Arena Luci Elite Series User manual

BOUTIQUELED
51°
User'smanual
LEDtrackluminaireEliteseries
Please note that as part of Arena Luci's ongoing commitment to continuous product development,
specifications are subject to change in the course of product improvement without notice.Arena Luci is not
responsiblefordamagesresultingfromimproperordifferentusethanexpected.
This unit should only be used for purpose for
which it has been intended and should be
installed using the instructions which are
provided. Arena Luci cannot be held liable for
damages to person, animals or objects as a
result of improper, unreasonable and wrong
usage.
This instruction manual contains important
information about the installation and use of the
projector. Please read and follow these
instructionscarefully.
The security of this device is guaranteed only
with the proper use of the following instructions,
thereforetheymustbekeptcarefully.
Never install the device in locations easily
accessiblebypeoplewhoignoretheexistenceof
thisuser'smanualandsafetyinstructions.
Disconnecttheunitfromanypowersupplybefore
attempting any operation in contact or inside the
unit,andwhennotinuse.
It is essential that each device is correctly
earthedandthatelectricalinstallationconformsto
all relevant standards. Never supply the unit
withouttheearthlink.
Prior to connect the unit to the mains supply,
check the output voltage fits the technical
requirementsonthelabel.
Nevertouchtheelectricalcontacts,eitherdirectly
withyourfingers,orindirectlybymeansofsharp
ormetalobjects.
Donotattempttodismantleandmodifytheunit.
Due to the high technological level of this unit,
anyservicemaintenanceshouldbeperformedby
specialisedoperators.Please contactyourArena
Lucidealerforanyoperation.
Alwaysensurethatthestructuretowhichyouare
attachingtheunitissecureandisabletosupport
theweightofeachunit.
Do not allow contact with water or any other
fluids,ormetallicobjects(IP40).
Do not install the projector in areas of high
humidity. The unit is intended only for indoor
purposes.
Avoidinstallingtheunitclosetoheatsources.
Allowed to be mounted directly on inflammable
surfaces.
Avoid direct exposure to the light from the lamp.
Thelightluminanceisharmfultotheeye.
Installtheunitwhereitcanbeeasilyaerated.
Thelightingapparatusmustbeusedonlywithits
protectiveplasticshield.
Contact your Arena Luci dealer if the protective
shieldisvisiblydamagedtothepointatwhichits
effectiveness is diminished, for example by
becomingcrackedordeeplyscratched.
LEDmoduleisnotreplaceable.
Do not use any solvent based cleaning agents.
Useonlyasoft,dryantistaticcloth.
TheinstallationofLEDmodules(includingpower
supplies) should be done according to current
technical rules and regulations. The installation
shouldbeperformedonlybyaqualifiedoperator.
Avoid contact with either corrosive agents or
humidity and moisture on delicate elements:
damages from corrosion are not refunded as
componentdefects.
WARNINGS
TCK2337BGWW
TCK2337BGNW
TCK2337BP

2/4
TCK2337
GETTINGSTARTED
Open the shipping carton and verify that all
equipment necessary to operate the system has
arrived intact. Refer to the following packing list
for information on what items are included with
your model. If any equipment is missing or
damaged, contact your Arena Luci dealer
immediately.
n°1BoutiqueLED51°TCK2337
Before beginning initial setup of your projector,
make sure that there is no evident damage
caused by transportation. In the event that the
unit’shousingorcableisdamaged,donotplug it
in and do not attempt to use it until after
contactingyourArenaLucidealerforassistance.
INSTALLINGTHEDEVICE
Before carrying out any operation, remove the
mainsvoltagefromthesystem.
The appliance can only be installed on electrified
tracks. Always make sure that the structure on
which you are fixing the appliance is safe and is
abletobeartheweightofeachunit.
Refer to the track installation instructions for
selecting the number of fixtures that can be
attachedtothetrack.
Thetrackadapterwithwhichthespotlightisfitted
contains all the mechanisms for correct locking
and selection of the power supply line. It is
therefore necessary to become familiar with this
system in order to avoid damaging the adapter
andcausingaccidentalfallsoftheequipment.
Thetrack adapter hasa sidelever that servesto
lockthespotlightonthetrack.Tobeabletoinsert
theadapterinthetrackitisnecessarytobringthis
levertoalateralposition.
The electrified tracks are not symmetrical, but
haveaprotrusionononeside,sincetheinsertion
of the various devices must take place in the
same way, so as to respect the polarity of the
three ignition lines 123. Insert the adapter into
the track, taking care to orient it as shown in the
figure.
Tolockthespotlightinthedesiredposition,move
thesideleverparalleltothetrack.
To choose which ignition line will command the
spotlight, use the wheel at the bottom of the
adapter. The locking mechanism prevents the
wheelfrommovinguntilthesideleverisparallelto
thetrack.
To select line 3 simply rotate the wheel to bring
thesymbol3incorrespondencewiththearrow.

3/4
USER'SMANUAL
Toselectline2,pressthewheelandatthesame
time rotate it to bring the symbol 2 in
correspondencewiththearrow.
Toselectline1,pressthewheelandatthesame
time rotate it to bring the symbol 1 in
correspondencewiththearrow.
The locking mechanism prevents the rail adapter
from being removed until an ignition line is
selected. Return the wheel to position 0, unlock
the adapter by moving the lever to the side
positionandremovethe appliancefromthe track.
To prevent accidental falls it is necessary to
supporttheapplianceduringthewholeoperation.
Respect the polarity LNE indicated on the
terminalsoftheelectrifiedtrack.
It is essential that each appliance is correctly
grounded and that the electrical installation
complieswithallcurrentgoodtechnicalandsafety
standards.
The device allows to adjust the projection angle
both on the horizontal plane and on the vertical
plane.
The fork allows an adjustment of the projection
angleof130°/+130°withrespecttothevertical.
Foradjustmentonthehorizontalplane,rotatethe
spotlight with respect to the track. The system
allowsyoutorotatetheforkforanangleofabout
270°.
In case of installation for direct lighting, pay
particular attention to avoid dazzling phenomena
towardspeoplepresent.

4/4
TCK2337
ArenaLucisrlviaSvizzera12/1446042CastelGoffredo(MN),Italy
Tel.+390376782411Fax+390376780973
www.arenaluci.com[email protected]
WARRANTYCONDITIONS
The unit is guaranteed for 24 months from the
date of purchase against defects in workmanship
ormaterialsthatcomposeit.
This warranty does faults due to incorrect or
improperuseofthedevice.
The warranty is immediately void if the unit has
been tampered with or opened by unauthorized
personnel.
The warranty provides, at the discretion ofArena
Luci,repairorreplacementoffaultyequipment.
The serial number and model of the device are
required to obtain information or assistance from
the dealer. We invite you to transcribe them in
time: for any request of information or services,
thiswillresultinaquickandeffectiveoperation.
CERULES
The device meets the essential requirements of
the Directives LVD 2014/35/UE, EMC
2014/30/UE, RAEE 2012/19/UE, RoHS
2011/65/UE, Ecodesign 2009/125/CE  reg. (UE)
1194/2012, Energy label 2010/30/UE  reg. (UE)
874/2012  reg. (UE) 518/2014, GPSD
2001/95/CE.
Warnings
DisposalofOld Electrical&Electronic Equipment
(applicable in the European Union and other
European countries with separate collection
systems).
The product shall not be treated as
householdwastebutmustbehandedoverto
the applicable collection point for the
recycling of electrical and electronic
equipment. By ensuring this product is correctly
disposed, you will help prevent potential negative
consequences for the environment and human
health, which could otherwise be caused by
inappropriate waste handling. The recycling of
materialswillhelptoconservenaturalresources.For
more detailed information about recycling of this
product, please contact your city office, your
householdwastedisposalserviceoryoursupplier.
Powersupply
Powerconsumption
Lightsource
ColourTemp.
Luminousflux
Beamangle
Socket
Material
Fixturecolour
Weight
Dimensions
Insulationclass
Protectionrating
Operatingtemp.
Suitabletobemountedonnormallyinflammablesurfaces
Applicablestandards
230VAC,50/60Hz
45W
COBLED
3200K(GWW)4200K(GNW)pink(P)
5763lm(GWW)6262lm(GNW)3682lm(P)
51°
Tracklight
Aluminum
White
1.3kg
Ø120x155mm(body)
I
IP40
20°C...+45°C
TECHNICALSPECIFICATION
TCK2337BoutiqueENR0|09/2018
