Aqua Products SSDP37 Series User manual

ENGLISH |FRANÇAIS |ESPAÑOL
H0720000_REVC
User's Manual
TYPE: SSDP37--
IMPORTANT: PLEASE READ BEFORE
OPERATING CLEANER
WARNING
FOR YOUR SAFETY - For anything other than the routine cleaning and maintenance described in this manual, this product must be serviced by
a contractor who is licensed and qualified in pool equipment by the jurisdiction in which the product will be installed where such state or local
requirements exist. In the event no such state or local requirement exists, the maintainer must be a professional with sufficient experience in
pool equipment installation and maintenance so that all of the instructions in this manual can be followed exactly. Improper installation and/or
operation may void the warranty.

2
ENGLISH
FCC Statement
This device complies with Part 15 of the FCC Rules and IC licence-exempt RSS standard. Operation is subject to the
following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any
interference received, including interference that may cause undesired operation.
NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant
to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful
interference in a residential installation. This equipment generates, uses and can radiate radio frequency
energy and, if not installed and used in accordance with the instruction, may cause harmful interference
to radio communications. However, there is no guarantee that interference will not occur in a particular
installation. If this equipment does cause harmful interference to radio or television reception which can be
determined by turning the equipment off and on, the user is encouraged to try to correct interference by
one or more of the following measures:
- Reorient or relocate the receiving antenna.
- Increase the separation between the equipment and receiver.
- Connect the equipment into an outlet on circuit different from that to which the receiver is connected.
- Consult the dealer or an experienced radio/TV technician for help
CAUTION
Any changes or modifications not expressly approved by the part responsible for compliance could void the user's
authority to operate the equipment.
NOTE: This device complies with FCC and IC RF radiation exposure limits set forth for general population. This
device must be installed to provide a separation distance of at least 20cm from all persons and must not be
co-located or operating in conjunction with any other antenna or transmitter.
Under Industry Canada regulations, this radio transmitter may only operate using an antenna of a type and
maximum (or lesser) gain approved for the transmitter by Industry Canada. To reduce potential radio interference
to other users, the antenna type and its gain should be so chosen that the equivalent isotropically radiated power
(e.i.r.p.) is not more than that necessary for successful communication.

3
ENGLISH
THANK YOU FOR PURCHASING THIS AQUA PRODUCTS CLEANER.
YOUR AQUA PRODUCTS ROBOTIC CLEANER HAS BEEN DESIGNED AND MANUFACTURED TO BE
EASILY INSTALLED AND TO PROVIDE LOW MAINTENANCE OPERATION. PRIOR TO INSTALLING YOUR
NEW AQUA PRODUCTS CLEANER, PLEASE DO THE FOLLOWING:
1) Register your cleaner online at fluidrausa.com/registration.
2) Record your purchase information on the spaces provided below.
3) Attach your invoice (or a copy) to this page.
Taking these steps will help ensure prompt warranty service, should it be required. If service is required,
please contact your original dealer. If the original dealer does not perform warranty service, please visit
www.AquaProducts.com to locate an independent service company near you. If you are unable to locate a
service company, please call our Technical Support department at 1-800-822-7933.
RECORD YOUR AQUA PRODUCTS CLEANER DATA HERE:
Date of Purchase Purchased From Serial Number:
(located on robot- head)
City State/Province Zip/Postal Code
Table of Contents
Important Safety Instructions..................... 4
Cleaner Specications................................ 6
General Specications ................................................. 6
Connect to Power...................................... 6
Install the Cleaner...................................... 7
Submerge in the Pool................................................... 7
Start / Stop Cleaning.................................................... 8
Optimal Patterning/Cable Tangling ............................. 8
Remove from Pool........................................................ 9
Remove Debris............................................................. 9
Store the Cleaner When Not in Use........................... 10
Maintenance Tips..................................... 11
Spare Parts .............................................. 11
Troubleshooting....................................... 12

4
ENGLISH
WARNING
Failure to comply with the following warnings can result in permanent injury, electrocution
or death.
PREVENT ELECTRICAL SHOCK
To reduce risk of electrical shock:
• Connect unit to receptacle protected by a ground fault circuit interrupter (GFCI). Such a GFCI
receptacle should be provided by a qualied installer and should be tested on a routine basis.
To test the GFCI, push the test button. The GFCI should interrupt power. Push the reset button.
Power should be restored. If the GFCI fails to operate in this manner, the GFCI is defective. If the
GFCI interrupts power to the pump without the test button being pushed, a ground current is
owing, indicating the possibility of an electric shock. Do not use this product. Disconnect the
cleaner and have the problem corrected by a qualied service representative before using.
• Per the United States National Electrical Code®(NEC®), keep the control unit at least ve (5) feet
from the edge of the (pool/spa) water. In Canada, the Canadian Electrical Code (CEC) requires a
minimum distance of 3m (10 ft.) to be maintained between the pool edge and the control unit.
Never submerge the control unit.
• Do not enter pool while the Aqua Products cleaner is in water.
• Do not bury cord. Locate cord so as to prevent it from being damaged by lawn mowers, hedge
trimmers and other equipment.
• To reduce the risk of electrical shock, do not use the Aqua Products robotic cleaner or control unit if
the cord is worn or damaged. Contact Fluidra Technical Support immediately for proper servicing
and replacement of the damaged cord.
• Double insulation—For continued protection against possible electric shock, use only identical
replacement parts when servicing. Do not attempt repair of the Aqua Products robotic cleaner,
control unit, power cord, or oating cable.
• NEVER OPEN CONTROL UNIT.
• DO NOT USE AN EXTENSION CORD TO CONNECT THE UNIT TO ELECTRIC SUPPLY; PROVIDE
A PROPERLY LOCATED GFCI RECEPTACLE. THE CONTROL UNIT SHOULD BE PLUGGED INTO
THE GFCI RECEPTACLE BOX.
PREVENT ELECTRICAL SHOCK
• To reduce the risk of injury, do not permit children to operate this product.
• Do not let anyone, especially small children, sit, step, lean, or climb on any equipment installed as
part of your pool’s operational system.
Important Safety Instructions
Congratulations on purchasing this Aqua Products Robotic Cleaner. Please read
through the entire manual before installing your new robotic pool cleaner. Your
cleaner must be installed and operated as specied.

5
ENGLISH
CAUTION
Failure to comply with the following warnings could cause damage to pool equipment or personal injury.
• The Aqua Products cleaner must be installed and operated as specied.
• Clean out the debris from the Aqua Products cleaner after each use.
• Do not use the product in your pool if the water temperature is above 95°F (35°C) or below 55°F (13°C).
USE OF THE AQUA PRODUCTS ROBOTIC CLEANER IN A VINYL LINER POOL
Certain vinyl liner patterns are particularly susceptible to rapid surface wear of pattern removal caused
by objects coming into contact with the vinyl surface, including pool brushes, pool toys, oats, fountains,
chlorine dispensers, and automatic pool cleaners. Some vinyl liner patterns can be seriously scratched or
abraded simply by rubbing the surface with a pool brush. Ink from the pattern can also rub off during the
installation process or when it comes into contact with objects in the pool. Fluidra is not responsible for, and
the Limited Warranty does not cover, pattern removal, abrasion or markings on vinyl liners.
SAVE THESE INSTRUCTIONS

6
ENGLISH
Cleaner Specications
General Specications
The general specications for the cleaner are
as follows:
Control box
supply voltage
100-240 VAC, 50-60 Hz
Output voltage 30 V DC
Installed load 100 W max
When unpacking the cleaner and its
components:
• Check cleaner and components for damage
during transport.
• If there are any missing parts or damage,
contact Technical Support at 1-800-221-1750
Connect to Power
WARNING
• Failure to comply with the following warnings
can result in permanent injury, electrocution
or drowning.
• Prevent Electrical Shock
• U.S.: Per NEC®requirements, keep the
control unit at least five (5) ft. (1.5 m) from
the edge of the pool. CANADA: Per CEC
requirements, keep the control unit at least
three (3)m (10 ft.) from the edge of the pool.
• Only connect the control unit to a
receptacle protected by a ground fault
circuit interrupter (GFCI). Contact a certified
electrician if you cannot verify that the
receptacle is protected by a GFCI.
• Do not use an extension cord to connect the
control unit.
• Do not allow anyone to swim while the
cleaner is in the pool.
• The control unit is not waterproof. In order to
prevent electrocution, never submerge the
control unit or leave exposed to inclement
weather.
1. Plug power supply into a GFCI outlet
(Ground Fault Circuit Interrupter)
(Figure 1). Power Supply must be 5 ft.
from the pool's edge.
Figure 1. Plug into Power Supply
2. Straighten the oating cable. Lift the
ap on the power supply and plug in
the power cable (Figure 2).
Figure 2. Connect the Power Cable

7
ENGLISH
Install the Cleaner
CAUTION
To prevent damage to the cleaner, be sure
to adhere to the following guidelines:
• Remove the cleaner from the pool after the
cleaning cycle is completed.
• Store cleaner out of direct sunlight out of
direct sunlight or inclement weather.
• Never lift the cleaner out of the pool by the
floating cable.
• Take additional care when lifting the cleaner
out of the pool. It becomes heavier when
filled with water.
• Always remove the cleaner from the pool
before super chlorinating or adding acid.
• Do not handle cleaner while it is in operation.
IMPORTANT
• Always make sure the cleaner head is fully
submerged before you begin operation.
• Clean out debris after each cleaning cycle.
• Do not leave your cleaner in the pool on a
permanent basis.
• At the end of each cycle, remove the cleaner
from the pool.
• Start at the cleaner head and untangle any
coils in the cable before storing the cleaner.
Submerge in the Pool
1. With the control box plugged into a
GFCI outlet, spread the oating cable
across the pool deck until you reach the
middle of the pool length.
NOTE: For optimal patterning and reduced tangling,
the floating cable should enter the water near
the middle of the pool length (Figure 3).
12ft / 4m
Midpoint of the Long side of Pool
Figure 3. Pool Entry Point for Optimal Patterning
2. Submerge cleaner vertically and turn
upside down until the bubbles stop to
remove any air trapped inside (Figure 4).
3. When the bubbles stop, allow the
cleaner to sink to the bottom of the
pool.
Figure 4. Submerge and Remove Trapped Air
4. Verify the cleaner is sitting right-side
up on the bottom of the pool. Remove
additional air if the cleaner is still
oating.
5. Spread all of the floating cable carefully
in the pool, ensuring there are no kinks
or coils. Use only as much cable as you
need to reach the farthest wall. This can
help prevent cable tangling (Figure 5).

8
ENGLISH
Figure 5. Spread Floating Cable to Prevent Tangling
Start / Stop Cleaning
1. Press On/Off button to begin or
interrupt cleaner operation (Figure 6).
ON / OFF
Figure 6. Begin Cleaning
2. Press Select button to choose between
Small Pool and Large Pool. Cleaning
duration for Small Pool is 1 hour; for
Large Pool, duration is 2 hours
(Figure 7).
3. Cleaner will begin to move.
= 1 Hour Shut-off
= 2 Hour Shut-off
Figure 7. Select Pool Size and Duration
Optimal Patterning/Cable Tangling
It is recommended to alternate the angle and
direction of the cleaning path every cleaning
cycle to ensure the cleaner is covering
the whole pool, as well as prevent cable
tangling.
1. Turn the cleaner upside down. Locate the
wheel pins on the axle: one adjustable
pin; one xed pin (Figure 8).
2. Reverse the positions of adjustable and
xed wheel pins (Figure 9).
Figure 8. Change Wheel Turning Direction

9
ENGLISH
Axle Position
Fixed
Pin
Adjustable
Pin
Figure 9. Alternate Wheel Axle Pins
Remove from Pool
1. Gently pull the oating cable to bring
the cleaner within arm's reach
(Figure 10).
Figure 10. Bring Cleaner to Pool's Edge
2. Gently pull the cleaner up to the
waterline (Figure 11).
Figure 11. Pull Cleaner to Waterline
3. Use the handle to lift the cleaner
from the water (Figure 12). Never lift
the cleaner out of the pool by the
oating cable.
Figure 12. Lift Cleaner Using the Handle
Remove Debris
For best performance, remove debris after
every cleaning cycle.
WARNING
To avoid electric shock and other hazards
which could result in permanent injury or
death, disconnect (unplug) the cleaner
from the power source before performing
any cleaning and maintenance.
1. Unplug power to the cleaner at the
control unit. Unplug the control unit
from the power source.
2. Push side tabs down and outward to
release the cleaner lid (Figure 13).
Figure 13. Remove the Cover
3. Pull gently on the elastic band around
the suction ports to release the lter
bag (Figure 14).

10
ENGLISH
Figure 14. Release the Elastic Band around Bag
4. Pull tabs to unfasten and turn the
bag inside out for thorough cleaning
(Figure 15).
Figure 15. Turn Bag Inside Out
5. Using a hose with clean water, rinse
the lter bag to remove all debris
(Figure 16).
Figure 16. Rinse
6. Replace back into the cleaner body
and replace the cover.
7. Store the cleaner out of direct sunlight
for next use.
Store the Cleaner When Not in Use
Do not leave the cleaner in the pool when
not in use. The cleaner should be cleaned
regularly using slightly soapy clean water. Do
not use solvents such as trichlorethylene or
its equivalent. Rinse the cleaner generously
using clean water. Do not let your cleaner dry
in direct sunlight near the pool.
1. Disconnect cleaner from the power
source.
2. Start at the cleaner head, remove all
coils and tangles from the oating
cable. Lay the cable in the sun to
loosen any tangling memory
(Figure 17).
3. Disconnect the cable from the control
unit.
Figure 17. Untangle the Floating Cable
4. Loosely coil the oating cable starting
at the cleaner and moving toward the
connection point at control unit.
5. Store the cleaner and power supply in
a dry/shaded area.
6. For extended periods, such as Winter
months, store the cleaner in a box
to keep motors, plastics and seals
protected (make sure the cleaner is dry
before storing) (Figure 18).
Figure 18. Long Term Storage for Extended Period

11
ENGLISH
Maintenance Tips
Regular maintenance is recommended to
extend the life of your cleaner.
WARNING
To avoid electric shock and other hazards which
could result in permanent injury or death,
disconnect (unplug) the cleaner from the power
source before performing any cleaning and
maintenance.
1. Avoid dropping the unit or the power
supply.
Dropping the cleaner may cause serious
damage.
3. Adjust wheel direction after every
cleaning cycle.
Adjusting wheel direction ensures your
cleaner reaches all areas of the pool and
prevents cable tangling.
4. Rinse the cleaner with fresh water.
Rinsing the outside and the inside of the
cleaner removes chlorinated pool water
and protects internal components.
Store in a cool, dry location when not in
use.
Coil the cable under the cleaner and store
in a dry/shaded area. Store in a dry box
for longer periods.
2. Clean the lter bags regularly.
Regular cleaning prevents clogging and
keeps recirculated water cleaner.

12
ENGLISH
Spare Parts
The complete spare parts list and exploded view is available on the Aqua Products website:
AquaProducts.com
Contact an authorized service center to perform diagnostic tests or repairs not shown in general
maintenance.
Troubleshooting
The following provides some helpful hints for troubleshooting common issues when using the
cleaner.
Problem Solution
Cleaner moving too slowly/
not sucking debris
• Clean the filter bags.
• Check to ensure the suction ports are not clogged or blocked.
All LEDs flashing on the
power supply
• Check if cleaner is turned on when out of the water.
• Check the motor protection screen, filter bag may be stuck.
• Check the propeller.
• Restart the cleaner. Press On/Off button, cleaner will resume.
Floating cable is coiled or
tangled
• Lay the cable flat in the sun on the ground to straighten.
• Change the order of the wheel axle pins.
• Verify the floating cable enters the water near the middle of the pool
length. (TIP: mark the correct length with black electrical tape)
• Reduce the amount of cable in the water.
Cleaner not sucking debris
• Check cleaner is set up properly and turned on.
• Make sure the filter bags are clean.
• Check the propeller.
• Adjust the suction ports under the cleaner for blockages.
Cleaner is stuck in the mid-
dle of the pool and is pump-
ing out water
• Check for obstructions or any loose objects in the pool.
• Check and adjust the height of the suction ports. They may be
touching the bottom of the pool.
Cleaner pattern stays in a
certain area of the pool
• Restart the cleaner at a different end of the pool.
• Check for correct pool size setting: Large or Small.
• Change the order of the wheel axle pins.
Cleaner does not cover
entire pool
• Clean the filter bags.
• Adjust the cycle time setting.
• Check the wheels and axles for blockages.
• Change the order of the wheel axle pins.

13
ENGLISH
NOTES

14
ENGLISH
NOTES

15
ENGLISH
NOTES

Zodiac Pool Systems LLC
2882 Whiptail Loop # 100
Carlsbad, CA 92010
Zodiac Pool Systems Canada, Inc.
2-3365 Mainway, Burlington
ON, Canada L7M 1A6
H0720000_REVC
©2021 Zodiac Pool Systems LLC. All rights reserved. Zodiac®is a registered trademark of Zodiac International,
S.A.S.U., used under license. All other trademarks are the property of their respective owners.
AquaProducts.com | 800.221.1750

FRANÇAIS
H0720000_REVC
Manuel de
l’utilisateur
TYPE: SSDP37--
IMPORTANT: VEUILLEZ LIRE AVANT
D’UTILISER LE NETTOYEUR
AVERTISSEMENT
POUR VOTRE SÉCURITÉ – Pour les tâches autres que les opérations de nettoyage et d’entretien décrites dans ce manuel, ce produit doit être
entretenu par un entrepreneur disposant d’une licence et qualifié en équipements de piscine par la juridiction dans laquelle le produit est
installé lorsque de telles exigences étatiques ou locales existent. S’il n’existe aucune exigence provinciale ou locale, le préposé à l’entretien
doit être un professionnel ayant assez d’expérience en équipement et en entretien de piscine pour pouvoir suivre exactement toutes les
instructions du présent manuel. Une mauvaise installation ou utilisation annule la garantie.

18
FRANÇAIS
Déclaration de la FCC
Cet appareil est conforme à la section 15 de la réglementation de la FCC et à la norme RSS exempte de licence IC.
Son fonctionnement est soumis aux deux conditions suivantes : (1) cet appareil ne doit pas causer d'interférences
nuisibles et (2) il doit accepter toutes les interférences reçues, y compris celles pouvant entraîner un fonctionnement
indésirable.
REMARQUE: cet équipement a été testé et déclaré conforme aux limites pour un appareil numérique de Classe B,
conformément à la partie 15 des directives FCC. Ces limites sont conçues pour fournir une protection
raisonnable contre les interférences nuisibles dans une installation résidentielle. Cet équipement
génère, utilise et peut émettre de l'énergie de fréquence radio. S'il n'est pas installé et utilisé
conformément aux instructions, il peut causer des interférences nuisibles aux communications radio.
Toutefois, il n’existe aucune garantie que des interférences ne se produiront pas dans une installation
particulière. Si cet équipement provoque des interférences nuisibles avec la réception de radio ou
de télévision, ce qui peut être déterminé en éteignant et en rallumant l'équipement, l'utilisateur est
invité à tenter de corriger les interférences en appliquant l'une ou plusieurs des mesures suivantes:
- Réorienter ou déplacer l’antenne de réception.
- Augmenter la distance entre l'équipement et le récepteur.
- Brancher l’équipement sur une prise différente de celle sur laquelle le récepteur est connecté.
- Consulter le revendeur ou un technicien radio/TV expérimenté pour obtenir de l’aide
MISE EN GARDE
Tout changement ou modification non expressément approuvé par la partie responsable de la conformité pourrait
annuler l'autorité de l'utilisateur à utiliser l'équipement.
REMARQUE: Cet appareil est conforme aux limites d’exposition aux rayonnements RF de la FCC et d’IC, établies
pour la population en général. Cet appareil doit être installé de manière à assurer une distance de
séparation d'au moins 20cm par rapport à toutes les personnes. Il ne doit pas être co-implanté ni
fonctionner conjointement avec une autre antenne ou un autre émetteur.
Selon les réglementations d'Industrie Canada, cet émetteur radio ne peut fonctionner qu'avec une antenne d'un
type et d'un gain maximal (ou inférieur) approuvé pour l'émetteur par Industrie Canada. Pour réduire le risque
de brouillage radioélectrique causé aux autres utilisateurs, le type d’antenne et son gain doivent être choisis de
manière à ce que la puissance rayonnée de manière isotrope équivalente ne soit pas supérieure à celle nécessaire
au succès de la communication.

19
FRANÇAIS
NOUS VOUS REMERCIONS D’AVOIR ACHETÉ CE ROBOT NETTOYEUR AQUA PRODUCTS.
VOTRE ROBOT NETTOYEUR AQUA PRODUCTS A ÉTÉ CONÇU ET FABRIQUÉ POUR ÊTRE FACILEMENT
INSTALLÉ ET FOURNIR DES OPÉRATIONS NÉCESSITANT PEU D’ENTRETIEN. AVANT D’INSTALLER VOTRE
NOUVEAUROBOT NETTOYEUR AQUA PRODUCTS, VEUILLEZ PROCÉDER COMME SUIT:
1) Enregistrer votre robot nettoyeur en ligne sous fluidrausa.com/registration.
2) Enregistrer vos informations d'achat sur les espaces fournis ci-dessous.
3) Joindre votre facture (ou une copie) à cette page.
En prenant ces mesures, vous assurerez un service de garantie rapide, le cas échéant. Si une réparation
est nécessaire, veuillez contacter votre revendeur original. Si le revendeur original ne propose pas de
services d’entretien couverts par la garantie, veuillez visiter le site www.AquaProducts.com pour localiser
un prestataire de service indépendant près de chez vous. Si vous êtes dans l’impossibilité de localiser un
prestataire de service, veuillez appeler notre Service de soutien technique au 1-800-822-7933.
ENREGISTRER LES DONNÉES RELATIVES À VOTRE ROBOT NETTOYEUR AQUA PRODUCTS ICI :
Date d’achat Acheté de Numéro de série:
(situé sur la tête du robot)
Ville État/Province Zip/Code postal
Table des matières
Consignes de sécurité importantes.......... 20
Spécications du robot nettoyeur ........... 22
Spécications générales............................................. 22
Connecter à l’alimentation électrique...... 22
Installer le nettoyeur................................ 23
Submerger dans la piscine ......................................... 23
Démarrer/Arrêter le nettoyage................................... 24
Acheminement optimal/Enchevêtrement
du câble............................................................ 24
Sortir de la piscine...................................................... 25
Enlever les débris ....................................................... 25
Ranger le robot nettoyeur lorsqu’il
n’est pas utilisé................................................. 26
Conseils d’entretien................................. 27
Pièces de rechange.................................. 28
Dépannage .............................................. 28

20
FRANÇAIS
AVERTISSEMENT
Le non-respect des avertissements ci-dessous peut entraîner des dommages permanents,
l’électrocution ou la mort.
PRÉVENIR LES CHOCS ÉLECTRIQUES
Pour réduire les risques de chocs électriques:
• Brancher l'unité à une prise protégée par un disjoncteur différentiel de fuite à la terre
(DDFT). Une telle prise DDFT doit être fournie par un installateur qualié et doit être testée
régulièrement. Pour tester le différentiel, appuyer sur le bouton de test. Le différentiel doit
couper le DDFT de l’alimentation. Appuyer sur le bouton de remise en route. L’alimentation
doit être rétablie. Si le DDFT ne fonctionne pas comme indiqué, c’est qu’il est défectueux. Si le
DDFT coupe l'alimentation de la pompe sans qu'on ait appuyé sur le bouton de test, un courant
à la terre circule, indiquant la possibilité d'une décharge électrique. Ne pas utiliser ce produit.
Débrancher le robot nettoyeur et faire corriger le problème par un technicien qualié avant de
l'utiliser.
• Conformément aux exigences de la National ElectricalCode®(NEC®) des États-Unis, maintenir le
boîtier de commande à au moins 1,5 m (5 pi) du bord de l’eau de la piscine/du spa . Au Canada,
le Code canadien de l'électricité (CEC) impose de respecter une distance minimale de 3m (10 pi)
entre le bord de la piscine et le boîtier de commande. Ne jamais immerger le boîtier de
commande.
• Ne pas entrer dans la piscine tandis que le robot nettoyeur Aqua Products est immergé.
• Ne pas enterrer le cordon. Installer le cordon de manière à ce qu’il ne soit pas endommagé par
les tondeuses à gazon, les taille-haies et d’autres équipements.
• An de réduire les risques de choc électrique, ne pas utiliser lerobot nettoyeur Aqua Products
ou le boîtier de commande sile cordon est usé ou endommagé. Contacter le Service de soutien
technique Fluidra immédiatement pour un entretien approprié et pour le remplacement du
cordon d’alimentation endommagé.
• Double isolation—Pour une protection permanente contre les risques de décharge électrique,
utiliser uniquement des pièces de rechange identiques lors de l'entretien. Ne pas tenter de
réparer du robot nettoyeurAqua Products, le boîtier de commande, le cordon d’alimentation ou
le câble ottant.
• NE JAMAIS OUVRIR LE BOÎTIER DE COMMANDE.
• NE PAS UTILISER DE RALLONGE POUR BRANCHER L'UNITÉ À L'ALIMENTATION ÉLECTRIQUE.
UTILISER UNE PRISE PROTÉGÉE PAR UN DISJONCTEUR DIFFÉRENTIEL DE FUITE À LA TERRE
(DDFT). LE BOÎTIER DE COMMANDE DEVRA ÊTRE BRANCHÉ DANS LE BOÎTIER DE LA PRISE
DDFT.
PRÉVENIR LES CHOCS ÉLECTRIQUES
• Pour réduire le risque de blessures, ne pas permettre aux enfants d’utiliser ce produit.
• Ne laisser personne, surtout des jeunes enfants, s’asseoir, mettre le pied, s’appuyer ou monter
sur des appareils faisant partie du système opérationnel de la piscine.
Consignes de sécurité importantes
Nous vous félicitons d’avoir fait l’acquisition de ce robot nettoyeur Aqua Products. Veuillez lire
l'intégralité du manuel avant d'installer votre nouveau robot nettoyeur de piscine. Votre robot
nettoyeur doit être installé et utilisé comme spécié.
