Dell Inspiron One 2330 User manual

Dell Inspiron One 2330
Owner’s Manual
Computer model: Inspiron One 2330 Regulatory model: W05C Regulatory type: W05C001
OM_Book.book Page 1 Saturday, October 6, 2012 12:50 AM

Notes, Cautions, and Warnings
NOTE: A NOTE indicates important information that helps you make better use of
your computer.
CAUTION: A CAUTION indicates potential damage to hardware or loss of data if
instructions are not followed.
WARNING: A WARNING indicates a potential for property damage, personal
injury, or death.
____________________
© 2012 Dell Inc.
Trademarks used in this text: Dell™, the DELL logo, and Inspiron™are trademarks of Dell Inc.;
Microsoft®, Windows®, and the Windows start button logo
are either trademarks or registered
trademarks of Microsoft corporation in the United States and/or other countries; Bluetooth®is a
registered trademark owned by Bluetooth SIG, Inc. and is used by Dell under license; Intel® and Intel
SpeedStep®are registered trademarks of Intel Corporation in the U.S. and/or other countries.
2012 - 10 Rev. A01
OM_Book.book Page 2 Saturday, October 6, 2012 12:50 AM

Contents 3
Contents
1Before You Begin. . . . . . . . . . . . . . . . . . . . 9
Turn Off Your Computer and Connected Devices . . . . . 9
Safety Instructions. . . . . . . . . . . . . . . . . . . . 10
Recommended Tools. . . . . . . . . . . . . . . . . . . 10
2After Working Inside Your Computer. . . . 11
3Technical Overview . . . . . . . . . . . . . . . . . 13
Inside View of Your Computer . . . . . . . . . . . . . . 13
System Board Components . . . . . . . . . . . . . . . 14
4Stand . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
Removing the Stand . . . . . . . . . . . . . . . . . . . 17
Replacing the Stand . . . . . . . . . . . . . . . . . . . 19
5Back Cover . . . . . . . . . . . . . . . . . . . . . . . 21
Removing the Back Cover . . . . . . . . . . . . . . . . 21
Replacing the Back Cover . . . . . . . . . . . . . . . . 22
OM_Book.book Page 3 Saturday, October 6, 2012 12:50 AM

4Contents
6Touchscreen Board . . . . . . . . . . . . . . . . 23
Removing the Touchscreen Board . . . . . . . . . . . . 23
Replacing the Touchscreen Board. . . . . . . . . . . . 26
7Converter Board . . . . . . . . . . . . . . . . . . 27
Removing the Converter Board . . . . . . . . . . . . . 27
Replacing the Converter Board . . . . . . . . . . . . . 29
8Power-Button Board . . . . . . . . . . . . . . . 31
Removing the Power-Button Board . . . . . . . . . . . 31
Replacing the Power-Button Board . . . . . . . . . . . 32
9Memory Module(s). . . . . . . . . . . . . . . . . 33
Removing the Memory Module(s) . . . . . . . . . . . . 33
Replacing the Memory Module(s) . . . . . . . . . . . . 35
10 Optical Drive . . . . . . . . . . . . . . . . . . . . . 37
Removing the Optical Drive . . . . . . . . . . . . . . . 37
Replacing the Optical Drive . . . . . . . . . . . . . . . 40
OM_Book.book Page 4 Saturday, October 6, 2012 12:50 AM

Contents 5
11 VESA-Mount Bracket . . . . . . . . . . . . . . . 41
Removing the VESA-Mount Bracket. . . . . . . . . . . 41
Replacing the VESA-Mount Bracket . . . . . . . . . . 42
12 Hard Drive . . . . . . . . . . . . . . . . . . . . . . . . 43
Removing the Hard Drive . . . . . . . . . . . . . . . . 43
Replacing the Hard Drive . . . . . . . . . . . . . . . . 46
13 System-Board Shield . . . . . . . . . . . . . . . . 47
Removing the System-Board Shield . . . . . . . . . . . 47
Replacing the System-Board Shield. . . . . . . . . . . 49
14 Wireless Mini-Card . . . . . . . . . . . . . . . . . 51
Removing the Wireless Mini-Card . . . . . . . . . . . 51
Replacing the Wireless Mini-Card . . . . . . . . . . . 53
15 Speakers . . . . . . . . . . . . . . . . . . . . . . . . . 55
Removing the Speakers . . . . . . . . . . . . . . . . . 55
Replacing the Speakers . . . . . . . . . . . . . . . . . 57
OM_Book.book Page 5 Saturday, October 6, 2012 12:50 AM

6Contents
16 Processor Heat-Sink . . . . . . . . . . . . . . . 59
Removing the Processor Heat-Sink . . . . . . . . . . . 59
Replacing the Processor Heat-Sink . . . . . . . . . . . 61
17 Processor Heat-Sink Fan. . . . . . . . . . . . 63
Removing the Processor Heat-Sink Fan. . . . . . . . . 63
Replacing the Processor Heat-Sink Fan. . . . . . . . . 65
18 Processor. . . . . . . . . . . . . . . . . . . . . . . . 67
Removing the Processor . . . . . . . . . . . . . . . . . 67
Replacing the Processor. . . . . . . . . . . . . . . . . 69
19 Power-Supply Fan Bracket . . . . . . . . . . 71
Removing the Power-Supply Fan Bracket. . . . . . . . 71
Replacing the Power-Supply Fan Bracket . . . . . . . 73
20 I/O Cover . . . . . . . . . . . . . . . . . . . . . . . . 75
Removing the I/O Cover . . . . . . . . . . . . . . . . . 75
Replacing the I/O Cover . . . . . . . . . . . . . . . . . 77
OM_Book.book Page 6 Saturday, October 6, 2012 12:50 AM

Contents 7
21 I/O Board Shield . . . . . . . . . . . . . . . . . . . 79
Removing the I/O Board Shield . . . . . . . . . . . . . 79
Replacing the I/O Board Shield . . . . . . . . . . . . . 82
22 Power-Supply Unit. . . . . . . . . . . . . . . . . . 83
Removing the Power-Supply Unit . . . . . . . . . . . . 83
Replacing the Power-Supply Unit. . . . . . . . . . . . 85
23 Power-Supply Fan . . . . . . . . . . . . . . . . . . 87
Removing the Power-Supply Fan . . . . . . . . . . . . 87
Replacing the Power-Supply Fan . . . . . . . . . . . . 89
24 I/O Board . . . . . . . . . . . . . . . . . . . . . . . . . 91
Removing the I/O Board . . . . . . . . . . . . . . . . . 91
Replacing the I/O Board . . . . . . . . . . . . . . . . . 94
25 Coin-Cell Battery . . . . . . . . . . . . . . . . . . . 95
Removing the Coin-Cell Battery . . . . . . . . . . . . . 95
Replacing the Coin-Cell Battery. . . . . . . . . . . . . 97
26 System Board . . . . . . . . . . . . . . . . . . . . . 99
Removing the System Board . . . . . . . . . . . . . . . 99
OM_Book.book Page 7 Saturday, October 6, 2012 12:50 AM

8Contents
Replacing the System Board. . . . . . . . . . . . . . 101
Entering the Service Tag in the BIOS . . . . . . . . . 102
27 Antenna Module(s) . . . . . . . . . . . . . . . . 103
Removing the Antenna Module(s) . . . . . . . . . . . 103
Replacing the Antenna Module(s) . . . . . . . . . . . 106
28 Display Panel . . . . . . . . . . . . . . . . . . . . . 109
Removing the Display Panel . . . . . . . . . . . . . . 109
Replacing the Display Panel. . . . . . . . . . . . . . 116
29 Camera Module . . . . . . . . . . . . . . . . . . . 119
Removing the Camera Module. . . . . . . . . . . . . 119
Replacing the Camera Module . . . . . . . . . . . . 122
30 System Setup . . . . . . . . . . . . . . . . . . . . . 125
Overview . . . . . . . . . . . . . . . . . . . . . . . . 125
Entering System Setup . . . . . . . . . . . . . . . . . 125
Clearing Forgotten Passwords. . . . . . . . . . . . . 134
Clearing CMOS Settings . . . . . . . . . . . . . . . . 136
31 Flashing the BIOS . . . . . . . . . . . . . . . . . 139
OM_Book.book Page 8 Saturday, October 6, 2012 12:50 AM

Before You Begin 9
1
Before You Begin
Turn Off Your Computer and Connected Devices
CAUTION: To avoid losing data, save and close all open files and exit all open
programs before you turn off your computer.
1 Save and close all open files and exit all open programs.
2 Follow the instructions to shut down your computer based on the
operating system installed on your computer.
Windows 8:
Move your mouse pointer to the upper-right or lower-right corner of the
screen to open the Charms sidebar, and click
Settings → Power →
Shutdown.
Windows 7:
Click Start and click Shut down.
Microsoft Windows shuts down and then the computer turns off.
NOTE: If you are using a different operating system, see the documentation of
your operating system for shut-down instructions.
3 Disconnect your computer and all attached devices from their
electrical outlets.
4 Disconnect all telephone cables, network cables, and attached devices
from your computer.
5 Press and hold the power button for 5 seconds, after the computer is
unplugged, to ground the system board.
OM_Book.book Page 9 Saturday, October 6, 2012 12:50 AM

10 Before You Begin
Safety Instructions
Use the following safety guidelines to protect your computer from potential
damage and ensure your personal safety.
WARNING: Before working inside your computer, read the safety information
that shipped with your computer. For additional safety best practices information,
see the Regulatory Compliance Homepage at dell.com/regulatory_compliance.
WARNING: Disconnect all power sources before opening the computer cover or
panels. After you finish working inside the computer, replace all covers, panels,
and screws before connecting to the power source.
CAUTION: To avoid damaging the computer, ensure that the work surface is flat
and clean.
CAUTION: To avoid damaging the components and cards, handle them by their
edges and avoid touching pins and contacts.
CAUTION: Only a certified service technician is authorized to remove the
computer cover and access any of the components inside the computer. See the
safety instructions for complete information about safety precautions, working
inside your computer, and protecting against electrostatic discharge.
CAUTION: Before touching anything inside your computer, ground yourself by
touching an unpainted metal surface, such as the metal at the back of the
computer. While you work, periodically touch an unpainted metal surface to
dissipate static electricity, which could harm internal components.
CAUTION: When you disconnect a cable, pull on its connector or on its pull-tab,
not on the cable itself. Some cables have connectors with locking tabs or
thumb-screws that you must disengage before disconnecting the cable. When
disconnecting cables, keep them evenly aligned to avoid bending any connector
pins. When connecting cables, ensure that the connectors and ports are correctly
oriented and aligned.
CAUTION: To disconnect a network cable, first unplug the cable from your
computer and then unplug the cable from the network device.
Recommended Tools
The procedures in this document may require the following tools:
• Phillips screwdriver
• Plastic scribe
OM_Book.book Page 10 Saturday, October 6, 2012 12:50 AM

After Working Inside Your Computer 11
2
After Working Inside Your Computer
After you complete the replacement procedures, ensure the following:
• Replace all screws and ensure that no stray screws remain inside
your computer.
• Connect any external devices, cables, cards, and any other part(s)
you removed before working on your computer.
• Connect your computer and all attached devices to the electrical outlets.
CAUTION: Before turning on your computer, replace all screws and ensure
that no stray screws remain inside the computer. Failure to do so may damage
your computer.
OM_Book.book Page 11 Saturday, October 6, 2012 12:50 AM

12 After Working Inside Your Computer
OM_Book.book Page 12 Saturday, October 6, 2012 12:50 AM

Technical Overview 13
3
Technical Overview
WARNING: Before working inside your computer, read the safety information that
shipped with your computer and follow the steps in "Before You Begin" on page 9.
For additional safety best practices information, see the Regulatory Compliance
Homepage at dell.com/regulatory_compliance.
Inside View of Your Computer
1 touchscreen-board shield 2 optical-drive assembly
3 power-supply unit 4 hard-drive assembly
5 processor heat-sink fan 6 coin-cell battery
7 processor heat-sink 8 memory module(s)
15
16
2
3
47
8
13
9
5
12
10
11
14
6
1
OM_Book.book Page 13 Saturday, October 6, 2012 12:50 AM

14 Technical Overview
System Board Components
9 wireless Mini-Card 10 system board
11 speakers (2) 12 I/O cover
13 I/O board shield 14 power-supply fan
15 power-button board 16 converter board
15
21
17
24
8
20
1 2
3
5
11 9
12
13
14
22
10
6
23
19
18
16
4
7
OM_Book.book Page 14 Saturday, October 6, 2012 12:50 AM

Technical Overview 15
1 camera cable connector (WEBCAM) 2 battery socket (BAT1)
3 processor socket (PROCESSOR) 4 memory-module connector
(CHANNEL A DIMM 1)
5 memory-module connector
(CHANNEL A DIMM 0)
6 CMOS reset jumper (SW50)
7 left speaker cable connector
(LINE_OUT)
8 right speaker cable connector
(LINE_OUT)
9 password reset jumper (E49) 10 SPI connector (E16)
11 processor heat-sink fan cable
connector (CPU FAN)
12 power-button board cable connector
(FRONT_PANEL)
13 I/O board cable connector (LVDS1) 14 converter board cable connector
(INVERTER)
15 main power-supply cable connector
(CON5171) (CN3111)
16 touchscreen-board cable connector
17 infrared cable connector (CN29) 18 display cable connector (For non-AV
board) (P170)
19 SATA connector (SATA1) 20 power-supply fan cable connector
(P10)
21 SATA connector (CON5141) 22 power cable connector (P161)
23 power cable connector (P160) 24 processor power-supply cable
connector (CON5176)
OM_Book.book Page 15 Saturday, October 6, 2012 12:50 AM

16 Technical Overview
OM_Book.book Page 16 Saturday, October 6, 2012 12:50 AM

Stand 17
4
Stand
WARNING: Before working inside your computer, read the safety information that
shipped with your computer and follow the steps in "Before You Begin" on page 9.
For additional safety best practices information, see the Regulatory Compliance
Homepage at dell.com/regulatory_compliance.
Removing the Stand
Procedure
CAUTION: Before opening your computer, ensure that you place the computer
on a soft cloth or clean surface to avoid any scratches on the display.
1 Place the computer face down on a flat surface.
2 Using a plastic scribe, release the stand cover starting from the bottom
of your computer.
1 stand cover 2 plastic scribe
1
2
OM_Book.book Page 17 Saturday, October 6, 2012 12:50 AM

18 Stand
3 Slide and lift the stand cover off your computer.
4 Remove the screws that secure the stand to your computer.
5Pivot the stand upward and remove the stand off your computer.
1 screws (4) 2 stand
1
2
OM_Book.book Page 18 Saturday, October 6, 2012 12:50 AM

Stand 19
Replacing the Stand
Procedure
1 Align the screw holes on the stand with the screw holes on your computer.
2 Replace the screws that secure the stand to your computer.
3 Slide the stand cover and snap it into place.
4 Follow the instructions in "After Working Inside Your Computer" on page 11.
OM_Book.book Page 19 Saturday, October 6, 2012 12:50 AM

20 Stand
OM_Book.book Page 20 Saturday, October 6, 2012 12:50 AM
