ARC R10 User manual

Fill the shock oil to just cover the inside bevel of the gears.
DO NOT COMPLETELY COVER THE GEARS WITH OIL.
Diff case direction
needs to match as below.
Apply Oil before assembly
Apply Oil before assembly

Tighten the shock
cap slowly so the
extra oil will leak
out from oil hole
in the shock cap.
1. Before fully tightening the shock cap, push the
shaft into the shock to adjust shock rebound.
2. Once the extra oil has been removed through
the cap hole, tighten then shock cap fully.
For 50% or 25% rebound,
push the shaft completely
into the shock, and then
tighten the shock cap to reach
desired rebound stroke.
R104101
R104099
R104100
R104102
48dp 84T
48dp 82T
48dp 83T
48dp 85T
Kit
Option
Option
Option
CNC SPUR 48dp
R104110
R104111
R104112
R104113
R104118
R104119
64dp 96T
64dp 98T
64dp 100T
64dp 102T
64dp 112T
64dp 114T
Option
Option
Option
Option
Option
Option
CNC SPUR 64dp

Front Pulley
38
Middle Pulley
19
Rear Pulley
38
Internal Ratio 2.0
R103022
R103021
R103020
1.0mm
0.5mm
0.3mm
Kit
Option
Option

Front lower arms have 4 different shock positions.
Make sure left and right sides are both symmetrical during assembly.
Rear lower arms have 6 different positions for shocks and anti-roll bars.
Make sure left and right sides are symmetrical during assembly.
R103022
R103021
R103020
1.0mm
0.5mm
0.3mm
Kit
Option
Option

R103022
R103021
R103020
1.0mm
0.5mm
0.3mm
Kit
Option
Option

Use a screw to push the ball
into the ball joint to avoid
damage to the ball joint.

R103015
Pivot Pin Front-Out
23mm

The bumper can be cut at the black
lines to make it smaller.

R102011
Servo Mount Alu R
R102012
Servo Mount Alu L
R102013
Servo Mount L-Low Alu
It is recommended to
use servo mount rubber.

Motor Pinion
48P
(Not included)
Gear mesh should have a minimal amount of play between spur and pinion.
A gear mesh that is too tight will put extra strain on the spur gear.
A gear mesh that is too loose will strip the spur.
Use a small file to shape the battery holder edge.

Use glass fiber tape attached to the battery
mount plate to secure the battery.
Battery location can be adjusted by moving the battery holder.
It can be used to adjust weight distribution.
