Aqua-Scope KFRLWE01 User manual

www.aqua-scope.com
Gate Valve Servo
For Angled and Straight Seats
The Angled Seat Valve Servo is a motor to retrofit existing and installed Gate or even Angled Seat Gate
Valves popular in several European countries into smart water controlling devices. Its wireless
communication capabilities are compatible with the LoRaWAN industry standard for easy integration
into existing networks. Additionally, the device is controlled directly by the Aqua-Scope Monitor to
compose a complete Leak Protection System. The motor is powered by a 12 V external power supply or
- optional – a battery block.
Various adapter rings and a sophisticated patented connection system allow to apply the motor on all
contemporary Angled Seat Valves from DN15 to DN32. The device can operate in difficult environmental
conditions, even submerged under water, and allows to directly connect one additional local water
sensor pad by cable.

Technical Data:
• SKU:
KFRLWE01
• EAN: 425 129 578 040
• Mechanical Performance:
o Rotation Speed: 15 rpm
o Travel Time (full open close) 40 s
o Mechanical Power: 10,95 W
o Gearbox: 1 to 704 ratio
o Noise: < 50 dB
o Vibration: < 10 dB
• Installation space:
o Min. Space from Wall: Pipe center
min 35 mm from wall
o Min. Space vertically: 175 mm
above pipe center
o Min. Space vertically for mounting
220 mm above pipe center
o Adapters: M17, M22, M27, M30
o Supported Stem height (from
bottom of bonnet): 58 mm – 135
mm, raising and non-raising spindles
o Supported Stem connector: 6, 7, 8
mm square
o Supports Pipes DN15 … DN 32
• Controls and interfaces:
o Tree Color LED (red, yellow, green)
o Single button for pairing, unpairing,
local operation and alarm clearing
o Jack to plug-in external water
sensor pad for local loop operation.
• RF Communication LoRaWAN
o Radio Chip: SX 1261
o Standard: Class C
o Frequency: 868…869 MHz, other
frequencies such as US configurable
o Range: 150 … 200 m (depends on
gateway)
o Network Joining: OTAA
• Dimensions and Shipment:
o Weight: 380 ... 420 gr (depends on
adapters used)
o Dimensions: 70 x (170 … 195) mm
• Electrical data:
o Voltage: 12 V DC
o Max. Current: < 1000 mA
• Environmental Conditions and Trading
o Shipment/Storage: -30 °C … +70 °C
o Operation: - 20 °C … 60 °C
o Outdoor Use: IP67 (to power supply
coupling), Power Supply is IP20
o UN Customs Tariff: 85011093900
Scope of Delivery
• Motor with power cable,
• 4 * adapter rings to connect to the valve
housing
• 3 different connectors for the stem
• Distance Ring for EWE Valve Design
• Holder plus 2 wrist bands
• Main sleeve plus internal coupler
• Two Distance rings for raising stem
valves
• External wired Flood Sensor
• External Power Supply
• Spare Hand Wheel
• Users Manual
(*) Please note that the device is not exposed to drinking water there therefore not subject to European
Drinking Water directive.
Aqua-Scope Technologies OÜ, Sakala tn 7-2, 10141 Tallinn Republic of Estonia Phone: [phone],
Mail: infoaqua-scope.com, Web: aqua-scope.com

Parts
Handwheel (H)
Inner Coupler (K)
Adapters (Ax)
Spacer Rings (D1,D2)
Ball Bearing Seat (Ws)
Motor (M)
Main Housing (G)
Holder (N)
Installation
The motor actuator can be applied to all contemporary angle seat valves commercially available. The
motor replaces the - usually green - handwheel mounted on the valve, which must be uninstalled for
this purpose.
The motor servo consists of three main components:
• The motor head with the power supply cable (M).
• The inner coupler, which connects the motor to the spindle (black part) (K)
• The outer housing, which connects the motor housing to the valve housing. (G)
In addition, adapters are needed both to adapt the inner coupler to the different spindle diameters
(W1…W3) and to connect the outer housing to the different valve housings (A1…A4).
Modification on the valve spindle
The first step is to remove the handwheel from the stem by removing the screw in the center. A few
manufacturers do not use the typical green handwheel. However, the metal spindle is always hidden
under the plastic. The appropriate ball bearing seat (W1 … W3) is now placed on its square end and
fastened with the screw of the handwheel. With the new handwheel (H) supplied, the valve can also be
operated manually in this state.
Mounting the main housing
The main housing (G) must be firmly connected to the valve body. Adapter rings (Ax) for M17, M22, M27
or M30 wrench sizes are used for this purpose. The appropriate adapter ring is placed on the valve body.
If none of the supplied adapters fit the valve, please contact Aqua-Scope support.

Depending on the length of the valve spindle, one of both of the spacer rings (D1,D2) may need to be
inserted between the adapter ring (Ax) and the main housing (G). To determine the need for this, the
following steps must be carried out:
1. The valve is completely open.
2. The main housing (G) is slipped over the spindle and the inner coupler (K) is pushed into the main
housing from above.
3. If the inner coupler (K) cannot be pushed completely into the main housing (G) without sitting
on the valve housing, or if the main housing can be connected to the adapter ring already
installed at the same time, then a spacer ring (D1 or D2) must be placed between the adapter
ring (Ax) and the main housing (G). This is usually the case for valves with rising stem. The spacer
rings are12 or 24 mm.
4. The supplied handwheel (H) can be put on the inner main coupler (K) and operate the valve
manually. Make sure that the valve can be moved to both the OPEN and CLOSED positions.
Final assembly
The final step is to slide the hold-down bracket (N) over the main body and secure it in place with the
two supplied tension straps so that the entire structure is firmly attached to the valve body. The
tensioning straps can be released again by applying slight pressure at the ends. As a final step, the drive
motor (M) is plugged onto the main housing (G). In doing so, it connects to the inner coupler.
Valves of Wilhelm Ewe GmbH & Co. KG
The valves of this company have a very special design. You need to
apply the split ring (S1+S2) instead of the adapter ring and use the
space ring 24 mm to hold the split ring in place. Below the ball bearing seat, you need to place the small
spacer ring (D).
External Flood Sensor
The device allows attaching an optional wired flood sensor to the device. There is a connector on the
power cable next to the motor. Remove the blue protection pad and plugin the sensor. You must apply
some force to push the jack to ensure water-proof connection. Once the sensor head detects water a
flood alarm is issued, the valve is closed and the alarm is indicated with buzzer and LEDs. Once the sensor
head is free of water, you may want to clear the alarm by hitting the button for 2 seconds. It is also
possible to clear alarm using a wireless LORA command. In both cases an Alarm clear report is sent uplink
to the LORA network.
Operating the device
You can open or close the valve by briefly pressing the button. If you press the pushbutton while the
motor is running, the running direction will be reversed.
S1/2
D

The device must calibrate to detect the end positions of the valve. Once these end positions are known
the motor will gently stop at this position and not ‘hit against the wall’ to protect the mechanics and
ensure long lifetime and reliable operation. After powering up the device will perform a short move to
detect if the last position was open or close. The first opening or closing operations are used to perform
the calibration. No further user interaction is needed for calibration.
The device has a two-color LED with the following meaning:
• Green slowly flashing: valve is open
• Red slowly flashing: Valve is closed
• Red/green flashing: Motor is moving
• Red flashing: Flood alarm
• Red triple flashing: motor is blocked.
Wireless Communication - LoRaWAN
To pair the device with an Aqua-Scope Monitor, follow the instructions in the Aqua-Scope app.
The device can be controlled directly via LoRaWAN. For this purpose, different commands are defined, which are used either 'uplink’, i.e.
from the device to the LoRa network, or 'downlink’, i.e. from the LoRa network to the device. Commands can be cascaded up to the
maximum number of 52 bytes. All values of the command descriptions are bytes, unless otherwise specified.
Downlink-Commands:
• 0x07 XX: Set valve position XX = 0 = close, XX = 0x64 = open
• 0x0b 0x00: Clear local alarm
• 0x17: Get valve position, device answers with uplink command 0x07
• 0x03: Get hardware ID, device answers with uplink command 0x03
• 0x04: PP VV_MSB VV_LSB: Set configuration parameter PP for new 16 Bbt value VV
• 0x1a: Get firmware version, device answers with uplink command 0x03a
• 0x14 PP: Get configuration parameter PP, device answers with uplink command 0x04
Uplink-Commands:
• 0x03 XX YY_MSB, YY_LSB: Report hardware version XX and device capabilities bitmap YY
• 0x04 PP VV_MSB VV_LSB: Report 16 Bit Value VV of configuration parameter PP
• 0x06 01 VV_MSB VV_LSB: Report 16 Bit temperature sensor value VV
• 0x07 XX: Report valve position XX
• 0x0a YY_MSB YY YY YY_LSB: Report firmware version as 32 Bit value
• 0x0b XX YY ZZ_MSB, ZZ_LSB: Report alarm state XX (1 or 0) of alarm type YY with optional value Z. Current alarm types are 0x01
= external flood sensor, 0x02 = temperature alarm
Configuration Parameters
Parameter 1 - Status interval
Description: The device reports regularly to the LORA network. This parameter defines the time interval for these reports in minutes. The
default is 0x015 = 15 minutes. The value range is 0x0005 - 0x10E0
Parameter 2 - Message type
Description: This parameter defines whether confirmed or unconfirmed messages are sent over LoRaWAN. The default is 0x01 =
confirmed message. The value 0x00 sets to unconfirmed message.
Parameter 3 - Scale value for temperature report
Description: This parameter defines whether a temperature value should be in Celsius (0x00) or Fahrenheit (0x01). The default setting is
Celsius.
Parameter 4 - Repeat alarm report
Description: This parameter defines how an alarm report is sent to the LoRa network. The parameter combines two different values: The
more significant byte describes how often an alarm packet is retransmitted. The default setting here is 0x03 = 3 times. A value between
0x00 (no repetition) and 0xff (unlimited repetition) can be selected. The least significant byte defines the repeat interval in minutes. Here
the default setting is 0x01. This means the default parameter is 0x0301.

Parameter 5 - Regular valve training
Description: A valve should be moved regularly to maintain its smooth operation. The device can perform this training independently from
control by a LoRa network.
The parameter combines two different values: The higher-order byte describes whether (1) or not (0) valve training should take place. The
low-order byte defines the interval of the training in days. Values between 1 and 30 days are possible. The default value is 0x0107, i.e.
training takes place every 7 days.
Parameter 6 - Local display
Description: With this parameter the buzzer and the LEDs can be activated (0x01) or deactivated (0x00) directly at the device. The lower
byte defines the behavior of the buzzer, the higher byte the behavior of the LED. The default value is 0x0101, i.e. both buzzer and LED are
active (for example during motor movement).
Parameter 7 - Threshold value for temperature report
Description: This parameter defines at which temperature change an additional temperature report is sent in addition to the regular
temperature report. The value is given in 0.1 degrees Celsius and must be greater than 0x000a (= 1 degree). The default value is 0x000a.
Support and Contact
Should you encounter any problem, please give us an opportunity to address it before returning this product. Please check our website
www.aqua-scope.com and particularly the support section for answers and help. You can also send a message to [e-mail]
While the information in this manual has been compiled with great care, it may not be deemed an assurance of product characteristics.
Aqua-Scope shall be liable only to the degree specified in the terms of sale and delivery. The reproduction and distribution of the
documentation and software supplied with this product and the use of its contents is subject to written authorization from Aqua-Scope.
We reserve the right to make any alterations that arise as the result of technical development.
Phone: [phone]
eMail: [e-mail] / [e-mail]
Web: www.aqua-scope.com
Declaration of Conformity
Aqua-Scope Technology OÜ, Sakala 7-2, 10141 Tallinn, Republic of Estonia,
The radio emitting device works on frequency 868…849 MHz with output power of 4 dBm. (2.5 mW)
Български С настоящото Aqua-Scope Technology OÜ декларира, че този тип радиосъоръжение KFRLWE е в съответств ие с Директива 2014/53/ЕС. Цялостният
текст на ЕС декларацията за съответствие може да се намери н а следния интернет адрес: www.aqua-scope.com/ce Čeština Tímto Aqua-Scope Technology OÜ
prohlašuje, že typ rádiového zařízení KFRLWE je v souladu se směrnicí 2014/53/EU. Úplné znění EU prohlášení o shodě je k dispozici na této internetové adrese:
www.aqua-scope.com/ce Dansk Hermed erklærer Aqua-Scope Technology OÜ, at radioudstyrstypen KFRLWE er i overensstemmelse med direktiv 2014/53/EU.
EUoverensstemmelseserklæringens fulde tekst kan findes p følgende internetadresse: www.aqua-scope.com/ce Deutsch Hiermit erklärt Aqua-Scope Technology
OÜ, dass der Funkanlagentyp KFRLWE der Richtlinie 2014/53/EU entspricht. Der vollständige Text der EUKonformitätserklärung ist unter der folgenden
Internetadresse verfügbar: www.aqua-scope.com/ce Eesti Käesolevaga deklareerib Aqua-Scope Technology OÜ, et kesolev raadioseadme tp KFRLWE vastab
direktiivi 2014/53/EL nuetele. ELi vastavusdeklaratsiooni tielik tekst on kttesaadav jrgmisel internetiaadressil: www.aqua-scope.com/ce English Hereby, Aqua-Scope
Technology OÜ declares that the radio equipment type KFRLWE is in compliance with Directive 2014/53/EU. The full text of the EU declaration of conformity is
available at the following internet address: www.aqua-scope.com/ce Español Por la presente, Aqua-Scope Technology OÜ declara que el tipo de equipo
radioeléctrico KFRLWE es conforme con la Directiva 2014/53/UE. El texto completo de la declaracin UE de conformidad está disponible en la direccin Internet
siguiente: www.aqua-scope.com/ce Ελληνικά Με την παρούσα ο/η Aqua-Scope Technology OÜ, δηλώνει ότι ο ραδιοεξοπλισμόςKFRLWE πληροί την οδηγία
2014/53/ΕΕ. Το πλήρες κείμενο της δήλωσης συμμόρ φωσης ΕΕ διατίθεται στην ακόλουθη ιστοσελίδα στο διαδίκτυο: www.aqua-scope.com/ce Français Le
soussigné, Aqua-Scope Technology OÜ, déclare que l'équipement radioélectrique du type KFRLWE est conforme la directive 2014/53/UE. Le texte complet de la
déclaration UE de conformité est disponible l'adresse internet suivante: www.aqua-scope.com/ce Hrvatski Aqua-Scope Technology OÜ ovime izjavljuje da je radijska
oprema tipa KFRLWE u skladu s Direktivom 2014/53/EU. Cjeloviti tekst EU izjave o sukladnosti dostupan je na sljedećoj internetskoj adresi: www.aqua-scope.com/ce
Italiano Il fabbricante, Aqua-Scope Technology OÜ, dichiara che il tipo di apparecchiatura radio KFRLWE conforme alla direttiva 2014/53/UE. Il testo completo della
dichiarazione di conformit UE disponibile al seguente indirizzo Internet: www.aqua-scope.com/ce Latviešu Ar šo Aqua-Scope Technology OÜ deklarē, ka radioiekārta
KFRLWE atbilst Direktīvai 2014/53/ES. Pilns ES atbilstības deklarācijas teksts ir pieejams šādā interneta v ietnē: www.aqua-scope.com/ce Lietuvių Aš, Aqua-Scope
Technology OÜ, patvirtinu, kad radijo įrenginių tipas KFRLWE atitinka Direktyvą 2014/53/ES. Visas ES atitikties deklaracijos tekstas prieinamas šiuo internet adresu:
www.aqua-scope.com/ce Magyar Aqua-Scope Technology OÜ igazolja, hogy a KFRLWE típus rádiberendezés megfelel a 2014/53/EU irányelvnek. Az EUmegfelelőségi
nyilatkozat teljes szövege elérhető a következő internetes címen: www.aqua-scope.com/ce Malti B'dan, Aqua-Scope Technology OÜ, niddikjara li dan it-tip ta'
tagħmir tar-radju KFRLWE huwa konformi madDirettiva 2014/53/UE. It-test kollu tad-dikjarazzjoni ta' konformit tal-UE huwa disponibbli f'dan l-indirizz talInternet li
ġej: www.aqua-scope.com/ce Nederlands Hierbij verklaar ik, Aqua-Scope Technology OÜ, dat het type radioapparatuur KFRLWE conform is met Richtlijn
2014/53/EU. De volledige tekst van de EUconformiteitsverklaring kan worden geraadpleegd op het volgende internetadres: www.aqua-scope.com/ce Polski Aqua-
Scope Technology OÜ niniejszym oświadcza, że typ urządzenia radiowego KFRLWE jest zgodny z dyrektywą 2014/53/UE. Pełny tekst deklaracji zgodnośc I UE jest
dostępny pod następującym adre sem internetowym: www.aqua-scope.com/ce Português O(a) abaixo assinado(a) Aqua-Scope Technology OÜ declara que o
presente tipo de equipamento de rádio KFRLWE está em conformidade com a Diretiva 2014/53/UE. O texto integral da declarao de conformidade está disponível no
seguinte endereo de Internet: www.aqua-scope.com/ce Română Prin prezenta Aqua-Scope Technology OÜ declară că tipul de echipamente KFRLWE este în
conformitate cu Directiva 2014/53/UE. Textul integral al declarației UE de conformitate este disponibil la următoarea adresă internet: www.aqua-scope.com/ce
Slovensko Aqua-Scope Technology OÜ potrjuje, da je tip radijske opreme KFRLWE skladen z irektivo 2014/53/EU. Celotno besedilo izjave EU o skladnosti je na voljo
na naslednjem spletnem naslovu: www.aqua-scope.com/ce Slovensky Aqua-Scope Technology OÜ týmto vyhlasuje, že rádiové zariadenie typu KFRLWE je v slade so
smernicou 2014/53/EÚ. Úplné EÚ vyhlásenie o zhode je k dispozícii na tejto internetovej adrese: www.aqua-scope.com/ce Soumi Aqua-Scope Technology OÜ
vakuuttaa, että radiolaitetyyppi KFRLWE on direktiivin 2014/53/EU mukainen. EUvaatimustenmukaisuusvakuutuksen täysimittainen teksti on saatavilla seuraavassa
internetosoitteessa: www.aqua-scope.com/ce Svenska Härmed försäkrar Aqua-Scope Technology OÜ att denna typ av radioutrustning KFRLWE verensstmmer med
direktiv 2014/53/EU. Den fullständiga texten till EUförsäkran om verensstämmelse finns på följande webbadress: www.aqua-scope.com/ce
