Arcadia JungleDawn RAJDP1Z Setup guide

Safety, Installation and
Maintenance Instructions
Safety, Installation and Maintenance Instructions
JungleDawn LED BAR
LEDLED BARBAR

LampGuardPro JungleDawn LED BAR
RALGP0 16” / 410mm RAJDP1Z 11.5” / 290mm
RALGP1 20” / 510mm RAJDP2Z 18.5” / 470mm
RALGP2 26” / 660mm RAJDP3Z 22.5” / 570mm
RALGP4 38” / 960mm RAJDP4Z 34” / 870mm
5” / 125mm
SAFETY
Protects animals. Protects lamps.
Allows as much light as possible to travel into the vivarium.
Minimum distance 5” / 125mm
LINK CABLE / PROT5
The link cable will allow for up to 10 light units from one power
source, including the ProT5 UVB Kit.
ProT5 UV-B KIT
Code RAJDP1Z RAJDP2Z RAJDP3Z RAJDP4Z
Length 11.5” 290mm 18.5” 470mm 22.5” 570mm 34” 870mm
Watt 15W 22W 34W 51W
No LED’s 72 108 216 288
Beam Angle 120º
kWh/1000h 18.27 24.78 37.64 53.99
Working Temperature 20-40ºC
IP Rating IP20
Voltage 80-260V 60Hz
Current 0.09A 0.12A 0.18A 0.26A

KEEP THESE INSTRUCTIONS FOR FUTURE REFERENCE. READ AND FOLLOW ALL SAFETY INSTRUCTIONS.
DANGER - To avoid possible electric shock, special care should be taken if water is employed in the use of vivarium equipment. For each
of the following situaons, do not aempt repairs yourself; return the appliance to an authorized service facility or discard the appliance.
This product is designed for indoor use and the illuminaon of Vivariums and Terrariums only and will provide a good and safe service life,
provided that these instrucons are followed. Failure to do so may result in serious personal injury or property damage.
If you are in any doubt about the installaon or operaon of this product, please consult a qualied and experienced electrician.
Check that the voltage and frequency rang on the product label is the same as your electrical supply before proceeding further.
WARNING- To guard against injury, basic safety precauons should be observed, including the following:
• Disconnect from the mains supply socket before maintaining the Luminaire. Never pull on the cord to remove the plug from the socket,
instead grasp the plug and pull to disconnect.
• The luminaire can get HOT. Never touch the luminaire while it is operang, allow adequate me for it to cool before aempng any
maintenance.
• This luminaire is rated IP20 NOT waterproof so do not use above or around water.
• If electrical components of the appliance get wet unplug the appliance immediately. If the appliance shows any sign of water leakage
disconnect from the power supply immediately.
• Do not use the appliance other than for its intended use. The use of non-Arcadia aachment or accessories is not recommended and may
cause an unsafe condion.
• Do not install or store the appliance where it will be exposed to extremes of weather or temperatures below freezing.
PHYSICAL INSTALLATION
Select a suitable site close to your electricity supply. Do not connect appliance to the mains supply socket during installaon. This
appliance is for indoor use only. Ensure the appliance is kept in a venlated area and away from other heat sources. Make sure that the
light from the appliance is aimed within the vivarium.
Place the
luminaire in the desired posion either on top of the Vivarium mesh or screwed to the top of the Vivarium.
Ensure the mains lead and the luminaire are kept well out of reach of animals that might bite or damage them.
ELECTRICAL INSTALLATION
Before installing, ensure that the rated voltage and frequency of the luminaire match that of your power supply, and that the mains lead
plug is fully compable with your mains supply socket. If in doubt, please return the unit to the point of purchase for vericaon.
Plug the luminaire into the mains socket. A suitable plug in mer may be used with this product.
TROUBLE SHOOTING
If the luminaire does not light:
• Check that the mains power is connected and switched on both at the wall (including Timer if used) and on the Luminaire.
• Check that the luminaire plug is properly fused.
• Check that the luminaire is rated for the same supply voltage that you are using.
MAINTENANCE
Cleaning: Disconnect from the power supply and wait ll the luminaire is cool before cleaning, this not only avoids smears but also reduces
the likelihood of any damage from moisture entering the luminaire.
Both the appearance and performance of your luminaire can benet
from regular cleaning. A
damp cloth is normally adequate to clean the body.
GUARANTEE
We oer a 12 month guarantee for our electrical products. These are guaranteed for 12 months from the date of sale. The keeper should
return the ng to store for basic tesng with the original sales receipt. We do not cover user damage, (lamps inserted when power is
available to the unit (Hot Starts) nor glass lamps. Fings with suspected faults should be presented back to store for tesng. If a fault is
found and within this 12 month period an exchange may be oered at the point of purchase. In all cases please visit our YouTube channel
for problem solving and lamp ng advice.
END OF USE RECYCLING INFORMATION
This product is covered by European Direcve 2002/96/EC. Please do not dispose of this product or replacement lamps with your normal household
waste. To safely and responsibly dispose of the product please ensure all the components are deposited in the appropriate areas of your local civic
recycling center. Proper disposal of this product helps to prevent potenal negave consequences for the environment and human health. All
electronic components (this includes the power supply and the lamp holder) should be placed in the electronic waste recycling area.
Do not look directly
at light source.
Class II Luminaire.
Double insulated.
Monkfield Nutrition Ltd,
Arthur Rickwood Farm, Chatteris Road,
Mepal, Ely, Cambs CB6 2AZ. United Kingdom
[e-mail]
JBR003
For use with Reptiles,
Amphibians,
Invertebrates & Plants.
EU Authorised Representative:
Comply Express LDA,
StartUp Madeira EV41, Campus da
Penteada, 9020 105 Funchal, Portugal.
