Arcsound HAZE User manual
USER MANUAL
HAZE
THANK YOU!
Thank you for purchasing this Arcsound product. Please read through this
product manual carefully before using the product. Heed all warnings and
follow the instructions. Keep the product manual safe and accessible as you
might need it later on for future usage.
SAFETY INFORMATION
Do not use this product near water or in a moist environment. Do not block any
openings or ventilations on the product. Only clean the product using a dry
cloth. Do not insert any plugs in the product if the plugs or cords are wet or
moist. Do not place the product near any heat sources like radiators, stoves or
other appliances that produce heat. Do not expose the product to direct
sunlight for extensive periods of time, operating temperature 5-40 degrees
celsius. Unplug the product during lightning/thunder storms.
Arcsound products are all designed and manufactured to meet great quality
standard. Refer all potential servicing of the product to qualied service
personnel only. The product requires service if it has been damaged in any
way, if it has been exposed to moisture, does not operate normally or has been
dropped. No user serviceable parts are included inside this product.
Products design and specications are subject to change without notice.
1
INCLUDED ACCESSORIES
The HAZE portable speaker comes included with several accessories:
• Wireless microphone • Remote control • Power charger
• AA batteries (mic) • AAA batteries (rem) • User manual
TABLE OF CONTENT
PRODUCT INFORMATION.........................................................................
BLUETOOTH FUNCTION...........................................................................
First time connection with smartphone............................................
Previously connected smartphone..................................................
WIRELESS MICROPHONE.........................................................................
TRUE WIRELESS CONNECTION...............................................................
True wireless stereo (TWS) technology............................................
First time connection with TWS.......................................................
Previously connected with TWS......................................................
Disconnect speakers from TWS......................................................
LED DISPLAY.............................................................................................
CONTROL PANEL.....................................................................................
REMOTE CONTROL..................................................................................
SPECIFICATIONS............. ........................................................................
3
4
4
4
5
6
6
6
7
7
7
8
9
10
2
PRODUCT INFORMATION
HAZE portable speaker is equipped with a 12V/7A battery to give you the
freedom to play music wherever you are. Before using the speaker for the rst
time, the battery needs to be charged for 8 hours. Please make sure that the
speaker is turned off when you charge it. When the speaker is fully charged,
unplug the power cord from the speaker and power socket. Depending on
how much power is in the speaker, the battery charging time can vary
between 3-10 hours after usage. To extend the battery life time, recharge the
speaker to full power after every use.
WARNING! The speaker should be kept at least 2 meters away from CRT
displays and televisions because of the speaker’s strong magnetic eld. Mag-
netic interference can cause display magnetization or discoloration phenome-
nons.
BLUETOOTH FUNCTION
Turn the power on the speaker, press the ”MODE” button or ”INPUT” button
on the panel or remote control, and switch the speaker to Bluetooth chan-
nel. Make sure that your smartphone’s Bluetooth function is on.
First time connection with smartphone / device
1)
Search the Bluetooth device list and select the Bluetooth device named
”HAZE”. The speaker will play a notication tone when the connection’s
successful.
2)
Open your smartphone’s music player and play a song. The music is trans-
ferred via Bluetooth and sound comes out through the HAZE speaker.
3)
Previously connected smartphone / device
When the smartphone’s Bluetooth function is turned on, press the ”MODE”
button and select Bluetooth mode. The speaker will automatically connect to
the smartphone/device which was connected last time to the speaker. You
can also search the Bluetooth device list on your smartphone, select ”HAZE”
and connect your smartphone to the speaker.
3
WIRELESS MICROPHONE
Included with the HAZE portable speaker is a wireless microphone with a built-
in battery. With the microphone you can use the HAZE portable speaker for
outdoor concerts, advertising, entertainment, events and other activities.
Make sure that the HAZE speaker and its microphone has fully charge batte-
ries before using it outdoors to make sure it lasts through the whole event.
Hold the ”MODE” button on the HAZE speaker down for more than two
seconds to prioritize the wireless Microphone. Test the microphone out before
using it, adjust its volume by turning the volume knob on the HAZE speaker.
Please turn off the microphone when it is not used.
To ensure good sound quality the wireless microphone should be used within
10 meter from the HAZE speaker’s location. If the microphone has low battery
or the environment contains other Bluetooth devices that might cause interfe-
rence, the 10 meter usage distance will be reduced. Make sure that the
microphone’s frequency is unique and does not get interrupted by other freq-
uencies or wireless microphones.
For optimal performance when using the wireless microphone, keep a distan-
ce of 5-15cm between your mouth and the microphone and hold the microp-
hone in a 45 degree angle.
If you own several speakers with wireless microphones that you want to use at
the same time, please make sure that they use different standard frequencies
to avoid interferences and other technological issues. Do not put the HAZE
portable speaker too close to any VCD/CD/DVD while using it, since these
types of devices are equipped with strong frequencies that might cause inter-
ference.
4
TRUE WIRELESS CONNECTION
True wireless stereo (TWS) technology
TWS technology enables you to make a wireless connection between two
speakers of the same model. When you use TWS to connect two HAZE porta-
ble speakers, they will automatically be grouped as a stereo-speaker system
and use outputs for the left and right channel.
Turn the power on both of the speakers, press the ”MODE” button or
”INPUT” button on the panel or remote control, and switch the speakers to
Bluetooth channel. Make sure the speakers are not connected to any smart
phone unit yet.
First time connection with TWS
1)
Press the ”PLAY/PAUSE” button on the control panel of one of the speakers
for 5 seconds until you hear the rst notication tone (beep). This speaker
becomes the main speaker (left channel) and automatically searches for
and connects with the other speaker (right channel). When the connection
between the speakers is successful, you will hear the second notication
tone (ding-dong).
2)
Connect your smartphone to the main speaker via Bluetooth. Search the
Bluetooth device list and select the Bluetooth name ”HAZE”. The speaker
will play a notication tone after a successful connection.
3)
Open your smartphone’s music player and play a song. The music is trans-
ferred via Bluetooth and sound comes out through both the HAZE speakers
as a TWS stereo-speaker system.
4)
NOTE! When you have connected two HAZE speakers together via TWS
mode, manipulations to the main speaker (left channel) will be simultaneously
done to the other speaker (right channel). Examples of these actions are
volume up/down, previous/next song selection, play/pause and power on/off.
5
TRUE WIRELESS CONNECTION
Previously connected with TWS
When the two HAZE portable speakers are turned on, press the ”MODE”
button and select Bluetooth mode. The speakers will automatically reconnect
with TWS as a stereo-speaker system. The speaker setup regarding main
speaker (left channel) and the second speaker (right channel) will remain the
same.
Disconnect speakers from TWS
To disconnect the speakers from each other, turn the speakers on and hold
the ”PLAY/PAUSE” button down for 5 seconds on the main speaker (left chan-
nel).
LED LIGHTS
The HAZE portable speaker has a built in LED display at the top, and decorati-
ve LED lights at the front behind the speaker grill. The LED display uses red
colour while the LED lights can shift between several colours. Press the
”LIGHT” button to switch between different decorative LED light modes. The
LED lights will follow the music beat when the speaker is playing. To turn off the
decorative LED lights, press the ”LIGHT” button down for 3 seconds.
6
CONTROL PANEL
DC 1 5V
CHARGE
VOLUMEMIC VOLUME
MODE
REC
LIGHT
REPEAT
EC+
EC
GT+ TR+ BA+
BATRGT
MI C 2MI C 1
GUITAR IN
LINE
POWER
OFF
ON
USB
Mini SD
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16 17 18 19 20 21 22
1)
2)
3)
4)
5)
6)
7)
8)
9)
10)
11)
Mini SD port
USB port
LINE input
Guitar input
MIC1 input
MIC 2 input
Recharging indicator
DC15V External Power Jack
Power ON / OFF
Guitar volume + / - control
MIC volume control
12)
13)
14)
15)
16)
17)
18)
19)
20)
21)
22)
Echo + / - control
Treble + / - control
Music volume control
BASS + / - control
MODE selection
Record
Previous & FM channel -
Play / Pause & FM scan
Next & FM channel +
Repeat
LED display mode
7
REMOTE CONTROL
1)
2)
3)
4)
5)
6)
7)
8)
Mute
Previous folder
EQ mode
Previous & FM channel -
Record
Power ON / OFF
Next folder
Folder repeat
9)
10)
11)
12)
13)
14)
15)
Repeat
Volume control +
Play / Pause & FM scan
Next & FM channel +
Volume control -
Tracks select
MODE selection
8
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
SPECIFICATIONS
Product model
Product type
Frequency response
RMS output power
Speaker woofer
Speaker tweeter
S/N ratio
Charge while playing
Play time (with LED)
Play time (without LED)
Battery indicator
HAZE
Portable Bluetooth
speaker with LED
55Hz - 18kHz (+/-3dB)
120W
2x8"
1"
≥ 70dB
Yes
>9 hours (50% volume)
>11 hours (50% volume)
Yes
Bluetooth version
USB decoder
3,5mm audio input
5.0
Yes
Yes
9
Dimensions 369x340x780 mm
Net. weight 9.4 kg
AC/DC adapter Input: 110-240V ~ 50/60Hz
Output: 15V/3A
Winn Scandinavia AB reserves for possible typos, factual or numeric errors that may have been
printed on any products, package designs, user manuals and/or other included accessories.
Arcsound is a trademark byWinn Scandinavia AB
Winn Scandinavia AB ׀Elementvägen 15, 70227 Örebro, Sweden ׀www.winnscandinavia.com
