aquanique QFPASL185 User manual

Before returning to your retailer, call our customer service department at
1-888-314-2588, 8 a.m.-6 p.m., EST, Monday-Friday.
Fountain Pump Plus Light with Low
Water Auto Shut-off Feature 140 gph
Item # QFPASL185
PACKAGE CONTENTS
WARNINGS AND CAUTIONS
WARNING
Risk of electrical shock. This pump is supplied with a grounding conductor and grounding–type
attachment plug. To reduce the risk of electric shock, be certain that it is connected only to a properly
grounded, grounding- type receptacle.
Do not exceed the voltage shown on the pump.
Always disconnect pump from the power source before beginning any maintenance or work on the
pump.
Inspect cord for damage before installation and/or maintenance. Replace the entire pump assembly if
damage is found.
Do not remove the grounding pin from the power cord plug.
To reduce the risk of electric shock, use only on portable, self-contained fountains no larger than 5 ft. in
any dimension.
Risk of electrical shock –This pump has not been investigated for use in swimming pool or marine
areas
Part
Description
Quantity
A
Pump
1
B
Light
1
C
1/2-in. tubing adapter
1
D
Adapter for 1/2” outlets
1
REMINDER
CALL 1-888-314-2588
BEFORE RETURNING TO STORE.
Questions, problems, missing parts? Before returning
to your retailer, call our customer service department at
1-888-314-2588, 8 a.m.-6 p.m., EST, Monday-Friday
B
A
C
D

Before returning to your retailer, call our customer service department at
1-888-314-2588, 8 a.m.-6 p.m., EST, Monday-Friday.
CAUTION
This pump has been evaluated for use with fresh water only.
Use a proper power source as indicated on the pump label.
Keep the cord away from high temperatures or other heat sources.
Do not pump heated liquids.
Do not let the pump run dry. Pump must be completely submerged for proper operation and cooling.
Operate in freshwater only. Avoid heavily chlorinated water and water with high pH levels.
Do not lift the pump by its power cord.
PREPARATION
Before beginning assembly or operation of product, make sure all parts are present. Compare parts with
package contents list and diagram above. If any part is missing or damaged, do not attempt to assemble,
install or operate the product. Contact customer service for replacement parts.
Estimated Assembly Time: 5 minutes
No tools required for assembly.
ASSEMBLY INSTRUCTIONS
1. Connect tubing to the outlet of the pump with the appropriate
adapter. Fig 1
NOTE: Tubing is NOT INCLUDED.
Fig. 1
2. Connect the light to the pump by pushing the plug into the socket
until it is firmly seated. Hand tighten the nut from the plug to the
socket. Fig. 2
Fig. 2
3. Place the pump into the water and connect to a proper power
source. Fig. 3
Fig. 3
GFCI
Plug from
light
Socket
from pump
Pump
Tubing

Before returning to your retailer, call our customer service department at
1-888-314-2588, 8 a.m.-6 p.m., EST, Monday-Friday.
4. Adjust the flow control to the preferred setting. Fig. 4
Fig. 4
CARE AND MAINTENANCE –PUMP
Regular cleaning of the pump may be necessary depending upon the environment in which it is
operated. Clean the pump when it is visibly soiled or when a drop in performance is detected.
Before cleaning, always disconnect the pump from the power source.
Remove all parts from the pump and clean in warm, soapy water.
Disassemble the pump cover and remove the impeller cover to expose the impeller assembly.
Remove the impeller assembly by gently pulling on the impeller blades. Use a soft cloth or brush
to clean the impeller assembly and the inside of the impeller housing.
CARE AND MAINTENANCE –LIGHT
Periodically, your light may require cleaning for optimal performance.
Cleaning should only be done with warm soapy water. Be sure to use biodegradable soap.
The frequency of cleaning depends upon the conditions of the environment where the light is used.
TROUBLESHOOTING
If the pump fails to operate:
Check to make sure the power cord is plugged in, the pump is getting power and the pump is
fully submerged.
Check the pump outlet and any tubing, fountains, spitters etc. for kinks or obstructions.
Remove the inlet screen and/or pump cover, and impeller cover to expose the impeller. Turn
the impeller to ensure that it is not broken or jammed.
If the performance of the pump is not satisfactory or the pump does not flow evenly:
Check to make sure the pump is completely submerged in water.
Check to make sure the impeller, water sensor and the housing are clean.
Adjust flow control.
Fig. 5
Impeller cover
Front cover
Front cover
Impeller
cover
Impeller
assembly
Water sensor

Before returning to your retailer, call our customer service department at
1-888-314-2588, 8 a.m.-6 p.m., EST, Monday-Friday.
REPLACEMENT PARTS LIST
For replacement parts, call our customer service department at 1-888-314-2588, 8 a.m.-6 p.m., EST, Monday-
Friday.
PUMP PERFORMANCE
FLOW RATES
LIFT (FEET)
4
42
GPH
3
80
GPH
2
120
GPH
1
157
GPH
0
173
GPH
QFPASL185
Part
Description
B
Light
C
1/2 in. ID tubing adapter
D
Adapter for 1/2” outlets
E
Flow control knob
F
Front cover
G
Impeller cover
H
O-ring
I
Shaft support
J
Shaft
K
Impeller assembly
C
E
F
G
I
I
K
J
D
H
B
I

Before returning to your retailer, call our customer service department at
1-888-314-2588, 8 a.m.-6 p.m., EST, Monday-Friday.
LIMITED WARRANTY
All pumps and electrical products are warranted to the user against defective material and workmanship,
under normal working conditions. This warranty period begins on the date of purchase by the original
purchaser.
All aquanique™ electrical products are warranted to the user against defective material and workmanship,
under normal working conditions for 1 year from the date of purchase. All aquanique™ liners are
warranted to the user against defective workmanship, under normal working conditions for 20 years from
the date of purchase. All other aquanique™ product is warranted to the user against defective material
and workmanship, under normal working conditions for 90 days.
Application
Warranty covers only properly installed and maintained units. Pump warranty is limited to applications
pumping fresh water in a pond or fountain only. Other liquid applications or extreme temperature uses
must be approved in writing by the manufacturer. Receipt and product date code are required for warranty
claims.
Warranty Claim
Warranty claims must be made by calling customer service (at 1-888-314-2588). If the item is
determined to be defective, you will be given authorization to return the defective part(s), freight pre-paid,
along with proof of purchase.
Disposition
The manufacturer will make a good faith effort for prompt disposition regarding all warranty claims.
Returned product will be inspected to determine cause of failure before warranty is applied. Warranty does
not cover any costs associated with the shipping, handling, installation or removal of products or parts
subject to this warranty. For products damaged in transit, a claim should be filed with the carrier.
Disclaimer
Any oral statements made about the product by the seller, the manufacturer, the representatives, or any
other parties do not constitute warranties, should not be relied upon by the user, and are not part of the
contract for sale. The seller’s and manufacturer’s only obligation, and buyer’s only remedy shall be for the
manufacturer to either replace and/or repair at the manufacturer’s sole discretion, the product as described
above. Neither seller nor the manufacturer shall be liable for injury, loss or damages for lost profits, lost
sales, injury to person or property, or any other incidental or consequential loss arising from any cause
whatsoever, no matter whether based upon warranty, contract, negligence or other misuse, and the buyer
and user agree that no other remedy shall be available to them. Before using, the buyer and user shall
determine the suitability of the product for the intended use, and assume all risk and liability whatsoever in
connection therewith. The warranty and remedy described in this limited warranty is an exclusive warranty
and remedy in lieu of any other warranty or remedy expressed or implied. All other warranties and
remedies are hereby expressly excluded, including but not limited to any implied warranty of
merchantability of fitness for any particular purpose. This warranty gives the buyer and user specific legal
rights, and buyer and user may also have other rights which vary from state to state. Some states do not
allow exclusions or limitations of incidental or consequential damages, so the above limitations or
exclusions may not apply to you.
REMINDER
CALL 1-888-314-2588
BEFORE RETURNING TO STORE.
