98GCK-45DR
INSTALATION AND PROGRAMMING GUIDE
REV.03092018

Page 2of 14
RV AWNING PRODUCTS
1361 CALLE AVANZADO, SAN CLEMENTE, CA 92673 [phone] FAX [phone]
www.girardrv.com
Girard Systems awnings may be operated in light wind and rain conditions. When
periods of heavy rain and or high wind are expected the awning must be closed.
Never leave the awning open and unattended.
Damage caused by wind and rain is not covered by warranty.
All awnings must be closed prior to moving the vehicle for any reason. As an extra
safety precaution a visual check that every awning is fully closed is required.
Damage caused by failure to comply with these instructions is not covered
by warranty.
Before using your awning, ensure that the area into which the awning will be
deployed is free of obstructions (Trees, walls, pillars, posts, other vehicles etc.)
Damage caused by collisions with any of the above or similar is not
covered by warranty.
Before using your awning make sure that all of your electrical circuits are operating
correctly. Recreational Vehicles can generate AC power from three separate sources.
The electrical system transfer switch in your vehicle will select power for the awning
as follows:
Shore Power –if connected;
Generator Power –if the generator is running;
Inverter Power –batteries must be charged for inverter operation.
Girard Systems awnings are supplied with an electric motor appropriate to the product.

Page 3of 14
CONTENTS
Product description ………………………………………………………………………………………. 3
DC Controller Installation Wiring Diagram.………………………………….…………………… 4
PAIRING WITH 98GC1063 SINGLE CHANNEL HANDSET…………………...........……. 5-6
PAIRING WITH Dry Contact Module GC1149A…………….…………………...........……. 7-9
PAIRING WITH A MOTION SENSOR GC779G…………….…………………...........……..10-14
THE G–LINK SYSTEM
The G-Link motors and control modules provided by Girard Systems communicate by
use of RF signals on a frequency of 433.92 MHZ. This eliminates the need for wiring
and the drilling of holes in the vehicle. These components must be electronically
matched, programmed or paired before use. This is usually done at the Girard Systems
factory. Should the need arise for the user to pair a device with the motor controller
they must refer to the appropriate manual for the devices applicable to their particular
installation.
PRODUCT DESCRIPTION
The GC1146C is a 12v DC Motor Control Module which requires a 20 Amp Circuit
breaker or fuse protected power supply, designed to control a single awning motor. The
thicker RED and BLACK wires are the module’s input power supply which should be
connected to the vehicle’s Power distribution panel. The thinner RED and BLACK wires
are the 12v output to the LED lighting strip. The BLUE and BROWN wires are the 12v
output which should be connected to the awning motor. The longer White wire is the
modules RF antenna. The GC1146C has an operating frequency of 433Mhz, and a range
of up tp 650’ in the open or 110’ where there are obstructions. This module can be
paired with up to 20 compatable RF remote devices. If additional devices are paired
with the GC1146C, previously paired devices will be overwritten in turn from the second
device onward.

Page 4of 14
WARNING
“To reduce the risk of electric shock the operator power is to be
provided from a weatherproof junction box in the case of permanent
wiring, as per 314.15 of the National Electrical Code, NFPA 70.”
To prevent the motor protector from tripping do not exceed 2 minutes
of operation per hour.

Page 5of 14
PAIRING WITH REMOTE DEVICES
The following pages give instructions on how to pair the GC1146C Motor controller with
various compatable RF remote control devices. Please ensure that the correct set of
instructions are followed for the device being paired with the Motor controller.
98GC1063 SINGLE CHANNEL HANDSET
Fig.1 Fig.2
The 9GC1063 is the simplest of devices, IN and OUT buttons clearly marked. If you
should wish to stop the awning at any point press the center of the control pad. See
Fig.1 Above. On the back of the handset you will find the P2 button and the battery
tray.
The programming window for this module is only 10 seconds so please
ensure that the programming instructions are read and understood before
attempting to execute them.
1) Supply power to the motor control module. (It will beep ONCE )
2) Press the P2 button on the handset TWICE. (The motor controller will beep with
each press)

Page 6of 14
3) Press the IN button on the handset. (The awning should retract)
If the awning extends at this point instead of retracting, press the STOP button
immediately, then remove the power supply to the motor controller for at least 10
seconds.
Next repeat steps 1 and 2 above then press the OUT button on the handset to complete
the programming procedure.
Ensure that the awning responds correctly to the handset by pressing the OUT, STOP
and IN buttons alternately.

Page 7of 14
DRY CONTACT MODULE GC1149A
Fig.1
Technical Specification
•Input voltage：12V/24V
•Transmitting frequency：433MHz
•Transmitting power：10 milliwatts
•Transmitting distance：500 Feet open area
•120 feet on two walls

Page 8of 14
MODES OF OPERATION
The GC1149A has 3 modes of operation;
1. Continuous Mode (Default) –A single press of a command button will allow the
awning to fully extend or retract unless interrupted by the STOP button.
2. Step Mode (Selected) –The command button must be held down to allow the
awning to fully extend or retract. The motor will stop as soon as the command
button is released.
3. Secondary Continuous Mode (Selected) –A single press of a command button will
allow the awning to fully extend or retract unless interrupted by pressing either the
same command button or the stop button.
To select each mode the module must be connected to a 12v power supply.
•Use a small screwdriver or similar tool to press and hold the SET button, a
blue/purple LED next to the set button will begin to flash 5 times slowly and then
ONCE quickly to indicate the DEFAULT mode.
•Continue to hold the set button (for about 12 seconds) until the LED flashes TWICE
quickly. This will select the STEP mode.
•Continue to hold the set button (for about 20 seconds) until the LED flashes 3
TIMES quickly. This will select the secondary continuous mode.
The LED will be
seen flashing here

Page 9of 14
PROGRAMMING STEPS
NOTE:
•Before starting this procedure, the Receiver must be without power
(OFF) for at least 10 seconds.
•During the programming function the interval between each step
required must be less than 10 seconds
1. Programming the 98GC1149A
a. Connect the Dry Contact Control Module (GC1149A) to 12 Volts DC (Fig.1)
b. Supply power to the Remote Motor: a soft beep will be emitted by the RF
receiver in the unit.
c. Press the P2 button twice on a programmed transmitter, (A beep will be
emitted by the RF receiver with each press)
d. Press the Retract button on the dry contact or using a small jumper from
Common to Retract, which will link the GC1149A to the motor.
e. Try to operate the Awning by using the system or by using small jumpers
from common to retract terminal. If the Awning does not move, repeat steps
“a” to “e”.
Note: If the motor turns in the opposite direction, repeat “a to e’ but now
use Extend instead of Retract.

Page 10 of 14
PAIRING WITH A MOTION SENSOR GC779G
Identify the Primary remote which operates the Motor controller for the awning on
which the motion sensor is to be mounted. There may be more than one on the vehicle.
Prepare the Motion Sensor for pairing by carrying out the following procedure.
Remove the 2 small
Phillips screws which
secure the motion sensor
to the mounting bracket.
The base of the module
is magnetized so will
need to be gently lifted
off.
Fig.1
Then turn it over.
Fig.2

Page 11 of 14
Remove the 4 Phillips
screws holding the
module together.
Remove the base plate
and silicone insert.
Fig.3
Turn the base plate over
(Magnet down). Then
place the motion sensor
on top of it so that the
magnet is aligned with
the reed switch. If this
is not done the
default program
cannot be changed.
Fig.4
Fully extend the awning to ensure smooth operation, then retract the awning leaving it
partially open (about 3 feet).
Locate the P2 Button on the back of the handset.
Base Plate
Magnet
Insert
Reed Switch
Adjustment Dial
Programming
Button
LED

Page 12 of 14
Note; when carrying out this part of the procedure each step must be
executed within 6 seconds of the previous one or the module will revert to
factory settings. It is highly recommended that you read and understand the
following sequence before attempting to execute it.
1) Set the Motion Sensor Adjustment Dial to 0. (See Fig.4).
2) Connect the GC779G Motion sensor to a 12volt DC circuit. At this point the
Purple LED will illuminate and then begin to blink. If it does not, the unit is not
receiving the correct power. Ensure that the magnet and reed switch are aligned
and verify the electrical connection before proceeding.
3) Using an appropriate tool, press the P2 Button on the back of the Remote
Controller TWICE. The GC1146C will bleep ONCE with each press.
4) Press the programming button on the GC779G Motion sensor ONCE (See Fig.4).
The GC1146C will bleep several times to indicate that the program has been
accepted.
5) Ensure that the code was accepted by pressing the Program button on the
GC779G Motion sensor again. The Awning should make a small step IN or OUT.
Or shake the motion sensor and the Awning will fully retract.
6) If the Awning does not retract, repeat steps a. to d.
7) Set the Adjustment Dial to the desired sensitivity level 1 to 5. Never set higher
than 5. (The factory setting is 3).
Once programming is complete, reassemble the Motion sensor module and
mount it on the awning lead rail.

Page 13 of 14
PAIRING WITH ADDITIONAL DEVICES
As mentioned in the Product description the GC1146C can be paired with up to 20
compatible devices, wall switches handsets and others. The first device to be paired
with the 98GC74 Motor Controller shall now be referred to as the PRIMARY REMOTE
which is used to program all additional devices which shall be referred to as the
SECONDARY REMOTE or SECONDARY DEVICE. To add a secondary device to the motor
controller, carefully follow the steps below.
Note; when carrying out this part of the procedure each step must be
executed within 6 seconds of the previous one or the module will revert to
factory settings. It is highly recommended that you read and understand the
following sequence before attempting to execute it.
1) First ensure that the Primary remote device is functioning correctly.
2) Ensure that the Secondary device has the battery /batteries inserted correctly.
3) Press the P2 Button on the Primary Remote TWICE (The Motor controller will
beep with each press)
4) Press the P2 Button on the Secondary remote ONCE (The motor controller will
beep again)
5) Press IN or OUT on the Secondary remote and ensure that the awning responds
accordingly.

Page 14 of 14
REMOVING AN ADDITIONAL DEVICE
Select the Secondary device that is to be removed from the 98GC74’s list and follow the
steps below;
1) Press the P2 Button on the device ONCE (The Motor controller will beep in
response.
2) Press the STOP Button on the device ONCE.
3) Press the P2 Button on the device again. The Motor controller will beep several
times indicating that the secondary device has been cancelled.
For queries or assistance with programming any of your G-Link devices
please call Girard Systems TOLL FREE on 800–382–8442 between 7:30am
and 3:30pm P.S.T.
