AquaEuroUSA 135 User manual

1
IN SUMP PROTEIN SKIMMER
TOP QUALITY & HIGHLY EFFICIENT
INCLUDES NEEDLE WHEEL PUMP
1 YEAR WARRANTY

2
ASSEMBLY PARTS
NOTE:
Make sure all connections are secure. Examine for damages before installation.
Top Cover
Collection Cup
Silencer
Air Hose
Water Level Adjuster
Bubble Diffuser
Pump Elbow
Aqua Euro
Needle Wheel Pump
PARTS CHECK LIST
1 Silencer
1 Pump Elbow
Collection Cup
Pump with air hose
Water Level Adjuster
Foam bubble post filter
Collection cup lid

3
INSTRUCTIONS
SET UP & OPERATION
Note: Protein Skimmer is designed for in-sump use only.
1. Remove all accessories from box and examine for damages.
2. Rinse skimmer thoroughly to remove any fabrication debris.
(Can also be done after skimmer has been assembled)
3. Assemble Skimmer according to diagram as shown in 2nd
4. For an easier setup join pump union with pump elbow before the skimmer has
been seated in the sump.
page.
5. Slowly place skimmer in the sump.
6. Leave sufficient clearance to be able to remove the skimmer collection cup.
7. Position the pump in desired location then place air hose and silencer on
skimmer body as shown in 2nd
8. Do not allow water to get into air hoses or silencers.
page.
9. The recommended water level is between 5” to 7”.
The sump water line varies depending on sump size and water flow
10. Turn pumps on. Use with ground fault circuit interrupter (GFCI)
Skimmer will require 24 - 48 hours to “break-in” in some cases longer depending on the
bio-load, during which time an excess of waste and bubbles might appear. Let skimmer
run for a few hours before adjusting the water level. Once the skimmer has settled you
can adjust the water level inside the skimmer to obtain a better consistency in foam
production. The side opening on the second chamber is normal and will prevent the
water from getting to the collection cup. Keep skimmer in a calm area of the sump away
from turbulence. Dry skimming can be achieved by adjusting the water level in skimmer.
Use the water level adjuster (see page 2) to lower the water level. .
Note: Water on second chamber is normal and will not affect the performance of the
skimmer.
MAINTENANCE
Warning: Do not touch pump, cord or electrical plugs with wet hands. Disconnect
pumps from electricity (power supply) before performing maintenance, moving or
adjusting skimmer.
Every Week:
The skimmer collection cup should be cleaned on a regular basis. For better
performance clean the collection cup more than once a week even if collection cup is not
full. Empty collection cup and then use clean water and a brush to clean the cup.

4
Every Year:
An annual clean up is recommended. If a decrease in performance has occurred and the
pump has developed lime deposits perform a complete clean up.
1. Unplug the pump (hands must be dry)
2. Remove pump from skimmer
3. Remove skimmer and pump from sump
4. Rinse all parts with clean water use brush if necessary
5. Unscrew pump cover and clean any residue on needle wheel
6. Use white vinegar to remove any lime residue
7. Clean air hose for any salt residue obstructions
8. Reassemble the skimmer
SAFETY
WARNING: FOLLOW THE SAFETY PRECAUTIONS BELOW TO PREVENT
PROPERTY DAMAGE, FIRE, PERSONAL INJURY AND LOSS OF LIFE.
1. Make sure tubing and all connections are secure
2. Connect pumps to ground fault circuit interrupter (GFCI).
3. Do not touch electrical plugs with wet hands to connect pumps to outlet.
4. Do not attempt to repair a damaged pump
5. Do not operate the pumps if cords or plugs have been damaged in any way.
6. Do not run skimmer with a timer that has a rapid on/off cycle.
7. Do not clean skimmer with any chemicals that contain alcohol or ammonia.
8. Create a drip loop for each pump power cord to prevent water from running the
length of the power cord and reaching the power outlet.

5
Aqua Euro USA™ One-Year Limited Warranty
Inspect skimmer when it is received. If skimmer is received damaged, notify the carrier,
note damage on freight bill. Otherwise no claim can be made against the carrier.
Aqua Euro USA™ guarantees this product, to the original purchaser, against defects in
components, materials and workmanship (that occur under normal use) for a period of
ONE (1) YEAR from the date of retail purchase. The warranty is not transferable and is
confined to the original retail purchaser only.The warranty does not extend to damages
caused by power surges, improper installation or any form of abuse. The warranty does
not apply if (1) damages result from misuse, accident, lack of reasonable care or abuse,
(2) the product is not purchased from Aqua Euro USA™ or an authorized dealer, (3)
damage due to modification or alteration that is made to the product (4) wrong circuitry
or unspecified electrical input to the pump, (5) the site (location where the product is
kept) conditions do not conform to the recommended operating conditions for the
skimmer, (6) the original brand name is removed, obliterated or altered from the product.
Contact the company at www.aquaeurousa.com
Purchaser pays any postage, shipping and insurance fees to return skimmer
In the event of product failure within the warranty period, please contact the store where
the product was purchased for further instructions for repair or replacement. Repair or
replacement will be carried out through Aqua Euro USA™ or its authorized dealers. A
return authorization number and a copy of original purchase receipt are required for
return of the defective product. After any repairs/replacement of the unit, this warranty
will thereafter continue and remain in force only for the unexpired period of warranty.
Moreover, the time taken for repair/replacement and in transit whether under the
warranty or otherwise shall not be excluded from the warranty period.
Limitation of Implied Warranties and Exclusion of Certain Damages.
Limit of Liability: For any single claim, the limit of liability under this contract is the least of the cost
of (1) authorized repairs, (2) replacement with a product or equal or greater value, (3)
reimbursement for authorized repairs or replacement, or (4) the price that you paid for the
product. (No cash refunds will be made). The total liability under this contract is the purchase
price you paid for the product; in the event we replace the product or reimburse you for
replacement of the product with another product of equal or greater value, we shall have satisfied
all obligations owed under this contract.
