(Large LED)
Signal/ Power LED
Indicator (Small LED)
Button
(Tamper Switch,
Connection Button)
RED LED
On: In connecting Status
Flashing rapidly: Sending SMS or ready to connect to
WiFi network in Smart Mode
Flash once in every second: Warning/ Alarm
Flash once in every 2 seconds: Connecticng to network
WiFi in AP Mode
Green LED
On: Power On
Mati: Power O
Tamper Switch
Press Once: Trigger Tamper Alarm
Connection Button:
Press once: Initiates sensors connections
Press and hold for 5 seconds until one beep sounds:
Start setting on Aqila Smart App
Press 7 times: Clears all connected sensors
Press 5 times: Restores the system to default settings.
Restoring the settings will not delete the connected
sensors.
WHITE LED
On: System armed in Away Arm mode
O: System in Disarm mode
Slowly flashing: System is in protected mode “Stay Arm”
Berkedip cepat: WiFi Connection Lost
Orange LED:
Flashing rapidly: Searching for GSM network
Flashing normally: GSM network found

9
www.getaqila.com
Quick Start
Guide
Installing Aqila
Securehub™
1. Open the battery
cover.
2. Insert the SIM Card
(Note! Make sure that
your SIM card has
been activated).
3. Plug the power
adapter cable to
adapter interface and
connects it to power
source.
4. Slide the power
switch into ON
position.
5. Test sensor
connections by
pressing the
connection button.
Important:
The SIM card that you purchased may not ask for a
PIN number. However, if your SIM card required a
pin number, please first deactivate the PINT on your
mobile phone and then re-insert the SIM card in Aqila
Securehub™.
1
3
2
4
5

10 Smart Security
PANDUAN
PENGGUNA
Remote Control Usage
and Testing
Door/ Window
Sensor Usage and
Testing
Press the SOS button. The small LED on
the remote will light up. Then alarm tone
will immediately sound and the large LED
light on the Aqila Securehub™ will flash red.
Turn o the alarm by pressing the “Disarm”
(image of an open padlock) on your
remote control. Congratulations! Your
AQILA Remote Control is working properly!
Pull out the insulating paper/ Protector.
Activate the alarm system by pressing the
“Awal Arm” button (closed padlock) on
your remote control.
Turn o the alarm by pressing the “Disarm”
(image of an open padlock) on your
remote control. Congratulations! Your
AQILA Door/ Window Sensor is working
properly!
Move the two sensor parts of apart at
least 5 cm away from one another.

11
www.getaqila.com
Motion Sensor
Usage and Testing Open the screw using a screwdriver, then
open the motion sensor cover slowly by
pressing the clip. Pull the insulating paper/
Protector.
Close the cover and screw.
Activate the alarm system by pressing the
“Away Arm” button (closed padlock) on your
remote control.
Press the connection button on the back of
the motion sensor.
Turn o the alarm by pressing the “Disarm”
(image of an open padlock) on your
remote control. Congratulations! Your
AQILA Motion Sensor is working properly!

12 Smart Security
PANDUAN
PENGGUNA
MOTION
SENSOR
Feature Motion Sensor embedded with Infrared technology,
designed with a modern, elegant design and can
be easily installed. This sensor adopts fuzzy logic
technology, designed to detect human movement in the
room. The small alarm inside will notify you whenever
the battery level is low or there is an attempt to damage
it by triggering a tamper alarm. This sensor will maximize
the security of your home.
Infrared Sensor: Detects the infrared rays released by
human body motion. Do not touch the infrared sensor
surface and keep it clean.
Tamper switch: Whenever the sensor cover is opened,
the tamper switch will trigger and emit and alarm
sound. Turn o the alarm by pressing the “Disarm”
button (image of an open padlock) on your remote
control.
1. Sensor Window
2. LED Indicator
3. Connection Button
4. Clip
5. Battery Compartement
6. Zone Jumper
7. Tamper Switch
8. Infrared Sensor

13
www.getaqila.com
Status Indicator
Test Mode &
Normal Operation
Walk Test
LED flashes one time:
Movement is detected.
The LED flashes 5 times and the buzzer
beeps 5 times :
Sensor activated, tamper alarm activated
or indicates low battery level.
Replace the battery immediately if the
battery level is low.
Test Mode: When the sensor is turned on, the LED
indicator flashes 5 times and an alarm sounds 5 times
to enter the test mode. In this mode, each movement
will trigger the sensor and activate the alarm. The
sensor will switch into Work Mode after 20 detections.
Normal Operation: When the test mode ended, this
motion sensor will switch to normal operation, after
one motion is detected, the sensor will go into sleep
mode to preserve energy. Sleep mode will end after 4
minutes. This can save battery energy when the house
is occupied and residents are constantly moving.
When the sensor turned on, the LED indicator flashes 5
times and an alarm sounds 5 times to enter work mode.
Walk through the detection area and pay attention to
the LED indicator to make sure it blinks once it detects
movements.

14 Smart Security
PANDUAN
PENGGUNA
Warning
Detection Area
Top View Side View
1. Avoid installing the sensor close to places with high
temperatures that frequently changed or places with
strong airflow (ie. air conditioner, tube lights, ovens,
refrigerator, etc.).
2. Avoid areas which face directly to the window.
Sensor’s performance can be aected by
enviromental factors (such as direct sunlight,
crowded place, passing cars, etc.).

15
www.getaqila.com
Working Status:
Door/ Window Sensors can be installed on doors,
windows and any other objects that can be opened and
closed.
The sensor transmits a signal to Aqila SecurehubTM
when sensor’s magnets moved away from the sensor
main part.
Tamper Alarm: When someone attempts to damage or
move the sensor, it will trigger the alarm. Then Aqila
Securehub TM will immediately send an alarm notification
to the home owner.
The LED flashes one time:
Opened door/ window is detected and a sensor send a
signal to Aqila Securehub™.
The LED flashes 5 times and the alarm sounds 5 times:
Tamper alarm or indicates a low battery level.
Repalce the battery immediately whenever the battery is
in a low level status.
1. Transmitter Sensor
2. Open/ Close Magnet
3. Tamper Switch
4. Battery Compartment
DOOR/ WINDOW
SENSOR

16 Smart Security
PANDUAN
PENGGUNA
Installation
• Open the sensor case and insert the battery
properly.
• Sensor can be attached to doors or windows
that can be opened and closed. Make sure door/
window surface are clean.
• Place double-sided adhesive tape on the back of
the transmitter and magnet sensor. Carefully install
the magnet part on the door/ window and the
magnet part on the door/ window frame.
• Make sure the LED indicator is in the correct
direction and make sure the magnet part is on the
right side of the transmitter.
• Place the transmitter sensor at the desired spot.
Install the magnet with a distance of not more than 1
cm from the transmitter sensor.
• Avoid installing the sensor in areas where there is a
lot of metal and power cables.
Note! Door/ window will be automatically set in
zones 1 normal as standard setting. This will cause
an alarm to sound and send a notification to the
app directly if the magnet moves away from the
transmitter sensor more then 2 cm whenever the
alarm mode is activated.

17
www.getaqila.com
Aqila Smart App
Settings
Download the App
Enter the keyword “Aqila Smart” in the App Store or
Google Play.
Create an App Acoount
to create an account on the Aqila Smart App, tap
“Register” and follow the instructions.
NOTE
The language of instructions in this application will
follow the chosen language on your smartphone.
The Aqila system use Wi-Fi network: 2.4GHz (802.11
b/g/n).
Supported operating system specifications:
iOS: iOS 8 or later.
Android: Android 4.0 or later.

18 Smart Security
PANDUAN
PENGGUNA
Connect Aqila Securehub™ to the App with
“Smart Mode”
Tap “Add Device” or “+”.
Then choose “Aquila
SecurehubTM”.
Turn on the Aqila
SecurehubTMand confirm
that the big red LED light
flashing quickly.
After confirming the LED
flashes quickly, select/
enter the Wi-Fi network
then enter your Wi-Fi
password.
Wait a few moments to
connect.
After the device is
successfully added. You
can change the device
name and select where
Aqila SecurehubTM will be
located.
Note: There are times when
the connection with Smart
Mode doesn’t work. When
this condition occur, please
use “AP Mode” or Access
Point as an alternative.
How to make the big red LED light
flashing quickly?*
Turn on the device, then press
Connection Button for 5 seconds.
ADD DEVICE

19
www.getaqila.com
Connect Aqila Securehub™ to the application with
“AP Mode (Access Point)”
• If the connection via Smart Mode is not
successful, the alternative option will appear.
Tap “Switch Pairing Mode”
• Press and hold the Connection button for 5
seconds until the red LED light flashes SLOWLY.
• Choose “Confirm Indicator Slowly Blinking”
• Go to Wi-Fi settings on your mobile phone,
connect your mobile phone’s Wi-Fi to the
“Smartlife-xxxx”
• Wait a few seconds to connect
• After the device has been successfully added.
You can change the device name and select
where Aqila Securehub™ will be located.

20 Smart Security
PANDUAN
PENGGUNA
Select the “Aqila Securehub™”
in Aqila Smart App to enter its
main menu.
From the remote control
(press and hold the button
for one second).
QUICK ALARM
OPERATION
To enter “Away Arm” or “Disarm”
in Silent Mode, press the “Stay
Arm” butoon on the remote
control one time, then press the
“Away Arm” or “Disarm” button
within period of 3 seconds.
Silent Mode:
Trigger the alarm on the
emergency situations.
SOS/
Emergency Call:
Will use a phone call to listen
to the surrounding sound and
you also talk to people who
are in the room through Aqila
Securehub™. Required an active
GSM with sucient credit
balance.
Two-way Call
To be used whenever house
conditions is totally empty. This
mode activates all sensors.
Aqila SecurehubTM will send a
notification/ sms/ phone calls
when the alarm is triggered
(depending on notification
settings you on the application).
Away Arm:
To be used when you don’t need
security supervision, for example
during the day when there are
family member(s) at home. The
alarm system will be disabled
and only sensors which on the
24 hours Zone can trigger an
alarm.
Disarm:
To be activated whenever any
residents/ family member inside
the house, for example activated
at night when house members
are going sleep. Sensors which
are set in Normal Zone will be
active, sensors which are set in
the Stay Zone will be inactive.
Stay Arm
Mode:
Kembali
Stay Arm
Gunakan Mode ini apabila ada orangdi rumah, sensor yang
diset pada Zona Normal akan aktif, sedangkan sensor yang diset
padaZ ona Rumah akantidak aktif.
SOS
Disarm
Mode ini digunakanketika anda tidak membutuhkan pengawasan
dan pemberitahuan alarm. Sistem alarm di non-aktifkan & hanya
sensor yang diatur pada Zona 24 jamyang dapat memicu alarm.
Two Way Call
Dengarkankeadaan ruangan melalui Aqila Securehub™ dan
berbicara denganorang-orang di ruangan tersebut.
Away Arm
Mode mengaktifkan seluruh sensor alarm. Aqila Securehub™
akan mengirimkanNotifikasi/ S ms/Telp ket ika sensor terpicu.
Setting Aksesoris
Nyalakan sirine pada keadaan darurat
Away Arm
Stay Arm
Emergency Call
Disarm
