ARC R11 MID User manual

1
INSTRUCTION
MANUAL
#R100021
R102017 3X5.5X3mm Alu Shims(4pcs)
R102020 3x6x0.5mm Alu Shims(8pcs)
R103050 3x5x0.3mm Shims (10)
R105103 3x4 Round Screw (10)
R105104 3x6 Round Screw (10)
R105107 3x12 Round Screw (10)
R105203 3x6mm Flat Screw (10)
R105204 3x8mm Flat Screw (10)
R105206 3x12mm Flat Screw (10)
R106001 3x6x2.5mm Ball Bearing (2)
R106002 5x8x2.5mm Ball Bearing /Metal Seal (4)
R111071 20T Center Pulley-MID (2)
R112500 Pulley Adaptor Long-MID
R112501 Pulley Adaptor Short-MID
R112502 Motor Bulkhead Mount Plate-MID
R112503 Motor Bulkhead -MID
R113032 Spur Shaft -MID
R114022 S3M-351-3mm Belt
R115001 3mm Nylon Nut-Black Alu (4)
R118302 R11 MID Upper Deck
R118303 R11 MID Chassis Flex Plate
R118304 R11 MID Upper Deck Flex Plate
R118305 R11 MID Main Chassis 2.0mm
R112108 R11 MID Aluminum Chassis 2.0mm (Option Parts)
NOTICE
R106002 5x8x2.5 ball bearing only
2pcs included inside R11 MID kit.
R106002
R118304
R105103
R118303
R115001
R102017
R115001
R115001
R105204
R105107
R106001
R111071
R112500
R112501
R111071
R106002
Spur Not Included
R105104
R114022
R118305
R118302
R103050
R113032
R112503
R105204
R112502
R102020
R105104
R105203
R105203
R105206
R105103
R114022
1:1 Scale
R102017
3x5.5x3mm Alu Shims (4)
R102020
3x6x0.5mm Alu Shims (8)
R103050
3x5x0.3mm Shims (10)
R105104
3x6 Round Screw (10)
R105103
3x4 Round Screw (10)
R105107
3x12 Round Screw (10)
R105203
3x6mm Flat Screw (10)
R105204
3x8mm Flat Screw (10)
R105206
3x12mm Flat Screw (10)
R106002
5x8x2.5mm Ball Bearing
/Metal Seal (4)
R106001
3x6x2.5mm Ball Bearing (2)

INSTRUCTION
MANUAL
2
NOTICE
Default setup of R11 MID upper deck.
Reverse upper deck of R11 MID, more
flex in front side for more steering.
Chassis flex can be adjusted with the
chassis flex plate R118303 via four screws.
Installing more screws will reduce chassis
flex and increase response in the rear end.
The upper deck for the R11 MID can be mounted in two different ways. The default setup has less flex at the front,
making the R11 MID easier to drive. Reversing the upper deck will create more flex in the front end to provide the car
with more steering. The X-shaped upper deck flex plate can be installed in different locations to enable you to fine tune
the flex response according to track conditions.
Only R11 2018 & R11 2019 able to convert into R11 MID
